MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) Fuse/Relay
LocationFuse Amp
RatingPower Distribution Box Description
DIODE Ð Ð
H/L RELAY
MICROÐ Headlamp (High/Low, Right/Left Relay)
ÐÐÐ
INJ 30A** EEC (VPWR), EVR, MAF, IAC, Bulkhead
MAIN 120A

Page 142 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) Fuse/Relay
LocationFuse Amp
RatingPower Distribution Box Description
FUEL
PUMP ISOÐ Fuel Pump Relay
MAIN FAN
ISOÐ Low Speed Fan Control Relay
(2.0L Engine)
High Speed Fan Control Relay 1
(3.0L Engin

Page 143 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) It is not recommended that the vehicle be operated in 4WD modes with
a temporary spare. If 4WD operation is necessary, do not operate above
speeds of 16 km/h (10 mph) or for distances above 80 km (50

Page 144 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) 1. Park on a level surface, activate
hazard flashers and place
gearshift lever in P (Park)
(automatic transmission) or R
(Reverse) (manual
transmission).
2. Set the parking brake and turn
engine OFF.

Page 145 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) Before placing the jack under the vehicle, NOTE the jack locations:
²Frontjacking notches are located
under the front suspension
arm.
²Rearjacking notches are located
under the rear trailing arm.
6.

Page 146 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) Never use the differentials as a
jacking point. It is too easy for
the vehicle to tilt or fall and you
can be injured.
WARNING: To lessen the risk
of personal injury, do not put
any part of your body

Page 147 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) NOTE:To stow the full size flat tire
in the cargo floor, the long spare
tire rod in the tool bag needs to be
installed.
11. Using the lug wrench, remove
the spare tire rod from the
cargo floor and ins

Page 148 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) Do not attempt to push start your vehicle. Automatic
transmissions do not have push-start capability.
Preparing your vehicle
When the battery is disconnected or a new battery is installed, the
transmi

Page 149 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) Connecting the jumper cables
1. Connect the positive (+) booster cable to the positive (+) terminal of
the discharged battery.
Note:In the illustrations,lightning boltsare used to designate the
assist

Page 150 of 232

MAZDA MODEL TRIBUTE 2001  Owners Manual (in English) 3. Connect the negative (-) cable to the negative (-) terminal of the
assisting battery.
4. Make the final connection of the negative (-) cable to an exposed
metal part of the disabled vehicles engin
