Side airbags, in combination with seat belts, can help reduce the risk of
severe injuries in the event of a significant side impact collision.
The side airbags are fitted on the outboard side of the seatbacks of the
front seats. In certain lateral collisions, the airbag on the side affected by
the collision will be inflated. If the front passenger sensing system
detects an empty seat, the front passenger seat-mounted side airbag will
be deactivated. The airbag was designed to inflate between the door
panel and occupant to further enhance the protection provided
occupants in side impact collisions.
The airbag SRS is designed to activate when the vehicle sustains lateral
deceleration sufficient to cause the sensors to close an electrical circuit
that initiates airbag inflation.
The fact that the airbags did not inflate in a collision does not mean that
something is wrong with the system. Rather, it means the forces were
not of the type sufficient to cause activation. Side airbags are designed
to inflate in side-impact collisions, not roll-over, rear-impact, frontal or
near-frontal collisions, unless the collision causes sufficient lateral
deceleration. WARNING: Several airbag system components get hot after
inflation. Do not touch them after inflation.
WARNING: If the side airbag
has deployed, the airbag will
not function again. The side
airbag system (including the
seat) must be inspected and
serviced by an authorized
dealer. If the airbag is not
replaced, the unrepaired area
will increase the risk of injury
in a collision.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
108

How do the side-curtain airbags (if equipped) work?
The design and development of the
side air curtain system included
recommended testing procedures
that were developed by a group of
automotive safety experts known as
the Side Airbag Technical Working
Group. These recommended testing
procedures help reduce the risk of
injuries related to the deployment of
side airbags (including side air
curtain systems).
The side-curtain airbags (if
equipped) consists of the following:
• An inflatable nylon curtain with a
gas generator concealed behind
the headliner and above the doors
(one on each side of vehicle).
• A headliner designed to flex open
above the side doors to allow side-curtain airbag deployment.
• The same warning light, electronic control and diagnostic unit as used
for the front airbags.
• Two crash sensors mounted at lower B-Pillar (one on each side).
• Two crash sensors located at the c-pillar behind the rear doors (one
on each side).
• Rollover sensor in the restraints control module (RCM).
The side-curtain airbags (if equipped), in combination with seat belts,
can help reduce the risk of severe injuries in the event of a significant
side impact collision or rollover event.
Children 12 years old and under should always be properly restrained in
the rear seats. The side-curtain airbags (if equipped) will not interfere
with children restrained using a properly installed child or booster seat
because it is designed to inflate downward from the headliner above the
doors along the side window opening.
The side-curtain airbags (if equipped) are designed to activate when the
vehicle sustains lateral deceleration sufficient to cause the RCM to
initiate side-curtain airbag (if equipped) inflation or when a certain
likelihood of a rollover event is detected by the rollover sensor.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Seating and Safety Restraints
111

Important:Remember to replace the wheel valve stems when the road
tires are replaced on your vehicle.
It is recommended that the two front tires or two rear tires generally be
replaced as a pair.
The tire pressure sensors mounted in the wheels (originally installed on
your vehicle) are not designed to be used in aftermarket wheels.
The use of wheels or tires not recommended by Mazda Motor
Corporation may affect the operation of your Tire Pressure Monitoring
System.
If the TPMS indicator is flashing, your TPMS is malfunctioning. Your
replacement tire might be incompatible with your TPMS, or some
component of the TPMS may be damaged.
Safety practices
Driving habits have a great deal to do with your tire mileage and safety.
• Observe posted speed limits
• Avoid fast starts, stops and turns
• Avoid potholes and objects on the road
• Do not run over curbs or hit the tire against a curb when parking
WARNING: If your vehicle is stuck in snow, mud, sand, etc., do
not rapidly spin the tires; spinning the tires can tear the tire
and cause an explosion. A tire can explode in as little as three
to five seconds.
WARNING: Do not spin the wheels at over 35 mph (56 km/h).
The tires may fail and injure a passenger or bystander.
Highway hazards
No matter how carefully you drive there’s always the possibility that you
may eventually have a flat tire on the highway. Drive slowly to the
closest safe area out of traffic. This may further damage the flat tire, but
your safety is more important.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Tires, Wheels and Loading
135

The Tire Pressure Monitoring System complies with part 15 of the FCC
rules and with RSS-210 of Industry Canada. Operation is subject to the
following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation. WARNING: The Tire Pressure Monitoring System is NOT a
substitute for manually checking tire pressure. The tire
pressure should be checked periodically (at least monthly)
using a tire gauge, see Inflating your tiresin this chapter.
Failure to properly maintain your tire pressure could increase
the risk of tire failure, loss of control, vehicle rollover and
personal injury.
Changing tires with TPMS
Each road tire is equipped with
a tire pressure sensor fastened
to the inside rim of the wheel.
The pressure sensor is covered
by the tire and is not visible
unless the tire is removed. The
pressure sensor is located
opposite (180 degrees) from the
valve stem. Care must be taken
when changing the tire to avoid
damaging the sensor.
It is recommended that you always
have your tires serviced by an
authorized dealer.
The tire pressure should be checked
periodically (at least monthly) using
an accurate tire gauge, refer to
Inflating your tires in this chapter.
Understanding your Tire Pressure Monitoring System (TPMS)
The Tire Pressure Monitoring System measures pressure in your four
road tires and sends the tire pressure readings to your vehicle. The Low
Tire Warning Lamp will turn ON if the tire pressure is significantly low.
Once the light is illuminated, your tires are under inflated and need to be
inflated to the manufacturer’s recommended tire pressure. Even if the
light turns ON and a short time later turns OFF, your tire pressure still
needs to be checked.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Tires, Wheels and Loading
144

CHANGING A FLAT TIRE
If you get a flat tire while driving:
• do not brake heavily.
• gradually decrease the vehicle’s speed.
• hold the steering wheel firmly.
• slowly move to a safe place on the side of the road.
Your vehicle may be equipped with a conventional spare tire that is
different in one or more of the following: type, brand, size, speed rating
and tread design. If this is the case, this dissimilar spare tire is still rated
for your vehicle loads (GAWR and GVWR). This temporary spare tire is
not equipped with a Tire Pressure Monitor System (TPMS) sensor.
Note: The tire pressure monitoring system (TPMS) indicator light will
illuminate when the spare is in use. To restore the full functionality of
the TPMS system, all road wheels equipped with the tire pressure
monitoring sensors must be mounted on the vehicle.
Have a flat tire serviced by an authorized dealer in order to prevent
damage to the TPMS sensor, refer to Tire Pressure Monitoring System
(TPMS) in theTires, Wheels, and Loading chapter. Replace the spare
tire with a road tire as soon as possible. During repairing or replacing of
the flat tire, have the authorized dealer inspect the TPMS sensor for
damage.
WARNING: The use of tire sealants may damage your tires. The
use of tire sealants may also damage your Tire Pressure
Monitoring System and should not be used.
WARNING: Refer to Tire Pressure Monitoring System (TPMS)
in the Tire, Wheels and Loading chapter for important
information. If the tire pressure monitor sensor becomes
damaged, it will no longer function.
Dissimilar spare tire/wheel information WARNING: Failure to follow these guidelines could result in an
increased risk of loss of vehicle control, injury or death.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
196

fog lamps ...................................32
headlamps .................................32
headlamps, flash to pass ..........33
instrument panel, dimming .....33
interior lamps .....................35–37
replacing bulbs .........................38
Lane change indicator
(see Turn signal) ........................35
Liftgate ..................................54, 64
Lights, warning and indicator ....12 anti-lock brakes (ABS) ..........167
Load limits .................................148
Loading instructions .................154
Locks childproof ..................................62
doors ..........................................62
Lubricant specifications ...........271
Lug nuts ....................................206
Luggage rack ...............................57
Lumbar support, seats ...............74
M
Manual transaxle fluid, checking and adding ....269
Manual transmission .................179 fluid capacities ........................271
lubricant specifications ..........271
reverse .....................................180
Mirrors .........................................48 fold away ...................................49
heated ........................................49
side view mirrors (power) .......48
Moon roof ....................................53
Motorcraft parts ........................256
O
Octane rating ............................260 Oil (see Engine oil) ..................244
Overdrive ...................................175
Overheating ...............................206
P
Parking brake ............................167
Passenger Occupant
Classification Sensor ...................83
Power distribution box
(see Fuses) ...............................193
Power door locks ........................62
Power mirrors .............................48
Power point .................................46
Power Seats .................................74
Power steering ..........................172
fluid, refill capacity ................271
fluid, specifications .................271
Power Windows ...........................47
Preparing to drive your
vehicle ........................................173
R
Radio ............................................19
Relays ........................................189
Remote entry system ...........63–64 illuminated entry ................66–67
locking/unlocking doors ...........64
opening the trunk .....................64
panic alarm ...............................65
replacement/additional
transmitters ...............................66
replacing the batteries .............65
Roof rack .....................................57
S
Safety defects, reporting ..........225
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Index
280

Safety restraints ..............81, 85–89 Belt-Minder
.............................92
extension assembly ..................90
for adults .............................86–88
for children .....................113–114
Occupant Classification
Sensor ........................................83
seat belt maintenance ..............91
warning light and chime ....91–92
Safety seats for children ..........117
Safety Compliance
Certification Label ....................274
Scheduled Maintenance ...........232
Seat Belt Maintenance ...............91
Seat belts (see
Safety restraints) ............81, 85–89
Seats ............................................72 child safety seats ....................117
heated ........................................76
SecuriLock passive anti-theft
system ..........................................68
Servicing your vehicle ..............238
Side-curtain airbags system
(if equipped) .............107, 109, 111
Snowplowing .................................7
Spark plugs, specifications .......273
Special notice ambulance conversions ..............7
Specification chart,
lubricants ...................................271
Speed control ..............................49
Starting your
vehicle ........................161–162, 164 jump starting ..........................207
Steering wheel controls ......................................52
tilting .........................................43 T
Tilt steering wheel ......................43
Tire Pressure Monitoring
System (TPMS)
Tires, Wheels and Loading ....143
Tires ...................................127–129 alignment ................................136
care ..........................................132
changing ..........................199, 201
checking the pressure ............132
inflating ...................................130
label .........................................142
replacing ..................................133
rotating ....................................136
safety practices .......................135
sidewall information ...............138
snow tires and chains ............148
spare tire .........................196, 199
terminology .............................129
tire grades ...............................128
treadwear ........................128, 132
Towing .......................................154 recreational towing .................160
trailer towing ..........................154
wrecker ....................................213
Transaxle fluid, checking and adding
(manual) .................................269
Transmission automatic operation ...............173
brake-shift interlock (BSI) ....173
fluid, checking and adding
(automatic) .............................267
fluid, refill capacities ..............271
lubricant specifications ..........271
manual operation ....................179
Trunk ...........................................64
Turn signal ..................................35
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Index
281
