MAZDA MODEL TRIBUTE 2008 Owners Manual (in English)

MAZDA CAR CARE PRODUCTS
Your Mazda dealer has many quality products available to clean your
vehicle and protect its finishes. These quality products have been
specifically engineered to fulfill your automotive needs; they are custom
designed to complement the style and appearance of your vehicle. Each
product is made from high quality materials that meet or exceed rigid
specifications. For best results, use these products or products of
equivalent quality. These products are available at your authorized Mazda
dealer.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Cleaning
231

INTRODUCTION
Be extremely careful to prevent injury to yourself and others or damage
to your vehicle when using this manual for inspection and maintenance.
If you’re unsure about any procedure it describes, we strongly urge you
to have a reliable and qualified service shop perform the work, preferably
an authorized Mazda Dealer.
Factory-trained Mazda technicians and genuine Mazda parts are best for
your vehicle. Without this expertise and the parts that have been
designed and made especially for your Mazda, inadequate, incomplete,
and insufficient servicing may result in problems. This could lead to
vehicle damage or an accident and injuries.
For expert advice and quality service, consult an authorized Mazda
Dealer.
The owner should retain evidence that proper maintenance has been
performed as prescribed.
Claims against the warranty resulting from lack of maintenance, as
opposed to defective materials or authorized Mazda workmanship, will
not be honored.
Any auto repair shop using parts equivalent to your Mazda’s original
equipment may perform maintenance. But we recommend that it
always be done by an authorized Mazda Dealer using genuine
Mazda parts.
SCHEDULED MAINTENANCE
Follow Schedule 1 if the vehicle is operated mainly where none of the
following conditions apply.
If any do apply, follow Schedule 2 (Canada and Puerto Rico residents
follow Schedule 2).
• Repeated short-distance driving
• Driving in dusty conditions
• Driving with an extended use of brakes
• Driving in areas where salt or other corrosive materials are being used
• Driving on rough or muddy roads
• Extended periods of idling or low-speed operation
• Driving for long periods in cold temperatures or extremely humid
climates
• Towing a trailer or using a car-top carrier
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
232

NOTE:After the described period, continue to follow the described
maintenance at the recommended intervals.
SCHEDULE 1
I : Inspect and repair, clean, adjust, or replace if necessary
(Oil-permeated air filter cannot be cleaned using the air-blow method)
R : Replace
L : Lubricate
Maintenance Item Maintenance Interval (Number of months or km (miles),
whichever comes first)
Months 6 12 18 24 30 36 42 48 54 60 66 72
x 1000 Miles 7.5 15 22.5 30 37.5 45 52.5 60 67.6 75 82.5 90
(x 1000 Km) (12) (24) (36) (48) (60) (72) (84) (96)
(108) (120) (132) (144)
ENGINE
Engine valve clearance
(for 2.3L engine) Audible inspect every 75,000 miles (120,000 km),
if noisy, adjust
Engine oil RRRRRRRRRRRR
Oil filter RRRRRRRRRRRR
Drive belts (tension) 2.3L engine I I 3.0L engine I I I
PCV valve
(for 3.0L engine) *1 Replace every 100,000 miles (160,000 km)
IGNITION SYSTEM
Spark plugs Replace every 75,000 miles (120,000 km)
FUEL SYSTEM
Air cleaner filter R R
Fuel filter *1 R R R
Fuel lines and hoses *1 I I I
Hoses and tubes for
emission *1 I
COOLING SYSTEM
Cooling system and hoses I I I
Engine coolant (yellow) Replace at first 100,000 miles (160,000 km) or 72 months; after that, every 50,000 miles(80,000 km) or 36 months
Engine coolant level IIIIIIIIIIII
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
233

Maintenance Item Maintenance Interval (Number of months or km (miles),
whichever comes first)
Months 6 12 18 24 30 36 42 48 54 60 66 72
x 1000 Miles 7.5 15 22.5 30 37.5 45 52.5 60 67.6 75 82.5 90
(x 1000 Km) (12) (24) (36) (48) (60) (72) (84) (96)
(108) (120) (132) (144)
CHASSIS and BODY
Brake lines, hoses and connections I I I
Disc brakes IIIIII
Drum brakes I I I
Tire (rotation),
check wheel lug nut torque*3 Rotate every 7,500 miles (12,000 km)
Tire inflation and wear IIIIIIIIIIII
Steering operation and linkages I I I
Power steering fluid level IIIIIIIIIIII
Manual transaxle fluid Replace every 100,000 miles (160,000 km)
Automatic transaxle fluid Replace every 150,000 miles (240,000 km)
Rear differential fluid
(4WD only) *2 Replace every 150,000 miles (240,000 km)
Transfer case fluid
(4WD only) Replace every 150,000 miles (240,000 km)
Front and rear suspension ball
joints III
Driveshaft dust boots I I I
Bolts and nuts on chassis and body I I I
Exhaust system heat shields I I I
All locks and hinges L L L L L L L L L L L L
Washer fluid level IIIIIIIIIIII
*1 According to state and federal regulations, failure to perform maintenance on these
items will not void your emissions warranties. However, Mazda recommends that all
maintenance services be performed at the recommended time or miles (kilometers)
period to ensure long-term reliability. Refer to Fuel filterin theMaintenance and
Specifications chapter for fuel filter replacement requirements.
*2 If this component has been submerged in water, the oil should be changed.
*3 The wheel lug nuts must be retightened to the proper specifications at 500 miles
(800 km) of new vehicle operation, at any wheel change, or at any other time the
wheel lug nuts have been loosened. Refer to Wheel Lug Nut Torque Specificationin
the Tires, Wheels and Loading chapter for the proper lug nut torque specification.
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
234

SCHEDULE 2
I : Inspect and repair, clean, adjust, or replace if necessary
(Oil-permeated air filter cannot be cleaned using the air-blow method)
R : Replace
L : Lubricate
Maintenance Item Maintenance Interval (Number of months or km (miles),
whichever comes first)
Months 4 8 12 16 20 24 28 32 36 40 44 48
x 1000 miles 5 10 15 20 25 30 35 40 45 50 55 60
(x 1000 Km) (8) (16)
(24)(32) (40) (48) (56) (64) (72) (80) (88) (96)
ENGINE
Engine valve clearance
(for 2.3L engine) Audible inspect every 75,000 miles (120,000 km),
if noisy, adjust
Engine oil R R R RRRRRRRRR
Engine oil (for Puerto Rico)
Replace every 3,000 miles (5,000 km) (or 3 months)
Oil filter R R R RRRRRRRRR
Drive belts (tension) 2.3L engine I 3.0L engine I I
PCV valve
(for 3.0L engine) *1 Replace every 100,000 miles (160,000 km)
IGNITION SYSTEM
Spark plugs USA Replace every 60,000 miles (96,000 km) Others *2 Replace every 75,000 miles (120,000 km)
FUEL SYSTEM
Air cleaner filter Puerto Rico R R Others R
Fuel filter *1 R R
Fuel lines & hoses *1 I I
Hoses and tubes for
emission *1
I
COOLING SYSTEM
Cooling system and hoses I I
Engine coolant (yellow) Replace at first 100,000 miles (160,000 km) or 72 months; after that, every 50,000 miles(80,000 km) or 36 months
Engine coolant level I I I IIIIIIIII
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
235

Maintenance Item Maintenance Interval (Number of months or km (miles),
whichever comes first)
Months 4 8 12 16 20 24 28 32 36 40 44 48
x 1000 miles 5 10 15 20 25 30 35 40 45 50 55 60
(x 1000 Km) (8) (16)
(24)(32) (40) (48) (56) (64) (72) (80) (88) (96)
ELECTRICAL SYSTEM
Function of all lights I I I IIIIIIIII
CHASSIS and BODY
Brake lines, hoses and connections I I
Brake fluid level I I I IIIIIIIII
Disc brakes I I I I
Drum brakes I I
Tire (rotation),
check wheel lug nut torque *4 Rotate every 5,000 miles (8,000 km)
Tire inflation pressure and tire wearIIIIIIIIIIII
Steering operation and linkages I I
Power steering fluid level I I I IIIIIIIII
Manual transaxle oil Replace every 100,000 miles (160,000 km)
Automatic transaxle fluid Replace every 30,000 miles (48,000 km)
Rear differential
fluid (4WD only) *3 Replace every 100,000 miles (160,000 km)
Transfer case fluid
(4WD only) *3 Replace every 30,000 miles (48,000 km)
Front and rear suspension ball
joints II
Driveshaft dust boots I I
Bolts and nuts on chassis and body I I I I
Exhaust system heat shields I I
All locks and hinges L L L LLLLLLLLL
Washer fluid level I I I IIIIIIIII
*1 According to state and federal regulations, failure to perform maintenance on these
items will not void your emissions warranties. However, Mazda recommends that all
maintenance services be performed at the recommended time or miles (kilometers)
period to ensure long-term reliability. Refer to Fuel filterin theMaintenance and
Specifications chapter for fuel filter replacement requirements.
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
236

*2 If the vehicle is operated under any of the following conditions, change the spark
plugs every 60,000 miles (96,000 km) or shorter.
a) Repeated short-distance driving.
b) Extended periods of idling or low-speed operation.
c) Driving for long periods in cold temperatures or extremely humid climates.
*3 If this component has been submerged in water, the oil should be changed.
*4 The wheel lug nuts must be retightened to the proper specifications at 500 miles
(800 km) of new vehicle operation, at any wheel change, or at any other time the
wheel lug nuts have been loosened. Refer to Wheel Lug Nut Torque Specificationin
the Tires, Wheels and Loading chapter for the proper lug nut torque specification.
OWNER MAINTENANCE SCHEDULE
The owner or a qualified service technician should make these vehicle
inspections at the indicated intervals to ensure safe and dependable
operation.
Bring any problem to the attention of an authorized Mazda Dealer or
qualified service technician as soon as possible.
When Refueling
• Brake and clutch fluid level
• Engine coolant level
• Engine oil level
• Washer fluid level
At Least Monthly
• Tire inflation pressures
At Least Twice a Year (For Example, Every Spring and Fall)
• Automatic transaxle fluid level
• Power steering fluid level
Retightening lug nuts
• Retighten the lug nuts to the specified torque at 500 miles (800 km)
after any wheel disturbance (tire rotation, changing a flat tire, wheel
removal, etc.).
• Refer to Wheel Lug Nut Torque Specification in theTires, Wheels
and Loading chapter for the proper lug nut torque specification.
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
237

SERVICE RECOMMENDATIONS
To help you service your vehicle, we provide scheduled maintenance
information which makes tracking routine service easy.
If your vehicle requires professional service, your authorized dealer can
provide necessary parts and service. Check your “Warranty Information”
to find out which parts and services are covered.
Use only recommended fuels, lubricants, fluids and service parts
conforming to specifications. Genuine Mazda parts are designed and built
to provide the best performance in your vehicle.
PRECAUTIONS WHEN SERVICING YOUR VEHICLE
WARNING: A hot engine is dangerous. If the engine has been
running, parts of the engine compartment can become very hot.
You could be burned. Don’t inspect the coolant system or add
coolant when the engine is hot.
• Do not work on a hot engine.
• Make sure that nothing gets caught in moving parts.
• Do not work on a vehicle with the engine running in an enclosed
space, unless you are sure you have enough ventilation.
• Keep all open flames and other lit material away from the battery and
all fuel related parts.
Working with the engine off
• Automatic transmission/transaxle:
1. Set the parking brake and shift to P (Park).
2. Turn off the engine and remove the key.
3. Block the wheels.
• Manual transmission/transaxle:
1. Set the parking brake, depress the clutch and place the gearshift in 1 (First).
2. Turn off the engine and remove the key.
3. Block the wheels.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
238

Working with the engine on
• Automatic transmission:
1. Set the parking brake and shift to P (Park).
2. Block the wheels.
• Manual transmission:
1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral).
2. Block the wheels.
WARNING: To reduce the risk of vehicle damage and/or
personal burn injuries do not start your engine with the air
cleaner removed and do not remove it while the engine is
running.
OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under
the bottom of the instrument
panel.
2. At the front of the vehicle, lift up on the auxiliary latch handle
located in the center between
the hood and the grille.
3. Lift the hood open and secure it with the prop rod.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
239

IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT
2.3L I4 engine 1. Engine coolant reservoir
2. Engine oil filler cap
3. Automatic transmission dipstick (if equipped)
4. Brake/Clutch fluid reservoir
5. Air filter assembly
6. Power distribution box
7. Battery
8. Engine coolant bleed valve
9. Engine oil dipstick
10. Windshield washer fluid reservoir
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
240
