MAZDA MODEL TRIBUTE 2008 Owners Manual (in English)

MAINTENANCE PRODUCT SPECIFICATIONS AND CAPACITIES
Item Application Mazda part name or
equivalent Capacity
Brake fluid and (clutch fluid–if equipped) All High Performance DOT 3
Motor Vehicle Brake Fluid Between MIN and MAX
on reservoir
Engine coolant 2.3L I4 engine
with manual transaxle
Mazda yellow-colored Premium Engine Coolant
1
5.3 quarts (5.0L)
2.3L I4 engine
with automatic transaxle 6.3 quarts (6.0L)
3.0L V6 engine with automatic transmission 10.6 quarts (10.0L)
Engine oil (including filter change) 2.3L I4 engine
SAE 5W-20 Motor Oil 4.5 quarts (4.25L)
3.0L V6 engine 6.0 quarts (5.7L)
Transfer case fluid 4WD with
automatic transaxle API service GL-5
SAE 75W-140 Synthetic Lubricant 12 ounces (0.35L)
4WD with manual transaxle API service GL-5
SAE 80W-90
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
271

Item Application Mazda part name or
equivalent Capacity
Manual transaxle fluid Manual transaxle
(2WD) API service GL-4
SAE 75W-90 2.4 quarts (2.3L)
2
Manual transaxle
(4WD) 2.5 quarts (2.4L)
2
Automatic transaxle
fluid Automatic
transaxle MERCON

VATF
3
10.2 quarts (9.6L)
4
Rear axle fluid 4WD SAE 80W-90 Axle
Lubricant 2.4 pints (1.15L)
5
Windshield washer fluid All Ultra-Clear Windshield
Washer Concentrate 4.8 quarts (4.5L)
Fuel tank All — 16.5 gallons (62.5L)1Add the coolant type originally equipped in your vehicle. Do not mix different colors or types of
coolant. Do not use Mazda Extended Life Engine Coolant (orange in color). Refer to Adding
engine coolant in this chapter.2Service refill capacity is determined by filling the transmission to the bottom of the filler hole with
the vehicle on a level surface.3Automatic transmissions that require MERCON
V should only use MERCON
V fluid or fluid that
is specified dual usage MERCON
/MERCON
V. Refer toscheduled maintenance to determine
the correct service interval. Use of any fluid other than the recommended fluid may cause
transmission damage.4Indicates only approximate dry-fill capacity. Some applications may vary based on cooler size and
if equipped with an in-tank cooler. The amount of transmission fluid and fluid level should be set
by the indication on the dipstick’s normal operating range.5Fill from 1/4 inch to 9/16 inch (6mm to 14mm) below bottom of fill hole.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
272

ENGINE SPECIFICATIONS
Engine 2.3L I4 engine 3.0L DOHC V6 engine
Cubic inches 140 183
Required fuel 87 octane 87 octane
Firing order 1-3-4-2 1-4-2-5-3-6
Ignition system Coil on plug Coil on plug
Spark plug gap 0.049–0.053 inch (1.25–1.35mm) 0.052–0.056 inch
(1.32–1.42mm)
Compression ratio 9.7:1 10.0:1
Engine drivebelt routing
• 2.3L I4 Engine with A/C—Without A/C similar
• 3.0L V6 Engine
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
273

IDENTIFYING YOUR VEHICLE
Safety Compliance Certification Label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the structure (B-Pillar)
by the trailing edge of the driver’s
door or the edge of the driver’s
door.
Vehicle identification number (VIN)
The vehicle identification number is
located on the driver side
instrument panel.
Please note that in the graphic,
XXXX is representative of your
vehicle identification number.
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XX RC: XXDSO:
WB BRK INT TR TP/PS R AXLE TR SPR XXXXX
XXX X XX X XX X XX XXX
XXXXXXXXXXXXX XXX XXXX-XXXXXXX-XX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR
VEHICLE SAFETY AND THEFT PREVENTION STANDARDS IN
EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
VIN: XXXXXXXXXXXXXXXXX XXXXX
TYPE: XXX XXXXX
DATE:
XX/XX GVWR: XXXXXLB/ XXXXX KG
FRONT GAWR: XXXXL REAR GAWR: XXXXLB
AT XXX kPa/XX PSI COLD AT XXX kPa/XX PSI COLD
XXXX
KG WITH
XXXX/XXXXXXX TIRES
XXXX.XX RIMS XXXX
KG WITH
XXXX/XXXXXXX TIRES
XXXX.XX RIMS
FOR MAZDA MOTOR CORPORATION
XXXXXXXXXXXXXXXXX
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
274

The Vehicle Identification Number (VIN) contains the following
information: 1. World manufacturer identifier
2. Brake system / Gross Vehicle Weight Rating (GVWR) /
Restraint System
3. Vehicle line, series, body type
4. Engine type
5. Check digit
6. Model year
7. Assembly plant
8. Production sequence number
TRANSMISSION/TRANSAXLE CODE DESIGNATIONS
You can find a
transmission/transaxle code on the
Safety Compliance Certification
Label . The following table tells you
which transmission or transaxle
each code represents.
Description Code
Five-speed manual 3
Four-speed automatic 4
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XX RC: XXDSO:
WB BRK INT TR TP/PS R AXLE TR SPR XXXXX
XXX X XX X XX X XX XXX
XXXXXXXXXXXXX XXX XXXX-XXXXXXX-XX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL MOTOR
VEHICLE SAFETY AND THEFT PREVENTION STANDARDS IN
EFFECT ON THE DATE OF MANUFACTURE SHOWN ABOVE.
VIN: XXXXXXXXXXXXXXXXX XXXXX
TYPE: XXX XXXXX
DATE:
XX/XX GVWR: XXXXXLB/ XXXXX KG
FRONT GAWR: XXXXL REAR GAWR: XXXXLB
AT XXX kPa/XX PSI COLD AT XXX kPa/ XX PSI COLD
XXXX
KG WITH
XXXX/XXXXXXX TIRES
XXXX.XX RIMS XXXX
KG WITH
XXXX/XXXXXXX TIRES
XXXX.XX RIMS
FOR MAZDA MOTOR CORPORATION
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
275

CELL PHONES
Use of cell phones and other devices by driver: WARNING: Use of any electrical devices such as cell phones,
computers, portable radios, vehicle navigation or other devices
by the driver while the vehicle is moving is dangerous. Dialing a
number on a cell phone while driving also ties-up the driver’s
hands. Use of these devices will cause the driver to be
distracted and could lead to a serious accident. If a passenger is
unable to use the device, pull off the right-of-way to a safe area
before use. If use of a cell phone is necessary despite this
warning, use a hands-free system to at least allow the hands
free to drive the vehicle. Never use a cell phone or other
electrical device while the vehicle is moving and, instead,
concentrate on the full-time job of driving.
In addition, the gasoline distributors are warning against using
cell phones during refueling procedures, due to their increased
concern about static electricity fires in the self-service pump
environment.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
