Maintenance and Specifications 232
Engine compartment 240
Engine oil 244
Battery 248
Engine coolant 250
Fuel information 256
Air filter(s) 269
Maintenance product specifications and capacities 271
Engine data 273
Accessories 276
Index 277
All rights reserved. Reproduction by any means, electronic or mechanical
including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is not permitted without written
authorization from MNAO. MNAO may change the contents without notice and
without incurring obligation. Copyright © 2006 MNAO
Table of Contents
3
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)

Vehicle Symbol Glossary
Rear Window
Defrost/Demist
Power Windows
Power Window LockoutPersonal Alarm System
Feature
Engine OilEngine Coolant
Engine Coolant
TemperatureDo Not Open When Hot
BatteryAvoid Smoking, Flames,
or Sparks
Battery AcidExplosive Gas
Fan WarningPower Steering Fluid
Maintain Correct Fluid
LevelMAX MIN
Emission System
Engine Air FilterSpeed Control
Passenger Compartment
Air FilterJack
Check Fuel CapLow Tire Pressure
Warning
INFORMATION ABOUT THIS GUIDE
The information found in this guide was accurate at the time of printing.
Mazda may change the contents without notice.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Introduction
9

GAUGES
Speedometer: Indicates the
current vehicle speed.
Engine coolant temperature
gauge: Indicates engine coolant
temperature. At normal operating
temperature, the needle will be in
the normal range (between “H” and
“C”). If it enters the red section,
the engine is overheating. Stop
the vehicle as soon as safely
possible, switch off the engine and let the engine cool.
WARNING: When the engine and radiator are hot, scalding
coolant and steam may shoot out under pressure and cause
serious injury. Do not remove the cooling system cap when the
engine and radiator are hot.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Instrument Cluster
17

WARNING: Engine exhaust, some of its constituents, and
certain vehicle components contain or emit chemicals known to
the State of California to cause cancer and birth defects or
other reproductive harm. In addition, certain fluids contained in
vehicles and certain products of component wear contain or
emit chemicals known to the State of California to cause cancer
and birth defects or other reproductive harm.
Important ventilating information
If the engine is idling while the vehicle is stopped in an open area for
long periods of time, open the windows at least once inch (2.5 cm).
Adjust the heating or air conditioning (if equipped) to bring in fresh air.
Note: Improve vehicle ventilation by
keeping all air inlet vents clear of
snow, leaves and other debris.
ENGINE BLOCK HEATER (IF EQUIPPED)
An engine block heater warms the engine coolant which aids in starting
and heater/defroster performance. Use of an engine block heater is
strongly recommended if you live in a region where temperatures reach
-10°F (-23°C) or below. For best results, plug the heater in at least three
hours before starting the vehicle. The heater can be plugged in the night
before starting the vehicle.
WARNING: To reduce the risk of electrical shock, do not use
your heater with ungrounded electrical systems or two-pronged
(cheater) adapters.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Driving
165

4. Check whether coolant or steam is escaping from under the hood or from the engine compartment.
• If steam is coming from the engine compartment: do not go near
the front of the vehicle. Stop the engine, then turn the ignition switch
to the ON position without starting the engine. The radiator cooling
fans will start to cool the engine.
• If neither coolant nor steam is escaping: open the hood and idle
the engine until it cools. If this does not lower the temperature, stop
the engine and let it cool.
5. Check the coolant level. If it is low, look for leaks in the radiator hoses and connections, heater hoses and connections, radiator and
water pump.
If you find a leak or other damage, or if coolant is still leaking, stop the
engine and call an authorized dealer.
WARNING: When the engine and radiator are hot, scalding
coolant and steam may shoot out under pressure and cause
serious injury. Do not remove the cooling system cap when the
engine and radiator are hot.
See Adding coolant in theMaintenance and Specifications section. If
you find no problems, the engine is cool and no leaks are obvious,
carefully add coolant as required.
Note: If the engine continues to overheat or frequently overheats, have
the cooling system inspected. The engine could be seriously damaged
unless repairs are made.
JUMP STARTING
WARNING: The gases around the battery can explode if
exposed to flames, sparks, or lit cigarettes. An explosion could
result in injury or vehicle damage.
WARNING: Batteries contain sulfuric acid which can burn skin,
eyes and clothing, if contacted.
Do not attempt to push-start your automatic transmission
vehicle. Automatic transmissions do not have push-start
capability. Attempting to push-start a vehicle with an automatic
transmission may cause transmission damage.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
207

NOTE:After the described period, continue to follow the described
maintenance at the recommended intervals.
SCHEDULE 1
I : Inspect and repair, clean, adjust, or replace if necessary
(Oil-permeated air filter cannot be cleaned using the air-blow method)
R : Replace
L : Lubricate
Maintenance Item Maintenance Interval (Number of months or km (miles),
whichever comes first)
Months 6 12 18 24 30 36 42 48 54 60 66 72
x 1000 Miles 7.5 15 22.5 30 37.5 45 52.5 60 67.6 75 82.5 90
(x 1000 Km) (12) (24) (36) (48) (60) (72) (84) (96)
(108) (120) (132) (144)
ENGINE
Engine valve clearance
(for 2.3L engine) Audible inspect every 75,000 miles (120,000 km),
if noisy, adjust
Engine oil RRRRRRRRRRRR
Oil filter RRRRRRRRRRRR
Drive belts (tension) 2.3L engine I I 3.0L engine I I I
PCV valve
(for 3.0L engine) *1 Replace every 100,000 miles (160,000 km)
IGNITION SYSTEM
Spark plugs Replace every 75,000 miles (120,000 km)
FUEL SYSTEM
Air cleaner filter R R
Fuel filter *1 R R R
Fuel lines and hoses *1 I I I
Hoses and tubes for
emission *1 I
COOLING SYSTEM
Cooling system and hoses I I I
Engine coolant (yellow) Replace at first 100,000 miles (160,000 km) or 72 months; after that, every 50,000 miles(80,000 km) or 36 months
Engine coolant level IIIIIIIIIIII
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
233

SCHEDULE 2
I : Inspect and repair, clean, adjust, or replace if necessary
(Oil-permeated air filter cannot be cleaned using the air-blow method)
R : Replace
L : Lubricate
Maintenance Item Maintenance Interval (Number of months or km (miles),
whichever comes first)
Months 4 8 12 16 20 24 28 32 36 40 44 48
x 1000 miles 5 10 15 20 25 30 35 40 45 50 55 60
(x 1000 Km) (8) (16)
(24)(32) (40) (48) (56) (64) (72) (80) (88) (96)
ENGINE
Engine valve clearance
(for 2.3L engine) Audible inspect every 75,000 miles (120,000 km),
if noisy, adjust
Engine oil R R R RRRRRRRRR
Engine oil (for Puerto Rico)
Replace every 3,000 miles (5,000 km) (or 3 months)
Oil filter R R R RRRRRRRRR
Drive belts (tension) 2.3L engine I 3.0L engine I I
PCV valve
(for 3.0L engine) *1 Replace every 100,000 miles (160,000 km)
IGNITION SYSTEM
Spark plugs USA Replace every 60,000 miles (96,000 km) Others *2 Replace every 75,000 miles (120,000 km)
FUEL SYSTEM
Air cleaner filter Puerto Rico R R Others R
Fuel filter *1 R R
Fuel lines & hoses *1 I I
Hoses and tubes for
emission *1
I
COOLING SYSTEM
Cooling system and hoses I I
Engine coolant (yellow) Replace at first 100,000 miles (160,000 km) or 72 months; after that, every 50,000 miles(80,000 km) or 36 months
Engine coolant level I I I IIIIIIIII
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
235

*2 If the vehicle is operated under any of the following conditions, change the spark
plugs every 60,000 miles (96,000 km) or shorter.
a) Repeated short-distance driving.
b) Extended periods of idling or low-speed operation.
c) Driving for long periods in cold temperatures or extremely humid climates.
*3 If this component has been submerged in water, the oil should be changed.
*4 The wheel lug nuts must be retightened to the proper specifications at 500 miles
(800 km) of new vehicle operation, at any wheel change, or at any other time the
wheel lug nuts have been loosened. Refer to Wheel Lug Nut Torque Specificationin
the Tires, Wheels and Loading chapter for the proper lug nut torque specification.
OWNER MAINTENANCE SCHEDULE
The owner or a qualified service technician should make these vehicle
inspections at the indicated intervals to ensure safe and dependable
operation.
Bring any problem to the attention of an authorized Mazda Dealer or
qualified service technician as soon as possible.
When Refueling
• Brake and clutch fluid level
• Engine coolant level
• Engine oil level
• Washer fluid level
At Least Monthly
• Tire inflation pressures
At Least Twice a Year (For Example, Every Spring and Fall)
• Automatic transaxle fluid level
• Power steering fluid level
Retightening lug nuts
• Retighten the lug nuts to the specified torque at 500 miles (800 km)
after any wheel disturbance (tire rotation, changing a flat tire, wheel
removal, etc.).
• Refer to Wheel Lug Nut Torque Specification in theTires, Wheels
and Loading chapter for the proper lug nut torque specification.
2008 Tribute(j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
237

SERVICE RECOMMENDATIONS
To help you service your vehicle, we provide scheduled maintenance
information which makes tracking routine service easy.
If your vehicle requires professional service, your authorized dealer can
provide necessary parts and service. Check your “Warranty Information”
to find out which parts and services are covered.
Use only recommended fuels, lubricants, fluids and service parts
conforming to specifications. Genuine Mazda parts are designed and built
to provide the best performance in your vehicle.
PRECAUTIONS WHEN SERVICING YOUR VEHICLE
WARNING: A hot engine is dangerous. If the engine has been
running, parts of the engine compartment can become very hot.
You could be burned. Don’t inspect the coolant system or add
coolant when the engine is hot.
• Do not work on a hot engine.
• Make sure that nothing gets caught in moving parts.
• Do not work on a vehicle with the engine running in an enclosed
space, unless you are sure you have enough ventilation.
• Keep all open flames and other lit material away from the battery and
all fuel related parts.
Working with the engine off
• Automatic transmission/transaxle:
1. Set the parking brake and shift to P (Park).
2. Turn off the engine and remove the key.
3. Block the wheels.
• Manual transmission/transaxle:
1. Set the parking brake, depress the clutch and place the gearshift in 1 (First).
2. Turn off the engine and remove the key.
3. Block the wheels.
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
238

IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT
2.3L I4 engine 1. Engine coolant reservoir
2. Engine oil filler cap
3. Automatic transmission dipstick (if equipped)
4. Brake/Clutch fluid reservoir
5. Air filter assembly
6. Power distribution box
7. Battery
8. Engine coolant bleed valve
9. Engine oil dipstick
10. Windshield washer fluid reservoir
2008 Tribute (j14)
Owners Guide (post-2002-fmt)
USA (fus)
Maintenance and Specifications
240
