MERCEDES-BENZ C CLASS COUPE 2003 Owners Manual

91
Controls in detail
Seats
Rear seat head restraints
Removing rear head restraints
Pull head restraint to its highest posi-
tion.

Push button
1 and pull out head re-
straint.
Installing rear head restraints

Insert head restraint and push it down
until it engages.

Push button 1 and adjust head re-
straint to desired position.
Heated seats*
The switches are located in the center con-
sole.
1 Normal heating
2 Rapid heating
Make sure that the ignition is switched
on.
All the lamps in the instrument cluster
light up.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.

92 Controls in detailSeatsSwitching on seat heating
Press upper switch position1.
A red indicator lamp on the switch
lights up.
Switching on rapid seat heating

Press lower switch position 2.
Both red indicator lamps on the switch
light up. Switching off seat heating

If one indicator lamp is on, press upper
switch position
1.

If both indicator lamps are on, press
lower switch position 2.
!If one or both of the lamps on the seat
heater switch are blinking, there is in-
sufficient voltage available since too
many electrical consumers are turned
on. The seat heater switches off auto-
matically.
The seat heater will switch back on
again automatically as soon as suffi-
cient voltage is available.
iThe system switches over to normal
heating mode after approximately five
minutes. Only one indicator lamp re-
mains lit. iThe seat heater will be automatically
switched off after approximately
30 minutes.

93
Controls in detail
Memory function*
Memory function*
The memory button and stored position
switch are located on the door.
You can store up to three different settings
per key.
The following settings are saved for each
stored position:

Driver’s seat and backrest position


Steering wheel position


Driver’s side exterior rear view mirror
position


Passenger side exterior rear view mir-
ror position


Front passenger seat position
These key-dependent memory settings
can be deactivated if desired
(
page 124).
!Prior to operating the vehicle, the driv-
er should check and adjust the seat
height, seat position fore and aft, and
seat backrest angle if necessary, to en-
sure adequate control, reach and com-
fort. The head restraint should also be
adjusted for proper height. Also see air-
bag section (
page 57) for proper seat
positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, opera-
tion and comfort. Both the inside and
outside rear view mirrors should be ad-
justed for adequate rear vision.
Fasten seat belts. Infants and small
children should be seated in a properly
secured restraint system that complies
with U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian
Motor Vehicle Safety Standards 213
and 210.2.
Warning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.

94 Controls in detailMemory function*1Memory button
2 Stored position button
Make sure that the ignition is switched
on or the relevant door is open and the
SmartKey is inserted in the starter
switch.
Storing positions into memory
Adjust the seats, steering wheel and
rear view mirrors to the desired posi-
tion (
page 32).

Turn button 2 to selected memory po-
sition.

Press memory button 1.

Release memory button and push
button 2 within three seconds.
All the settings are stored at the select-
ed position.
Recalling positions from memory
Turn button 2 to selected memory po-
sition.

Press and hold button 2 until the seat,
steering wheel and rear view mirrors
have fully moved to the stored posi-
tions.iReleasing the button immediately
stops movement to the stored posi-
tions.Warning!
G
Do not operate the power seats using the
memory button if the seat backrest is in an
excessively reclined position. Doing so
could cause damage to front or rear seats.
First move backrest to an upright position.

95
Controls in detail
Memory function*
Storing exterior rear view mirror park-ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gear
R.
You can store a parking position for the
passenger exterior rear view mirror for
each key using the memory switch.
For information about activating the park-
ing position, see “Activating exterior rear
view mirror parking position”
(page 124). 1
Adjustment button
2 Passenger side exterior rear view mir-
ror
3 Memory button

Stop the vehicle.

Switch ignition on (if not already on).

Press button 2.
The passenger side exterior rear view
mirror is selected.

Adjust the exterior rear view mirror
with button 1 so that you see the rear
wheel and the curb.

Press memory button “M” 3 on the
door.

Within three seconds press bottom of
adjustment button 1 above the exterior
lamp switch.
The parking position is stored if the
mirror does not move.iIf the mirror does move, repeat the
above steps. After the setting is stored
you can move the mirror again.

96 Controls in detailLighting
LightingFor notes on how to switch on the head-
lamps and use the turn signals, see the
“Getting started” section (
page 47).
Exterior lamp switch
The exterior lamp switch is located on the
dashboard to the left of the steering wheel
M
Off
U
Automatic headlamp mode
C
Parking lamps (also side marker
lamps, tail lamps, license plate
lamps, instrument panel lamps)
Canada only: When engine is run-
ning, the low beam is also switched
on.
B
Low beam plus parking lamps or
high beam headlamps (combination
switch pushed forward).
ˆ
Standing lamps, right (turn left one
stop)
‚
Standing lamps, left (turn left two
stops)
iIf you remove the key and open the
driver’s door while the parking lamps or
low beam headlamps are switched on,
then

a warning sounds


$
appears in the multifunction
display


the message
TURN OFF LAMPS
ap-
pears in the multifunction display
iWith the daytime running lamp mode
activated and the engine running, the
low beam headlamps cannot be
switched off manually.

97
Controls in detail
Lighting
Manual headlamp mode
The low beam headlamps and parking
lamps can be switched on and off with the
exterior lamp switch. For exterior lamp
switch, see above.
Automatic headlamp mode
The parking lamps, low beam headlamps
and license plate lamps switch on and off
automatically depending on the brightness
of the ambient light.
Turn the exterior lamp switch to
U
.
Warning!
G
In automatic headlamp mode, the head-
lamps will not be automatically switched on
under foggy conditions. To minimize risk to
you and to others, activate headlamps by
turning exterior lamp switch to
B
.
The driver is responsible for the operation of
the vehicle’s lights at all times. The automat-
ic headlamp feature is only an aid to the driv-
er. Switch on the vehicle lights manually
when driving or when traffic conditions re-
quire you to do so.
iWith the daytime running lamp mode
activated, the low beam headlamps will
not be switched off automatically.
iFront fog lamps and rear fog lamp can
not be switched on manually with exte-
rior lamp switch in position
U
. To
activate the fog lamps, turn exterior
lamp switch to position
B
.
iIf you drive in countries where vehicles
drive on the other side of the road than
the country where the vehicle is regis-
tered, you must have the headlamps
modified for symmetrical low beams.
Relevant information can be obtained
at your authorized Mercedes-Benz Cen-
ter.

98 Controls in detailLightingDaytime running lamp mode
Turn exterior lamp switch to
position
M
or
U
.
When the engine is running, the low beam
headlamps are automatically switched on.
In low ambient light conditions the parking
lamps will also switch on.
Canada only
When you shift from a driving position to
position N or P, the low beam switches off
(with a three-minute delay).
For nighttime driving you should turn the
exterior lamp switch to position
B
to
permit activation of the high beam head-
lamps.
USA only
The high beam headlamps can also be ac-
tivated when driving with the daytime run-
ning lamp mode activated and exterior
lamp switch in position
M
. To activate the daytime running lamp
mode, see “Setting daytime running lamp
mode” (
page 119).
Locator lighting and night security illu-
mination
Locator lighting and night security illumi-
nation are described in the control system
section under “Setting locator lighting”
(
page 120) and “Exterior lamps delayed
shut off” (
page 120).
Switching on front fog lamps

Make sure that the low beam head-
lamps are switched on.

Pull out exterior lamp switch to first
stop.
The green indicator lamp
‡
in the
lamp switch lights up. Switching on rear fog lamp

Make sure that the low beam head-
lamps are switched on.

Pull out exterior lamp switch to second
stop.
The yellow indicator lamp
†
in the
lamp switch lights up.
iSee notes on the exterior lamp switch
(page 96).
iFog lamps will operate with the parking
lamps and/or the low beam headlamps
on. Fog lamps should only be used in
conjunction with low beam headlamps.
Consult your State or Province Motor
Vehicle Regulations regarding allow-
able lamp operation.

99
Controls in detail
Lighting
Combination switch
The combination switch is located on the
left side of the steering column.
1 High beam
2 High beam flasher
Switching on high beams
Turn exterior lamp switch to
position
B
or to
U
(page 96).

Push the combination switch in
direction 1.
The high beam symbol is illuminated on
the instrument cluster. High beam flasher

Pull the combination switch briefly in
direction
2.
Hazard warning flasher
The hazard warning flasher can be activat-
ed with the ignition switched on or off. It is
activated automatically when an airbag is
deployed.
The switch is located on the center con-
sole.
1 Hazard warning flasher switch Switching on the hazard warning
flasher

Press the hazard warning flasher
switch.
All turn signals will blink.
Switching off the hazard warning
flasher

Press hazard warning flasher switch
again.

100 Controls in detailLightingInterior lighting
The controls are located in the overhead
control panel.1 Rear interior lights
2 Right front reading lamp
3 Rocker switch: Automatic control off
4 Rocker switch: Automatic control on
5 Rocker switch: Front interior lights on
6 Left front reading lamp Activating automatic control

Press the rocker switch to the center
position
4.
Interior lamps are switched on in dark-
ness, when

unlocking the vehicle


opening a door


removing the SmartKey from start-
er switch
The interior lamps are switched off follow-
ing an adjustable time delay (
page 121). Deactivating automatic control

Press the rocker switch to the right
position
3
The interior lighting remains switched
off, even when

centrally unlocking the vehicle


opening a door


removing the SmartKey from the
starter switch
Manual control
Switching rear interior lights on and off

Press button 1.
The lights in the rear passenger com-
partment go on.

Press button 1 again.
The lights in the rear passenger com-
partment go out.
iIf the door remains open, the interior
lamps switch off automatically after ap-
proximately five minutes, when the key
is removed or in the starter switch
position 0.
An interior lamp switched on manually
does not go out automatically.
