MERCEDES-BENZ C55AMG 2006 W203 Owner's Manual

220 Controls in detail
Audio system
Playing tracks
You have the following options:

Audio system with CD changer*:
selecting CDs

Direct track entry

Track skip forward/reverse

Fast forward/reverse

Scan

Random tracks

Repeat trackSelecting CDs in the audio unit with CD
changer*
You can select from among the
inserted CDs with buttons
Rto6.
R = CD player in the audio unit
1to6 = CDs in the
CD changer*
The magazine slot number of the
selected CD appears next to
CD in the
display, and the number of the
currently played track appears next
to
TRACK.Direct track entry
You can make a direct selection from
among the tracks on a CD.
Press * button.
Enter track number using buttons 1
to R.
The number of the track being played
appears next to
TRACK in the display.
You can only enter available track
numbers.
i
If there is no CD in the selected
magazine slot,
NO CD appears in the
display with the corresponding slot
number.

221 Controls in detail
Audio system
Skipping tracks forward/backward

Skipping tracks forward
Press S button briefly.
The next track will be played.

Skipping tracks backward
Press T button briefly.
If the track has been playing for
more than 10 seconds, the unit
skips back to the beginning of the
track currently playing. If less than
10 seconds have been played, the
unit skips back to the beginning of
the previous track.
Pressing the T or S button
repeatedly will result in multiple tracks
being skipped.Fast forward/reverse

Fast forward
Press and hold S button until
desired point has been reached.

Reverse
Press and hold T button until
desired point has been reached.
Scan

Starting scan
Press SC soft key.
SC will appear in the display.
Each track on the current CD will be
played for approx. 8 seconds in as-
cending order.

Ending scan
Press SC soft key or T or S.Random play
The random function (RDM) plays the
tracks of the current CD in random order.

Switching on random
Press RDM soft key.
RDM appears in the display.
A randomly selected track is
played.

Switching off random
Press RDM soft key again.
i
The track number and the relative time
of the track is shown in the display
during the search.
i
When you start the RDM function, the
RPT function is automatically switched
off.

222 Controls in detail
Audio system
Repeat
The track being played is repeated until the
repeat function is switched off.

Switching on repeat
Press RPT soft key.
RPT appears in the display.

Switching off repeat
Press RPT soft key again.Pause function
The CD changer mode is interrupted by an
incoming call on the telephone*
(
page 227).

Switching on pause function
Press U button.
The CD changer mode is
interrupted and
PAUSE appears in
the display.

Switching off pause function
Press U button.
The CD changer mode is active
again.Track and time display
Press T soft key.
The number of the track being played
and the elapsed playing time appear in
the display.
Press T soft key again.
The total number of tracks and the total
playing time of the CD appear in the
display.
Press T soft key.
The standard CD playback menu
appears in the display.
i
When you start the RPT function, the
RDM function is automatically
switched off.

223 Controls in detail
Audio system
GSM network phones
Using your Mercedes-Benz specified
mobile telephone*, a number of functions
and operating steps can be performed and
displayed in the audio system display.
Further operating instructions not covered
here can be found in the operating instruc-
tions for the multifunction steering wheel
and the cellular telephone*.
I f y o u r a u d i o s y s t e m i s s e t u p f o r t e l e p h o n e
operation, the tsymbol will appear in
the display.
When you insert your Mercedes-Benz
specified mobile telephone* into the
telephone cradle, you will be prompted to
enter your PIN for 30 seconds
(
page 223). This display disappears
when you press any button.
When your mobile telephone is inserted
into the telephone cradle, you will see the
reception strength in the upper right-hand
corner of the display.Switching on the telephone
Switching on the telephone
Pressh button.
If the telephone was previously
switched off,
PROCESSING appears in
the display and you will then be
prompted to enter your PIN.
Switching off the telephone
Pressh button for approximately
3 seconds.
PROCESSING appears in the display until
the telephone is off. Afterward,
PHONE OFF appears in the display.PIN entry
Enter PIN number using buttons 1
to R.
If necessary, correct number entered
with the
CLR soft key. Press soft key
briefly to delete the last digit entered;
press soft key and hold to delete the
complete number.
Press OK soft key after entering correct
PIN.
READY or ROAMING will appear in the
display.

224 Controls in detail
Audio system
Adjusting the volume
Turn rotary control of N button
during a telephone call.
The volume will increase or decrease
depending on the direction turned.
Adjusting sound
Adjust sound during a telephone call.
Sound adjustment (
page 201).Placing a call
Entering a telephone number and
starting the dialing process
Enter desired telephone number using
buttons 1 to R.
The number can have up to 32 digits,
but only twelve of these are visible in
the display.
If necessary, correct number entered
with the
CLR soft key. Press soft key
briefly to delete the last digit entered;
press soft key and hold to delete the
complete number.
After correct telephone number has
been entered, press s button.
Phone book
The numbers stored in the phone book of
the telephone can be called up either by
name or number.
In addition, incoming calls are stored in the
phone book.
i
If the PIN is entered incorrectly three
times,
NEED PUK will appear in the
display. Enter PUK via your telephone.
Please refer to the separate telephone
operating instructions for more
information.
i
The volume can be adjusted separately
for telephone mode and audio mode.
i
If the telephone number has been
saved together with a name in the
telephone book, the name will appear
in the display.

225 Controls in detail
Audio system

Searching and calling up telephone
book entries by name
You can access your mobile
telephone’s phone book using the
audio system. You can access both the
main entries and the sub-entries of
your phone book.
Press MEM soft key or press
button‚ orƒ.
Press desired numerical key 2
to 9.
The stored entries are selected
according to the alphabetical order
of the initial letters (e.g. for
S-Schneider, press button 7
four times).
or
Press and hold button ‚
orƒ.
The system jumps from one initial
letter to the next in ascending or
descending order.
Press and hold button ‚
orƒ until desired initial letter
has been reached.
or
Press button ‚ or ƒ
repeatedly until desired entry has
been reached.
The stored entries are selected in
alphabetical order with the
sub-entries.i
This is only possible, however, when
the call information transmitted
includes the number of the person
calling. If the telephone number is not
transmitted,
NO NUMBER will be stored
in the phone book.
i
Several sub-entries can be stored for
each main entry (name). These entries
are marked by a corresponding
abbreviation that appears in the upper
left-hand corner of the display. The
following abbreviations for sub-entries
are possible:
CEL = Mobile phone
HOM = Home
WOR = Work
FAX = Fax
PAG = Pager
TEL = Main


226 Controls in detail
Audio system
When you have selected a number,
press s button.
The call will be made.

Viewing the telephone number of a
telephone book entry
Search for desired entry.
Press NUM soft key.
The telephone number of the phone
book entry appears in the display.

Returning calls received
Press MEM soft key or press
button‚ orƒ.
Press RCV soft key (received calls).
The number of received calls and
then the call last received appear
briefly in the display.
Select desired telephone number
with button ‚ or ƒ.
The letter
R and the number of the
memory position appear in the
upper left-hand corner of the
display. The numbers are stored in
the order of the calls received.
When you have selected a number,
press s button.
The call will be made.

Speed dial
If you have stored telephone numbers
as speed dial numbers in your
telephone, you can also enter these
with buttons 1 to R on the radio
head unit.
Press desired button 1 to R
briefly.
Press s button.
The call will be made.

Turbo dial
If you have stored telephone numbers
as turbo dial numbers in your
telephone, you can also enter these
with buttons 1 to R on the radio
head unit.
Press desired button 1 to R
until the call is made.


227 Controls in detail
Audio system
Redial
If the number you have dialed is busy, you
can again place calls to the last ten
telephone numbers dialed using the redial
function.

Manual redial
Press s button.
The telephone number last dialed
will appear in the display.
Select desired telephone number
with button ‚ or ƒ.
The letter
L and the number of the
memory position appears in the
left-hand corner of the display. The
numbers are stored in the order of
the calls received.
When you have selected a number,
press s button.
The call will be made.Accepting an incoming call
If the telephone is active in the background
(reception symbol is visible in the display),
the audio source is muted when an incom-
ing call is received. A ringing tone can be
heard and the caller’s telephone number,
or the name under which the telephone
number has been saved in the phone book,
appears in the display. If the caller’s
number is not transmitted with the call,
CALL will appear in the display.
Press s button.
The call is accepted.
i
If you have activated the automatic
redial function on your telephone, the
number of the person being called is
automatically redialed after a short
waiting period if there is a busy signal.
Refer to the separate operating
instructions for the mobile telephone.

228 Controls in detail
Audio system
Muting a call
It is possible to mute a call; the caller is
then no longer able to hear you.

Mute on
PressMUT soft key.
MIC MUTE will appear in the display.

Mute off
PressMUT soft key again.
Terminating a call
Press t button.
The current call is terminated and the
muted audio source becomes active
again.Talking with two callers at the same
time
If you wish to receive or place another call
during an already active call, you can
accept or place the second call and switch
between the callers or combine them into
one call. Note that the features described
here are depending on availability from
your mobile phone service provider.

Placing/accepting a second call
Place new call by entering
telephone number manually.
Press s button.
You are connected to the second
caller; the first caller is kept on
hold.
or
Press s button to accept a
second call.
You are connected with the second
caller; the first caller is kept on hold.

Switching between calls
Press 2 and s buttons.
This switches between the calls.
The non-active call is kept on hold.
i
You will be notified of the second call
acoustically, but you will not see this in
the display.

229 Controls in detail
Audio system

Terminating a call
Press t button.
The current call is terminated. You
are again connected with the caller
previously placed on hold.

Combining two calls
Press 3 and s buttons.
The calls are combined into one
call.

Terminating a combined call
Press t button.
The connection to both callers is
terminated.
TDMA or CDMA network phones
Using your Mercedes-Benz specified
mobile telephone*, a number of functions
and operating steps can be performed and
displayed in the audio system display.
Further operating instructions not covered
here can be found in the operating instruc-
tions for the multifunction steering wheel
and the mobile telephone*.
If your audio system is set up for telephone
operation, the t symbol will appear in
the display.
When you insert your Mercedes-Benz
specified mobile telephone* into the
telephone cradle, you will be prompted to
enter your PIN for 30 seconds
(
page 229). This display disappears
when you press any button.
When your mobile telephone is inserted
into the telephone cradle, you will see the
reception strength in the upper right-hand
corner of the display.Switching on the telephone
Switching on the telephone
Press h button.
If you have programmed an unlock
code for the telephone, you must now
enter the code.
Enter code using buttons 1
toR.
If necessary, correct number entered
with the
CLR soft key. Press soft key
briefly to delete the last digit entered;
press soft key and hold to delete the
complete number.
