MERCEDES-BENZ C55AMG 2006 W203 Owner's Manual

250 Controls in detail
Loading
5Button
Open trunk lid.
Press button5.
The flap opens downward.
From trunk, slide skis into ski sack.6Strap
Tighten strap6 by pulling at the loose
end (arrow) until the skis in the ski sack
are tightly secured.
Warning!G
The ski sack is designed for up to four pairs
of skis. Do not load the ski sack with other
objects.
Always fasten the ski sack securely. In an
accident, an unfastened ski sack can cause
injury to vehicle occupants.


251 Controls in detail
Loading
7Hook
8Eye
Connect hook7 to eye8.
Tighten strap by pulling at the loose
end (arrow).Unloading and folding
Loosen the straps.
Disconnect hook7 from eye8.
Unload skis.
Close flap in trunk.
Fold and flatten ski sack lengthwise.
Place folded ski sack inside recess of
backrest.
Fasten hook and loop fastener.
Close ski sack compartment cover.Removing the ski sack
You can remove the ski sack for cleaning
or drying.
1Button
2Ski sack frame
3Flap
Open trunk lid.
Press button1.
The flap3 opens downward.
Press button1 firmly until ski sack
frame2 is released.
Pull ski sack frame2 with ski sack
out.

252 Controls in detail
Loading
Installing the ski sack
Install the ski sack in the reverse order.
Push ski sack frame2 with ski sack
inward until the ski sack frame snaps
into place.
Close flap3.
Close trunk lid.
Split rear bench seat
To expand the cargo area, you can fold
down the left and right rear seat backrests.
The two sections can be folded down
separately.Folding the backrest forward
The release handle1 is located in the
trunk.
Pull release handle1.
Fully retract and fold rearward head
restraints (
page 108).
Warning!G
Never drive vehicle with trunk open while
the ski sack is removed. Deadly carbon
monoxide (CO) gases may enter vehicle in-
terior, resulting in unconsciousness and
death.
i
To prevent unauthorized persons from
accessing the trunk, always close the
flap.
Warning!G
When expanding the luggage area, always
fold the seat cushions fully forward.
Unless you are transporting cargo, the
backrests must remain properly locked in
the upright position.
In an accident, during hard braking or
sudden maneuvers, loose items will be
thrown around inside the vehicle, and cause
injury to vehicle occupants unless the items
are securely fastened in the vehicle.
Always use the cargo tie down rings*
(
page 255).

253 Controls in detail
Loading
Pull release handle2.
Fold seat cushion3 forward.
Fold backrest4 forward.Returning the backrest to original
positionFold backrest2 rearward until it
engages.
Fold seat cushion1 rearward until it
locks into position.If the backrest is not locked into position,
a red indicator3 will be visible.
Check for secure locking by pushing
and pulling on the backrest.
!
Always release the seat cushion and
fold it forward before folding the seat
backrests forward. Otherwise, the
backrest covering may be damaged.

254 Controls in detail
Loading
Loading instructions
The total load weight including vehicle
occupants and luggage/cargo should not
exceed the load limit or vehicle capacity
weight indicated on the corresponding
placard located on the driver’s door
B-pillar.
The handling characteristics of a fully load-
ed vehicle depend greatly on the load dis-
tribution. It is therefore recommended to
load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.Always place items being carried against
front or rear seat backrests, and fasten
them as securely as possible.
The heaviest portion of the cargo should al-
ways be kept as low as possible since it in-
fluences the handling characteristics of
the vehicle.
Warning!G
If a red indicator is visible with the backrest
up, then the backrest is not properly locked
into position.
Always lock backrest in its upright position
when rear seat bench is occupied, cargo is
being carried in the trunk, or the extended
cargo compartment is not in use. Check for
secure locking by pushing and pulling on the
backrest.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and cause injury
to vehicle occupants unless the items are
securely fastened in the vehicle.
To help avoid personal injury during a
collision or sudden maneuver, exercise care
when transporting cargo.
i
To prevent unauthorized persons from
access to the trunk, always lock
backrest in its upright position.
Warning!G
Always fasten items being carried as secure-
ly as possible using cargo tie-down rings and
fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.

255 Controls in detail
Loading
Cargo tie-down rings*
The four cargo tie-down rings are located
in the trunk.
Cargo tie-down rings
Carefully secure cargo by applying
even load on all rings with rope
sufficient strength to hold down the
cargo.
Always follow loading instructions
(
page 254).
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.
i
The trunk is the preferred place to carry
objects.
The enlarged cargo area should only be
used for items which do not fit in the
trunk alone.

256 Controls in detail
Useful features
Storage compartments Glove box
1Glove box lid release
2Glove box
Opening glove box
Pull glove box lid release1.
The glove box lid2 opens downward.
Closing glove box
Push glove box lid2 up to close.1Unlocking
2Locking
Locking glove box
Insert mechanical key (page 386)
into the glove box lock and turn it to
position2.
Unlocking glove box
Turn mechanical key in the glove box
lock to position1.
Warning!G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
g a g e o r c a r g o i n t h e t r u n k i f p o s s i b l e . D o n o t
pile luggage or cargo higher than the seat
backs. Do not place anything on the shelf
below the rear window.
Luggage nets cannot secure hard or heavy
objects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during
an accident.
i
Audio system/COMAND* with CD
changer*: The CD changer* is located
in the glove box.

257 Controls in detail
Useful features
Armrest storage compartments
1Handle
2Button, passenger side
3Button, driver’s side
Opening storage compartment
Pull handle1 and lift armrest.
Closing storage compartment
Press armrest down until it engages
into place.Opening upper compartment
Press button3 on driver’s side or
button2 on passenger side and lift
armrest.
Closing upper compartment
Press armrest down until it engages
into place.Armrest in the rear passenger
compartment
Pull the top of the armrest out and fold
it down.
i
The Roadside Assistance button•
and the Information button¡ are
located in the armrest storage com-
partment (if equipped).
!
Do not sit on or lean your body weight
against the armrest when it is folded
down, as you could otherwise damage
it.

258 Controls in detail
Useful features
Parcel net in front passenger footwell
A small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.Cup holders
Cup holders in front of seat armrest
Underneath the swiveling cup holder is
another stationary cup holder. You can
only use this when the swiveling cup holder
is pulled out and completely turned
outward.
Warning!G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard brak-
ing, or sudden maneuvers, they could be
thrown around inside the vehicle and cause
injury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.
Warning!G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or an ac-
cident. Liquids spilled on vehicle occupants
may cause serious personal injury. Liquids
spilled on vehicle equipment may cause
damage not covered by the Mercedes-Benz
Limited Warranty.
When not in use, keep the cup holder
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an acci-
dent.
Keep in mind that objects placed in the cup
holder may come loose during braking, vehi-
cle maneuvers, or in an accident and be
thrown around in the vehicle interior.
Objects thrown around in the vehicle interi-
or may cause an accident and/or serious
personal injury.

259 Controls in detail
Useful features
Sliding out swiveling cup holder
Push button1.
The cup holder slides upward.Turning swiveling cup holder outwardTurn the cup holder in direction of
arrow2 until it engages.
You can now use both cup holders.Turning swiveling cup holder inward and
sliding it in
Turn the cup holder in direction of
arrow3 until it engages.
Press the cup holder in direction of
arrow4 until it engages.!
No objects should be in the swiveling
cup holder when the swiveling cup
holder is slid upward. Otherwise the
swiveling cup holder or the objects
could be damaged.
!
No objects should be in the stationary
cup holder when the swiveling cup
holder is turned inward and pushed in.
Otherwise the swiveling cup holder or
the objects could be damaged.
