MERCEDES-BENZ CL-CLASS 2007 Owners Manual

350 Controls in detail
Seats
Placing head restraints upright
Switch on the ignition (page 336).
Press and hold switch1 in the front
center console (
page 349).
The rear seat head restraints will place
upright.Manually placing head restraints up-
right
Pull the rear seat head restraint upright
until it locks into place.
iWhen fasten a rear seat belt (page 360),
the respective rear seat head restraint places
upright.
Warning!G
Make sure the rear seat head restraints en-
gage when placing them upright manually.
Otherwise their protective function cannot
be ensured.
The back of the head will not be supported
in the event of a collision. That could cause
serious or even fatal injuries. Rear seat oc-
cupants can be seriously injured or killed.
ProCarManuals.com

351 Controls in detail
Steering wheel
Steering wheel
Make sure that

you can reach the steering wheel with
your arms slightly bent at the elbows

you can move your legs freely

all displays (including malfunction and
indicator lamps) on the instrument
cluster are clearly visible
Steering wheel adjustment
1Adjusting steering wheel, in or out
2Adjusting steering column, up or down
Switch on the ignition (page 336) or
open the driver’s door.
Adjusting steering wheel in or out:
Move stalk forward or back in the direc-
tion of arrow1 until a comfortable
steering wheel position is reached with
your arms slightly bent at the elbow.
Adjusting steering wheel up or
down: Move stalk up or down in the di-
rection of arrow2.
Warning!G
Do not adjust the steering wheel while driv-
ing. Adjusting the steering wheel while driv-
ing could cause the driver to lose control of
the vehicle.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the steering
wheel adjustment feature can be operated
when the driver’s door is open. Therefore,
do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
A child’s unsupervised access to a vehicle
could result in an accident and/or serious
personal injury.
iThe memory function (page 357) lets you
store settings for the steering wheel together
with the settings for the seat position and the ex-
terior rear view mirrors.
ProCarManuals.com

352 Controls in detail
Steering wheel
Heated steering wheel*
The steering wheel heating warms up the
leather area of the steering wheel.
1Switching on
2Switching off
3Indicator lamp
Switch on the ignition (page 336).
Switching on: T urn s witc h at t he tip of
stalk in the direction of arrow1.
The steering wheel is heated. Indicator
lamp3 comes on.
Switching off: T u r n s w i t c h a t t h e t i p o f
stalk in the direction of arrow2.
The steering wheel heating is turned
off. Indicator lamp3 goes out.
iThe steering wheel heating will not switch
on, when the temperature of the vehicle interior
is above 86°F (30°C).
iIndicator lamp3 flashes or goes out

in case of power surge or undervoltage

in case of a steering wheel heating
malfunction
iThe steering wheel heating switches off
automatically:

when you remove the SmartKey from the
starter switch

on vehicles with KEYLESS-GO*, when you
switch off the ignition (
page 336) and
open the driver’s door

when the temperature of the vehicle interior
is above 86°F (30°C)

after approximately 30 minutes
ProCarManuals.com

353 Controls in detail
Mirrors
Mirrors
Adjust the interior and exterior rear view
mirrors before driving so that you have a
good view of the road and traffic condi-
tions.
Interior rear view mirror
Manually adjust the interior rear view
mirror.
For more information, see “Auto-dimming
rear view mirrors” (
page 355).
Exterior rear view mirrors1 Selector switch for right or left exterior
mirror
2Adjustment button
Switch on the ignition (page 336).
Press button1 repeatedly until de-
sired exterior mirror is selected.
The left or right indicator lamp in
button1 comes on.
Push adjustment button2 up, down,
left, or right according to the desired
setting.
Warning!G
Exercise care when using the passenger
side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your in-
terior rear view mirror or glance over your
shoulder before changing lanes.
iWhen you press button1 for the first time,
the exterior mirror on the driver’s side is always
selected.
If you do not make adjustments to the selected
exterior rear view mirror within 15 seconds, the
indicator lamp goes out. You will then have to se-
lect the desired exterior rear view mirror again
before any adjustments can be made. Adjust-
ments can only be made with the indicator lamp
for the respective exterior rear view mirror but-
ton illuminated.
iAt low ambient temperatures, the exterior
rear view mirrors will be heated automatically.
iThe memory function (page 357) lets you
store the setting for the exterior rear view mir-
rors together with the setting for the steering
wheel and the seat positions.
ProCarManuals.com

354 Controls in detail
Mirrors
Power folding exterior rear view
mirrors
Folding exterior rear view mirrors in
and out automatically
When the corresponding function in the
COMAND system is activated
(
page 237):

The exterior rear view mirrors automat-
ically fold in as soon as the vehicle is
locked from the outside.

The exterior rear view mirrors automat-
ically fold out as soon as the vehicle is
unlocked and the driver’s or passenger
door are subsequently opened.Folding exterior rear view mirrors in
and out manually
The exterior rear view mirrors can vibrate if
they are not folded out completely.
1Folds the exterior mirrors in and outSwitch on the ignition (page 336).
Folding in: Press button1.
Folding out: Press button1 again.
!Before driving the vehicle through an auto-
matic car wash, fold the exterior mirrors in. Oth-
erwise they may get damaged.
iThe mirrors do not fold out if they were pre-
viously folded in manually.
iIf you are driving at more than approximately
9 mph (15 km/h), you will not be able to fold the
exterior mirrors in.
!If an exterior rear view mirror housing is
forcibly pushed forward (hit from the rear), repo-
sition it manually by applying firm pressure until
it snaps back into place.
If an exterior rear view mirror housing is forcibly
pushed rearward (hit from the front), press
button1 to fold mirrors in, then press
button1 again to fold mirrors out. Do not force
mirrors by hand as this may damage the adjust-
ment mechanism.
The mirror housing is then properly positioned
and you can adjust the mirror in the usual
manner.
ProCarManuals.com

355 Controls in detail
Mirrors
Auto-dimming rear view mirrors
The reflection brightness of the exterior
rear view mirror on the driver’s side and
the interior rear view mirror will respond
automatically to glare when

the ignition is switched on
(
page 336)
and

incoming light from headlamps falls on
the sensor in the interior rear view
mirror
The interior rear view mirror will not react if

reverse gear R is engaged
and

the interior lighting is turned on
Warning!G
The auto-dimming function does not react if
incoming light is not aimed directly at the
sensors in the interior rear view mirror.
The interior rear view mirror and the exterior
rear view mirror on the driver’s side do not
react, for example, if the rear window sun-
shade is in raised position.
Light hitting the mirror(s) at certain angles
(incident light) could blind you. As a result,
you may not be able to observe traffic con-
ditions and could cause an accident.
Warning!G
Exercise care when using the passen-
ger-side exterior rear view mirror. The mirror
surface is convex (outwardly curved surface
for a wider field of view). Objects in mirror
are closer than they appear. Check your in-
side rear view mirror or glance over your
shoulder before changing lanes.
ProCarManuals.com

356 Controls in detail
Mirrors
Activating exterior rear view mirror
parking position
Follow these steps to activate the mirror
parking position so that the passen-
ger-side exterior rear view mirror will be
turned downward to the stored position.
Make sure you have stored a parking
position for the passenger-side exterior
rear view mirror (
page 359).
Make sure the “Lower mirror when re-
versing” function in the “Exterior Mirror
Convenience Settings” submenu of the
COMAND system is selected
(
page 237).
Switch on the ignition (page 336).1Selector switch for right or left exterior
mirror
Press switch1 repeatedly until the
exterior mirror on the front passenger
side is selected.
Shift the automatic transmission in re-
verse gearR.
The passenger-side exterior rear view
mirror will be turned downward to the
stored position.
The exterior rear view mirror returns to its
previously stored driving position:

when you switch off the ignition

10 seconds after you have put the au-
tomatic transmission out of reverse
gearR

immediately once your vehicle exceeds
a speed of approximately 6 mph
(10 km/h)

immediately when you press button1
for driver’s side exterior rear view mir-
ror.iWith the automatic transmission in reverse
gear R, the previously selected exterior rear view
mirror is activated.
iIf you adjust the exterior mirrors while they
are in the parking position, the new mirror posi-
tion is stored as a new parking position.
ProCarManuals.com

357 Controls in detail
Memory function
Memory function
Prior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach, and comfort. The head
restraint should also be adjusted for
proper height. See also the section on
air bags (
page 42) for proper seat
positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the interior and exterior
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small
children should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and
Canadian Motor Vehicle Safety Standards
213 and 210.2.With the memory function you can store up
to three different configurations.
The following settings are stored when us-
ing the buttons on the driver’s door:

Driver’s seat, head restraint height and
backrest position

Lumbar support (CL 550)

Drive-dynamic multicontour seat*:
activation/deactivation

Steering wheel position

Exterior rear view mirrors positionThe following settings are stored when us-
ing the buttons on the passenger door:

Front passenger seat, head restraint
high and backrest position

Lumbar support (CL 550)

Drive-dynamic multicontour seat*:
activation/deactivation
Warning!G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.
ProCarManuals.com

358 Controls in detail
Memory function
MMemory button
1 2 3Memory position buttons
Switch on the ignition (page 336).
or
Open the respective door.
Storing positions into memory
Adjust the seat (page 339) to the de-
sired position.
On the driver’s side: adjust the steering
wheel (
page 351) and the exterior
rear view mirrors (
page 353) to the
desired position.
Press memory buttonM.
Release memory buttonM and press
one of the memory position buttons
1,2or3 within 3 seconds.
All the settings are stored at the
selected position.
Recalling positions from memory
Press and hold one of the memory
position buttons1,2or3 until the
seat, steering wheel and exterior rear
view mirrors have completely moved to
the stored positions.
!Do not operate the power seats using a
memory position button if the seat backrest is in
an excessively reclined position. Doing so could
cause damage to front or rear seats.
First move seat backrest to an upright position.
iReleasing the memory position button
immediately stops movement to the stored
positions.
The drive-dynamic multicontour front seat*
and/or lumbar support (CL 550) will continue to
be adjusted.
ProCarManuals.com

359 Controls in detail
Memory function
Storing exterior rear view mirror park-
ing position
For easier parking, you can adjust the pas-
senger-side exterior rear view mirror so
that you can see the right rear wheel as
soon as you engage reverse gearR.
For information on activating the parking
position, see “Activating exterior rear view
mirror parking position” (
page 356).
1Memory button M
2Adjustment button
3Selector switch for right or left exterior
mirror
Stop the vehicle.
Make sure the ignition is switched on
(
page 336).
Press switch3 until the exterior mir-
ror on the front passenger side is se-
lected.
Adjust the passenger-side exterior rear
view mirror with button2 so that you
see the rear wheel and the road curb.
Press memory button M.
Within 3 seconds, press one of adjust-
ment buttons2.
The parking position is stored if the
mirror does not move.
iIf the mirror does move, repeat the above
steps. After the setting is stored, you can move
the mirror again.
ProCarManuals.com
