MERCEDES-BENZ CLK COUPE 2006 C209 Owner's Manual

110 Controls in detailLocking and unlockingLoss of the SmartKey with KEYLESS-GO
If you lose your SmartKey with
KEYLESS-GO, you should do the following:
Have the SmartKey with KEYLESS-GO
deactivated by an authorized
Mercedes-Benz Center.

Report the loss of the SmartKey with
KEYLESS-GO or the mechanical key
immediately to your car insurance
company.

Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a
replacement.
Opening the doors from the inside
You can open a locked door from the in-
side. Open doors only when conditions are
safe to do so.
1Locking knob
2Inside door handle
iIf the vehicle has previously been
locked with the SmartKey or
KEYLESS-GO*, opening a door from the
inside will trigger the anti-theft alarm
system.
To cancel the alarm, do one of the
following:
With the SmartKey

Insert the SmartKey in the starter
switch.


Press button‹orŒ on the
SmartKey.
With KEYLESS-GO*


Pull an outside door handle.
The SmartKey with KEYLESS-GO
must be within 3 ft (1 m) of the ve-
hicle.


Press the KEYLESS-GO* start/stop
button (
page 35).
The SmartKey with KEYLESS-GO
must be inside the vehicle.

111 Controls in detail
Locking and unlocking

Pull on door handle2.
If door was locked, locking knob1 will
move up.
Opening the trunk
Opening the trunk from the outside
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
Vehicles without KEYLESS-GO*:
The vehicle must be unlocked.
The handle is located in the rear license
plate recess.
1Handle
Pull on handle1.
The trunk opens.
iIf you open a door, the side windows on
that side of the vehicle will lower slight-
ly. The windows close again when you
close the door.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.
Vehicles with trunk opening/closing
system*: To stop the opening proce-
dure, press button Š on the Smart-
Key or SmartKey with KEYLESS-GO*.iIf the trunk does not open, it is still
locked separately (
page 119).
iThe trunk can also be opened using
buttonŠ on the SmartKey or
SmartKey with KEYLESS-GO* or from
its inside in an emergency, see “Trunk
emergency release” (
page 118).

112 Controls in detailLocking and unlockingOpening the trunk from the inside
You can open the trunk from the inside if
the vehicle is stationary.
A minimum height clearance of 5.71 ft
(1.74 m) is required to open the trunk lid.
The remote trunk opening switch is locat-
ed on the driver’s door (vehicles without
trunk opening/closing system*).
1Remote trunk opening switchThe remote trunk opening switch and the
trunk closing switch are located on the
driver’s door (vehicles with trunk open-
ing/closing system*).
1Remote trunk opening switch*
2Remote trunk closing switch*

Press remote trunk opening switch1
until the trunk begins to open.
The trunk opens. The indicator lamp
comes on and remains lit until the
trunk is closed.
!The trunk lid swings open upwards au-
tomatically. Always make sure there is
sufficient overhead clearance.
Vehicles with trunk opening/closing
system*: To stop the opening proce-
dure, press switch1 or 2.iIf the trunk does not open, it is still
locked separately (
page 119).
iThe trunk can also be opened using
buttonŠ on the SmartKey
SmartKey with KEYLESS-GO* or from
its inside in an emergency, see “Trunk
emergency release” (
page 118).

113 Controls in detail
Locking and unlocking
Closing the trunk
Closing the trunk from the inside
automatically*
In vehicles with trunk opening/closing sys-
tem* you can close the trunk from the in-
side using the remote trunk closing*
switch.
Press the remote trunk closing*
switch2 (
page 112) until the indi-
cator lamp in the switch goes out and
the trunk lid is closed.
To interrupt the closing procedure:

Release remote trunk closing*
switch2.If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), in the sequence, the
upper motion the closing procedure is
stopped and the trunk reopens slightly.iYou can also close the trunk by hand
(page 114).
Warning!
G
Maintain sight of trunk area while operating
the door mounted remote trunk closing*
switch. Monitor the closing procedure care-
fully to ensure that no one is in danger of be-
ing injured.
To interrupt the closing procedure, release
the door mounted remote trunk closing
switch.
Even with the SmartKey or the SmartKey
with KEYLESS-GO* removed from the start-
er switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the remote trunk opening/closing* switch
can be operated. Therefore, do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. Unsuper-
vised use of vehicle equipment may cause
an accident and/or serious personal injury.
Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility,
exhaust fumes may enter the vehicle
interior.

114 Controls in detailLocking and unlockingClosing the trunk from the outside
manually
1Handle
2Handles
Lower trunk lid by pulling firmly on
handle1 or handles2.

Close trunk from the outside with
hands placed flat on the trunk lid.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility,
exhaust fumes may enter the vehicle
interior.
iDo not place the SmartKey in the open
trunk. You may lock yourself out.
Vehicles with KEYLESS-GO*:
To prevent a possible inadvertent lock-
out, the trunk lid will open automatical-
ly if a SmartKey with KEYLESS-GO* is
recognized inside the vehicle or in the
trunk.iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it (
page 113). All turn
signal lamps flash three times, and an
acoustic signal sounds three times (if
equipped and feature activated), to
confirm locking.

115 Controls in detail
Locking and unlocking
Closing the trunk from the outside
(vehicles without KEYLESS-GO*)
In vehicle with trunk opening/closing sys-
tem* you can close the trunk separately.
1Trunk closing switch
Press trunk closing switch1 briefly.
The trunk closes.If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.iYou can also close the trunk by hand
(page 114).
Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press trunk closing switch1


press the Š button on the SmartKey


press the remote trunk opening or clos-
ing switch (on driver’s door)
Even with the SmartKey removed from the
starter switch, the trunk closing switch can
be operated. Therefore, do not leave chil-
dren unattended in the vehicle, or with ac-
cess to an unlocked vehicle.
Unsupervised use of vehicle equipment may
cause an accident and/or serious personal
injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility,
exhaust fumes may enter the vehicle
interior.iDo not place the SmartKey in the open
trunk. You may lock yourself out.iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it (
page 113). All turn
signal lamps flash three times, and an
acoustic signal sounds three times (if
equipped and feature activated), to
confirm locking.

116 Controls in detailLocking and unlockingClosing the trunk from the outside
(vehicles with KEYLESS-GO*)
In vehicles with trunk opening/closing sys-
tem* you can close the trunk separately.
1Trunk closing switch
Make sure you have the SmartKey with
KEYLESS-GO with you.

Press trunk closing switch1 briefly.
The trunk closes.If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.
iYou can also close the trunk by hand
(page 114).
iTo prevent a possible inadvertent lock-
out, the trunk will open automatically if
a SmartKey with KEYLESS-GO is recog-
nized inside the vehicle or in the trunk.
Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press trunk closing switch1


press KEYLESS-GO locking/closing
switch


press the remote trunk opening or clos-
ing switch (on driver’s door)


press the Š button on the SmartKey
with KEYLESS-GO

117 Controls in detail
Locking and unlocking
Closing the trunk and locking the vehi-
cle from the outside (vehicles with
KEYLESS-GO*)
In vehicles with trunk opening/closing sys-
tem* and KEYLESS-GO, you can close the
trunk lid and lock the vehicle simulta-
neously.
1KEYLESS-GO locking/closing switch
Make sure you have the SmartKey with
KEYLESS-GO with you.

Press switch1 briefly.
The vehicle is locked and the trunk
closes automatically.With the trunk and both doors closed:


All turn signal lamps flash three
times.


An acoustic signal sounds three
times (if equipped and feature acti-
vated).


The locking knobs in the doors
move down.


The anti-theft alarm system is
armed.
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has
been piled too high), the closing procedure
is stopped and the trunk reopens slightly.
Even with the SmartKey with KEYLESS-GO
removed from the vehicle, the trunk closing
switch can be operated. Therefore, do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility,
exhaust fumes may enter the vehicle
interior.iIf the vehicle was previously centrally
locked, the trunk will lock automatical-
ly after closing it (
page 113). All turn
signal lamps flash three times, and an
acoustic signal sounds three times (if
equipped and feature activated), to
confirm locking.
iYou can also close the trunk by hand
(page 114).

118 Controls in detailLocking and unlocking
Trunk emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
The emergency release button is located
on the inside of the trunk lid.
1Emergency release button
Briefly press emergency release
button1.
The trunk unlocks and opens slightly.

Push up the trunk lid to fully open.
iTo prevent a possible inadvertent lock-
out, the trunk will open automatically if
a SmartKey with KEYLESS-GO is recog-
nized inside the vehicle or in the trunk.Warning!
G
Monitor the closing procedure carefully to
ensure that no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press KEYLESS-GO locking/closing
switch1


press trunk closing switch


press the Š button on the SmartKey
with KEYLESS-GO


press the remote trunk opening or clos-
ing switch (on driver’s door)
Even with the SmartKey with KEYLESS-GO
removed from the vehicle, the trunk closing
switch can be operated. Therefore, do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility,
exhaust fumes may enter the vehicle
interior.

119 Controls in detail
Locking and unlocking
Illumination of the emergency release but-
ton:

The button will flash for 30 minutes
after opening the trunk.


The button will flash for 60 minutes
after closing the trunk.
Valet locking
The lock is located next to the handle
above the rear license plate recess.
1Neutral position
2Locked
iThe emergency release button unlocks
and opens the trunk while the vehicle is
standing still or in motion.iThe emergency release button does
not open the trunk if the vehicle battery
is discharged or disconnected.iIf the trunk does not open, it is still
locked separately (
page 119).
iIf the vehicle has previously been
locked using the SmartKey or
KEYLESS-GO*, opening the trunk from
the inside using the emergency release
button will trigger the anti-theft alarm
system.
To cancel the alarm, do one of the
following:

Insert the SmartKey in the starter
switch.


Press button‹orŒ on the
SmartKey.
In vehicles with KEYLESS-GO*:


Pull an outside door handle.
The SmartKey with KEYLESS-GO*
must be within 3 ft (1 m) of the ve-
hicle.


Press the KEYLESS-GO* start/stop
button (
page 35).
The SmartKey with KEYLESS-GO*
must be inside the vehicle.
iTo deny any unauthorized person ac-
cess to the trunk, e.g. when you valet
park the vehicle, lock it separately with
the mechanical key. Leave only the
SmartKey or SmartKey with
KEYLESS-GO* less its mechanical key
with the vehicle.
