MERCEDES-BENZ CLK COUPE 2006 C209 Owner's Manual

120 Controls in detailLocking and unlocking
Close the trunk (
page 113).

Pull the mechanical key out of the
SmartKey (
page 404).

Insert the mechanical key in the trunk
lid lock.

Turn the mechanical key clockwise to
position2 and remove the mechani-
cal key in that position to lock the
trunk.
The trunk remains locked even when the
vehicle is centrally unlocked.

Insert the mechanical key in the trunk
lid lock.

Turn the mechanical key counterclock-
wise to neutral position1 and remove
the mechanical key in that position to
unlock the trunk.
You can now open the trunk
(page 111).
Automatic central locking
The doors and the trunk automatically lock
when the ignition is switched on and the
wheels are turning at vehicle speeds of
approximately 9 mph (15 km/h) or more.
You can open a locked door from the
inside. Open doors only when conditions
are safe to do so.
You can deactivate the automatic locking
mode using the control system, see “Set-
ting automatic locking” (
page 163).
iYou can only cancel the separate trunk
locking mode by means of the
mechanical key.
iThe doors unlock automatically after an
accident if the force of the impact
exceeds a preset threshold.
To prevent the vehicle door locks from
locking, deactivate the automatic
central locking when the vehicle

is pushed or towed


is on a test stand


121 Controls in detail
Locking and unlocking
Locking and unlocking from the inside
You can lock or unlock the doors and the
trunk from inside using the central locking
or unlocking switch. This can be useful, for
example, if you want to lock the vehicle
before starting to drive.
You cannot lock or unlock the fuel filler flap
with the central locking or unlocking
switch.
The switches are located in the center
console.1Central locking switch
2Central unlocking switchLocking

Press central locking switch1.
If both doors are closed, the vehicle
locks.
Unlocking

Press central unlocking switch2.
The vehicle unlocks.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked with the SmartKey or the
SmartKey with KEYLESS-GO*, it will
not unlock using the central unlocking
switch2.
If the vehicle was previously locked
with the central locking switch1

while in the selective remote
control mode, only the door opened
from inside is unlocked.


while in the global remote control
mode, the complete vehicle is
unlocked when a door is opened
from the inside.

122 Controls in detailSeatsFor information on seat adjustment, see
“Adjusting” (
page 37).
Front seat active head restraints
You cannot remove the active head re-
straints on the driver’s and passenger’s
seat.
For removal of the active head restraints
we recommend that you contact an
authorized Mercedes-Benz Center.
For information on head restraint adjust-
ment, see “Seats” (
page 37).For information on active head restraints,
see “Active head restraints” (
page 73).
Rear seat head restraintsHead restraint height
1Release button
Raising:

Manually adjust the height of the head
restraint by pulling it upward.
If the head restraint is fully retracted,
push release button1 and pull the
head restraint out.
Lowering:

To lower the head restraint, push
release button1 and push down on
the head restraint.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust the head restraint so that it is as
close to the head as possible and the center
of the head restraint supports the back of
the head at eye level. This will reduce the po-
tential for injury to the head and neck in the
event of an accident or similar situation.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.

123 Controls in detailSeats
Folding head restraints back with re-
lease button
1Release button
Push release button1.
The head restraints will fold backward.Folding head restraints back with
switch in the center console
1Rear head restraints folding switch

Start the engine (
page 48).

Press switch1 to release the head re-
straints.
The head restraints will fold backward.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust the head restraint so that it is as
close to the head as possible and the center
of the head restraint supports the back of
the head at eye level. This will reduce the po-
tential for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are
intended to help reduce injuries during an
accident.
iYou can also fold the head restraints
back using the switch in the center
console.

124 Controls in detailSeatsPlacing rear head restraints upright
Pull the rear head restraint forward un-
til it locks into position.
Head restraint tilt
Two different head restraint angle
positions are available.

Press the release button (
page 123)
and tilt the head restraint to the
desired position.
Removing and installing rear seats
head restraints
1Release button
Removing rear seat head restraints

Fold back head restraint (
page 123).

Pull head restraint to its highest
position.

Push release button1 and pull out
head restraint.
Installing rear head restraints

Insert head restraint and push it down
until it engages.

Push release button1 and adjust
head restraint to desired position.
Warning!
G
Make sure the head restraints engage when
placing them upright. Otherwise their pro-
tective function cannot be assured.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust the head restraint so that it is as
close to the head as possible and the center
of the head restraint supports the back of
the head at eye level. This will reduce the po-
tential for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an
accident.
Do not interchange head restraints from
front and rear seat.

125 Controls in detailSeats
Multicontour seat*
The multicontour seat has a movable seat
cushion and inflatable air cushions built
into the backrest to provide additional
lumbar and side support.
The seat cushion movement, backrest
cushion height and curvature can be
continuously varied with switches on the
side of the seat after switching on ignition.
1Seat cushion depth
2Backrest bottom
3Backrest center
4Side bolster adjustment

Switch on ignition (
page 36).Seat cushion depth

Adjust the seat cushion depth to the
length of your upper leg using
switch1.
Backrest contour

Adjust the contour of the backrest to
the desired position using switches2
and3.
Backrest side bolsters

Adjust the backrest side bolsters so
that they provide good lateral support
using switch4.iIf, after a period of time, the seat no
longer provides the desired contour,
then repeat the adjustment procedure.

126 Controls in detailSeatsSeat heating*
Both switches for the front seats are
located in the center console.
1Seat heating switchThe red indicator lamps on the switch1
show which heating level you have select-
ed.

Switch on the ignition (
page 36).Switching on seat heating

Press seat heating switch1 once.
Three red indicator lamps in the switch
come on.

Continue pressing seat heating
switch1 until desired seat heating
level is reached.
Switching off seat heating

Press seat heating switch1
repeatedly until all red indicator lamps
go out.
Level3
Three indicator lamps on
(highest level).
After approximately five minutes,
seat heating is automatically
switched to level 2.
2
Two indicator lamps on.
After approximately ten minutes,
seat heating is automatically
switched to level 1.
1
One indicator lamp on
(lowest level).
After approximately 20 minutes,
seat heating is automatically
switched off.
off
No indicator lamp on.
iIf one or more of the indicator lamps on
the seat heater switch1 are flashing,
there is insufficient voltage due to too
many electrical consumers being
switched on. The seat heating switches
off automatically.
The seat heating will switch back on
again automatically as soon as
sufficient voltage is available.

127 Controls in detailSeats
Seat ventilation*
Both switches for the front seats are
located in the center console.
1Seat ventilation switchThe blue indicator lamps in the switch1
show which ventilation level you have
selected:

Switch on the ignition (
page 36).
All lamps in the instrument cluster
come on.
Switching on seat ventilation

Press seat ventilation switch1.
Three blue indicator lamps come on.

Press seat ventilation switch1
repeatedly until the desired seat venti-
lation level is reached.Switching off seat ventilation

Press seat ventilation switch1
repeatedly until all blue indicator lamps
go out.
Level3
Three indicator lamps on
2
Two indicator lamps on
1
One indicator lamp on
off
No indicator lamp on
iThe seat ventilation for the driver’s seat
is automatically set to the highest level
if activated via summer opening
feature (
page 249).
iIf one or more of the indicator lamps on
the seat ventilation switch1 are flash-
ing, there is insufficient voltage due to
too many electrical consumers being
switched on. The seat ventilation
switches off automatically.
The seat ventilation will switch back on
again automatically as soon as
sufficient voltage is available.

128 Controls in detailMemory functionPrior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach and comfort. The head
restraint should also be adjusted for
proper height. See also the section on
air bags (
page 63) for proper seat
positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the interior and exterior
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small chil-
dren should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and
Canadian Motor Vehicle Safety Standards
213 and 210.2.The following settings are stored when
using the buttons on the driver’s door:


Driver’s seat, backrest and head
restraint position


Steering wheel position


Exterior rear view mirror position
The following settings are stored when us-
ing the buttons on the passenger door:


Front passenger seat, backrest and
head restraint positionThe memory button and memory position
switch are located on the door.
1Memory button
2Memory position switch

Switch on the ignition (
page 36).
or

Open the respective door and insert
the SmartKey in the starter switch.
Warning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.

129 Controls in detail
Memory function
Storing positions into memory
Adjust the seats, steering wheel and
exterior rear view mirrors to the
desired position (
page 38).

Turn memory position switch2 to the
desired memory position.

Press memory button1.

Release memory button1 and press
memory position switch2 within
three seconds.
All settings are stored to the selected
position.
Recalling positions from memory
Turn memory position switch2 to the
desired memory position.

Press and hold memory position
switch2 until the seat, steering wheel
and exterior rear view mirrors have
completely moved to the stored
positions.!Do not operate the seats using the
memory button if the seat backrest is
in an excessively reclined position.
Doing so could cause damage to front
or rear seats.
First move the seat backrest to an
upright position.
iReleasing the memory position switch
stops movement to the stored
positions immediately.
