MERCEDES-BENZ CLK320 CABRIOLET 2005 A209 Owner's Manual

110 Controls in detailLocking and unlockingAutomatic central locking
The doors and the trunk automatically lock
when the ignition is switched on and the
wheels are turning at vehicle speeds of
approximately 9 mph (15 km/h) or more.
You can open a locked door from the
inside. Open door only when conditions
are safe to do so.
You can deactivate the automatic locking
mode using the control system, see “Set-
ting automatic locking” (
page 155).
Locking and unlocking from the inside
You can lock or unlock the doors and the
trunk from inside using the central locking
or unlocking switch. This can be useful, for
example, if you want to lock the vehicle
before starting to drive.
You cannot lock or unlock the fuel filler flap
with the central locking or unlocking
switch.Depending on production date, your
vehicle is equipped with either switch
design A or B.
The switches are located in the center
console.
Switch design A1Central locking switch
2Central unlocking switch
iThe doors unlock automatically after an
accident if the force of the impact
exceeds a preset threshold.
To prevent the vehicle door locks from
locking, deactivate the automatic
central locking when the vehicle

is pushed or towed


is on a test stand
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.

111 Controls in detail
Locking and unlocking
Switch design B1Central locking switch
2Central unlocking switchLocking

Press central locking switch1.
If both doors are closed, the vehicle
locks.
Unlocking

Press central unlocking switch2.
The vehicle unlocks.
iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked with the SmartKey or the
SmartKey with KEYLESS-GO*, it will
not unlock using the central unlocking
switch2.
If the vehicle was previously locked
with the central locking switch1

while in the selective remote
control mode, only the door opened
from inside is unlocked.


while in the global remote control
mode, the complete vehicle is
unlocked when a door is opened
from the inside.

112 Controls in detailSeatsFor information on seat adjustment, see
“Adjusting” (
page 37).
Easy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle.
The easy-entry/exit feature can be
activated or deactivated in the Convenience
submenu of the control
system (
page 156).When exiting the vehicle, with the
easy-entry/exit feature activated and
depending on your selection, the steering
wheel tilts upwards and/or the driver’s
seat moves a few inches to the rear when
you:


remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position0
or1 or the KEYLESS-GO* start/stop
button (
page 35) in position1.
Warning!
G
You must make sure that no one can be-
come trapped or injured by the moving
steering wheel and driver’s seat when the
easy-entry / exit feature is activated.
To cancel seat /steering wheel movement,
do one of the following:

Press the seat adjustment switch
(page 38).


Move the steering column stalk
(page 40).


Press the memory position switch
(page 120).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver's door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.
iIf the current position for the steering
wheel is in the uppermost tilt position,
the steering wheel will no longer be
able to move upward when the
easy-entry/exit feature is activated.

113 Controls in detailSeats
When entering the vehicle, with the
easy-entry/exit feature activated, the
steering wheel or, depending on your
selection, the steering wheel and driver’s
seat will return to their last set position or
a factory-set maximum forward position
when you:

close the driver’s door with the ignition
switched on.
or


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 35) once
with the driver’s door closed.Removing and installing front seat
head restraints
For information on head restraint adjust-
ment, see “Seats” (
page 37). If the current seat position falls into a
factory-set position range and the
system recognizes the current seat
position to be rearward enough for
easy entry and exit, the driver’s seat
will not move to the rear when the
easy-entry/exit feature is activated.
iFor safety reasons, the driver’s seat will
not return to its last set position with
the easy-entry/exit feature activated if
the system recognizes the last set posi-
tion as an extreme forward position.
Instead, the driver’s seat will remain at
or move to a factory-set maximum
forward position. To again fully return
the driver’s seat to your last set posi-
tion or to memory position, adjust the
seat to the desired position or press
and hold the respective memory
position switch (
page 120).
iAdjust the head restraint in such a way
that it is as close to the head as
possible.Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an
accident.

114 Controls in detailSeatsFront seat head restraints
1Head restraint switch
Switch on the ignition (
page 34).Removing front seat head restraints

Press switch1 upwards and hold until
the head restraint is fully extended.

Pull out head restraint.
Installing front seat head restraints:

Press switch1 upwards and hold for
about five seconds.

Push the head restraint down until it
engages.

Adjust head restraint to desired
position (
page 38).
Rear seat head restraints
iTilt the seat backrest to the rear for
easier removal and installation of the
head restraints.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the raised position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
lowering/raising operation of the head
restraints.

115 Controls in detailSeats
Raising rear head restraints
1Rear seat head restraint
Pull head restraint1 to its highest
position.Lowering rear head restraints
1Rear head restraint lowering switch

Switch on the ignition (
page 34).

Push the rear head restraints lowering
switch1.
The rear head restraints are lowered.
iThe rear head restraints cannot be low-
ered using the switch1 when the roll
bars have been released. The roll bars
need to be lowered before the rear
head restraints can be operated again
using switch1.

If the roll bars have released and
the soft top is closed, contact an
authorized Mercedes-Benz Center
to have the roll bars lowered. Do
not attempt to lower the roll bars
manually with the soft top closed.
Lowering the roll bars manually
with the soft top closed may impair
the function of the roll bars.


If the roll bars have released and
the soft top is open, you can lower
the roll bars manually (
page 402)
or contact an authorized
Mercedes-Benz Center to have the
roll bars lowered.

116 Controls in detailSeatsMulticontour seat*
The multicontour seat has a movable seat
cushion and inflatable air cushions built
into the backrest to provide additional
lumbar and side support.
The seat cushion movement, backrest
cushion height and curvature can be
continuously varied with switches on the
side of the seat after starting the engine.
1Seat cushion depth
2Backrest bottom
3Backrest center
4Side bolster adjustment

Start the engine.Seat cushion depth

Adjust the seat cushion depth to the
length of your upper leg using
switch1.
Backrest contour

Adjust the contour of the backrest to
the desired position using switches2
and3.
Backrest side bolsters

Adjust the backrest side bolsters so
that they provide good lateral support
using switch4.

117 Controls in detailSeats
Seat heating*
Both switches for the front seats are
located in the center console.
1Seat heating switchThe red indicator lamps on the switch1
show which heating level you have select-
ed.

Switch on the ignition (
page 34).
All the lamps in the instrument cluster
come on.Switching on seat heating

Press seat heating switch1 twice.
Three red indicator lamps in the switch
come on.

Continue pressing seat heating
switch1 until desired seat heating
level is reached.
Switching off seat heating

Press seat heating switch1
repeatedly until all red indicator lamps
go out.
Level3
Three indicator lamps on.
After approximately five minutes,
seat heating is automatically
switched to level 2.
2
Two indicator lamps on.
After approximately ten minutes,
seat heating is automatically
switched to level 1.
1
One indicator lamp on.
After approximately 20 minutes,
seat heating is automatically
switched off.
off
No indicator lamp on.
iIf one or all of the indicator lamps flash
on the seat heating switch1, there is
insufficient voltage due to too many
electrical consumers being switched
on. The seat heating switches off
automatically.
The seat heating will switch back on
again automatically as soon as
sufficient voltage is available.

118 Controls in detailSeatsSeat ventilation*
Both switches for the front seats are
located in the center console.
1Seat ventilation switchThe blue indicator lamps in the switch1
show which ventilation level you have
selected:

Switch on the ignition (
page 34).
All lamps in the instrument cluster
come on.
Switching on seat ventilation

Press seat ventilation switch1.
Three blue indicator lamps come on.

Press seat ventilation switch1
repeatedly until the desired seat venti-
lation level is reached.Switching off seat ventilation

Press seat ventilation switch1
repeatedly until all blue indicator lamps
go out.
Level3
Three indicator lamps on
2
Two indicator lamps on
1
One indicator lamp on
off
No indicator lamp on
iIf one or all of the indicator lamps flash
on the seat ventilation switch1, there
is insufficient voltage due to too many
electrical consumers being switched
on. The seat ventilation switches off
automatically.
The seat ventilation will switch back on
again automatically as soon as
sufficient voltage is available.

119 Controls in detail
Memory function
Memory function
You can store up to three different settings
per SmartKey or SmartKey with
KEYLESS-GO*.
The following settings are stored when
using the buttons on the driver’s door:

Driver’s seat, backrest and head
restraint position


Steering wheel position


Exterior rear view mirror position
These key-dependent memory settings
can be deactivated if desired. For informa-
tion on key-dependent memory settings,
see “Setting key-dependency”
(
page 157).The following settings are not
key-dependent. They are stored when
using the buttons on the passenger door:


Front passenger seat, backrest and
head restraint position
!Prior to operating the vehicle, the
driver should check and adjust the seat
height, seat position fore and aft, and
seat backrest angle if necessary, to
ensure adequate control, reach and
comfort. The head restraint should also
be adjusted for proper height. See also
the section on air bags (
page 61) for
proper seat positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, opera-
tion and comfort. Both the interior and
exterior rear view mirrors should be
adjusted for adequate rear vision.
Fasten seat belts. Infants and small
children should be seated in a properly
secured restraint system that complies
with U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and Canadian
Motor Vehicle Safety Standards 213
and 210.2.
Warning!
G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.
