150 Controls in detailControl system
Press buttonj ork repeatedly
until the message
Set date month

appears in the multifunction display.
The selection marker is on the month
setting.

Press buttonæ orç to set the
month.Setting the date (day)
This function can only be seen in vehicles
with audio system.

Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Set date day

appears in the multifunction display.
The selection marker is on the day
setting.

Press buttonæ orç to set the
day.
iVehicles with COMAND*:
For information on setting the date in
COMAND, refer to the separate
COMAND operating instructions.


151 Controls in detail
Control system
Setting the date (year)
This function can only be seen in vehicles
with audio system.
Move the selection marker with
buttonæ orç to the
Time/Date

submenu.

Press buttonj ork repeatedly
until the message
Set date year

appears in the multifunction display.
The selection marker is on the year
setting.

Press buttonæ orç to set the
year.Lighting submenu
Access the
Lighting
submenu via the
Set-
tings
menu. Use the
Lighting
submenu
to change the lamp and lighting settings on
your vehicle.
The following functions are available:
iVehicles with COMAND*:
For information on setting the date in
COMAND, refer to the separate
COMAND operating instructions.
Function
Page
Setting daytime running lamp
mode (USA only)
152
Setting locator lighting
153
Exterior lamps delayed
switch-off
153
Interior lighting delayed
switch-off
154

152 Controls in detailControl systemSetting daytime running lamp mode
(USA only)
Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until the message
Lamp circuit
headlamp
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to select
manual operation (
manual
) or daytime
running lamp mode (
constant
) activat-
ed.
With daytime running lamp mode activated
and the exterior lamp switch in
positionM or U the low beam
headlamps are switched on when the
engine is running.
In low ambient light conditions the
following lamps will switch on additionally:


Parking lamps


Tail lamps


License plate lamps


Side marker lampsFor more information on the daytime run-
ning lamp mode, see “Lighting”
(
page 122).
iThis function is not available in
countries where the daytime running
lamp mode is mandatory and therefore
in a constant mode.
iIf you turn the exterior lamp switch to
another position, the corresponding
lamp(s) will switch on.
For safety reasons, resetting the Lighting
submenu to factory settings
(
page 143) while driving will not
deactivate the daytime running lamp
mode.
The following message appears in the
multifunction display:
Lighting – Cannot be completely
reset to factory settings while
driving
.

153 Controls in detail
Control system
Setting locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on when the vehicle is unlocked
with the SmartKey during darkness:

Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
with the SmartKey the lamps will switch off
automatically after approximately
40 seconds.
To activate locator lighting:

Make sure the function surround light-
ing is set to
on, see (
page 153).

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Function Surround
lighting
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the locator lighting function
On.

Turn the exterior lamp switch to
position U when exiting the vehicle
(page 122).
The locator lighting feature is
activated.Setting night security illumination
(Headlamps delayed shut-off)
Use this function to set whether and how
long you would like the exterior lamps to
illuminate during darkness after exiting the
vehicle and all doors closed.
With the delayed shut-off feature activated
and the exterior lamp switch in
positionU before the engine is turned
off, the following lamps will switch on after
you have removed the SmartKey from the
starter switch:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps
If you do not open a door after removing
the SmartKey from the starter switch, the
lamps will switch off automatically after
approximately 60 seconds.

154 Controls in detailControl system
Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Headlamps delayed
shut-off
appears in the multifunction
display.
The selection marker is on the current
setting.

Pressæ orç to select the de-
sired lamp-on period.You can select:


0 s
, the delayed shut-off feature is
deactivated


15 s
, 30 s
, 45 s
or
60 s
, the delayed
shut-off feature is activated

Turn the exterior lamp switch to
position U before tuning off the
engine (
page 122).
The headlamps delayed shut-off
feature is activated.
You can temporarily deactivate the de-
layed shut-off feature:

Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.

Then turn it to position2 and back
to0.
The delayed shut-off feature is
deactivated. It will reactivate as soon
as you reinsert the SmartKey in the
starter switch.Setting interior lighting delayed shut-off
Use this function to set whether and how
long you would like the interior lighting to
remain lit during darkness after you have
removed the SmartKey from the starter
switch.

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Interior lamp de-
layed shut-off appears in the
multifunction display.
The selection marker is on the current
setting.
iYou can reactivate this function within
ten minutes by opening a door.

155 Controls in detail
Control system

Pressæ orç to select the de-
sired lamp-on time period.
You can select:

0 s
, the delayed shut-off feature is
deactivated.


5 s
, 10 s
, 15 s
or
20 s
, the interior
lighting delayed shut-off feature is
activated with the desired lamp-on
period.Vehicle submenu
Access the
Vehicle
submenu via the
Settings
menu. Use the
Vehicle
submenu
to make general vehicle settings.
The following function is available:Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the
automatic central locking system
activated, the vehicle is centrally locked at
vehicle speeds of approximately 9 mph
(15 km/h).

Move the selection marker with
buttonæ orç to the
Vehicle

submenu.

Press buttonj ork repeatedly
until the message
Automatic door
lock
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the automatic central locking
on or
off
.
Function
Page
Setting automatic locking
155

156 Controls in detailControl systemConvenience submenu
Access the
Convenience
submenu via the
Settings
menu. Use the
Convenience
sub-
menu to change the settings for a number
of convenience features.
The following functions are available:Activating easy-entry/exit feature
Use this function to activate and deacti-
vate the easy-entry/exit feature.

Move the selection marker with
buttonæ orç to the Convenience
submenu.

Press buttonj ork repeatedly
until the message
Function
Easy-entry feature appears in the
multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to change
the easy-entry/exit setting.
Function
Page
Activating easy-entry/exit
feature
156
Setting key-dependency
157
Setting parking position for exte-
rior rear view mirror
157
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and the driver’s seat when the
easy-entry/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:

Press the seat adjustment switch
(page 38).


Move the steering column stalk
(page 40).


Press the memory position switch
(page 120).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

157 Controls in detail
Control system
The following settings are available for the
easy-entry/exit feature:
Setting key-dependency
Use this function to set whether the
memory settings for the seats, the steering
wheel and the mirrors should be stored
separately for each SmartKey
(page 119).

Move the selection marker with
buttonæ orç to the Convenience
submenu.

Press buttonj ork repeatedly
until the message
Key-dependent

appears in the multifunction display.The selection marker is on the current
setting.

Press buttonæ orç to set
key-dependency to
on or
off
.
Setting parking position for exterior rear
view mirror
Use the
Mirror adjustment parking aid

function to select whether the passen-
ger-side exterior rear view mirror should be
turned downward during parking maneu-
vers, when reverse gear R is engaged. For
additional information, see “Activating ex-
terior rear view mirror parking position”
(
page 177).

Move the selection marker with
buttonæ orç to the Convenience
submenu.

Press buttonj ork repeatedly
until the message
Mirror adjustment
parking aid
appears in the
multifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
function
on or
off
.
off
The easy-entry/exit
feature is
deactivated.
Steering col.
Only the steering
column is moved.
Steer. col. + seat
Both the steering
column and the
seat are moved.

158 Controls in detailControl systemTrip computer menu
Use the trip computer menu to call up sta-
tistical data on your vehicle.
The following information is available:Fuel consumption statistics after start

Press buttonÿ orè repeatedly
until the first function of the Trip com-
puter menu appears in the multifunc-
tion display.

Press buttonj ork repeatedly
until the message
After start
appears
in the multifunction display.
1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since start
Function
Page
Fuel consumption statistics after
start
158
Fuel consumption statistics
since last reset
159
Call up range (distance to empty)
159
iAll statistics stored since the last
engine start will be reset approximately
four hours after the SmartKey in the
starter switch is turned to position0 or
removed from the starter switch.
Resetting will not occur if you turn the
SmartKey back to position1 or2
within this time period.

159 Controls in detail
Control system
Fuel consumption since last reset
Press buttonÿ orè repeatedly
until the first function of the Trip com-
puter menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the message
After reset
appears
in the multifunction display.
1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last re-
setResetting fuel consumption statistics

Press buttonÿ orè repeatedly
until the first function of the Trip com-
puter menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the reading that you want to reset
appears in the multifunction display.

Press and hold the reset button in the
instrument cluster (
page 130) until
the value is reset to 0.Call up range (distance to empty)

Press buttonÿ orè repeatedly
until the first function of the Trip com-
puter menu appears in the
multifunction display.

Press buttonj ork repeatedly
until the message
Range
appears in the
multifunction display.
The calculated range based on the
current fuel tank level appears in the
multifunction display.
