MERCEDES-BENZ CLK55AMG COUPE 2004 C209 Owner's Manual

341 Practical hints
Where will I find...?
In the case of a flat tire, you may tempo-
rarily use the Minispare wheel when ob-
serving the following restrictions:

Do not exceed a vehicle speed of
50 mph (80 km/h).


Drive to the nearest tire repair facility
to have the flat tire repaired or re-
placed as appropriate.


Do not operate vehicle with more than
one Minispare wheel mounted.
More information can be found in the
“Technical data” section (
page 381).
iThe arrow 2 on vehicle tool kit storage
well casing 4 must point in the direc-
tion of travel, otherwise you cannot
place the storage well casing
(page 337) on top and secure the
Minispare wheel with the retaining
screw (
page 337).
!To prevent damage, always disengage
trunk floor handle from upper edge of
trunk and lower trunk floor before clos-
ing the trunk lid.
Warning!
G
The dimensions of the Minispare wheel are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a Minispare wheel
mounted.
The Minispare wheel should only be used
temporarily, and should be replaced with a
regular road wheel as quickly as possible.

342 Practical hintsWhere will I find...?Minispare wheel bolts
1Wheel bolt for light alloy rims
2Wheel bolt for Minispare wheel or other
steel rims (located in trunk with spare
wheel)
!Wheel bolts2 must be used when
mounting the Minispare wheel. The use
of any wheel bolts other than wheel
bolts 2 for the Minispare will physical-
ly damage the vehicle's brakes.Warning!
G
Be sure to use the original length wheel
bolts when remounting the original wheel af-
ter it has been repaired.

343 Practical hints
Unlocking/locking in an emergency
Unlocking/locking in an emergency
Unlocking the vehicle
If you are unable to unlock the vehicle with
the SmartKey or KEYLESS-GO*, open the
driver’s door and the trunk using the me-
chanical key.
1Mechanical key locking tab
2Mechanical key

Move locking tab1 in direction of ar-
row and slide the mechanical key2
out of the housing.Unlocking the driver’s door
1Unlocking
2Locking

Unlock the door with the mechanical
key. To do so, push the mechanical key
in the lock until it stops and turn it to
the left.
iUnlocking your vehicle with the me-
chanical key will trigger the anti-theft
alarm system. To cancel the alarm, do
one of the following:

Press button Œ or ‹ on the
SmartKey.


Insert the SmartKey in the starter
switch.
Vehicles with KEYLESS-GO*


Pull the outside door handle.


Press the KEYLESS-GO* start/stop
button (
page 33).

344 Practical hintsUnlocking/locking in an emergencyUnlocking the trunk
A minimum height clearance of 5.41 ft
(1.65 m) is required to open the trunk lid.
The lock is located next to the recessed
handle.
1Unlocking in an emergency
2Handle

Insert the mechanical key into the
trunk lid lock.

Turn the mechanical key counterclock-
wise to position1 and hold it in this
position.

Pull the trunk lid handle2 and lift the
trunk lid.
Locking the vehicle
If you are unable to lock the vehicle with
the SmartKey, lock it with the mechanical
key as follows:
Close the passenger door and the trunk
lid.

Press the central locking switch in the
cockpit (
page 106).

Check to see whether the locking knob
on the passenger door is down. If nec-
essary push it down manually.

Lock the driver’s door with the me-
chanical key.

Lock the trunk lid if necessary with the
mechanical key (
page 104).
! Always make sure there is sufficient
overhead clearance.

345 Practical hints
Unlocking/locking in an emergency
Changing batteries in the SmartKey/ SmartKey with KEYLESS-GO*
If the batteries in the SmartKey or the
SmartKey with KEYLESS-GO* are dis-
charged, the vehicle can no longer be
locked or unlocked. It is recommended to
have the batteries replaced at an autho-
rized Mercedes-Benz Center.
Batteries contain materials that can harm
the environment if disposed of improperly.
Recycling of batteries is the preferred
method of disposal. Many states require
sellers of batteries to accept old batteries
for recycling.SmartKey
1Mechanical key
2Battery compartment
Replacement batteries: Lithium, type
CR 2025 or equivalent.

Remove mechanical key1
(page 343).

Insert the mechanical key in side open-
ing and push gray slide.
The battery compartment is unlatched.

Pull the battery compartment out of the
SmartKey housing in direction of ar-
row.

Remove the batteries.
Warning!
G
Keep the batteries out of reach of children.
If a battery is swallowed, seek medical help
immediately.
iWhen changing batteries, always re-
place both batteries.
The required replacement batteries are
available at any Mercedes-Benz
Center.


346 Practical hintsUnlocking/locking in an emergency3Battery
4Contact spring
Using a lint-free cloth, insert new bat-
teries under the contact spring with the
plus (+) side facing up.

Return battery compartment into hous-
ing until it locks into place.SmartKey with KEYLESS-GO*
1Battery
2Tilt battery up
3Mechanical key
Replacement batteries: Lithium, type
CR 2025 or equivalent.

Remove mechanical key (
page 343).

Insert the mechanical key in side open-
ing and push grey slide.
The battery compartment is unlatched.

Pull the battery compartment out of the
SmartKey housing in direction of ar-
row.

Using mechanical key3 apply pres-
sure to position2.
Battery1 tilts up slightly.

Pull out batteries1 in direction of ar-
row.

Using a lint-free cloth, insert new bat-
teries with the plus (+) side facing up.

Return battery compartment into hous-
ing until it locks into place.
iWhen changing batteries, always re-
place both batteries.
The required replacement batteries are
available at any Mercedes-Benz
Center.


347 Practical hints
Unlocking/locking in an emergency
Fuel filler flap
In case the central locking system does
not release the fuel filler flap, you can open
it manually.
Open trunk lid.

Remove right side trim panel in the
trunk.

Reach inside through opening2 in di-
rection of arrow.

Turn release knob 1 clockwise (ar-
row).
The fuel filler flap can be opened.Manually unlocking the gear selector
lever
In case of power failure, the gear selector
lever can be manually unlocked, e.g. to tow
the vehicle.
Open the storage compartment under
the center armrest (
page 246).

Take out cover 1.

Insert a pin into the opening of
division2 and pry the division out.

Insert a tool3 (e.g. screwdriver) into
the opening.

Perform the following two steps simul-
taneously:
Push pin3 forward in the direction
of the arrow.

Move gear selector lever from
positionP.

Reinstall the division and cover after re-
moving the tool from the opening.iThe gear selector lever is locked again
when moving it to positionP.

348 Practical hintsOpening/closing in an emergency
Opening/closing in an emergencySliding/pop-up roof*
You can open or close the sliding/pop-up
roof manually should an electrical malfunc-
tion occur.
The sliding/pop-up roof drive is located
behind the lens of the interior overhead
light.

Pry off lens1 using a flat blade screw-
driver.

Slide both locking tabs2 in direction
of arrow.

Lower rear of cover and remove.

Remove cover.iDo not disconnect electrical connec-
tors.

349 Practical hints
Opening/closing in an emergency

Obtain crank3.

Insert crank3 through hole.

Turn crank3 clockwise to:

slide roof closed


raise roof at the rear

Turn crank3 counterclockwise to:

slide roof open


lower roof at the rear
The sliding/pop-up must be resynchro-
nized after being operated manually
(
page 349).Synchronizing the sliding/pop-up roof

Take the fuse for the sliding/pop-up
roof out of the main fuse box
(page 372).

Reinsert the fuse.

Switch on the ignition.

Press the switch in the “raise” direction
until the sliding/pop-up roof is fully
raised at the rear.
Hold the switch for approximately one
second.
The sliding/pop-up roof is adjusted.

350 Practical hintsReplacing bulbs
Replacing bulbsSafe vehicle operation depends on proper
exterior lighting and signaling. It is there-
fore essential that all bulbs and lamp as-
semblies are in good working order at all
times.
Correct headlamp adjustment is extremely
important. Have headlamps checked and
readjusted at regular intervals and when a
bulb has been replaced. See your autho-
rized Mercedes-Benz Center for headlamp
adjustment.
Bulbs
iIf the headlamps are fogged up on the
inside as a result of high humidity, driv-
ing the vehicle a distance should clear
up the fogging.
iBackup bulbs will be brought into use
when the following lamps malfunction:

Turn signal lamps


Brake lamps


Parking lamps


Tail lamps
