Page 111 of 521
110 Controls in detailLocking and unlocking
Checking the batteries
Press button‹ orŒ.
Battery check lamp5 (
page 106)
comes on briefly to indicate that the
SmartKey batteries are in order.Unlocking and opening the tailgate
You can unlock and open the tailgate sep-
arately.
A minimum height clearance of 6.76 ft
(2.06 m) is required to open the tailgate.
Press and hold button Š until tail-
gate unlocks and begins to open.
!If you can no longer lock or unlock the
vehicle with the SmartKey, then either
the batteries in the SmartKey are dis-
charged, the SmartKey is malfunction-
ing or the vehicle battery is drained.
Check the batteries in the
SmartKey (
page 117) and re-
place them if necessary
(
page 429).
Use the mechanical key to unlock
the driver’s door (
page 424).
Use the mechanical key to lock the
driver’s door (
page 425).
Have the vehicle battery and the
battery connections checked.
If the SmartKey is malfunctioning, con-
tact an authorized Mercedes-Benz
Center.
iIf battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 429).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing the
button‹ orŒ will lock or unlock
the vehicle accordingly.
!The tailgate swings open upwards auto-
matically. Always make sure there is
sufficient overhead clearance.
Vehicles with tailgate opening/closing
system*: To stop the opening proce-
dure, press buttonŠ on the
SmartKey. The tailgate stops moving.iIf the vehicle was previously centrally
locked, the tailgate will lock automati-
cally when closed.
To confirm locking all turn signal lamps
flash three times.
Page 112 of 521
111 Controls in detail
Locking and unlocking
Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:
Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.
Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.
If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key. The locking tabs for the
mechanical key portion of the two Smart-
Keys with KEYLESS-GO are a different col-
or to help distinguish each SmartKey with
KEYLESS-GO unit.
The function of the SmartKey overrules the
KEYLESS-GO function.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you pull an outside
door handle.
If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks
the doors
the tailgate
the fuel filler flap
SmartKey with KEYLESS-GO1‹ Lock button
2Š Unlock button* for the tailgate
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 90)
iWhen any outside door handle other
than the driver’s outside door handle is
pulled, the vehicle is centrally un-
locked.
Page 113 of 521
112 Controls in detailLocking and unlockingWarning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. It is possible for children
to open a locked door from the inside, which
could result in an accident and/or serious
personal injury.!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.
iUSA only:
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any
interference received, including
interference that may cause
undesired operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
iCanada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions:
(1) This device may not cause
interference, and
(2) this device must accept any
interference received, including
interference that may cause
undesired operation of the device.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
Page 114 of 521
113 Controls in detail
Locking and unlocking
Important notes on using KEYLESS-GO
You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 106).
You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with button ‹).
Always carry the SmartKey with
KEYLESS-GO with you.
Never store the SmartKey with
KEYLESS-GO together with:
Electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO
Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.
To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within ap-
proximately 3 ft (1 m) of a door or the
tailgate.
In order to start the engine with the
SmartKey with KEYLESS-GO:
The SmartKey with KEYLESS-GO
must be located in the vehicle.
All the doors must be closed.
The brake pedal must be firmly de-
pressed. Do not depress the accel-
erator.
If you have started the engine with the
KEYLESS-GO start/stop button
(page 38), you can only turn it off
again with this button, even if you have
put the SmartKey in the starter switch
in the meantime.
This does not apply if, after starting, the
selector lever is still in positionP and
then the SmartKey is inserted in the
starter switch. The SmartKey will then
have priority over the KEYLESS-GO
function and the vehicle’s electrical
system will operate according to the
position of the SmartKey in the starter
switch, even stopping the engine.
If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle cannot be locked or the en-
gine started via the KEYLESS-GO sys-
tem.
iYou can also open and close the power
windows and tilt/sliding sunroof* us-
ing the SmartKey (
page 234).
iWhen you unlock the vehicle, the elec-
trohydraulic brake system is activated
(page 96).
Page 115 of 521
114 Controls in detailLocking and unlocking
If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while the igni-
tion is switched on (e.g. if passenger
exits the vehicle with the SmartKey
with KEYLESS-GO), the message
Key
not recognized
will appear in the mul-
tifunction display while driving off.
Find the SmartKey or change its
present location immediately (e.g.
place it on the front passenger seat or
insert it in shirt pocket).
Remember that the engine can be
started by anyone with a SmartKey
wi th KEY LES S-GO tha t i s le ft ins id e t he
vehicle. If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, the message
Key
still in vehicle
will appear in the
multifunction display.Factory settingGlobal unlocking
Pull an outside door handle.
All turn signal lamps flash once.
An acoustic signal sounds once (if
equipped and feature activated).
The locking knobs in the doors
move up.
The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and reactivate the anti-theft alarm system
within approximately 40 seconds if:
neither a door nor the tailgate is
opened
the central locking switch is not acti-
vated
iYour vehicle may be equipped with an
acoustic lock and unlock confirmation
signal feature. If your vehicle is
equipped with this feature and the fea-
ture is activated, an acoustic signal will
sound when the vehicle is locked or un-
locked using the SmartKey with
KEYLESS-GO.
To determine whether or not your vehi-
cle is equipped with this feature,
contact an authorized Mercedes-Benz
Center. If equipped and you wish to ac-
tivate or deactivate the feature, or ad-
just its signal volume, also contact an
authorized Mercedes-Benz Center.
Page 116 of 521
115 Controls in detail
Locking and unlocking
Global locking
Press lock button on an outside door
handle (
page 63) or tailgate
(
page 118).
All turn signal lamps flash three
times.
An acoustic signal sounds three
times (if equipped and feature acti-
vated).
The locking knobs in the doors
move down.
The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you pull the driver’s
outside door handle, only the driver’s door
and the fuel filler flap unlocks.
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 111)
flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:Unlocking driver’s door and fuel filler
flap
Pull the driver’s outside door handle.
All turn signal lamps flash once.
An acoustic signal sounds once (if
equipped and feature activated).
For more information, see “Factory
setting” (
page 114).
The locking knob in the driver’s
door moves up.
The anti-theft alarm system is dis-
armed.
Page 117 of 521
116 Controls in detailLocking and unlockingGlobal unlocking
Pull any outside door handle other than
the driver’s outside door handle.
All turn signal lamps flash once.
An acoustic signal sounds once
(if equipped and feature activated).
The locking knobs in the doors
move up.
The anti-theft alarm system is dis-
armed.Global locking
Press lock button on an outside door
handle (
page 63) or tailgate
(
page 118).
All turn signal lamps flash three
times.
An acoustic signal sounds three
times (if equipped and feature acti-
vated).
The locking knobs in the doors
move down.
The anti-theft alarm system is
armed.
Restoring to factory setting
Press and hold buttonsŒ and‹
simultaneously for about 6 seconds un-
til battery check lamp5 (
page 111)
flashes twice.
!If you can no longer lock or unlock the
vehicle with the SmartKey with
KEYLESS-GO, then the batteries in the
SmartKey are discharged, the
SmartKey with KEYLESS-GO is mal-
functioning or the vehicle battery is
drained.
Check the batteries in the
SmartKey with KEYLESS-GO
(page 117) and replace them if
necessary (
page 429).
Use the mechanical key to unlock
the driver’s door (
page 424).
Use the mechanical key to lock the
driver’s door (
page 425).
Have the vehicle battery checked
by an authorized Mercedes-Benz
Center.
If the SmartKey with KEYLESS-GO is
malfunctioning, contact an authorized
Mercedes-Benz Center.
Page 118 of 521
117 Controls in detail
Locking and unlocking
Checking the batteries
Press button‹ orŒ.
Battery check lamp5 (
page 111)
comes on briefly to indicate that the
SmartKey batteries are in order.Unlocking and opening the tailgate
You can unlock and open the tailgate sep-
arately.
A minimum height clearance of 6.76 ft
(2.06 m) is required to open the tailgate.
The handle is located in the rear license
plate recess.
Pull on the handle.
or
Press and hold buttonŠ until the
tailgate unlocks and opens.
!If battery check lamp5 does not
come on briefly during check, then the
SmartKey batteries are discharged.
Replace the batteries (
page 429).
You can obtain the required batteries
at any authorized Mercedes-Benz
Center.
iIf the batteries are checked within sig-
nal range of the vehicle, pressing the
button‹ orŒ will lock or unlock
the vehicle accordingly.
!The tailgate swings open upwards auto-
matically. Always make sure there is
sufficient overhead clearance.
Vehicles with tailgate opening/closing
system*: to stop the opening proce-
dure, press buttonŠ on the
SmartKey. The tailgate stops moving.iIf the vehicle was previously centrally
locked, the tailgate will lock automati-
cally when closed (
page 122).
To confirm locking all turn signal lamps
flash three times.
Page 119 of 521
118 Controls in detailLocking and unlockingGlobal locking using the lock button on
the tailgate
1Lock button
Press lock button1 on the tailgate.
All turn signal lamps flash three times.
An acoustic signal sounds three times
(if equipped and feature activated).
For more information, see “Factory set-
ting” (
page 114).
The locking knobs in the doors move
down.
The anti-theft alarm system is armed.Loss of the SmartKey with KEYLESS-GO
If you lose your SmartKey with
KEYLESS-GO, you should do the following:
Have the SmartKey with KEYLESS-GO
deactivated by an authorized
Mercedes-Benz Center.
Report the loss immediately to your car
insurance company.
Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
iTo prevent a possible inadvertent lock-
out, the tailgate will open automatically
if a SmartKey with KEYLESS-GO is
recognized inside the vehicle.iIf the vehicle was previously centrally
locked with KEYLESS-GO, the tailgate
will lock automatically after closing it.
To confirm locking all turn signal lamps
flash three times.iYou can also lock the vehicle using the
lock button on an outside door handle
(page 63) or KEYLESS-GO locking/
closing switch (
page 126).
Page 120 of 521
119 Controls in detail
Locking and unlocking
Opening the doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Locking knob
2Inside door handle
Front doors
Pull on door handle2 on the
respective front door to open door.
If door was locked, locking knob1 will
move up.Rear doors
Pull up locking knob1 on the
respective rear door to unlock door.
Pull on door handle2 on the
respective rear door to open door.iIf the vehicle has previously been
locked with the SmartKey or
KEYLESS-GO*, opening a door from the
inside will trigger the anti-theft alarm
system.
To cancel the alarm, do one of the fol-
lowing:
Press button Œ or ‹ on the
SmartKey.
Insert the SmartKey in the starter
switch.
In vehicles with KEYLESS-GO*:
Press the KEYLESS-GO* start/stop
button (
page 38).
The SmartKey with KEYLESS-GO
must be inside the vehicle.
Pull an outside door handle.
The SmartKey with KEYLESS-GO
must be within 3 ft (1 m) of the ve-
hicle.
