MERCEDES-BENZ E WAGON 2006 S211 Owner's Manual

130 Controls in detailSeatsFolding head restraints back with switch
in the center console
1Head restraint release switch
Switch on the ignition (
page 36).

Press the symbol-side on switch1 to
release the head restraints.
The head restraints will fold backward.Folding head restraints back manually
(rear outer seats only)
1Release button

Push release button1 and fold the
head restraints backward.Placing head restraints upright

Pull the head restraint forward until it
locks into position.!Make sure the head restraints engage
when placing them upright. Otherwise
their protective function cannot be as-
sured.

131 Controls in detailSeats
Head restraint height
(rear outer seats only)
1Release button
Raising:
Manually adjust the height of the head
restraint by pulling it upward.
If the head restraint is fully retracted,
push release button1 and pull the
head restraint out.Lowering:

To lower the head restraint, push
release button1 and push down on
the head restraint.Head restraint tilt
(rear outer seats only)
Two different head restraint angle
positions are available.
1Release button

Press the release button1 and tilt the
head restraint to the desired position.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the head
restraint supports the back of the head at
eye level. This will reduce the potential for
injury to the head and neck in the event of
an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are
intended to help reduce injuries during an
accident.

132 Controls in detailSeatsRemoving and installing rear seat head
restraints
1Release button
Removing rear seat head restraints

Fold back head restraint (
page 129).

Pull head restraint to its highest
position.

Push release button1 and pull out
head restraint.Installing rear seat head restraints

Insert head restraint and push it down
until it engages.

Push button1 and adjust head
restraint to desired position.
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the head re-
straint supports the back of the head at eye
level. This will reduce the potential for injury
to the head and neck in the event of an ac-
cident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.
!When installing the head restraints,
make sure that:

The proper head restraint for each
seat is installed. The bars of the
head restraint designed for the mid-
dle rear seat are of even length and
shorter than those designed for use
on the outer rear seats.


The head restraints engage fully.

133 Controls in detailSeats
Lumbar support
The curvature of the driver’s seat can be
adjusted to help enhance lower back sup-
port and seating comfort.
1Adjustment lever
Move adjustment lever1 in direction
of the arrows until you have reached a
comfortable seating position.Drive - Dynamic seat* with multicon-
tour features
The Drive - Dynamic seat automatically ad-
justs the lateral support provided by the
backrest to your driving style.
The Drive - Dynamic seat electronically
controls the air pressure in the air cham-
bers of the backrest side bolsters. This
function improves driving comfort and
pleasure.
In addition, the Drive-Dynamic seat has a
movable seat cushion and inflatable air
cushions built into the backrest to provide
additional lumbar and side support.
The seat cushion movement, backrest
cushion height and curvature can be con-
tinuously varied with switches on the right
side of the seat on the driver side, or the
left side of the seat on the passenger side
after turning the SmartKey in the starter
switch to position2 or pressing the KEY-
LESS-GO* start/stop button twice.1Backrest center
2Backrest bottom
3Seat cushion depth
4Activate drive dynamic function
5Backrest side bolsters
6Massage function

Switch on the ignition (
page 36).

134 Controls in detailSeatsMulticontour features
Seat cushion depth
Adjust the seat cushion depth to the
length of your upper leg using
switch3.
Backrest contour

Move the backrest support to the bot-
tom by using button2 or to the center
by using button1.

Adjust the contour of the backrest to
the desired position using æ or
ç.
Backrest side bolsters

Adjust the side bolsters so that they
provide good lateral support using
switch5.Drive-dynamic features
Activating

Press button4 (
page 133).
The indicator lamp on the button
comes on and the following display ap-
pears in the multifunction display for
about 5 seconds.
Deactivating

Press button4 (
page 133) again.
The indicator lamp on the button goes
out.Massage function (PULSE)
The massage function can help prevent
muscle tension during long drives.

Press button6 (
page 133).
The indicator lamp on the button
comes on. The air cushions in the lum-
bar area pulsate.
iYou can adjust the characteristics of
the Drive - Dynamic seat using the con-
trol system (
page 179).
iWhen the engine is turned off, the last
cushion setting is retained in memory.
The cushion is automatically adjusted
to this setting when the engine is re-
started.iThe massage function turns off auto-
matically after approximately
5minutes.

135 Controls in detailSeats
Seat heating*
Both switches for the front seats are locat-
ed in the center console. The red indicator
lamps in the switch come on to show
which heating level you have selected.
1Seat heating switch

Switch on the ignition (
page 36).
Switching seat heating on

Press switch1 repeatedly until the
desired heating level is set.
One or more red indicator lamps on the
switch show the selected heating level.Switching seat heating off

Press switch1 repeatedly until all in-
dicator lamps go out.
Level3
Three indicator lamps on
(highest level)
The seat heating automatically
switches to level2 after approxi-
mately 5 minutes.
2
Two indicator lamps on
The seat heating automatically
switches to level1 after approxi-
mately 10 minutes.
1
One indicator lamp on
(lowest level)
The seat heating automatically
switches off after approximately
20 minutes.
off
No indicator lamp on
iIf one or more of the lamps on the seat
heating switch are flashing, there is in-
sufficient voltage available since too
many electrical consumers are turned
on. The seat heating switches off auto-
matically.
The seat heating will switch back on
again automatically as soon as suffi-
cient voltage is available.

136 Controls in detailSeatsSeat ventilation*
The switch is located on the center con-
sole. Seat ventilation can be activated
manually with the ignition on, or by the
summer opening feature (
page 234).
The blue indicator lamps on the switch
show the ventilation level selected:
1Seat ventilation switch

Switch on the ignition (
page 36).
Switching seat ventilation on

Press button1 repeatedly until the
desired ventilation level is set.Switching seat ventilation off

Press button1 repeatedly until all in-
dicator lamps go out.
Level3
Three indicator lamps on
(highest level)
2
Two indicator lamps on
1
One indicator lamp on
(lowest level)
off
No indicator lamp on
iThe seat ventilation is automatically set
to the highest level if activated via sum-
mer opening feature (
page 234).
iIf one or more of the lamps on the seat
ventilation switch are flashing, there is
insufficient voltage available since too
many electrical consumers are turned
on. The seat ventilation switches off au-
tomatically.
The seat ventilation will switch back on
again automatically as soon as suffi-
cient voltage is available.

137 Controls in detailSeats
Folding bench seat in cargo compart-mentFolding out the folding bench seat
1Release handle for seat backrest
2Release handle for seat cushion
Before folding out the seat backrest, you
must:


fold the rear seat backrests into an up-
right position and lock them into place


move the handle for the twin roller
blind into the upper position
iThe folding bench seat in the cargo
compartment is approved only for per-
sons up to a height of 4.6 ft (1.40 m)
and a maximum weight of 110 lbs
(50 kg).
The twin roller blind must be installed
when the folding bench seat is in use.Warning!
G
When using the folding bench seat in the
cargo compartment, the seats in front of it
must be in the driving position.
Only drive when the head restraints for the
folding bench seat have been properly ad-
justed. The head restraints should be adjust-
e d so t ha t th e ba c k of th e h ea d is s uppo r te d
at approximately eye level. This can reduce
a child’s risk of injury in the event of an ac-
cident.
Warning!
G
Make sure that the seat belt is positioned
correctly on the body and is engaged in the
seat belt buckle.
Damaged covers should be replaced with
original covers only.
Do not leave children unattended in the ve-
hicle, even when they are secured in a child
restraint system.
Make sure that luggage and other objects
are adequately secured. The load could oth-
erwise injure someone in the event of an ac-
cident, during hard braking or steering
maneuvers.
iThe rear seat backrests can be adjust-
ed to a more reclined position to make
the folding bench seat more comfort-
able (
page 262).

138 Controls in detailSeats
Pull release handle 1 and fold seat
backrest for the folding bench seat up-
ward.
3Mountings for seat belts

Hook seat belts into mountings 3.

Pull release handle 2 and fold seat
cushion for the folding bench seat into
sitting position.

Press seat cushion as far down as it will
go.
The backrest will then also engage
properly.

Fold head restraints into upright posi-
tion.Removing and installing seat cushions
Removing
1Seat guides
2Seat cushion

Fold seat cushion 2 upward and re-
move it from seat guides 1.Installing

Insert seat cushion 2 into seat guides
1 from behind 3 at a slight angle.

Fold seat cushion 2 back into original
position 4 until it engages.
iYou must remove the seat cushion
when you want to raise the loading
floor, e.g. in the event of a flat tire.

139 Controls in detailSeats
Folding back folding bench seat
1Tab
2Backrest
Pull seat cushion upward using tab 1
and fold it back into original position
until it engages.1Release knob

Press release knob 1 and fold head
restraints down.1Release catch

Press release catch 1 and push head
restraints as far in as they will go.

Fold seat backrest of folding bench
seat back into original position until it
engages.
!To avoid damage, insert the head re-
straints completely into their guides
and engage the seat belt buckles in
their guides.
