469 Technical data
Fuels, coolants, lubricants etc.
Windshield and headlamp washer system
Both the windshield and headlamp washer
systems are supplied from the windshield
washer fluid reservoir.
The washer fluid reservoir has a capacity of
approximately:

7.4 US qt. (7.0 l) in vehicles with a
headlamp cleaning system* or heated
reservoir


4.8 US qt. (4.5 l) in vehicles without a
headlamp cleaning system

Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer sol-
vent/antifreeze, depending on ambient
temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above “freezing point”,
use MB Windshield Washer Concentrate
“S” and water:


1 part “S” to 100 parts water
(1.34 floz [40 ml] “S” to 1 gallon [4.0 l] wa-
ter).
For temperatures below “freezing point”
use MB Windshield Washer Concentrate
“S” and commercially available premixed
windshield washer solvent/antifreeze:


1 part “S” to 100 parts solvent
(1.34 floz [40 ml “S” to 1 gallon [4.0 l] sol-
vent).
Warning
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You can be seriously burned.

470

471 Technical terms
ABS
(A
ntilock B
rake S
ystem)
Prevents the wheels from locking up
during braking so that the vehicle can
continue to be steered.
ADS
(A
daptive D
amping S
ystem)
Automatically adapts the optimum sus-
pension damping to prevailing driving
conditions.
Airmatic DC
(A
irmatic D
ual C
ontrol)
Automatically selects the optimum sus-
pension tuning and ride height for your
vehicle. Airmatic consists of two com-
ponents:


Adaptive Damping System


Vehicle level control
Alignment bolt
Metal pin with thread. The centering
pin is an aid used when changing a tire
to align the wheel with the wheel hub.BAS
(B
rake A
ssist S
ystem)
System for potentially reducing braking
distances in emergency braking situa-
tions. The system is activated when it
senses an emergency based on how
fast the brake is applied.
Bi-Xenon headlamps*
Headlamps which use an electric arc as
a light source and produce a more in-
tense light than filament headlamps.
Bi-Xenon headlamps produce low
beam and high beam.
CAC
(C
ustomer A
ssistance C
enter)
Mercedes-Benz customer service cen-
ter which can help you with any ques-
tions about your vehicle and provide
assistance in the event of a break-
down.CAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control ve-
hicle functions such as door locking or
windshield wiping.
CDI
(C
ommon-Rail D
irect I
njection)
Diesel fuel injection technology where
all cylinders share a common diesel
fuel supply line. Fine injection nozzles
provide for highly accurate metering
that reduces diesel fuel consumption.
Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the passen-
ger compartment needed for vehicle
operation and monitoring.

472 Technical termsCOMAND
(C
ockpit M
anagement and D
ata Sys-
tem)
Information and operating center for
vehicle sound and communications
systems, including the radio and navi-
gation system, as well as other optional
equipment (CD changer, telephone,
etc.).
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to ad-
just settings.
Cruise control
Driving convenience system for auto-
matically maintaining the vehicle speed
set by the driver.Distronic*
A driving convenience cruise control
system which helps the driver maintain
a pre-selected speed:


If there is no vehicle directly ahead,
the system operates in the same
way as conventional ->cruise con-
trol.


If a slower moving vehicle is ahead,
Distronic will reduce your vehicle
speed to the extent permitted by re-
duced throttle and up to 20% brak-
ing power to maintain the preset
minimum following distance.
DTR
(->Distronic*)
Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine pro-
duced.Engine oil viscosity
Measurement for the inner friction (vis-
cosity) of the oil at different tempera-
tures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can tol-
erate without becoming viscous, the
better the viscosity.
ESP
(E
lectronic S
tability Pr
ogram)
Improves vehicle handling and direc-
tional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the sys-
tem's threshold to tighten the seat
belts.
->SRS

473 Technical terms
FSS PLUS (Canada vehicles)
(F
lexible S
ervice S
ystem PLUS)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. FSS evaluates en-
gine temperature, oil level, vehicle
speed, engine speed, distance driven
and the time elapsed since your last
service, calculates other maintenance
service work required, and calls for the
next maintenance service accordingly.
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the selector lever.GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special re-
ceivers. Employs DVD digital maps for
navigation.
Heater booster system
Provides for additional heat in the
vehicle interior in vehicle models with
diesel engines.
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision, in-
cluding the tachometer, speedometer
and fuel gauge.
KEYLESS-GO*
System for entering and operating the
vehicle without the use of a SmartKey.Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the vehi-
cle and should not be used for normal
acceleration needs.
Lock button
Button on the door which indicates
whether the door is locked or un-
locked. Pushing the lock button down
on an individual door from inside will
lock that door.
Maintenance System (U.S. vehicles)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. The Vehicle Main-
tenance System in your vehicle tracks
distance driven and the time elapsed
since your last maintenance service,
calculates other maintenance service
work required, and calls for the next
maintenance service accordingly.

474 Technical termsMemory function*
Used to store three individual seat,
steering wheel and exterior mirror posi-
tions for each SmartKey.
MON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized meth-
od. It is an indication of a gasoline's
ability to resist undesired detonation
(knocking). The average of both the
MON (Motor Octane Number) and
->RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Multifunction display
The display field in the instrument clus-
ter used to present information provid-
ed by the control system.
Multifunction steering wheel
Steering wheel with buttons for operat-
ing the control system.Overspeed range
Engine speeds within the red marking
on the tachometer dial. Avoid this en-
gine speed range, as it may result in se-
rious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Parktronic (Parking assist)*
System which uses visual and acoustic
signals to assist the driver during park-
ing maneuvers.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.Power train
Collective term designating all compo-
nents used to generate and transmit
motive power to the drive axles, includ-
ing:


Engine


Clutch/torque converter


Transmission


Transfer case*


Drive shaft


Axle shafts/axles
Program mode selector switch
Used to switch the automatic transmis-
sion between standard operationS and
operationC.
E 55 AMG with steering wheel gearshift
control and manual shift program: in
addition to S and C (for sporty S or
comfortable C operation), you can use
M for manual shift program.

475 Technical terms
PTC heating element
(P
ositive T
emperature C
oefficient)
Electronic component that warms up
quickly as electricity is supplied to it
and is used as a ->heater booster sys-
tem in diesel vehicles.
Restraint systems
Seat belts, belt tensioners, air bags and
child restraint systems. As indepen-
dent systems, their protective func-
tions complement one another.
RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired detona-
tion (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.SBC
(S
ensotronic B
rake C
ontrol)
Electronically controlled hydraulic
braking system for increased braking
safety and comfort.
Shift lock
When the vehicle is parked, this lock
prevents the transmission selector le-
ver from being moved out of positionP
without the ignition or engine on and
brake pedal depressed.
SRS
(S
upplemental R
estraint S
ystem)
Seat belts, emergency tensioning de-
vice and air bags. Though independent
systems, they are closely interfaced to
provide effective occupant protection.Tele Aid System
(T
elematic A
larm I
dentification on D
e-
mand)
The Tele Aid system consists of three
types of response: automatic and man-
ual emergency, roadside assistance
and information. Tele Aid is initially ac-
tivated by completing a subscriber
agreement and placing an acquain-
tance call.
The Tele Aid system is operational pro-
vided that the vehicle’s battery is
charged, properly connected, not dam-
aged and cellular and GPS coverage is
available.
Telematics*
A combination of the terms “telecom-
munications” and “informatics”.
Tightening torque
Force times lever arm (e.g. a lug
wrench) with which threaded fasteners
such as wheel bolts are tightened.

476 Technical termsTire speed rating
Part of a tire designation; indicates the
speed range for which a tire is ap-
proved.
Traction
Force exerted by the vehicle on the
road via the tires.
Vehicle level control
The ground clearance of the vehicle is
automatically controlled according to a
selected setting and speed.The driver
can set the ground clearance manually
for example on very rough roads.
VIN
(V
ehicle I
dentification N
umber)
The number set by the manufacturer
and placed on the body to uniquely
identify each vehicle produced.
Voice control system*
Voice control system for car phones,
portable cell phones and audio sys-
tems (radio, CD, etc.).

477 Index
A
ABS 85, 471
ABS control 86
Malfunction indicator lamp 356
Messages in display 369
Warning lamp 356
Accelerator position, automatic
transmission* 180
Accessory weight 337
Accident
In case of 54
Activating
Air conditioning (cooling) 201, 214
Air recirculation mode 199, 212
Anti-theft alarm system 94
Automatic climate control
(Dual-zone) 194, 195
Central locking (control system) 166
Defrosting 199
Distance warning function* 244
Distronic* 240
Easy-entry/exit feature* 167ESP 90
Exterior headlamps 50
Exterior lamps 134
Front fog lamps 136
Hazard warning flasher 138
Headlamps 50
High beams 137
Ignition 34
Ignition with KEYLESS-GO* 36
Immobilizer 56, 94
Rear fog lamp 136
Rear window defroster 191
Residual heat 202, 215
Seat heater* 128
Tow-away alarm 95
Windshield wipers 52
Adding
Engine oil 306
Additional turn signal 418
Adjustable air vents, rear passenger
compartment 216Adjusting 37
Air distribution 198, 210
Air volume 198, 211
Backrest tilt 38
Drive-dynamic seat* with multicontour
features 126
Exterior rear view mirror 41
Head restraint height 39
Head restraint tilt 39
Instrument cluster illumination 142
Interior rear view mirror 41
Mirrors 40
Seat cushion tilt 38
Seat fore and aft adjustment 38
Seat height 38
Seats 37
Steering column height 40
Steering wheel 39
Adjusting steering column in or out 40
Adjusting steering column up or down 40
Adjusting the dynamic seat 169

478 IndexAir conditioning (cooling)
Turning off 201, 214
Turning on 201, 214
Air distribution
Adjusting 198, 210
Air pressure 337
Air pressure see Tire inflation
pressure 322
Air pump, electric 430
Air recirculation mode 199, 212
Activating 199, 212
Deactivating 200, 213
Air vents, rear passenger compartment
Adjustable 216
Air volume
Adjusting 198, 211
Airbags 61
Children 62
Front 65
Passenger 65
Safety guidelines 64
Side impact 66
Window curtain 66Airmatic DC (Dual Control)* 247
Alarm
Audible 84, 95
Canceling 95
Visual 94
Alarm system
Anti-theft 94
Alignment bolt (vehicle tool kit) 409,
427, 471
Antilock brake system (ABS) 471
Anti-theft alarm system
Arming 94
Canceling alarm 95
Disarming 95
Anti-theft systems 94
Anti-theft alarm system 94
Immobilizer 94
Tow-away alarm 95
Aquaplaning see Hydroplaning 291Ashtray 268
Aspect ratio 337
At the gas station 299
AUDIO menu 150
Selecting radio station 150
Selecting satellite radio* station 151
Audio system
CD mode 151
Auto-dimming
Automatic 186
Auto-dimming for rear view mirrors 186
Automatic central locking
Activating/deactivating (control
system) 166
Automatic climate control
4-zone automatic climate
control* 204
Dual-zone automatic climate
control 192
Temperature sensor 29
