110 Controls in detailIn the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed on your vehi-
cle. If you are already familiar with the
basic functions of your vehicle, this section
will be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are
given at the beginning of each segment.Locking and unlocking
For more information on locking and un-
locking, see “Getting started” (
page 36)
and (
page 61).
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys are a differ-
ent color to help distinguish each
SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks
the doors
the tailgate
the fuel filler flap
SmartKey with remote control1‹ Lock button
2Š Opening button for the tailgate
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 96)
!
To prevent possible malfunction, avoid ex-
posing the SmartKey to high levels of electro-
magnetic radiation.
Page 112 of 514
111 Controls in detail
Locking and unlocking
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. It is possible
for children to open a looked door from the
inside, which could result in an accident
and/or serious personal injury.i
USA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
You can also open and close the windows
and tilt/sliding sunroof using the SmartKey
(
page 241).
!
If you can no longer lock or unlock the vehi-
cle with the SmartKey, then the batteries in the
SmartKey are discharged, the SmartKey is mal-
functioning or the vehicle battery is drained.
Check the batteries in the SmartKey
(page 119) and replace them if necessary
(page 440).
Use the mechanical key to unlock the driv-
er’s door (
page 435).
Use the mechanical key to lock the driver’s
door.
Have the vehicle battery checked by an au-
thorized Mercedes-Benz Center.
If the SmartKey is malfunctioning, contact an au-
thorized Mercedes-Benz Center.
Page 113 of 514
112 Controls in detailLocking and unlockingFactory settingGlobal unlocking
Press buttonŒ.
All turn signal lamps flash once.
An acoustic signal sounds once.
The locking knobs in the doors
move up.
The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:
neither a door nor the tailgate is
opened
the SmartKey is not inserted in the
starter switch
the central locking switch is not acti-
vatedGlobal locking
Press button‹.
With the tailgate and all doors closed:
All turn signal lamps flash three
times.
An acoustic signal sounds three
times.
The locking knobs in the doors
move down.
The anti-theft alarm system is
armed.
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that
pressingŒ only unlocks the driver’s
door and the fuel filler flap.
i
When unlocking or locking the vehicle with
the SmartKey an acoustic signal sounds. The
acoustic signal is activated at the factory. If you
wish to deactivate the feature, or adjust its signal
volume, contact an authorized Mercedes-Benz
Center.
Page 114 of 514
113 Controls in detail
Locking and unlocking
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 110)
flashes twice.
The SmartKey will then function as fol-
lows:
Unlocking driver’s door and fuel filler
flap
Press buttonΠonce.
All turn signal lamps flash once.
An acoustic signal sounds once.
The locking knob in the driver’s
door moves up.
The anti-theft alarm system is dis-
armed.
Global unlocking
Press buttonΠtwice.
All turn signal lamps flash once.
An acoustic signal sounds once.
The locking knobs in the doors
move up.
The anti-theft alarm system is dis-
armed.
Global locking
Press button‹.
All turn signal lamps flash three
times.
An acoustic signal sounds three
times.
The locking knobs in the doors
move down.
The anti-theft alarm system is
armed.
Restoring to factory setting
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 110)
flashes twice.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys with
KEYLESS-GO are a different color to help
distinguish each SmartKey with
KEYLESS-GO unit.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked every time you pull an outside
door handle.
If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks
the doors
the tailgate
the fuel filler flap
Page 115 of 514
114 Controls in detailLocking and unlockingSmartKey with KEYLESS-GO1‹ Lock button
2Š Opening button for the tailgate
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 96)
!
To prevent possible malfunction, avoid ex-
posing the SmartKey with KEYLESS-GO to high
levels of electromagnetic radiation.
Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. It is possible for children
to open a locked door from the inside, which
could result in an accident and/or serious
personal injury.i
USA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interfer-
ence, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
Canada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
i
You can also open and close the windows
and tilt/sliding sunroof using the SmartKey with
KEYLESS-GO* (
page 241).
Page 116 of 514
115 Controls in detail
Locking and unlocking
Important notes on using KEYLESS-GO
You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 110).
You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with button ‹).
Always carry the SmartKey with
KEYLESS-GO with you.
Never store the SmartKey with
KEYLESS-GO together with:
Electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO
Metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.
To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within ap-
proximately 3 ft (1 m) of a door or the
tailgate.
In order to start the engine with the
SmartKey with KEYLESS-GO:
The SmartKey with KEYLESS-GO
must be located in the vehicle.
The brake pedal must be firmly de-
pressed. Do not depress the accel-
erator.
If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle cannot be locked or the
engine started via the KEYLESS-GO
system.
If the SmartKey with KEYLESS-GO is re-
moved from the vehicle (e.g. if passen-
ger exits the vehicle with the SmartKey
with KEYLESS-GO)
when pressing the KEYLESS-GO
start/stop button or trying to lock
the vehicle with the outside door
handle the message
Key not rec-
ognized
appears in the multifunc-
tion display
!
If you can no longer lock or unlock the vehi-
cle with the SmartKey with KEYLESS-GO, then
the batteries in the SmartKey with KEYLESS-GO
are discharged, the SmartKey with KEYLESS-GO
is malfunctioning or the vehicle battery is
drained.
Check the batteries in the SmartKey with
KEYLESS-GO (
page 119) and replace
them if necessary (page 440).
Use the mechanical key to unlock the driv-
er’s door (
page 435).
Use the mechanical key to lock the driver’s
door.
Have the vehicle battery checked by an au-
thorized Mercedes-Benz Center.
If the SmartKey with KEYLESS-GO is malfunc-
tioning, contact an authorized Mercedes-Benz
Center.
Page 117 of 514
116 Controls in detailLocking and unlocking
with the engine running, the mes-
sage
Key not recognized
appears
in the multifunction display while
driving off.
Find the SmartKey with KEYLESS-GO or
change its present location immediate-
ly (e.g. place it on the front passenger
seat or insert it in shirt pocket).
If you have started the engine with the
KEYLESS-GO start/stop button, you
can turn it off again with:
the KEYLESS-GO start/stop button
the SmartKey with KEYLESS-GO in-
serted in the starter switch, when
the automatic transmission is in
positionP
Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle.
Possibility 1: (One SmartKey with
KEYLESS-GO in the vehicle, one
SmartKey with KEYLESS-GO outside
the vehicle):
If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, no message
appears in the multifunction display.
Possibility 2: (One SmartKey with
KEYLESS-GO in the vehicle, no
SmartKey with KEYLESS-GO outside
the vehicle):
When exiting and trying to lock the ve-
hicle, the message
Key still in ve-
hicle
appears in the multifunction
display. The vehicle will not be locked.Factory setting
i
When unlocking or locking the vehicle with
the SmartKey or with the KEYLESS-GO function
an acoustic signal sounds. The acoustic signal is
activated at the factory. If you wish to deactivate
the feature, or adjust its signal volume, contact
an authorized Mercedes-Benz Center.
Page 118 of 514
117 Controls in detail
Locking and unlocking
Global unlocking
Pull an outside door handle.
All turn signal lamps flash once.
An acoustic signal sounds once.
The locking knobs in the doors
move up.
The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds if:
neither a door nor the tailgate is
opened
the central locking switch is not acti-
vatedGlobal locking
Press lock button on an outside door
handle (
page 65).
All turn signal lamps flash three
times.
An acoustic signal sounds three
times.
The locking knobs in the doors
move down.
The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you pull the driver’s
outside door handle, only the driver’s door
and the fuel filler flap unlocks.
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 114)
flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:
Unlocking driver’s door and fuel filler
flap
Pull the driver’s outside door handle.
All turn signal lamps flash once.
An acoustic signal sounds once.
The locking knob in the driver’s
door moves up.
The anti-theft alarm system is dis-
armed.
Page 119 of 514
118 Controls in detailLocking and unlockingGlobal unlocking
Pull any outside door handle other than
the driver’s outside door handle.
All turn signal lamps flash once.
An acoustic signal sounds once.
The locking knobs in the doors
move up.
The anti-theft alarm system is dis-
armed.
Global locking
Press lock button on an outside door
handle (
page 65).
All turn signal lamps flash three
times.
An acoustic signal sounds three
times.
The locking knobs in the doors
move down.
The anti-theft alarm system is
armed.Restoring to factory setting
Press and hold buttonsŒ and‹
simultaneously for about 5 seconds un-
til battery check lamp5 (
page 114)
flashes twice.Global locking using the KEYLESS-GO
lock button on the tailgate
Depending on production date your vehicle
may be equipped with the KEYLESS-GO
lock button on the tailgate.
1KEYLESS-GO lock button on the tail-
gate
i
You can also lock the vehicle using the
KEYLESS-GO lock button on the tailgate (de-
pending on vehicle production date) or, vehicles
with tailgate opening/closing system*,
KEYLESS-GO locking/ closing switch*
(
page 126).
Page 120 of 514
119 Controls in detail
Locking and unlocking
With the tailgate and all doors closed:
Press lock button1 on the tailgate.
All turn signal lamps flash three
times.
An acoustic signal sounds three
times.
The locking knobs in the doors
move down.
The anti-theft alarm system is
armed.Checking batteries in the SmartKey or
SmartKey with KEYLESS-GO*
Press button‹ orŒ.
The battery check lamp (
page 110)
or (
page 114) comes on briefly to in-
dicate that the SmartKey or SmartKey
with KEYLESS-GO batteries are in or-
der.Loss of the SmartKey or SmartKey with
KEYLESS-GO*
If you lose your SmartKey, SmartKey with
KEYLESS-GO or mechanical key, you
should do the following:
Have the SmartKey or SmartKey with
KEYLESS-GO deactivated by an autho-
rized Mercedes-Benz Center.
Report the loss of the SmartKey,
SmartKey with KEYLESS-GO or the me-
chanical key immediately to your car
insurance company.
Have the mechanical lock replaced if
necessary.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
i
To prevent a possible inadvertent lockout,
the tailgate will open automatically if a SmartKey
with KEYLESS-GO is recognized inside the vehi-
cle or in the cargo compartment.
i
You can also lock the vehicle using the lock
button on an outside door handle (
page 65) or,
vehicles with tailgate opening/closing system*,
KEYLESS-GO locking/ closing switch*
(
page 126).
!
If the battery check lamp does not come on
briefly during check, the SmartKey or SmartKey
with KEYLESS-GO batteries are discharged.
Replace the batteries (
page 440).
You can obtain the required batteries at any au-
thorized Mercedes-Benz Center.
i
If the batteries are checked within signal
range of the vehicle, pressing button‹ or
Πwill lock or unlock the vehicle accordingly.
