Page 381 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 380 Practical hints
Replacing bulbs
Replacing bulbs for front lamps
Before you start to replace a bulb for a
front lamp, do the following first:
Turn the exterior lamp switch to
positionM (
page

Page 382 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 381 Practical hints
Replacing bulbs
Left headlamp shown, right headlamp
laterally reversed
3Securing screw (headlamp)
4Adjusting screw (headlamp)
5Headlamp
Loosen and remove headlamp-securing
screw

Page 383 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 382 Practical hints
Replacing bulbs
Front fog lamp bulb
Right front fog lamp shown, left front fog
lamp laterally reversed
1Securing screw (trim panel)
2Front fog lamp trim panel
Loosen and remove s

Page 384 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 383 Practical hints
Replacing bulbs
7Bulb
Pull bulb7 out of its bulb socket.
Insert the new bulb into the bulb
socket.
Hold front fog lamp5, insert bulb
socket6 into front fog lamp5, and
turn bu

Page 385 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 384 Practical hints
Replacing bulbs
Side marker lamp bulb
The following description applies to both,
the front and the rear side marker lamps.
Front side marker shown
1Securing screw
2Side marker lam

Page 386 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 385 Practical hints
Replacing bulbs
Reinstall side marker lamp housing2.
Install and tighten securing screws1.
Additional turn signal lamps
The additional turn signal lamps in the
exterior rear vie

Page 387 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 386 Practical hints
Replacing bulbs
Left tail lamp unit shown, right tail lamp
unit laterally reversed
3Turn signal lamp bulb
4Brake, tail, parking and standing lamp
bulb
5Tail, parking and standing

Page 388 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 387 Practical hints
Replacing bulbs
License plate lamp bulb
1Securing screw
2License plate lamp lens (with bulb
socket)
Loosen and remove securing
screws1.
Remove license plate lamp lens2.3Tubular

Page 389 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 388 Practical hints
Replacing wiper blades
Wiper blades
Remove the SmartKey from the starter
switch.Removing
Fold the wiper arms forward until they
engage.
1Safety tab
2Wiper blade
3Wiper arm
4Att

Page 390 of 457

MERCEDES-BENZ G55AMG 2007 W463 Owners Manual 389 Practical hints
Replacing wiper blades
Turn wiper blade2 at a right angle to
wiper arm3.
Press safety tab1 of attachment
link4 down and slide wiper blade2
from the end of wiper arm3.
Remove
