Page 7 of 601
Contents
Power tilt/sliding sunroof* ................ 251
Opening and closing ..................... 251
Synchronizing ............................... 253
Driving systems ................................. 255
Cruise control............................... 255
Distronic* (Canada only) .............. 260
Distance warning function*
(Canada only) ............................... 272
Downhill Speed Regulation
(DSR) ............................................ 273
Off-road driving program
(Vehicles without
enhanced off-road package*) ....... 277
Air suspension program ............... 278
Adaptive Damping System
(ADS)* .......................................... 278
Vehicle level control ..................... 279
Parktronic system* ...................... 288
Rear view camera* ....................... 293Loading .............................................. 295
Carriers* ...................................... 295
Loading instructions..................... 301
Cargo tie-down rings .................... 302
Hooks........................................... 304
Expanding cargo compartment .... 304
Cargo compartment cover blind... 310
Cargo net* ................................... 312
Useful features .................................. 315
Storage compartments ................ 315
Parcel nets ................................... 319
Cup holders.................................. 320
Ashtrays ....................................... 321
Cigarette lighter ........................... 323
Power outlets ............................... 324
Floormats ..................................... 325
Seat cover under third-row seats . 326
Heated steering wheel* ............... 327
Telephone* .................................. 328
Tele Aid ........................................ 331
Garage door opener ..................... 338
Compass ...................................... 344
Infrared reflecting windshield* ..... 344
Operation......................................... 345
The first 1000 miles (1500 km) ......... 346
Driving instructions ........................... 347
Drive sensibly – save fuel............. 347
Drinking and driving ..................... 347
Pedals .......................................... 347
Power assistance ......................... 348
Brakes.......................................... 348
Driving off .................................... 350
Parking......................................... 350
Tires ............................................. 351
Hydroplaning................................ 352
Tire traction ................................. 352
Tire speed rating .......................... 353
Winter driving instructions ........... 353
Standing water............................. 355
Off-road driving ............................ 355
Trailer towing ............................... 364
Passenger compartment .............. 370
Driving abroad ............................. 370
Control and operation of radio
transmitters ................................. 370
Catalytic converter
(gasoline engine).......................... 371
164.boo Seite 6 Freitag, 30. März 2007 12:54 12
Page 46 of 601
45 Getting started
Adjusting
Adjusting
Seats
Warning!G
All seat, head restraint, steering wheel, and
rear view mirror adjustments, as well as fas-
tening of seat belts, must be done before
the vehicle is put into motion.
Warning!G
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause
the driver to lose control of the vehicle.
Never ride in a moving vehicle with the seat
backrest in an excessively reclined position
as this can be dangerous. You could slide
under the seat belt in a collision. If you slide
under it, the belt would apply force at the ab-
domen or neck. That could cause serious or
fatal injuries. The seat backrest and seat
belts provide the best restraint when the
wearer is in a position that is as upright as
possible and belts are properly positioned
on the body.
Warning!G
Your seat must be adjusted so that you can
correctly fasten your seat belt (
page 53).
Observe the following points:
Adjust the backrest until your arms are
slightly angled when holding the steer-
ing wheel
Adjust the seat to a comfortable seating
position that still allows you to reach the
accelerator/brake pedal safely. The po-
sition should be as far back as possible
with the driver still able to operate the
controls properly.
Adjust the head restraint so that it is as
close to the head as possible and the
center of the head restraint supports the
back of the head at eye level.
Never place hands under the seat or
near any moving parts while a seat is be-
ing adjusted.
Failure to do so could result in an accident
and/or serious personal injury.
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or the SmartKey
with KEYLESS-GO* removed from the
starter switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the power seats can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
164.boo Seite 45 Freitag, 30. März 2007 12:54 12
Page 60 of 601
59 Getting started
Driving
Starting difficulties
If the engine does not start as described,
carry out the following steps:
If you are starting the engine with the
SmartKey, turn SmartKey in starter
switch to position0 and repeat starting
procedure.
If you are starting the engine with
KEYLESS-GO*: Close any doors that
may be open to allow for better
detection of the SmartKey with
KEYLESS-GO*.
Or:
Remove KEYLESS-GO* start/stop
button from starter switch (
page 43).
Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO*.
Repeat the starting procedure
(
page 56). Remember that extended
starting attempts can drain the battery.
Get a jump start (page 536).
If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.
Contact an authorized Mercedes-Benz
Light Truck Center or call Roadside
Assistance.
Parking brake
1Release handle
Release the parking brake by pulling on
release handle1.
The warning lamp; (USA only)
or3(Canada only) in the
instrument cluster goes out.
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake, which could result in an acci-
dent and/or serious personal injury.
164.boo Seite 59 Freitag, 30. März 2007 12:54 12
Page 62 of 601
61 Getting started
Driving
For more information, see “Driving instruc-
tions” (
page 347).
For information on off-road driving, see
“Off-road driving” (
page 355).
Switching on headlamps
Low beam headlamps
The exterior lamp switch is located on the
dashboard to the left of the steering wheel.
Exterior lamp switch
1Off
2Low beam headlamps on
Switch on the ignition (page 41).
Turn the exterior lamp switch to
positionB.
The low beam headlamps come on.High beam
The combination switch is located on the
left of the steering column.
Combination switch
1High beam
2High beam flasher
Push the combination switch in
direction of arrow1.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 26).
For more information on headlamps, see
“Lighting” (
page 143).
!Shift the automatic transmission to
positionPorR only when the vehicle is stopped
in order to avoid damaging the transmission.
!Do not run cold engine at high engine
speeds. Running a cold engine at high engine
speeds may shorten the service life of the
engine.
!Simultaneously depressing the accelerator
pedal and applying the brakes reduces engine
performance and causes premature brake and
drivetrain wear.
164.boo Seite 61 Freitag, 30. März 2007 12:54 12
Page 68 of 601
67 Getting started
Parking and locking
Parking and locking
You have now completed your first drive.
You have properly stopped and parked
your vehicle. End your drive as follows.Parking brake
1Parking brake pedal
Warning!G
With the engine not running, there is no
power assistance for the brake and the
steering system. In this case, it is important
to keep in mind that a considerably higher
degree of effort is necessary to brake and
steer the vehicle.
Warning!G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury, or
damage to the vehicle drivetrain, as a result
of vehicle movement, before turning off the
engine and leaving the vehicle always:
Keep right foot on brake pedal.
Firmly depress parking brake pedal.
Shift the automatic transmission to
positionP.
Slowly release brake pedal.
When parked on an incline, turn front
wheel towards the road curb.
Turn the SmartKey in the starter switch
to position0 and remove the SmartKey
from the starter switch, or press the
start/stop button (vehicles with
KEYLESS-GO*).
Take the SmartKey or the SmartKey with
KEYLESS-GO* with you and lock vehicle
when leaving.
Warning!G
Engaging the parking brake while the vehicle
is in motion can cause the rear wheels to
lock up. You could lose control of the vehicle
and cause an accident. In addition, the vehi-
cle’s brake lights do not light up when the
parking brake is engaged.
164.boo Seite 67 Freitag, 30. März 2007 12:54 12
Page 69 of 601
68 Getting started
Parking and locking
Step firmly on parking brake pedal1.
When the engine is running, the
warning lamp; (USA only) or3
(Canada only) in the instrument cluster
comes on.
Switching off headlamps
Turn the exterior lamp switch toM
(
page 61).
For more information, see “Lighting”
(
page 143).
Turning off the engine
Shift the automatic transmission to
positionP (
page 191).
Apply the parking brake (page 67).
Warning!G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Children could release the
parking brake and/or shift the automatic
transmission out of positionP, either of
which could result in an accident and/or
serious personal injury.
Warning!G
Getting out of your vehicle with the
automatic transmission not fully engaged in
positionP is dangerous. Also, when parked
on an incline, positionP alone may not
prevent your vehicle from moving, possibly
hitting people or objects.
Always set the parking brake in addition to
shifting to positionP (
page 191).
When parked on an incline, also turn front
wheel towards the road curb.
iIf the engine cannot be turned off as
described, see “Emergency engine shut-down”
(
page 545).
Warning!G
Do not turn off the engine before the vehicle
has come to a complete stop. With the en-
gine not running, there is no power assis-
tance for the brake and steering systems. In
this case, it is important to keep in mind that
a considerably higher degree of effort is nec-
essary to brake and steer the vehicle.
iAlways set the parking brake in addition to
shifting the automatic transmission to positionP
(
page 191).
When parked on an incline, also turn front wheel
towards the road curb.
164.boo Seite 68 Freitag, 30. März 2007 12:54 12
Page 102 of 601
101 Safety and Security
Driving safety systems
Driving safety systems
In this section you will find information on
the following driving safety systems:
ABS (Antilock Brake System)
BAS (Brake Assist System)
ESP® (Electronic Stability Program)
EBP (Electronic Brake Proportioning)
4-ETS (Electronic Traction System)
ABS
The Antilock Brake System (ABS) regulates
the brake pressure so that the wheels do
not lock during braking. This allows you to
maintain the ability to steer your vehicle.
The ABS is functional above a speed of ap-
proximately 5 mph (8 km/h) independent
of road surface conditions.
On slippery road surfaces, the ABS will
respond even to light brake pressure.
The -indicator lamp in the instrument
cluster (
page 26) comes on when you
switch on the ignition. It goes out when the
engine is running.
Warning!G
The following factors increase the risk of
accidents:
Excessive speed, especially in turns
Wet and slippery road surfaces
Following another vehicle too closely
The driving safety systems described in this
section cannot reduce these risks or pre-
vent the natural laws of physics from acting
on the vehicle.
Always adapt your driving style to the pre-
vailing road and weather conditions and
keep a safe distance to other road users and
objects in the street.
iIn winter operation, the maximum effective-
ness of the ABS, the BAS, the ESP®, the EBP, and
the 4-ETS is only achieved with winter tires
(
page 420) or snow chains as required.
Warning!G
Do not pump the brake pedal. Use firm,
steady brake pedal pressure instead. Pump-
ing the brake pedal defeats the purpose of
the ABS and significantly reduces braking
effectiveness.
164.boo Seite 101 Freitag, 30. März 2007 12:54 12
Page 103 of 601
102 Safety and Security
Driving safety systems
Braking
At the instant one of the wheels is about to
lock up, a slight pulsation can be felt in the
brake pedal, indicating that the ABS is in
the regulating mode.
Keep firm and steady pressure on the
brake pedal while experiencing the pul-
sation.
Continuous, steady brake pedal pressure
yields the advantages provided by the ABS,
namely braking power and ability to steer
the vehicle.
The pulsating brake pedal can be an
indication of hazardous road conditions
and functions as a reminder to take extra
care while driving.Emergency brake maneuver
Keep continuous full pressure on the
brake pedal.
Off-road – ABS
With the off-road driving program switched
on (
page 277), or with the transmission
in LOW RANGE* mode (
page 201), the
ABS designed for off-road use is automati-
cally activated.
When applying the brakes at speeds below
approximately 18 mph (30 km/h), the
front wheels are locked cyclically to short-
en the braking distance (dig-in effect). This
affects steering the vehicle.
For more information, see “Practical hints”
(
page 435).
Warning!G
When the ABS is malfunctioning, the BAS,
the ESP®, and the 4-ETS are also switched
off. The basic driving and braking functions
are still available.
When the ABS is malfunctioning, the wheels
may lock during hard braking, reducing
steering capability and extending the brak-
ing distance.
Warning!G
The ABS cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase braking or steering efficiency be-
yond that afforded by the condition of the
vehicle brakes and tires or the traction
afforded. The ABS cannot prevent acci-
dents, including those resulting from
excessive speed in turns, following another
vehicle too closely, or hydroplaning. Only a
safe, attentive, and skillful driver can pre-
vent accidents. The capabilities of an ABS
equipped vehicle must never be exploited in
a reckless or dangerous manner which
could jeopardize the user’s safety or the
safety of others.
164.boo Seite 102 Freitag, 30. März 2007 12:54 12
Page 105 of 601
104 Safety and Security
Driving safety systems
For more information, see the “Practical
hints” section (
page 441) and
(
page 457).
Warning!G
Never switch off the ESP® when you see the
ESP® warning lampv flashing in the in-
strument cluster. In this case, proceed as
follows:
While driving off, apply as little throttle
as possible.
While driving, ease up on the accelera-
tor.
Adapt your speed and driving style to
the prevailing road conditions.
Failure to observe these guidelines could
cause the vehicle to skid.
The ESP
® cannot prevent accidents result-
ing from excessive speed.
Warning!G
The ESP® cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase the traction afforded. The ESP
®
cannot prevent accidents, including those
resulting from excessive speed in turns, fol-
lowing another vehicle too closely, or hydro-
planing. Only a safe, attentive, and skillful
driver can prevent accidents. The capabili-
t i e s o f a n E S P
® equipped vehicle must never
be exploited in a reckless or dangerous
manner which could jeopardize the user’s
safety or the safety of others.
!Operational or performance test must only
be conducted on a two-axle dynamometer. If
such tests are necessary, contact an authorized
Mercedes-Benz Light Truck Center. You could
otherwise seriously damage the brake system or
the transfer case which is not covered by the
Mercedes-Benz Limited Warranty.
!Because the ESP® operates automatically,
the engine and ignition must be shut off
(SmartKey in starter switch position0 or1 or
KEYLESS-GO* start/stop button in
position0or1) when testing the parking brake
on a brake test dynamometer and such testing
should be no longer than 10 seconds.
Active braking action through the ESP
® may
otherwise seriously damage the brake system
which is not covered by the Mercedes-Benz
Limited Warranty.
iThe ESP® will only function properly if you
use wheels of the recommended tire size
(
page 555).
164.boo Seite 104 Freitag, 30. März 2007 12:54 12
Page 109 of 601
108 Safety and Security
Driving safety systems
For more information, see the “Practical
hints” section (
page 436) and
(
page 449).
Off-road - 4-ETS
With the off-road driving program switched
on (
page 277), or with the transmission
in LOW RANGE* mode (
page 201), the
4-ETS designed for off-road use is auto-
matically activated.
!Operational or performance test must only
be conducted on a two-axle dynamometer. If
such tests are necessary, contact an authorized
Mercedes-Benz Light Truck Center. You could
otherwise seriously damage the brake system or
the transfer case which is not covered by the
Mercedes-Benz Limited Warranty.
!Because the ESP® operates automatically,
the engine and ignition must be shut off
(SmartKey in starter switch position0 or1 or
KEYLESS-GO* start/stop button in
position0or1) when testing the parking brake
on a brake test dynamometer and such testing
should be no longer than 10 seconds.
Active braking action through the ESP
® may
otherwise seriously damage the brake system
which is not covered by the Mercedes-Benz
Limited Warranty.
iIf the yellow ESP® warning lampv
comes on while driving, the 4-ETS is being
switched off temporarily to prevent overheating
of the drive wheel brakes. In addition, the
message
ESP Unavailable See Operator’s
Manual
appears in the multifunction display.
164.boo Seite 108 Freitag, 30. März 2007 12:54 12
