MERCEDES-BENZ ML430 1997  Complete Repair Manual
 BA88.30-P-1003-01A
Screw, mount on brush guard
Nm
49

BA88.30-P-1011-01A
Bolt, underride guard to brush guard
Nm
25

BA88.30-P-1015-01A
Nut, underride guard to bracket
Nm
49

BA88.30-P-1016-01A
Bolt

Page 1982 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 AR88.20-P-2200GH
Remove/install rear bumper
6.4.99

MODEL
163.113 #A up to 289564,

163.154 #X up to 754619,

163.154 #A up to 289564,

163.136 /172

P88.20-0372-09

A
 Covers
 C
Screws

B
 Nuts

Page 1983 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 Number
Designation
Model 163

up to

31.8.01
Model 163

as of

1.9.01

BA88.30-P-1004-01A
Nut for retaining strap on mud guard on vehicle

underbody
Nm
66

Long wedge

115 589 03 59 00

Copyri

Page 1984 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 AR88.20-P-2200GI
Remove/install rear bumper
11.4.97

MODEL
163.113 #A up to 289564,

163.113 #X up to 754619,

163.154 #A up to 289564,

163.154 #X up to 716524,

163.136 /172 with CODE (849) S

Page 1985 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 11.1
Remove rubber seal for E-call emergency call

system antenna from body at right

 Only with emergency call system E-Call,

code 349.

12
Install in the reverse order


Bumper
Number

Desi

Page 1986 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 AR82.10-P-5103GH
Remove/install fog lamp
5.5.00

MODEL
163.113 /128 /136 /154 /157 /172 /175 with CODE (U49) Styling package

MODEL
 163.174

P82.10-2830-06

1
Cover

2
 Bolt

3
 Fog lamp


Remov

Page 1987 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 AR82.10-P-1825GH
Remove/install fog lamp bulb
23.4.01

MODEL
163.113 /128 /136 /154 /157 /172 /175 with CODE (U49) Styling package

MODEL
 163.174

P82.10-2833-06

1
Cover

2
 Bulb housing

3
 Bul

Page 1988 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 AR54.65-P-0001GH
Remove/install Parktronic system (PTS) sensors in front bumper
19.4.01

MODEL
163.113 /128 /154 /157 /174 /175 with CODE (220a) Parktronic System (PTS)

P54.65-2411-06

1
Plug conn

Page 1989 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 AR88.20-P-2000GI
Remove/install front bumper
5.4.99

MODEL
163.113 /128 /136 /154 /157 /172 /175 with CODE (U49) Styling package

MODEL
 163.174

P88.20-2093-09


Remove, Install

1
Unscrew nuts

Page 1990 of 4133

MERCEDES-BENZ ML430 1997  Complete Repair Manual
 Hooked extraction tool

140 589 02 33 00

Copyright DaimlerChrysler AG  17.05.2006 CD-Ausgabe G/10/04 . This WIS print-out will not be recorde
d by Modification services.
Page 2
