100 Safety and SecurityDriving safety systems
For more information, see the “Practical
hints” section (
page 409).
Warning!
G
Never switch off the ESP
® when you see the
ESP
® warning lampv flashing in the in-
strument cluster. In this case, proceed as
follows:


While driving off, apply as little throttle
as possible.


While driving, ease up on the accelera-
tor.


Adapt your speed and driving style to
the prevailing road conditions.
Failure to observe these guidelines could
cause the vehicle to skid.
The ESP
® cannot prevent accidents result-
ing from excessive speed.
Warning!
G
The ESP
® cannot prevent the natural laws of
physics from acting on the vehicle, nor can
it increase the traction afforded. The ESP
®
cannot prevent accidents, including those
resulting from excessive speed in turns, fol-
lowing another vehicle too closely, or hydro-
planing. Only a safe, attentive, and skillful
driver can prevent accidents. The capabili-
t i e s o f a n E S P
® equipped vehicle must never
be exploited in a reckless or dangerous
manner which could jeopardize the user’s
safety or the safety of others.
iThe ESP
® will only function properly if
you use wheels of the recommended
tire size (page 514).
!Because of the ESP’s
® automatic oper-
ation, the engine and ignition must be
shut off (SmartKey in starter switch
position0 or1 or KEYLESS-GO*
start / stop button* in position0 or1)
when


the parking brake is being tested on
a brake test dynamometer


the vehicle is being towed with the
front or rear axle raised
Active braking action through the ESP
®
may otherwise seriously damage the
brake system.
Operational tests with the engine
running can only be conducted on a
two-axle dynamometer.

101 Safety and Security
Driving safety systems
Switching off the ESP
®
To improve the vehicle’s traction, turn off
the ESP
® in driving situations where it
would be advantageous to have the drive
wheels spin and thus cut into surfaces for
better grip such as:


starting out on slippery surfaces and in
deep snow in conjunction with snow
chains


in sand or gravelWhen you switch off the ESP
®


the ESP
® does not stabilize the vehicle


the engine output is not limited, which
allows the drive wheels to spin and
thus cut into surfaces for better grip


the 4-ETS will still brake a spinning
wheel


the ESP
® continues to operate when
you are brakingThe ESP
® switch is located on the upper
part of the center console.
1ESP® switch

Press ESP
® switch1 until the
ESP
®warning lampv in the instru-
ment cluster comes on.
The ESP® is deactivated.
Warning!
G
The ESP
® should not be switched off during
normal driving other than in the circum-
stances described below. Disabling of the
system will reduce vehicle stability in stan-
dard driving maneuvers.
!Turn the ESP
® on immediately if the
aforementioned circumstances do not
apply anymore.
iWhen the ESP
® is switched off and one
or more drive wheels are spinning, the
ESP
® warning lamp v in the instru-
ment cluster flashes. However, the
ESP® will then not stabilize the vehicle.

102 Safety and SecurityDriving safety systems
Switching on the ESP
®

Press ESP
® switch1.
The ESP
® warning lampv in the in-
strument cluster goes out.
You are now again in normal driving
mode with the ESP
® switched on.
For more information, see the “Practical
hints” section (
page 404).
EBP
The EBP enhances braking effectiveness
by allowing the rear brakes to supply a
greater proportion of the braking effort
without a loss of vehicle stability.
4-ETS
The 4-Electronic Traction System (4-ETS)
improves the vehicle’s ability to utilize
available traction, especially under slip-
pery road conditions. The brakes are ap-
plied to the spinning wheel and power is
transferred to the wheel(s) with traction.
The ESP
® warning lampvin the instru-
ment cluster starts to flash at any vehicle
speed, as soon as a tire loses traction and
the wheel begins to spin.
Warning!
G
When the ESP
® warning lampv is
illuminated continuously, the ESP
® is
switched off.
Adapt your speed and driving to the prevail-
ing road conditions and to the non-operating
status of the ESP
®.
!Avoid spinning of a drive wheel for an
extended period of time with the ESP
®
switched off. This may cause serious
damage to the drivetrain which is not
covered by the Mercedes-Benz Limited
Warranty.

103 Safety and Security
Driving safety systems
For more information, see the “Practical
hints” section (
page 404) and
(
page 416).
Warning!
G
When you see the ESP
® warning lampv
flashing in the instrument cluster, then pro-
ceed as follows:


While driving off, apply as little throttle
as possible.


While driving, ease up on the accelera-
tor.


Adapt your speed and driving style to
the prevailing road conditions.
Failure to observe these guidelines could
cause the vehicle to skid.
The 4-ETS cannot prevent accidents resul-
ting from excessive speed.
!Because of the ESP’s
® automatic oper-
ation, the engine must be shut off
(SmartKey in starter switch position0
or1) when the parking brake is being
tested on a brake test dynamometer.
Active braking action through ESP
®
may otherwise seriously damage the
brake system.
Operational tests with the engine
running can only be conducted on a
two-axle dynamometer.
iIf the yellow ESP
® warning lampv
comes on while driving, the 4-ETS is be-
ing switched off temporarily to prevent
overheating of the drive wheel brakes.
In addition, the message
ESP unavail-
able See Operator’s Manual
appears
in the multifunction display.

104 Safety and SecurityAnti-theft systemsImmobilizer
The immobilizer prevents unauthorized
persons from starting your vehicle.
Activating
With the SmartKey
Remove the SmartKey from the starter
switch.
With KEYLESS-GO*

Press the KEYLESS-GO start / stop
button (
page 40) once.
The engine is turned off.

Open the driver’s door.Deactivating
With the SmartKey


Turn the SmartKey in the starter switch
to position2 (
page 38).
With KEYLESS-GO*


Switch on the ignition (
page 38).
Anti-theft alarm system
Once the alarm system has been armed, a
visual and audible alarm is triggered when
someone opens

a door


the tailgate


the hood
The alarm will stay on, even if the activat-
ing element (a door, for example) is imme-
diately closed.
The alarm system will also be triggered
when


the vehicle is raised, see “Tow-away
alarm” (
page 106)


the vehicle is opened with the mechan-
ical key, see “Unlocking the vehicle”
(page 459)


a door is opened from the inside, see
“Opening the doors from the inside”
(page 121)
iStarting the engine will also deactivate
the immobilizer.
In case the engine cannot be started
(yet the vehicle’s battery is charged),
the system is not operational. Contact
an authorized Mercedes-Benz Light
Truck Center or call
1-800-FOR-MERCedes (in the USA), or
1-800-387-0100 (in Canada).

105 Safety and Security
Anti-theft systems
Arming the alarm system
The alarm system is armed after you have
locked the vehicle with the SmartKey or
SmartKey with KEYLESS-GO*.
The alarm system indicator lamp is located
to the lower left of the hazard warning
flasher.1Alarm system indicator lamp

Make sure all doors and the tailgate are
closed.

Lock the vehicle (
page 67).
The turn signal lamps flash three times
to indicate that the vehicle is locked.
The alarm system is armed within ap-
proximately 10 seconds. Alarm system
indicator lamp 1 flashes.
iIf the alarm stays on for more than
30 seconds, a call to the Response
Center is initiated automatically by the
Tele Aid* system (
page 311) provid-
ed Tele Aid* service was subscribed to
and properly activated, and that neces-
sary cellular service and GPS coverage
are available.
iIf the turn signal lamps do not flash
three times, one of the following ele-
ments may not be properly closed:

a door


the tailgate
Close the respective element and lock
the vehicle again.

106 Safety and SecurityAnti-theft systemsDisarming the alarm system
Unlock the vehicle (
page 36).
The turn signal lamps flash once to
indicate that the vehicle is disarmed.Canceling the alarm
To cancel the alarm:
With the SmartKey

Insert the SmartKey in the starter
switch.
or

Press theŒ or ‹button on the
SmartKey.
With KEYLESS-GO*

Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft (1 m) of the vehicle.
or

Press the KEYLESS-GO start / stop
button (
page 40).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
Tow-away alarm
Once the tow-away alarm is armed, a visual
and audible alarm will be triggered when
someone attempts to raise the vehicle.
iThe alarm system will rearm automati-
cally again after approximately
40 seconds if neither a door nor the
tailgate is opened.
iThe tow-away protection alarm is trig-
gered, for example, if the vehicle is
lifted on one side.
If the alarm stays on for more than
30 seconds, a call to the Response
Center is initiated automatically by the
Tele Aid* system (
page 311) provid-
ed Tele Aid* service was subscribed to
and properly activated, and that neces-
sary cellular service and GPS coverage
are available.

107 Safety and Security
Anti-theft systems
Arming the tow-away alarm
Make sure all doors and the tailgate are
closed.

Lock your vehicle.
The tow-away alarm is automatically
armed after about 10 seconds.
Disarming the tow-away alarm

Unlock your vehicle.Switching off the tow-away alarm
To prevent triggering the tow-away alarm
feature, switch off the tow-away alarm be-
fore towing the vehicle, or when parking on
a surface subject to movement, such as a
ferry or auto train.
If the tow-away alarm is set to default en-
abled (
on) in the control system and you
wish to retain the default setting, you can
switch off the tow-away alarm temporarily
on a one-time basis as follows:

Switch off the ignition (
page 38).
With the tow-away alarm set to default
enabled (
on) in the control system, the
following message appears in the mul-
tifunction display.

If you now wish to deactivate the
tow-away alarm on a one-time basis,
press button + or - on the mul-
tifunction steering wheel.
The tow-away alarm is switched off.
The following message appears in the
multifunction display.
iWhen you unlock your vehicle, the
tow-away protection disarms automati-
cally.
The tow-away alarm remains disarmed
until you lock your vehicle again.
iThe tow-away alarm feature can be set
to default enabled (
on) or disabled (
off
)
using the control system (
page 191).


108 Safety and SecurityAnti-theft systems
Exit and lock the vehicle (
page 67).
The alarm system is armed indepen-
dently of whether the tow-alarm is
switched on or off.Canceling tow-away alarm
To cancel the alarm after it has been
triggered:
With the SmartKey

Insert the SmartKey in the starter
switch.
or

Press theŒ or ‹button on the
SmartKey.With KEYLESS-GO*

Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft (1 m) of the vehicle.
or

Press the KEYLESS-GO start/stop
button (
page 40).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
iThe tow-away alarm is switched off on
a one-time basis only. It will be armed
automatically the next time you lock
the vehicle.
If you have disabled the tow-away
alarm feature in the control system
(page 191), you can switch on the
tow-away alarm on a one-time basis as
described above.


109 Controls in detail
Locking and unlocking
Seats
Memory function*
Lighting
Instrument cluster
Control system
Automatic transmission
Good visibility
Climate control
3-zone automatic climate control*
Power windows
Power tilt/sliding sunroof*
Panorama roof with power tilt/sliding panel*
Driving systems
Loading
Useful features
