MERCEDES-BENZ R500 2006 W251 Owner's Manual

110 Controls in detailIn the “Controls in detail” section you will
find detailed information on how to oper-
ate the equipment installed in your vehicle.
If you are already familiar with the basic
functions of your vehicle, this section will
be of particular interest to you.
To quickly familiarize yourself with the ba-
sic functions of the vehicle, refer to the
“Getting started” section of this manual.
The corresponding page numbers are
given at the beginning of each segment.Locking and unlocking
For more information on locking and un-
locking, see the “Getting started” section
(page 36) and (
page 67).
SmartKey
Your vehicle comes supplied with two
SmartKeys, each with remote control and
a removable mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys are a differ-
ent color to help distinguish each
SmartKey unit.
The SmartKey provides an extended oper-
ating range. To prevent theft, however, it is
advisable to only unlock the vehicle when
you are in close proximity to it.
The SmartKey centrally locks and unlocks:

the doors


the tailgate


the fuel filler flap
SmartKey with remote control1‹Lock button
2ŠUnlock button* for tailgate
3Locking tab for mechanical key
4ŒUnlock button
5Battery check lamp
6ÂPanic button (
page 95)

111 Controls in detail
Locking and unlocking
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. It is possible
for children to open a locked door from the
inside, which could result in an accident
and/or serious personal injury.!To prevent possible malfunction, avoid
exposing the SmartKey to high levels of
electromagnetic radiation.
iUSA only:
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
iCanada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions:
(1) This device may not cause
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation of the device.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.iYou can also open and close the power
windows (
page 248) and tilt/sliding
sunroof* (page 255), or the
tilt/sliding panel* (
page 259) using
the SmartKey.

112 Controls in detailLocking and unlockingFactory setting
Global unlocking
Press buttonŒ.
All turn signal lamps flash once. The
locking knobs in the doors move up.
The anti-theft alarm system is
disarmed.
The vehicle will lock again automatically
and reactivate the anti-theft alarm system
within approximately 40 seconds of un-
locking if


neither door nor tailgate is opened


the SmartKey is not inserted in the
starter switch


the central locking switch is not
activatedGlobal locking

Press button‹.
With the tailgate and all doors closed,
the turn signal lamps flash three times.
The locking knobs on the doors move
down. The anti-theft alarm system is
armed.
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that
pressingŒ only unlocks the driver’s
door and the fuel filler flap.

Press and hold buttonsŒ and‹
simultaneously for about 5 seconds
until battery check lamp5
(page 110) flashes twice.
The SmartKey will then function as fol-
lows:Unlocking driver’s door and fuel filler
flap

Press buttonΠonce.
All turn signal lamps flash once. The
locking knob in the driver’s door moves
up. The anti-theft alarm system is
disarmed.
Global unlocking

Press buttonΠtwice.
All turn signal lamps flash once. The
locking knobs in the doors move up.
The anti-theft alarm system is
disarmed.

113 Controls in detail
Locking and unlocking
Global locking
Press button‹.
With the tailgate and all doors closed,
the turn signal lamps flash three times.
The locking knobs on the doors move
down. The anti-theft alarm system is
armed.
Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about 6 seconds
until battery check lamp5
(page 110) flashes twice.Checking the batteries

Press button‹orŒ.
Battery check lamp5 (
page 110)
comes on briefly to indicate that the
SmartKey batteries are in order.
!If you cannot lock or unlock the vehicle
with the SmartKey, then either the bat-
teries in the SmartKey are discharged,
the SmartKey is malfunctioning, or the
vehicle battery is drained.

Check the batteries in the
SmartKey and replace them if
necessary (
page 463).


Use the mechanical key to unlock
the driver’s door (
page 459).


Lock the vehicle as described in the
“Practical hints” section
(page 460).


Have the vehicle battery and the
vehicle battery connections
checked (
page 487).
If the SmartKey is malfunctioning, con-
tact an authorized Mercedes-Benz
Light Truck Center.
iIf battery check lamp5 does not
come on briefly during check, the
SmartKey batteries are discharged.
Replace the batteries (
page 463).
You can obtain the required batteries
at any authorized Mercedes-Benz Light
Truck Center.
iIf the batteries are checked within
signal range of the vehicle, pressing the
button‹orŒ will lock or un-
lock the vehicle accordingly.

114 Controls in detailLocking and unlockingUnlocking and opening the tailgate
You can unlock and open the tailgate sep-
arately.
A minimum height clearance of 7.2 ft
(2.20 m) is required to open the tailgate.
Press and hold buttonŠ on the
SmartKey until the tailgate unlocks and
begins to open.Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:

Have the SmartKey deactivated by an
authorized Mercedes-Benz Light Truck
Center.

Report the loss of the SmartKey or the
mechanical key immediately to your
car insurance company.

If necessary, have the mechanical lock
replaced.
Your authorized Mercedes-Benz Light
Truck Center will be glad to supply you
with a replacement.
SmartKey with KEYLESS-GO*
Vehicles equipped with KEYLESS-GO come
with two SmartKeys with KEYLESS-GO,
each with remote control and a removable
mechanical key.
The locking tabs for the mechanical key
portion of the two SmartKeys with
KEYLESS-GO are a different color to help
distinguish each SmartKey with
KEYLESS-GO unit.
The function of the SmartKey overrules the
KEYLESS-GO function.
The KEYLESS-GO function is integrated
into the SmartKey. On these vehicles, the
validity of the SmartKey with KEYLESS-GO
is checked when you grasp an outside door
handle.
If the SmartKey with KEYLESS-GO is valid,
your vehicle unlocks

the doors


the tailgate


the fuel filler flap
!The tailgate swings open upwards auto-
matically. Always make sure there is
sufficient overhead clearance.
Vehicles with tailgate opening/closing
system*:
To stop the opening procedure, press
buttonŠ on the SmartKey. The tail-
gate stops moving.
iIf the vehicle was previously centrally
locked with the SmartKey, the tailgate
will lock automatically when closed.
The turn signals will flash three times to
confirm locking.

115 Controls in detail
Locking and unlocking
SmartKey with KEYLESS-GO*1‹ Lock button
2Š Unlock button* for tailgate
3Mechanical key locking tab
4ΠUnlock button
5Battery check lamp
6Â Panic button (
page 95)
Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.!To prevent possible malfunction, avoid
exposing the SmartKey with
KEYLESS-GO to high levels of electro-
magnetic radiation.
iUSA only:
This device complies with Part 15 of
the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.

116 Controls in detailLocking and unlocking
Important notes on using KEYLESS-GO*

You can also use the SmartKey with
KEYLESS-GO like a normal SmartKey
(page 110).


You can combine KEYLESS-GO func-
tions with normal SmartKey functions
(e.g. unlocking with KEYLESS-GO and
locking with the ‹button).


Always carry the SmartKey with
KEYLESS-GO with you.


Never store the SmartKey with
KEYLESS-GO together with

electronic items such as a cellular
phone or another SmartKey with
KEYLESS-GO


metallic objects such as coins or
metal foil
Doing so could impair the function of
the KEYLESS-GO system.


To lock or unlock the vehicle, the
SmartKey with KEYLESS-GO must be
located outside the vehicle within ap-
proximately 3 ft (1 m) of the respective
door or the tailgate.


In order to start the engine with the
SmartKey with KEYLESS-GO:

The SmartKey with KEYLESS-GO
must be located in the vehicle.


All doors must be closed.


The brake pedal must be firmly de-
pressed. Do not depress the accel-
erator.
iCanada only:
This device complies with RSS-210 of
Industry Canada. Operation is subject
to the following two conditions:
(1) This device may not cause
interference, and
(2) this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation of the device.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.iYou can also open and close the power
windows (
page 248) and tilt/sliding
sunroof* (page 255), or the
tilt/sliding panel* (
page 259) using
the SmartKey with KEYLESS-GO.

117 Controls in detail
Locking and unlocking


If the SmartKey with KEYLESS-GO is
positioned farther away from the vehi-
cle, the system may no longer recog-
nize the SmartKey with KEYLESS-GO.
The vehicle then cannot be locked or
the engine started via the KEYLESS-GO
system.


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle while starter
switch position1(e.g. if a passenger
exits the vehicle with the SmartKey
with KEYLESS-GO), the message
Key
not detected
will appear in the multi-
function display while driving off.
Find the SmartKey with KEYLESS-GO or
change its present location immediate-
ly (e.g. place it on the front passenger
seat or insert it in shirt pocket).


If the SmartKey with KEYLESS-GO is re-
moved from the vehicle with the engine
running (e.g. if a passenger exits the
vehicle with the SmartKey with
KEYLESS-GO), the message
Key not
detected
will appear in the multifunc-
tion display while driving off.
Find the SmartKey with KEYLESS-GO or
change its present location immediate-
ly (e.g. place it on the front passenger
seat or insert it in shirt pocket).


Remember that the engine can be
started by anyone with a SmartKey
with KEYLESS-GO that is left inside the
vehicle.
Possibility 1: (One SmartKey with
KEYLESS-GO in the vehicle, one
SmartKey with KEYLESS-GO outside
the vehicle):
If you leave the SmartKey with
KEYLESS-GO behind when exiting and
locking the vehicle, no message
appears in the multifunction display.Possibility 2: (One SmartKey with
KEYLESS-GO in the vehicle, no
SmartKey with KEYLESS-GO outside
the vehicle):
When exiting and trying to lock the ve-
hicle, the message
Key detected in
vehicle
will appear in the multifunc-
tion display. The vehicle will not be
locked.

118 Controls in detailLocking and unlockingFactory setting
Global unlocking
Grasp an outside door handle.
All turn signal lamps flash once. The
locking knobs in the doors move up.
The anti-theft alarm system is dis-
armed.
The vehicle will lock again automatically
and reactivate the anti-theft alarm system
within approximately 40 seconds of
unlocking if


neither door nor tailgate is opened


the central locking switch is not
activatedGlobal locking

Press the lock button at an outside
door handle (
page 68) or the tailgate
(
page 120).
With the tailgate and all doors closed,
the turn signal lamps flash three times.
The locking knobs on the doors move
down. The anti-theft alarm system is
armed.Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey with
KEYLESS-GO so when you grasp the driv-
er’s door handle only the driver’s door and
the fuel filler flap unlocks.

Press and hold buttonsŒ and‹
simultaneously for about 6 seconds
until battery check lamp5
(page 115) flashes twice.
The SmartKey with KEYLESS-GO will
then function as follows:
Unlocking driver’s door and fuel filler
flap

Grasp the driver’s outside door handle.
All turn signal lamps flash once. The
locking knob in the driver’s door moves
up. The anti-theft alarm system is dis-
armed.
i If the vehicle has been parked for more
than 72 hours, you must pull an outside
door handle in order to activate the
KEYLESS-GO function.
iThe vehicle could be inadvertently
unlocked if the SmartKey with
KEYLESS-GO is within 3 ft (1 m) of the
vehicle and

an outside door handle is splashed
with water
or


you attempt to clean the outside
door handle

119 Controls in detail
Locking and unlocking
Global unlocking
Grasp any outside door handle other
than the driver’s outside door handle.
All turn signal lamps flash once. The
locking knobs in the doors move up.
The anti-theft alarm system is dis-
armed.
Global locking

Press the lock button on an outside
door handle (
page 68) or the tailgate
(
page 120).
All turn signal lamps flash three times.
The locking knobs in the doors move
down. The anti-theft alarm system is
armed.
Restoring to factory setting

Press and hold buttonsŒ and‹
simultaneously for about 6 seconds
until battery check lamp5
(page 115) flashes twice.Checking the battery

Press button‹orŒ.
Battery check lamp5 (
page 115)
comes on briefly to indicate that the
SmartKey with KEYLESS-GO battery is
in order.
!If you can no longer lock or unlock the
vehicle with the SmartKey with
KEYLESS-GO, then the battery in the
SmartKey is discharged, the SmartKey
with KEYLESS-GO is malfunctioning or
the vehicle battery is drained.

Check the battery in the SmartKey
with KEYLESS-GO (
page 119)
and replace it if necessary
(
page 463).


Use the mechanical key to unlock
the driver’ door (
page 459).


Lock the vehicle as described in the
“Practical hints” section
(page 460).


Have the vehicle battery and the
vehicle battery connections
checked (
page 487).
If the SmartKey with KEYLESS-GO is
malfunctioning, contact an authorized
Mercedes-Benz Light Truck Center.
iIf battery check lamp5 (
page 115)
does not come on briefly during check,
the SmartKey with KEYLESS-GO bat-
tery is discharged.
Replace the battery (
page 463).
You can obtain the required battery at
any authorized Mercedes-Benz Light
Truck Center.
iIf the battery is checked within signal
range of the vehicle, pressing the
button‹orŒ will lock or un-
lock the vehicle accordingly.
