Page 59 of 705
58 Safety and SecurityOccupant safetyEmergency tensioning device (ETD),
seat belt force limiter
The seat belts for the front and rear outer
seats are equipped with emergency ten-
sioning devices and belt force limiters.
The ETD is designed to activate in the
following cases:
in frontal or rear-end impacts exceed-
ing the system deployment threshold
in certain vehicle rollovers
if the restraint systems are operational
and functioning correctly,
see=indicator lamp (
page 552)In an impact, emergency tensioning
devices remove slack from the belts in
such a way that the seat belts fit more
snugly against the body. Belt force limiters,
when activated, are employed to help
reduce the peak force exerted by the seat
belts on occupants during a crash.
When using a seat belt to secure infant
or toddler restraints or children in
booster seats, always follow the child
seat manufacturer's instructions.
i
The ETDs for the front seats will only acti-
vate if the front seat belt is fastened (latch plate
properly inserted into buckle).
The ETDs for the rear outer seats will activate
with or without the respective seat belt fastened.
Warning!
G
A pyrotechnic emergency tensioning device
(ETD) that was activated must be replaced.
When disposing of the pyrotechnic emer-
gency tensioning device, our safety instruc-
tions must be followed. These are available
at your authorized Mercedes-Benz Center.
PRE-SAFE
® has electrically operated
reversible pre-tensioners that do not require
replacement after activation.
Page 60 of 705
59 Safety and Security
Occupant safety
Luxury active head restraints (S 600 only)
The active head restraints are intended to
offer the driver and front passenger in-
creased protection from head and neck in-
jury. In the event of a rear-end collision,
the active head restraints on the driver’s
and front passenger’s seats are designed
to move forward in the direction of travel,
providing the head with increased support
earlier on in the collision sequence. The ac-
tive head restraints move forward whether
the seat is occupied or not.
If the luxury active head restraints have
been triggered in an accident, the luxury
active head restraints must be reset. Oth-erwise, the luxury active head restraints
cannot offer any additional protection in
the event of another rear-end collision.
For information on resetting the activated
active head restraints, see “Resetting acti-
vated head restraints (S 600 only)”
(
page 618).
You cannot remove the active head re-
straint on the driver’s and passenger’s
seats.
For removal contact an authorized
Mercedes-Benz Center.
For information on head restraint adjust-
ment, see “Head restraints” (
page 324).
Warning!
G
Only use seat or head restraint covers which
have been tested and approved by
Mercedes-Benz for your vehicle model.
Using other seat or head restraint covers
may interfere with or prevent the activation
of the active head restraints. Contact an
authorized Mercedes-Benz Center for avail-
ability.
Do not attach any objects (e.g. hangers) to
the head restraint posts. Otherwise, the ac-
tive head restraints may not be able to func-
tion properly or offer the intended degree of
protection in the event of an accident.Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that it is as close to
the head as possible and the center of the
head restraint supports the back of the head
at eye level. This will reduce the potential for
injury to the head and neck in the event of
an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Page 65 of 705
64 Safety and SecurityOccupant safety
Installation of infant and child restraint
systems
This vehicle is equipped with tether an-
chorages for a top tether strap at each of
the rear seating positions.
1Cover of top anchorage ring
Bring the rear power seat backrest* to
a fully upright position (
page 320).
Remove cover1 from anchorage ring.
Store cover1 in a convenient place
(e.g. glove box).
Guide tether strap between head re-
straint and top of seat back.
Warning!
G
Infants and small children should never
share a seat belt with another occupant.
During an accident, they could be crushed
between the occupant and seat belt.
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle
and/or the child is not properly secured in
the child restraint.
Children too big for a toddler restraint must
ride in seats using regular seat belts. Posi-
tion shoulder belt across chest and shoul-
der, not face or neck. A booster seat may be
necessary to achieve proper belt positioning
for children over 41 lbs until they reach a
height where a lap/shoulder belt fits
properly without a booster.
When the child restraint is not in use,
remove it from the vehicle or secure it with
the seat belt to prevent the child restraint
from becoming a projectile in the event of
an accident.
Do not leave children unattended in the
vehicle, even if the children are secured in a
child restraint system. Unsupervised chil-
dren in a child restraint system may use
vehicle equipment and may cause an acci-
dent and/or serious personal injury.
Page 68 of 705
67 Safety and Security
Occupant safety
Override switch for rear passenger compartment
You can disable select functions in the rear
passenger compartment for added safety
(for instance when you have children riding
in the rear passenger compartment).
You can disable the following functions in
the rear passenger compartment:
rear door window operation
(page 353)
adjustment of front passenger seat
from the rear* (
page 320)
rear center console lighter
(page 458)
sunblinds for panorama roof*
(page 443)
rear window sunshade (
page 456)
and rear side window sunshades
(
page 355)The override switch is located on the driv-
er’s door.
1Override switch
2Indicator lamp
Activating: Press switch 1.
Indicator lamp2 comes on. The func-
tions in the rear are disabled.
Deactivating: Press switch 1 again.
Indicator lamp2 goes out. The func-
tions in the rear are enabled again.Warning!
G
Activate the override switch when children
are riding in the back seats of the vehicle.
The children may otherwise injure them-
selves, e.g. by becoming trapped in the win-
dow opening.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock your vehicle. Do not leave children un-
attended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.i
Operation of the rear door windows with the
switches located in the driver’s door is still pos-
sible.
Page 319 of 705
318 Controls in detailSeatsSeat adjustment
You can adjust the lumbar support, multi-
contour seats for driver and front passen-
ger, as well as drive-dynamic multicontour
seats using COMAND (
page 236).
Warning!
G
All seat, head restraint adjustments, as well
as fastening of seat belts, must be done be-
fore the vehicle is put into motion.Warning!
G
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause
the driver to lose control of the vehicle.
Never ride in a moving vehicle with the seat
back in an excessively reclined position as
this can be dangerous. You could slide un-
der the seat belt in a collision. If you slide
under it, the belt would apply force at the ab-
domen or neck. That could cause serious or
fatal injuries. The seat backrest and seat
belts provide the best restraint when the
wearer is in a nearly upright position and
belts are properly positioned on the body.
Your seat must be adjusted so that you can
correctly fasten your seat belt
(page 339).
Never place hands under the seat or near
any moving parts while a seat is being ad-
justed.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated when the respective door is
open. Therefore, do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
Warning!
G
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats
whenever possible. Regardless of seating
position, children 12 years old and under
must be seated and properly secured in an
appropriate infant, or toddler restraint, or
booster seat recommended for the size and
weight of the child. For additional informa-
tion, see “Children in the vehicle”
(page 61).
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
Page 321 of 705
320 Controls in detailSeatsRear power seat* adjustment
(rear outer seats)Example rear right door1Seat cushion tilt
2Seat backrest tilt
3Folding down and placing upright head
restraint (
page 326)
4Head restraint tilt (
page 326)
5Seat fore and aft adjustment
Switch on the ignition (
page 315).
or
Open the respective door.
Adjust desired seat using seat
switches1,2 and5.Adjusting front passenger seat from
driver’s seat/rear*
Warning!
G
The seat belt only offers its intended protec-
tion when the seat backrest is in a nearly
vertical position and the occupant is sitting
upright. Avoid sitting in positions that pre-
vent the seat belt from being properly posi-
tioned against the body (
page 339). You
should therefore adjust the backrest to a po-
sition as upright as possible.
Warning!
G
When adjusting the front passenger seat,
make sure the seat, if occupied, is as far
from the passenger front air bag as possi-
ble.
Otherwise, the passenger could be seriously
or even fatally injured in the event of an ac-
cident or braking maneuver.
Make sure no one is caught or injured while
the seat is being adjusted.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the power seats
can be operated when the respective door is
open. Therefore, do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.!
Do not move the front passenger seat com-
pletely forward if objects are stored in the parcel
net in the front passenger-side footwell. Items in
the net may be damaged.
Page 330 of 705
329 Controls in detailSeats
With the easy-entry/exit feature activated,
the steering wheel and driver’s seat will re-
turn to their last set memory position or a
factory-set maximum forward position
when you:
close the driver’s door with the ignition
switched on
insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 317) once
with the driver’s door closed. With the easy-entry/exit feature activated
the steering wheel tilts upwards and the
driver’s seat moves a few inches to the
rear when you:
remove the SmartKey from the starter
switch,
or
open the driver’s door with the
SmartKey in starter switch position 0
or 1 or the KEYLESS-GO* start/stop
button (
page 317) in position 1.
!
Do not activate the easy-entry/exit feature
if the seat backrest is in an excessively reclined
position. Doing so could cause damage to front
or rear seats.
First move the seat backrest to an upright posi-
tion.
i
For safety reasons, the driver’s seat will not
return to its last set position with the easy-en-
try/exit feature activated if the system recogniz-
es the last set position as an extreme forward
position. Instead, the driver’s seat will remain at
or move to a factory-set maximum forward posi-
tion. To again fully return the driver’s seat toyour last set position or to memory position, ad-
just the seat to the desired position or press and
hold the respective memory position button
(
page 337).
i
The last set driver’s seat and steering wheel
positions are stored when
the ignition is switched off
the position is stored in memory
(page 336)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
If the current seat position falls into a factory-set
position range and the system recognizes the
current seat position to be rearward enough for
easy entry and exit, the driver’s seat will not
move to the rear when the easy-entry/ exit fea-
ture is activated.
The adjustment procedure is briefly interrupted
when the engine is started.Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All driver’s seat and steering wheel ad-
justments must be completed before setting
the vehicle in motion. Driving off with the
driver’s seat/steering wheel still adjusting
could cause the driver to lose control of the
vehicle.
Page 354 of 705
353 Controls in detail
Power windows
Power windows
Opening and closing power windows
The door windows are opened and closed
electrically. The switches
for all side windows are on the driver’s
door
for the front passenger side window
are on the front passenger door
for each rear side window are on the
rear doors
1Left front door window
2Right front door window
3Left rear door window
4Right rear door window
Warning!
G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
Activate the override switch (
page 67)
when children are riding in the back seats of
the vehicle. The children may otherwise in-
jure themselves, e.g. by becoming trapped
in the window opening.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if the switch was pressed past the resis-
tance point and released, by pressing the
lower part of the respective switch again.
The door windows are equipped with the ex-
press-close and automatic reversal func-
tion. If the window encounters an
obstruction that blocks its path in a circum-
stance where you pressed the switch past
the resistance point and released it to close
the window, the automatic reversal function
will stop the window and open it slightly.
If the window encounters an obstruction
that blocks its path in a circumstance where
you are closing the window by pressing and
holding the switch, by pressing and holding
button ‹ on the SmartKey or SmartKey
with KEYLESS-GO*, by pressing and holding
the sensor surface (vehicles with
KEYLESS-GO*) on an outside door handle,
or by pressing and holding button, on
the climate control panel, the automatic re-
versal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
Page 543 of 705
542 OperationVehicle careHard plastic trim items
Use Mercedes-Benz approved Interior
Care, a soft, lint-free cloth and apply
with light pressure.
Steering wheel
Wipe with a damp cloth and dry thor-
oughly or clean with Mercedes-Benz
approved Leather Care.
Carpets
Use Mercedes-Benz approved Carpet
and Fabric Care for cleaning the car-
pets.
Headliner and shelf below rear window
Use a soft bristle brush or a dry-sham-
poo cleaner in case of excessive dirt. Seat belts
Only use clear, lukewarm water and
soap.
Upholstery
Using aftermarket seat covers or wearing
clothing that have the tendency to give off
coloring (e.g. when wet, etc.) may cause
the upholstery to become permanently dis-
colored. By lining the seats with a proper
intermediate cover, contact-discoloration
will be prevented.Leather upholstery
Wipe leather upholstery with a damp
cloth and dry thoroughly or clean with
Mercedes-Benz approved Leather
Care.
Exercise particular care when cleaning per-
forated leather as its underside should not
become wet.
Wood trims
Dampen cloth using water and use
damp cloth to clean wood trims in your
vehicle.
!
To prevent scratches, do not use scouring
agents.
!
The webbing must not be treated with
chemical cleaning agents. Do not dry the web-
bing at temperatures above 176°F (80°C) or in
direct sunlight.
Warning!
G
Do not bleach or dye seat belts as this may
severely weaken them. In a crash they may
not be able to provide adequate protection.
!
Do not use solvents like tar remover or
wheel cleaner nor polishes or waxes as these
may be abrasive.
!
S 600 only: Do not cover the luxury active
head restraints*.
