25 At a glance
Exterior view
Item
Page
1
Trunk

Unlocking


Opening and closing


Minispare wheel


Vehicle tool kit
436
436
629
611
2
Rear lamps
622
3
Rear window, defrosting
430
4
Fuel filler flap
Gasoline
489
664
5
Doors

Locking and unlocking


Opening and closing
304
312
Item
Page
6
Exterior rear view mirror
Parking position
334
335
7
Towing eye bolt
General information
644
642
8
Rims and tires

Checking tire inflation
pressure


Minispare wheel


Flat tire
655
511
613
629
9
Hood, opening
Engine oil
Coolant
492
494
497
Item
Page
a
Headlamp cleaning system
346
b
Front lamps
622
c
Windshield wipers
Wiper blades, replacing
Wiper blades, cleaning
351
627
540
d
Window, cleaning
540
e
Roofs

Power tilt/sliding sunroof


Panorama roof with power
tilt/sliding panel*
441
443

244 Control systemsInstrument cluster control system
Assistance* (
page 252)
Service (
page 253)
Settings (
page 254)
Commands/submenusDisplaying the distance graphic*
(DISTRONIC Plus*)
Call up vehicle malfunction, warning
and system status messages stored in
memory
Set daytime running lamp mode (USA only)
Distance warning function*
activating/deactivating
Check tire inflation pressure
Switch additional speedometer on or off
Switch on the Dynamic Rear View Moni-
tor* automatically
Call up maintenance service display
Switch radar sensors* on or off
Check engine oil level*
i
The headings used in the menus table are
designed to facilitate navigation within the sys-
tem and are not necessarily identical to those
shown in the control system displays. The first function displayed in each menu will au-
tomatically show you which part of the system
you are in.

253 Control systems
Instrument cluster control system
Switching on the Dynamic Rear View
Monitor* automatically
Press ( or & to select the
“Assistance” menu.

Press % or $ to select the
“Rearview camera” function.

Press #.

Press # again if you would like to
change the current status.The following settings are available:
Service menu
The “Service” menu is used for

calling up messages


checking tire inflation pressure elec-
tronically with the Advanced TPMS*
(standard on U.S. vehicles)


activating Run Flat Indicator
(Canada only)


calling up the maintenance service in-
dicator display


check engine oil level*Calling up vehicle malfunction, warning
and system status messages stored in
memory
Use the vehicle status message memory
menu to scan malfunction and warning
messages that may be stored in the sys-
tem. Such messages appear in the multi-
function display and are based on
conditions or system status the vehicle’s
system has recorded.
The vehicle status message memory menu
only appears if there are any messages
stored.
i
The image from the Dynamic Rear View
Monitor is shown on the COMAND display.
“On when in
Reverse”
The Dynamic Rear View
Monitor automatically
switches on when reverse
gear is engaged.
“OFF”
The Dynamic Rear View
Monitor is not switched on.
i
The menu overview can be found on
(
page 243).
Warning!
G
Malfunction and warning messages are only
indicated for certain systems and are inten-
tionally not very detailed. The malfunction
and warning messages are simply a remind-
er with respect to the operation of certain
systems and do not replace the owner’s
and/or driver’s responsibility to maintain
the vehicle’s operating safety by having all
required maintenance and safety checks


254 Control systemsInstrument cluster control system
Press ( or & to select the
“Service” menu.
If conditions have occurred causing
status messages to be recorded, the
number of messages appears in the
multifunction display: “2 Messages”.

Press % or $ to select the mes-
sage.

Press # to confirm.Checking tire inflation pressure
For information about checking tire infla-
tion pressure (
page 511).
Activating Run Flat Indicator*
For information about activating Run Flat
Indicator (
page 515).
Calling up the maintenance service in-
dicator display
For information about maintenance
(
page 532).
Checking engine oil level (S 600)*
For information about checking engine oil
level (
page 494).
Settings menu
In the “Settings” menu, you can:

switch the daytime driving lamps on or
off


switch the additional speedometer on
or off


switch the radar sensors* on or off.
performed on the vehicle and by bringing
the vehicle to an authorized Mercedes-Benz
Center to address the malfunction and
warning messages (
page 557).
i
See the “Practical hints” section for mal-
function and warning messages (
page 557).
i
If you turn the SmartKey in the starter
switch to position0 and then back to position2,
all messages will be deleted from the message
memory.
i
The menu overview can be found on
(
page 243).


437 Controls in detailTrunk
Vehicles with trunk opening/closing
system*
1Remote trunk opening/closing* switch
Press and hold switch1 until the
trunk is opened.
The indicator lamp in switch1 comes
on and remains lit until the trunk
closed.
To interrupt the closing procedure:

Release switch1.Trunk opening-height restriction*
Vehicles with trunk opening/closing sys-
tem*:
The trunk lid opening height can be limited
when transporting goods on a roof rack
(e.g. presence of an optional MB sport lug-
gage container). When activated, the trunk
opens to approximately the height of the
roof edge.

Activate the limiting opening height of
trunk lid using the COMAND system
(page 227).
Closing trunkClosing trunk from outside manually
1Handles

Lower trunk lid by pulling firmly on
handles1.

Close trunk lid with hands placed flat
on trunk lid.
The power closing assist automatically en-
sures that the lid is pulled closed com-
pletely (
page 313).
i
Do not place the SmartKey in the open
trunk. You may lock yourself out.
i
If the vehicle was previously centrally
locked, the trunk will lock automatically after
closing it. All turn signal lamps flash three times
to confirm locking.
Vehicles with KEYLESS-GO*: To prevent a possi-
ble inadvertent lockout, the trunk will open auto-
matically if a SmartKey with KEYLESS-GO is
recognized inside the vehicle or in the trunk. The vehicle is only locked when the turn signals
flash three times. If you are carrying a second
SmartKey with KEYLESS-GO with you, you can
still lock the vehicle.

479 Operation
Driving instructions
Driving instructions
Drive sensibly – save fuel
Fuel consumption, to a great extent,
depends on driving habits and operating
conditions.
To save fuel you should:

Keep tires at the recommended tire
inflation pressures.


Remove unnecessary loads.


Remove roof rack when not in use.


Allow engine to warm up under low
load use.


Avoid frequent acceleration and decel-
eration.


Have all maintenance work performed
at the intervals specified in the Mainte-
nance Booklet and as required by the
Maintenance System (U.S. vehicles) or
FSS PLUS (Canada vehicles). Contact
an authorized Mercedes-Benz Center.
Fuel consumption is also increased by driv-
ing in cold weather, in stop-and-go traffic,
on short trips, and in hilly area.
Drinking and driving
PedalsPower assistance
Warning!
G
Drinking and driving and/or taking drugs
and driving are very dangerous combina-
tions. Even a small amount of alcohol or
drugs can affect your reflexes, perceptions
and judgment.
The possibility of a serious or even fatal ac-
cident are greatly increased when you drink
or take drugs and drive.
Do not drink or take drugs and drive or allow
anyone to drive who has been drinking or
taking drugs.
Warning!
G
Make sure that absolutely no objects are ob-
structing the pedals’ range of movement.
Keep the driver’s footwell clear of all obsta-
cles. If there are any floormats or carpets in
the footwell, make sure that the pedals still
have sufficient clearance.Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle.

515 Operation
Tires and wheels

Press#.
The message
Tire pressure monitor
reactivated
appears in the multifunction display.
After a few minutes driving, the current
tire inflation pressure values are ac-
cepted as reference values and then
monitored.
If you wish to cancel activation:

PressL.
or

Press$ to exit menu screen.Run Flat Indicator (Canada only)
While the vehicle is being driven, the Run
Flat Indicator monitors the set tire inflation
pressures by evaluating each wheel’s rota-
tional speed. This allows the system to de-
tect a significant loss of pressure in a tire.
If a wheel’s rotational speed changes due
to falling tire inflation pressure, you will
see a corresponding warning message in
the multifunction display.
The Run Flat Indicator may function in a re-
stricted manner or with a delay if:


snow chains are mounted to the
vehicle


in presence of ice and snow


you are driving on a loose surface (e.g.
sand or gravel)


you are driving in a very sporty manner
(involving rapid acceleration or high
speeds in curves)
i
When the wheel positions are changed on
the vehicle, it is possible that the air pressure is
temporarily displayed for the wrong position.
This will be corrected after driving for several
minutes, and the air pressure will be shown for
the correct position.
Warning!
G
When the multifunction display shows the
message “Tire pressure Check tires”, one or
more of your tires is significantly under-in-
flated. You should stop and check your tires
as soon as possible, and inflate them to the
proper tire inflation pressure as indicated on
the vehicle’s tire information placard. Driv-
ing on a significantly underinflated tire caus-
es the tire to overheat and can lead to tire
failure. Under-inflation also reduces fuel ef-
ficiency and tire tread life, and may affect
the vehicle’s handling and stopping ability.
Each tire, including the spare, should be
checked monthly when cold and set to the
tire inflation pressure recommended by the
vehicle manufacturer on the vehicle placard
or the tire inflation pressure label.

516 OperationTires and wheels
Reactivating the Run Flat Indicator
The tire inflation pressure monitor must be
reactivated in the following situations:

If you have changed the tire inflation
pressure


If you have replaced the wheels or tires


If you have installed new wheels or
tires

Using the tire placard on the driver’s
door B-pillar (
page 503) or, if avail-
able, the inside of the fuel filler flap
(
page 489), make sure the tire infla-
tion pressure of all four tires is correct.

Switch on the ignition (
page 315).

Press( or& to select the menu
“Service”.

Press$ or% to select “Tire
pressure”.

Press#.
The message
Run Flat Indicator
active
Reactivation possible: OK
appears in the multifunction display.

Press#.
The message
Tire pressure
now OK?
appears in the multifunction display.
Warning!
G
The Run Flat Indicator does not provide a
warning for wrongly selected tire inflation
pressures. Always adjust tire inflation pres-
sure according to the placard on the driver’s
door B-pillar or fuel filler flap.
The Run Flat Indicator does not replace reg-
ular checks of the tire inflation pressures
since a gradual pressure loss in all four tires
cannot be detected by the Run Flat
Indicator.
The Run Flat Indicator is not able to issue a
warning due to a sudden dramatic loss of
tire inflation pressure (e.g. tire blowout
caused by a foreign object). In this case
bring the vehicle to a halt by carefully apply-
ing the brakes and avoiding abrupt steering
maneuvers.
Warning!
G
The Run Flat Indicator can only warn you in
a reliable manner if you have set the correct
tire inflation pressures for each tire.
If an incorrect tire inflation pressure was
set, the system will monitor the pressure ac-
cording to the incorrect value.
i
The menu overview can be found on
(
page 243).

517 Operation
Tires and wheels
If you wish to confirm activation:
Press$ or% to select “Yes”.

Press#.
The message
Run Flat Indicator
reactivated
appears in the multifunction display.
After a certain “learning phase”, the Run
Flat Indicator checks the set pressure val-
ues for all four tires.
If you wish to cancel activation:

PressL.
or
When the message
Tire pressure
now OK?
appears in the multifunction display:

Press$ or% to select “No”.

Press#.Potential problems associated with
underinflated and overinflated tires
Underinflated tires
Underinflated tires can:


cause excessive and uneven tire wear


adversely affect fuel economy


lead to tire failure from being
overheated


adversely affect handling
characteristicsOverinflated tires
Overinflated tires can:


adversely affect handling
characteristics


cause uneven tire wear


be more prone to damage from road
hazards


adversely affect ride comfort


increase stopping distance
Warning!
G
Follow recommended tire inflation
pressures.
Do not underinflate tires. Underinflated tires
wear excessively and / or unevenly,
adversely affect handling and fuel economy,
and are more likely to fail from being
overheated.
Warning!
G
Follow recommended tire inflation
pressures.
Do not overinflate tires. Overinflated tires
can adversely affect handling and ride
comfort, wear unevenly, increase stopping
distance, and result in sudden deflation
(blowout) because they are more likely to
become punctured or damaged by road
debris, potholes etc.

567 Practical hints
What to do if …?
Display
Possible cause/consequence
Possible solution
Park Assist
inoperative
Park Assist* is unavailable due to a mal-
function.

Visit an authorized Mercedes-Benz Center as soon as possible.
PRE-SAFE
inoperative
See Owner's Manual
PRE-SAFE
® itself has failed. All other occu-
pant safety systems, such as the air bags,
are still available.

Visit an authorized Mercedes-Benz Center as soon as possible.
Check tires
then restart
Run Flat Indicator
There was a warning message about a loss
in tire inflation pressure and the Run Flat In-
dicator* has not been restarted yet.

Check and adjust tire inflation pressure as required
(page 514).

Then restart the Run Flat Indicator* (
page 515).
Radar sensor
deactivated
See Oper. Manual
You attempt to activate DISTRONIC Plus*
or Park Assist* even though you have
switched off the radar sensors* on the vehi-
cle.

Check if the radar sensors* may be switched on (
page 256).

Switch on the radar sensors* using the instrument cluster
control system.
Run Flat Indicator
inoperative
The Run Flat Indicator* is malfunctioning.

Visit an authorized Mercedes-Benz Center as soon as possible.
Service X
due
Service X must be carried out (
page 532).

Have the maintenance service carried out by an authorized
Mercedes-Benz Center.
Service X exceeded
by X days
by XXX mls (km)
Service X must be carried within the next ...
or before you have driven ... miles (kilome-
ters) (
page 532).

Have the maintenance service carried out by an authorized
Mercedes-Benz Center as soon as possible.
Shift to P or N
to start engine
You have attempted to start the engine
while the automatic transmission was set to
position R or D.

Shift the automatic transmission to P or N (
page 367).
