MERCEDES-BENZ S550 4MATIC 2008 W221 Owner's Manual

500 Controls in detail
Loading and storing
Trunk
Storage spaces under trunk floor
You can place a suitcase in the hollow un-
der the front part of the trunk floor.
1Trunk floor
2Storage spaces1Storage space
2Trunk floorCargo tie-down hooks
4 hooks are located in the trunk.
Carefully secure cargo by applying
even load on all hooks with rope of suf-
ficient strength to hold down the cargo.
!Fold down the suitcase handle before clos-
ing the trunk to avoid damaging the trunk lid.

501 Controls in detail
Loading and storing
Retaining hooks
A hook is located on the upper edge of the
trunk and can be used to attach cargo
items such as bags.
1Tab
2Retaining hook
Pull tab1 of retaining hook2 down.Parcel net in trunk
There is a pocket net on each side of the
right and left trunk side walls to secure
loads.Retainer for Operator’s Manual pouch
1Hook-and-loop fastener
2Operator’s Manual pouch
Use hook-and-loop fasteners1 to fasten
Operator’s Manual pouch2 in place.
!Do not use the retaining hooks to tie down
cargo.

502 Controls in detail
Useful features
Sun visors
1Sun visor
2Vanity mirror cover
3Vanity mirror lamp
4Document holderGlare from front
Swing sun visor1 down.
Glare from front and sides
Disengage sun visor1 from the
mounting.
Pivot sun visor1 to the side.
Vanity mirror in sun visor
To use vanity mirror, lift up cover2.
Vanity mirror lamp3 comes on.
Document holder
You can use the plastic tab of document
holder4 to hold admission tickets, park-
ing passes, or similar items in place.
Vanity mirror in rear
Opening: Press mark1.
The vanity mirror swings down in the di-
rection of the arrow.
Closing: Swing vanity mirror up until it
engages.
Warning!G
Do not use the vanity mirror while driving.
Keep the vanity mirrors in the sun visors
closed while vehicle is in motion. Reflected
glare can endanger you and others.!Close vanity mirror cover2 (if open) before
you disengage sun visor1 from the mounting
and pivot it to the side.
iIf you disengage sun visor1 from the
mounting, vanity mirror lamp2 will switch off.

503 Controls in detail
Useful features
Rear window sunshade
The switches are on the rear doors.
1Opening
2Closing
You can also operate the rear window sun-
shade via COMAND (
page 249) or via
the favorite button (
page 238).
Switch on the ignition (page 344).
Press upper part 1 of the rocker
switch briefly to extend the sunshade.
Press lower part 2 of the rocker
switch briefly to retract the sunshade.
Ashtrays
Center console ashtray
1Button for disengaging ashtray
2Cover plate
iOperating the rear window sunshade from
the rear is not possible if you activate the over-
ride switch (
page 63).
iIf you operate the rear window sunshade via
COMAND or via the favorite button, this takes
precedence over the rear window sunshade but-
tons on the rear doors.
iT h e r e a r w i n d o w s u n s h a d e i s s w i t c h e d o f f a t
temperatures below -4°F (-20°C).
Warning!G
Remove ashtray only with vehicle standing
still. Engage the electronic parking brake to
secure vehicle from movement. Set auto-
matic transmission toP. With the automatic
transmission set toP, turn off the engine.

504 Controls in detail
Useful features
Opening ashtray
Press mark on cover plate2 forward.
Removing ashtray insert
Push sliding button1 to the left.
The ashtray is disengaged and slides
out a short way.
Remove the insert from the ashtray
frame.
Reinstalling ashtray insert
Install the insert by pushing it back into
the frame until it engages.
Closing ashtray
Briefly press mark on cover plate2
forward.
Rear door ashtray
Opening ashtray
Lift up the cover.Removing ashtray insert
1Insert
Press the open cover outwards beyond
the stop.
Ashtray insert1 pops out of the hold-
er.
Remove insert by pulling it upward.
Reinstalling ashtray insert
Install the insert by pushing it back into
the frame until it engages.
Cigarette lighters
Warning!G
Never touch the heating element or sides of
the lighter; they are extremely hot. Hold the
knob only.
Make sure that any children traveling with
you do not injure themselves or start a fire
with the hot cigarette lighter.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
To avoid possible injury to children sitting in
the rear seat, activate the override switch
(
page 63). Activation of the override
switch deactivates the rear center console
lighter.

505 Controls in detail
Useful features
1Center console cigarette lighter
Open the cover plate (page 503).
Switch on the ignition (page 344).
Push in cigarette lighter1.
The lighter will pop out automatically
when hot.1Rear center console lighter
Switch on the ignition (page 344).
Push in cigarette lighter1.
The lighter will pop out automatically
when hot.
!The lighter socket can be used to accommo-
date 12V DC electrical accessories (up to a max-
imum of 85 W) designed for use with the
standard “cigarette lighter” plug type. Keep in
mind, however, that connecting accessories to
the lighter socket (for example extensive con-
necting and disconnecting, or using plugs that do
not fit properly) can damage the lighter socket.
With the socket damaged, the lighter may no
longer be able to be placed in the heating
(pushed-in) position, or the lighter may pop out
too early with the lighter not hot enough.
To help avoid damaging the cigarette lighter
socket, we recommend connecting 12V DC elec-
trical accessories designed for use with a stan-
dard “cigarette lighter” plug type to the 12V
power outlets (
page 506) in your vehicle
whenever possible.
iOperation of the rear door lighters is only
possible, if the override switch (
page 63) is de-
activated.
iIf the engine is off and the cigarette lighter is
being used extensively, the vehicle battery may
become discharged.

506 Controls in detail
Useful features
Power outlet
The power outlet is located in the rear cen-
ter console.
Switch on the ignition (page 344).
Flip up cover1 and insert electrical
plug (cigarette lighter type).
Floormats*
1Retainer pin
2Eyelet
Removing
Pull floormat off of retainer pins1.
Remove the floormat.
Installing
Lay down the floormat in the respective
footwell.
Press the floormat eyelets2 onto re-
tainer pins1.
iThe power outlet can be used to
accommodate 12V DC electrical accessories
(e.g. air pump, auxiliary lamps) up to a maximum
of 180 W.
If the engine is off and the outlet is being used
extensively, the vehicle battery may become dis-
charged.
Warning!G
Whenever you are using floormats, make
sure there is enough clearance and that the
floormats are securely fastened.
Floormats should always be securely fas-
tened using the eyelets and the retainer
pins.
Before driving off, check that the floormats
are securely in place and adjust them if nec-
essary. A loose floormat could slip and
hinder proper functioning of the pedals.
Do not place several floormats on top of
each other as this may impair pedal move-
ment.
iTo install or remove the floormat more easi-
ly, move the driver’s seat or front passenger seat
as far to the rear as possible (
page 347).

507 Controls in detail
Useful features
Telephone*
Radio transmitters, such as a portable tele-
phone or a citizens band unit, should only
be used inside the vehicle if they are con-
nected to an antenna that is installed on
the outside of the vehicle.
The external antenna must be approved by
Mercedes-Benz. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on the installation of an approved
external antenna. Refer to the radio trans-
mitter operation instructions regarding use
of an external antenna.
Warning!G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or serious
personal injury.
Warning!G
Please do not forget that your primary re-
sponsibility is to drive the vehicle. A driver’s
attention to the road must always be
his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call.
If you choose to use the mobile phone
1
while driving, please use the hands-free de-
vice and only use the mobile phone when
road, weather and traffic conditions permit.
Some jurisdictions prohibit the driver from
using a mobile telephone while driving a ve-
hicle.
Only operate the COMAND (Cockpit Man-
agement and Data System)
1 if road, weather
and traffic conditions permit.
1Observe all legal requirements.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
iVarious mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Cen-
ter.
The functions and services available to you while
using the mobile phone depend on your service
provider and the type of mobile phone you are
using. See also separate operating manual for in-
structions on how to use your mobile phone.
iThe roof cargo container* may impair mo-
bile phone reception. In an emergency, remove
the mobile phone from the mobile phone cradle
to make a call.

508 Controls in detail
Useful features
When the mobile phone is inserted in the
cradle, you can operate the telephone us-
ing the following devices:

mobile phone keypad

COMAND telephone keypad
(
page 134)

buttonss andt on the multi-
function steering wheel (
page 265)

Voice Control* (page 289)

Bluetooth® headset (page 146)
Please note that these functions are only
available with Mercedes-Benz approved
mobile phones. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on features available for your mobile
phone of choice.
Open telephone compartment
(
page 495).Inserting mobile phone in mobile phone
cradle
Once the mobile phone has been inserted
in the mobile phone cradle, you have to
use the hands-free device or Bluetooth
headset to respond during phone calls.
If applicable, remove the cover for the
external antenna connection from the
back of the mobile phone and store it in
a s a f e p l a c e . B e s u r e t o c o m p l y w i t h t h e
mobile phone’s operating instructions,
as well.Example illustration
1Insert the mobile phone
2Connector contact
3Mobile phone cradle
Slide the lower end of the mobile phone
into connector contact 2 on
cradle3.
Push the top of the mobile phone in di-
rection of arrow 1, until the lug on the
mobile phone release button engages.
The mobile phone is connected to the
network via the external antenna.
!Do not try to remove the mobile phone along
with the cradle. You could otherwise damage the
mobile phone cradle.

509 Controls in detail
Useful features
The mobile phone is linked to the
hands-free device and the multifunc-
tion steering wheel.
The battery is charged depending on its
charge status and the position of the
SmartKey in the starter switch. The
charge procedure will be indicated in
the mobile phone’s display.
You can place or receive phone calls. You
can control other functions of the mobile
phone via the COMAND (
page 132),
instrument cluster control system
(
page 276) or Voice Control*
(
page 289). Removing mobile phone from mobile
phone cradle
Example illustration
1Release catch for mobile phone
2Mobile phone cradle
Press release catch in direction of
arrow1 and take mobile phone out of
mobile phone cradle2.Changing mobile phone cradle
If you require a different cradle for your
mobile phone, remove the present cradle
before installing a new one.
Removing an existing mobile phone
cradle
Example illustration
1To release the mobile phone cradle
2To remove the mobile phone cradle
3Mobile phone cradle
iWhen you take the SmartKey or SmartKey
with KEYLESS-GO* out of the starter switch, the
mobile phone remains switched on for approxi-
mately 10 minutes. If you place or receive a call
during this time, the mobile phone switches off
10 minutes after the call has been completed.iWhen using a flip-style mobile phone, open
flip top before removing from the cradle while a
call is connected. Otherwise, the call will be dis-
connected.
