MERCEDES-BENZ S550 4MATIC 2008 W221 Owner's Manual

490 Controls in detail
Panorama roof with power tilt/sliding panel*
Operating rear roller sunblind from rear
Rear door control panel
1Retracting
2Extending
Extending: Press button2 on the
rocker switch until the rear roller sun-
blind has reached the desired position.
Retracting: Press button1 on the
rocker switch until the rear roller sun-
blind has reached the desired position.Opening and closing panorama roof
with power tilt/sliding panel
Warning!G
When opening or closing the tilt/sliding pan-
el, make sure that there is no danger of any-
one being harmed by the opening or closing
procedure.
The opening procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch or, if the switch was moved
past the resistance point and released, by
moving the switch in any direction.
The closing procedure of the tilt/sliding
panel can be immediately halted by releas-
ing the switch.
The panorama roof with power tilt/sliding
panel is made out of glass. In the event of an
accident, the glass may shatter. This may re-
sult in an opening in the roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening.
Such an opening also presents a potential
for injury for occupants wearing their seat
belts properly as entire body parts or por-
tions of them may protrude from the pas-
senger compartment.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. A child’s unsupervised
access to a vehicle could result in an acci-
dent and/or serious personal injury.
!To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding panel.
Do not open the tilt/sliding panel if there is snow
or ice on the roof, as this could result in malfunc-
tions.
Depending on vehicle production date your vehi-
cle may be equipped with a crank to open or
close the tilt/sliding sunroof manually should an
electrical malfunction occur (
page 674).

491 Controls in detail
Panorama roof with power tilt/sliding panel*
The tilt/sliding panel only operates with
the roller sunblinds extended.
Roof panel switch
1Push back to slide roof panel open
2Push forward to slide roof panel closed
3Push up to raise roof panel
4Pull down to lower roof panel
Switch on the ignition (page 344).
To open, close, raise, or lower the
tilt/sliding panel, move the roof panel
switch to resistance point in the re-
quired direction of arrows1 to4.
Release the roof panel switch when the
tilt/sliding panel has reached the de-
sired position.
Express-opening: Move the roof panel
switch past the resistance point in di-
rection of arrow1 and release.
The tilt/sliding panel opens
completely.
Express-raising: Move the roof panel
switch past the resistance point in di-
rection of arrow3 and release.
The tilt/sliding panel raises
completely.
Stopping during Express-operation:
Move the roof panel switch in any di-
rection.
!Please keep in mind that weather conditions
can sometimes change rapidly. Make sure to
close the tilt/sliding panel when leaving the ve-
hicle. If water enters the vehicle interior, vehicle
electronics could be damaged which is not cov-
ered by the Mercedes-Benz Limited Warranty.
iWhen the panorama roof with power
tilt/sliding panel is open, resonance noises may
result in addition to the usual wind noises. They
are caused by minimal pressure changes in the
passenger compartment. To reduce or eliminate
these noises, change the position of the panora-
ma roof with power tilt/sliding panel or open a
side window slightly.
iYou can also open or close the tilt/sliding
panel using the SmartKey, see “Summer open-
ing feature” (
page 385) and “Convenience
closing feature” (
page 386).
Depending on current position, the tilt/sliding
panel may also open or close when the air recir-
culation button, in the control panel of the
climate control (
page 469), is pressed and
held for 2 seconds.
iIf the front roller sunblind is retracted while
being raised, it will extend first.
iYou cannot automatically close and lower
the panorama roof with power tilt/sliding panel.

492 Controls in detail
Panorama roof with power tilt/sliding panel*
Synchronizing
The tilt/sliding panel and front roller sun-
blinds must be synchronized

after the tilt/sliding panel has been
closed manually (
page 674)

after a malfunction

if the panorama roof with power
tilt/sliding panel can only be opened
with a jerking motion
Tilt/sliding panel and front roller
sunblind
Switch on the ignition (page 344).
Move and hold the roof panel switch in
direction of arrow2 until the front
roller sunblind is fully retracted.
Keep holding the roof panel switch in
direction of arrow2 for approximately
1 second.
Move and hold the roof panel switch in
direction of arrow1 until the front
roller sunblind is fully extended.
Move and hold the roof panel switch in
direction of arrow1 until the tilt/slid-
ing panel is slightly opened.
Move and hold the roof panel switch in
direction of arrow2 until the tilt/slid-
ing panel is fully closed.
Keep holding the roof panel switch in
direction of arrow2 for approximately
1 second.
Check the Express-open feature of the
tilt/sliding panel (
page 491).
If the tilt/sliding panel opens com-
pletely, the roof is synchronized. Other-
wise repeat the above steps.Rear roller sunblind
Switch on the ignition (page 344).
Press button1 until the rear roller
sunblind is fully retracted.
Keep holding button1 for approxi-
mately 1 second.

493 Controls in detail
Loading and storing
Loading and storing
Roof rack*
Flip the covers upward.
Only attach the roof-rack system to the
anchorage points under the covers.
Observe manufacturer’s instructions
for installation.
Loading instructions
The total load weight including vehicle oc-
cupants and luggage/cargo should not
exceed the load limit as indicated on the
corresponding placard located on the driv-
er’s door B-pillar (
page 553).
Warning!G
Only use roof racks approved by
Mercedes-Benz for your vehicle model to
avoid damage to the vehicle.
Follow the manufacturer’s installation
instructions. Otherwise, an improperly
attached roof rack system or its load could
become detached from the vehicle.
Do not exceed the maximum roof load of
220 lb (100 kg).
Take into consideration that when the roof
rack is loaded, the handling characteristics
are different from those when operating the
vehicles without the roof rack loaded.
!Load the roof rack in such a way that the ve-
hicle cannot be damaged while driving.
Make sure

you can fully raise tilt/sliding sunroof or the
panorama roof with tilt/sliding panel*

you can fully open the trunk
Warning!G
Always fasten items being carried as secure-
ly as possible using cargo tie-down hooks
and fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.


494 Controls in detail
Loading and storing
Storage compartments Storage compartments in the front pas-
senger compartment
Glove box
The glove box can be unlocked and locked
with the mechanical key (
page 671).
Opening: Press glove box lid
release1.
Closing: Push the lid up.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo. Put luggage or car-
go in the trunk if possible.
Do not pile luggage or cargo higher than the
seat backs. Do not place anything on the
rear-window shelf.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.
Warning!G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs.
Parcel nets cannot secure hard or heavy ob-
jects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during

braking

vehicle maneuvers or

an accident.
iAn overview of the storage compartments
can be found on (
page 36).
1Glove box lid release
2Unlocking glove box
3Locking glove box


495 Controls in detail
Loading and storing
Locking: Insert the mechanical key
into the glove box lock and turn it
clockwise to position3.
Unlocking: Insert the mechanical key
into the glove box lock and turn it coun-
terclockwise to position2.
Storage compartments in the front
armrest
1Storage tray/telephone* compartment
2Storage compartment (not with rear
climate control system*)
Opening storage tray/telephone*
compartment: Press button1 and
swing armrest to left or right side.
Opening storage compartment:
Press button2 and swing center arm-
rest upward.
Storage compartments below the front
seats
Opening: Pull tab1 upward and fold
cover2 forward.Eyeglasses compartment
Opening: Press mark1.
Closing: Swing eyeglasses compart-
ment upward until it engages.

496 Controls in detail
Loading and storing
Parcel net in front passenger footwellA small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.Storage compartments in rear passen-
ger compartment
Armrest with integrated storage
compartment
Vehicles without control panel* in rear arm-
rest
Opening: Pull release catch1 and
swing the cover upward.
Warning!G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard brak-
ing, or sudden maneuvers, they could be in-
jury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.
!Before storing the armrest in the backrest,
close the storage compartment cover.
!Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.

497 Controls in detail
Loading and storing
Vehicles with control panel* in rear armrest
Opening: Press button1 and swing
the cover upward.Storage compartment between rear
seatsVehicles without rear center seat*
Opening: Pull handle1 backward in
the direction of arrow. Rear storage box
Fold down rear center armrest.
Pull handle1 upward in the direction
of arrow.
Swing down cover2.
!Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.
iWhen the rear seats are in their basic posi-
tion, you can open the cover more easily.

498 Controls in detail
Loading and storing
Ruffled storage pockets
Ruffled storage pockets 1 are located on
the back of the front seats.Cup holders
Warning!G
Do not place objects with a combined
weight of more than 4.4 lbs (2 kg) into the
ruffled storage pocket. Otherwise, the Occu-
pant Classification System OCS (
page 47)
may not be able to properly approximate the
occupant weight category.
The ruffled storage pocket is intended for
storing light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
ruffled storage pocket. In an accident, dur-
ing hard braking, or sudden maneuvers, they
could be thrown around inside the vehicle
and cause injury to vehicle occupants.
The ruffled storage pocket cannot protect
transported goods in the event of an acci-
dent.
Warning!G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or in an
accident. Liquids spilled on vehicle occu-
pants may cause serious personal injury.
Liquids spilled on vehicle equipment may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
When not in use, keep the cup holders
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an acci-
dent.

499 Controls in detail
Loading and storing
Cup holder in front center console
1Mark
2Handle
Opening: Press mark1 on the front.
Closing: Fold cover in until it engages.
Removing: Pull cup holder out by pull-
ing silver handle2 upward in direction
of arrow.
Inserting: Press downward until it en-
gages. While doing so, make sure that
the word “Front” is in the proper instal-
lation position.
Cup holder in rear
Vehicles without control panel* in rear arm-
rest
1Compartment for cup holder
Opening: Press mark1 on the front.
Vehicles with control panel* in rear armrest
1Compartment for cup holder
Opening: Press front of cup holder1.
Keep in mind that objects placed in the cup
holder may come loose during braking, vehi-
cle maneuvers, or in an accident and be
thrown around in the vehicle interior.
Objects thrown around in the vehicle interi-
or may cause an accident and/or serious
personal injury. iYou can remove the cup holder to clean it.
Only clean it using clear, lukewarm water.
