Information zur Betriebsanleitung
Diese Er
gänzung ist Bes tandteil der gedruckten
und der digit alen Betriebsanleitung Sprinter.
Sie ersetzt dort im Kapitel „Fahren und Parken“ -
„A utomatik getriebe“ den Abschnitt „Par kstel‐
lung P einlegen“.
Be wa hren Sie diese Er gänzung zusammen mit der
Betriebsanleitung im Fahrzeug auf. Pa
rkstellung P einlegen #
Die Taste 1 drüc ken.
Im Multifunktionsdisplay zeigt die Getriebe‐
st ellungsanzeige auf 005D.
We nn eine der folgenden Bedingungen erfüllt ist,
wir d die Parkstellung 005Dautomatisch eingelegt:
R Sie stellen den Mo tor in der Getriebe stellung
005B oder 005Eab.
R Sie öffnen im Stills tand oder bei sehr geringer
Fa hrge schwindigkeit in der Getriebes tellung
005B oder 005Edie Fahrertür. English (UK)
