Mercury Grand Marquis 1996 s Manual PDF

68
*
[LG27900( GV)05/95]
Under certain conditions, the Check Engine
Warning Light may come on if the fuel cap is
not properly installed. If the Check Engine
Warning Light comes on and you suspect that
the fuel cap is not properly installed, pull off the
road as soon as it is safely possible and turn off
the engine. Remove and replace the fuel cap,
making sure it is properly seated.
*
[LG27950( GV)05/95]
After completing the three consecutive warm up
cycles and on the fourth engine start up, the
Check Engine Warning Light should turn off. If
the light does not go off after the fourth engine
restart, have your vehicle serviced by your
dealer or a qualified technician.
%*
[LG28101( GV)01/95]
Air Bag Readiness Light
[LG28102( GV)02/93]
The Air Bag Readiness light will go on each
time you start your vehicle and will remain on
for about 6-8 seconds indicating normal air bag
operation. If this light stays on continuously or
flashes, or if the light never comes on at all,
there is something wrong with the Air Bag
Supplemental Restraint System and your vehicle
should be taken in for service to the nearest
Lincoln-Mercury dealer as soon as possible.
Unless serviced, the Air Bag Supplemental
Restraint System may not function properly in
the event of a collision.
[LG28103( GV)10/90]
one inch art:0010514-AFile:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

69 %
*
[LG28104( GV)01/95]
Charging System Warning Light
*
[LG28105( GV)01/95]
This light comes on when you turn your ignition
key from OFF to ON. The light should go out
when the engine starts and the alternator begins
to charge.
*
[LG28106( GV)01/95]
If this light stays on or comes on while your
engine is running, this tells you that your
battery is not being charged and that you need
to have the electrical system checked as soon as
possible.
[LG28107( GV)10/90]
one inch art:0010533-A%*
[LG28108( GV)01/95]
Engine Oil Pressure Light
[LG28109( GV)10/90]
one inch art:0010532-A[LG28110( GV)06/93]
This light indicates the engine oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. The light
should come on every time your ignition key is
turned to ON or START, and should go out
when the engine starts. If the light stays on or
turns on while the engine is running, you have
lost oil pressure andcontinued operation will
cause severe engine damage.
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

70
*
[LG28111( GV)03/95]
If you lose engine oil pressure:
*
[LG28112( GV)03/95]
1. Pull off the road as soon as safely possible.
*
[LG28113( GV)01/95]
2. Shut off the engine immediately. If you do
not stop the engine as soon as safely
possible, severe engine damage could result.
[LG28114( GV)07/94]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil, seeEngine Oilin the Index. If you do
not follow these instructions, you or others
could be injured. To assure an accurate
reading, your vehicle should be on level
ground.
[LG28115( GV)06/93]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the light is on, regardless of the oil level.
Contact your nearest dealer for service as
soon as possible.
*
[LG28117( GV)01/95]
For more information about adding oil, see
Adding engine oilin theServicing Your Vehicle
chapter of this guide.
%*
[LG28120( GV)04/95]
Turn Signal Indicator Lights
*
[LG28122( GV)05/95]
The turn signal arrow will flash to indicate the
direction in which you are going to be turning.
[LG28137( GV)06/93]
one inch art:0010525-AFile:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

71 %
*
[LG28140( GV)01/95]
Speed Control Indicator Light
*
[LG28150( GV)01/95]
This light comes on when the speed control
system is actively maintaining the set speed. It
will go off when the brakes are used or if the
speed control is turned off.
[LG28160( GV)10/90]
one inch art:0010648-A*
[LG28170( GV)01/95]
This light does not indicate any problems but is
only a convenience to tell when the speed
control is active.
%*
[LG29700( GV)01/95]
Fuel Gauge
[LG30810( GV)03/94]
one third page art:0010516-B[LG30860( GV)03/95]
The fuel gauge tells you approximately how
many gallons/liters of fuel you have in the tank.
[LG30870( GV)03/93]
When your tank reaches 1/8 or approximately
2 gallons (8 liters), a flashing fuel pump will
appear.
[LG30880( GV)03/92]
Turn the ignition switch off while fueling to
obtain an accurate fuel gauge indication.
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

72 [LG30885( GV)05/94]NOTE: At least 2.5 gallons (9.5 liters) of fuel
must be added for the fuel gauge to
immediately show the new level of
fuel. If less than 2.5 gallons (9.5 liters)
of fuel is added, the gauge will reach
the new level slowly.
[LG30890( GV)10/90]
If the fuel gauge displays only the top two bars
and the bottom two bars, or, if fuel remaining or
distance to empty functions display CO or CS,
then there is a problem. Take your vehicle in for
service.
[LG30900( GV)03/92]
When you turn the ignition key to the ON or
ACC position, all the display segments will light
up, then go off for a second indicating the gauge
is working. Then the gauge will show you how
much fuel you have in the tank.
%*
[LG31000( GV)01/95]
FUEL REMAIN Ð Fuel Remaining
[LG31100( GV)05/95]
one inch art:0010526-C*
[LG31200( GV)01/95]
This function shows you how many gallons
(liters) of fuel you have left in the fuel tank.
[LG31300( GV)03/94]
If your fuel level is above 20 gallons (76 liters),
the letter ªFº (full) will appear on the display.
But if your fuel level has dropped to below
1 gallon (4 liters), the letter ªEº (empty) will
appear in the display.
*
[LG31400( GV)01/95]
Because of factors like rounding of numbers and
fuel movement in the tank, your fuel gauge and
the service station fuel pump readings may
disagree slightly.
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

73
*
[LG31500( GV)01/95]
A problem is indicated if the fuel gauge bar
graph displays only the top two and bottom two
bars and the message center display for Distance
To Empty or Fuel Remaining functions display
the letters ªCOº or ªCSº. If this happens, contact
your dealer for service as soon as possible.
%*
[LG33600( GV)01/95]
Speedometer
[LG33700( GV)05/95]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving. It
indicates the speed up to 120 mph or up to
195 km/h.
*
[LG34000( GV)01/95]
You can press the E/M (English/Metric) button
located just below the message center display to
show the speed you are going in either miles
per hour or kilometers per hour.
[LG34050( GV)05/95]
quarter page art:0010517-D%*
[LG34100( GV)01/95]
Odometer
*
[LG34200( GV)01/95]
The odometer tells you the total number of miles
or kilometers your vehicle has been driven. If
the cluster is replaced, and the accumulated
mileage on the odometer is unknown, the
replacement cluster will have the circled ªSº
illuminated with zero miles on the odometer. If
the actual vehicle mileage can be verified, then
an authorized service center can program the
actual mileage into the odometer of the
replacement cluster. The actual mileage (if
known) or an estimated mileage (if unknown) is
shown on a label affixed on the door pillar.
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

74
*
[LG34410( GV)01/95]
Press the E/M (English/Metric) button located
just below the message center display to show
miles or kilometers.
*
[LG34420( GV)01/95]
If the odometer displays the word ªERRORº
contact your dealer for service.
%
*
[LG46700( GV)04/95]
The Electronic Message Center
(If equipped)
*
[LG46800( GV)01/95]
Along with information the warning lights and
gauges provide, the electronic message center
lets you:
*
[LG47000( GV)01/95]
q
see problems such as Door Ajar, Air
Suspension, Trunk Ajar, Washer Fluid
*
[LG47100( GV)01/95]
q
see how many miles/kilometers you can
drive with the fuel remaining in your tank
[LG47200( GV)05/94]
q
see when overdrive has been turned off
*
[LG47300( GV)01/95]
q
monitor your average fuel economy
*
[LG47400( GV)01/95]
q
monitor your instantaneous fuel economy
*
[LG47600( GV)01/95]
q
check the distance you have travelled during
a trip on either Trip A or Trip B
*
[LG47700( GV)01/95]
q
monitor your average speed
[LG47900( GV)05/95]
one third page art:0010518-H
Message center display showing all segments on
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

75 % [LG48000( GV)10/90]
All of the message center functions are
controlled by the three switches located just
below the message center display:
[LG48030( GV)02/94]
q
E/M Ð Changes the electronic instrument
cluster display to read in either English or
Metric units.
*
[LG48060( GV)01/95]
q
ResetÐ Sets the selected function to zero
(if resettable).
*
[LG48100( GV)01/95]
q
SelectÐ Selects the function. This is a dual
action switch, the right side advances function
to the right, the left side advances function to
the left.
[LG48130( GV)03/94]
one inch art:0010520-C
Buttons for the message center
*
[LG48160( GV)01/95]
How to use the message center
*
[LG48200( GV)01/95]
To reset any function:
*
[LG48260( GV)01/95]
1. Push either the right or left side of the
SELECT button to choose the function you
would like to set.
*
[LG48300( GV)01/95]
2. Push the RESET button and the selected
message center function will be reset to zero.
(The only functions which can be reset to
zero are: AVG ECON, TRIP A or TRIP B,
and AVG SPEED.)
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

76
*
[LG48350( GV)01/95]
What the message center functions can
show you
%*
[LG48400( GV)01/95]
DIST TO EMPTY Ð Distance to Empty
(DTE)
[LG48450( GV)05/95]
one third page art:0010519-C
Message center display showing the DTE function selected
*
[LG48500( GV)01/95]
This function estimates how many miles or
kilometers you can drive with the fuel remaining
in your tank under standard driving conditions.
*
[LG48600( GV)01/95]
Remember to turn off the ignition when filling
up with fuel. Otherwise, the display will not
show the addition of fuel for a few miles.
[LG48625( GV)05/94]
NOTE: At least 2.5 gallons (9.5 liters) of fuel
must be added for the fuel gauge to
imediately show the new level of fuel.
*
[LG48650( GV)01/95]
When you have approximately 50 miles (80 km)
left before you run out of fuel, the DTE function
will flash for five (5) seconds and sound a tone
for one (1) second. The message center will
remain in the DTE function until you push the
select button to change it. This low fuel warning
also happens at 25 miles (40 km), and 10 miles
(16 km).
File:rclgg.ex
Update:Tue Jan 30 08:07:51 1996

77
*
[LG48675( GV)01/95]
Displayed DTE will not be equal to AVG ECON
multiplied by the FUEL REMAIN value. This is
because DTE is calculated using a method that
takes into consideration the fuel economy of the
last 500 miles (800 Km) driven.
[LG48700( GV)03/91]
one inch art:0010166-A*
[LG48800( GV)01/95]
If ªCOº or ªCSº is displayed, this means that
there is a problem with the fuel indication
system and you should contact your dealer for
service as soon as possible.
%*
[LG50000( GV)01/95]
AVG ECON Ð Average Fuel Economy
*
[LG50100( GV)01/95]
Select this function to display your average fuel
economy in miles per gallon or liters per
100 kilometers. Your message center computes
this figure using the distance traveled and fuel
used information. If you want to reset this
function, press the RESET button while the
average fuel economy feature is displayed.
[LG50150( GV)03/95]
The average shown is the average since the
reset.
[LG50200( GV)10/90]
one inch art:0010528-AFile:rclgg.ex
Update:Tue Jan 30 08:07:51 1996
