5
*
[II03210( ALL)05/96]
You may purchase Ford ESP from any
participating Ford Motor Company dealer. There
are several Ford ESP plans available in various
time-and-mileage combinations. Each plan can be
tailored to fit your own driving needs, including
reimbursement benefits for towing and rental.
(In Hawaii, rules vary. See your dealer for
details.)
*
[II03240( ALL)05/96]
When you buy Ford ESP, you receive
peace-of-mind protection throughout the United
States and Canada, provided by a network of
more than 5,100 participating Ford Motor
Company dealers.
*
[II03270( ALL)05/96]
NOTE: Repairs performed outside the United
States and Canada are not eligible for
ESP coverage.
*
[II03310( ALL)05/96]
This information is subject to change. Ask your
dealer for complete details about Ford ESP
coverage.
File:02rciig.ex
Update:Tue Jun 11 13:52:18 1996

19
*
[IS16800( ALL)03/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine, seeEngine Coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
*
[IS16900( ALL)03/96]
If the coolant continues to overheat, have the
coolant system serviced.
%*
[IS18100( ALL)03/96]
Speedometer
*
[IS18350( ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS18900( ALL)03/96]
Odometer
*
[IS19000( ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[IS20400( ALL)01/96]
Trip Odometer
*
[IS20500( ALL)04/96]
If you want to track your mileage up to 999.9
miles (kilometers), use the trip odometer. Simply
set the trip odometer to zero by pressing the
reset control firmly when beginning the distance
you wish to measure.
[IS20600( ALL)04/96]
Since the trip odometer displays distance
independent of the odometer it will not always
advance to the next mile (kilometer) at the same
time as the odometer.
[IS21400(M GV)05/96]
Battery Voltage Gauge
[IS21500(M GV)05/96]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
[IS21605( GV)05/96]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the normal band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the normal band.
File:03rcisg.ex
Update:Tue Jun 11 13:54:07 1996

63
*
[AS61400( ALL)08/95]
2. Terrain
*
[AS61500( ALL)08/95]
The terrain (hilly, mountainous, tall buildings) of
the area over which the signal travels may
prevent the FM signal from being noise-free.
*
[AS61700( ALL)08/95]
If there is a building or large structure between
the antenna and station, some of the signal
ªbendsº around the building, but certain spots
receive almost no signal. Moving out of the
ªshadowº of the structure will allow the station
to return to normal.
*
[AS61800( ALL)08/95]
When the radio waves are reflected off objects or
structures, the reflected signal cancels the normal
signal, causing the antenna to pick up noise and
distortion. Cancellation effects are most
prominent in metropolitan areas, but also can
become quite severe in hilly terrain and
depressed roadways.
*
[AS61900( ALL)08/95]
To minimize these conditions, a stereo/mono
blend circuit has been incorporated into this
system. This feature automatically switches a
weak stereo signal to a clearer monaural signal,
which improves the quality of reception.
*
[AS62000( ALL)08/95]
Several sources of static are normal conditions
on AM frequencies. These can be caused by
power lines, electric fences, traffic lights and
thunderstorms.
*
[AS62100( ALL)08/95]
Another reception phenomenon isStrong Signal
Capture and Overload. This can occur when
listening to a weak station and when passing
another broadcast tower. The close station may
capture the more distant station, although the
displayed frequency does not change. While
passing the tower, the station may switch back
and forth a few times before returning to the
original station.
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996

64
*
[AS62200( ALL)03/96]
When several broadcast towers are present
(common in metropolitan areas), several stations
may overload the receiver, resulting in
considerable station changing, mixing and
distortion.
*
[AS62300( ALL)08/95]
Automatic gain control circuitry for both AM
and FM bands has been incorporated into this
system to reduce strong signal capture and
overload.
%
*
[AS62400( ALL)08/95]
All About Radio Frequencies
*
[AS62500( ALL)08/95]
The Federal Communications Commission (FCC)
and the Canadian Radio Telecommunications
Commission (CRTC) establish the frequencies
that AM and FM radio stations may use for
their broadcasts. The allowable frequencies are,
AM: 530, 540...1600, 1610 kHz in 10 kHz steps;
FM: 87.9, 88.1...107.7, 107.9 MHz in 0.2 MHz
steps.
*
[AS62600( ALL)08/95]
Not all frequencies will be assigned to a given
area. This radio will tune to each of these
frequencies using manual tune and no fine
tuning is necessary as radio stations may not use
other frequencies.
*
[AS62700( ALL)08/95]
Some FM radio stations advertise a
ªrounded-offº frequency which is not the
frequency they actually broadcast on. For
example, a radio station that is assigned a
frequency of 98.7 MHz may call itself ªRadio 99º
even though 99.0 MHz is not an allowable FM
broadcast frequency.
File:04rcasg.ex
Update:Mon Sep 23 08:30:54 1996

83 [CF17700( BCGV)12/95]
Chime for headlamps on
*
[CF17800( ALL)12/95]
This chime sounds if the driver or any passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
%*
[CF17900( GV)05/96]
Setting the Autolamp On/Off Delay
System
*
[CF18100( BCGV)01/96]
The autolamp sets the headlamps to turn on and
off automatically. You can use the autolamp to:
*
[CF18200( BCGV)01/96]
q
turn on the lamps automatically at night
*
[CF18300( BCGV)01/96]
q
turn off the lamps automatically during
daylight
*
[CF18400( BCGV)01/96]
q
keep the lamps on for up to three minutes
after you turn the key to OFF.
[CF18500( GV)12/95]
one third page art:0010198-F
The autolamp system on the left side of the instrument
panel
[CF18800( GV)12/95]
To activate the autolamp feature, simply turn the
headlamp knob counterclockwise towards the
autolamp delay area. The autolamp
automatically turns the lamps on and off for
you.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

91
*
[CF28400( ALL)01/96]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
%*
[CF28700( ALL)01/96]
Flashing the Lights
*
[CF28800( ALL)01/96]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
%
*
[CF28900( ALL)01/96]
Windshield Wipers and Washer
*
[CF29000( ALL)04/96]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
[CF29100( ALL)12/95]
Rotate the end of the lever away from you to
activate the wipers. The first seven detents are
interval wipe positions, the eighth detent is the
LO position and the ninth detent is the HI
position.
[CF29200( ALL)04/96]
To turn the wipers off, turn the knob toward
you to the OFF position.
%*
[CF29300( ALL)01/96]
Variable Interval Wipers
*
[CF29400( ALL)12/95]
In addition to two speed wipers, your vehicle
has wipers that you can set to operate at
varying intervals. For example, you can set the
interval so they wipe less often when it drizzles
or more often in heavier rain.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

92 [CF29500( ALL)12/95]
one third page art:0011293-AThe variable interval wiper on the turn signal lever
[CF29600( ALL)04/96]
To set the interval wipers, turn the knob at the
end of the turn signal lever toward or away
from you until the wipers are going at the
desired interval.
*
[CF29700( ALL)01/96]
Windshield Washer
*
[CF29800( ALL)12/95]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob, the
wipers operate for two to three cycles before
turning off (if the wipers were OFF) or
returning to HI, LO, or the interval setting
selected.
*
[CF29900( ALL)03/96]
If the washer does not work, check the washer
fluid level and fill it if it is low. See the
Maintenance and Carechapter. If there is enough
fluid, consult your nearest Ford or
Lincoln-Mercury dealer.
*
[CF30000( ALL)08/95]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

95
%*
[CF31200( ALL)01/96]
Tilt Steering
*
[CF31300( ALL)02/96]
RWARNING
Never adjust the steering wheel when the
vehicle is moving.
[CF31500( GV)12/95]
half page art:0010459-D
The lever to tilt the steering wheel
*
[CF31600( ALL)01/96]
To change the position of the steering wheel,
pull the release lever on the column toward you.
Tip the steering wheel to the desired position.
Release the lever to lock the steering wheel in
place.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

116RUN position. The interior lights will not turn
off if you have turned them on manually or if a
door is open.
%*
[CF68400( ALL)03/96]
Replacing the batteries
*
[CF68600( GV)01/96]
The remote entry transmitter is powered by two
coin type three-volt lithium 1616
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
*
[CF68700( ALL)01/96]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
%*
[CF69000( ALL)02/96]
Replacement/additional transmitters
*
[CF69200( GV)12/95]
In the event a transmitter is lost, a new one may
be purchased from your dealer.
*
[CF69300( GV)12/95]
To program replacement or additional
transmitters you must have all the transmitters
intended for use on your vehicle.
*
[CF69400( GV)12/95]
Initiating the following procedure erases all prior
programmed transmitters, thus ALL must be
reprogrammed at the same time.
*
[CF69500( GV)12/95]
1. Enter the factory keyless entry code. Your
personal code will not allow programming.
*
[CF69700( GV)12/95]
2. Press the 1/2 button.
File:05rccfg.ex
Update:Mon Sep 23 08:32:35 1996

131
*
[SS19600( ALL)01/96]
2. While the belt retracts, guide the tongue to
its stowed position. If you do not guide the
tongue, it may strike you or part of the
vehicle.
[SS20300( GV)12/95]Lap Belts Ð Center Seating
Positions
*
[SS20400( GV)12/95]
The lap belts in the center of the front and rear
seats do not adjust automatically. You must
adjust them to fit snugly and as low as possible
around your hips. Do not wear them around
your waist.
*
[SS20600( BCGV)01/96]
Pull the belt across your hips andinsert the
tongue into the correct buckleon your seat
until you hear a snap and feel it lock. Make sure
the buckle is securely fastened.
%*
[SS20700( BCGV)01/96]
If you need to lengthen the belt, unfasten it and
tip the belt tongue at a right angle to the belt.
Pull the belt tongue over your lap until it
reaches the buckle.
*
[SS20800( BCGV)01/96]
If you need to shorten the belt, pull on the loose
end of the webbing until the belt fits snugly.
*
[SS20900( BCGV)12/95]
To unfasten the belt,push the release button on
the buckle. This allows the tongue to unlatch
from the buckle.
[SS21100( GV)12/95]
Because the center lap belts do not have
retractors, they should be shortened and fastened
when not in use.
File:06rcssg.ex
Update:Tue Apr 8 09:44:54 1997
