Mercury Mystique 1996 Owner's Manuals
Manufacturer: MERCURY, Model Year: 1996, Model line: Mystique, Model: Mercury Mystique 1996Pages: 284, PDF Size: 2.74 MB
Page 221 of 284
![Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
225
*
[SV25075(ALL)05/95]
RWARNING
Improperly inflated tires can affect vehicle handling and
can fail suddenly, possibly resulting in loss of vehicle
control.
%*
[SV25100(ALL)0 Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
225
*
[SV25075(ALL)05/95]
RWARNING
Improperly inflated tires can affect vehicle handling and
can fail suddenly, possibly resulting in loss of vehicle
control.
%*
[SV25100(ALL)0](/img/33/11007/w960_11007-220.png)
Servicing Your Mystique
225
*
[SV25075(ALL)05/95]
RWARNING
Improperly inflated tires can affect vehicle handling and
can fail suddenly, possibly resulting in loss of vehicle
control.
%*
[SV25100(ALL)02/95]
Tire Rotation
*
[SV25200(ALL)04/95]
Because your vehicle's front and rear tires perform different
jobs, they often wear differently. To make sure your tires wear
evenly and last longer, rotate them as indicated in the following
diagram.
*
[SV25300(ALL)04/95]
Do not include the spare tire as part of your rotation.
[SV25350(ALL)02/95]
If you notice that the tires wear unevely, have them checked.
[SV25400(ALL)02/94]
13-1/2 pica
art:0001224-A
Rotating the tires
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 222 of 284
![Mercury Mystique 1996 Owners Manuals 226
*
[SV25700(ALL)04/95]
Replacing the Tires
*
[SV25900(ALL)05/95]
Replace any tires that show wear bands. When your tire shows
a wear band, it has only 1/16 inch (2 mm) of tread left.
[SV26150(ALL)0 Mercury Mystique 1996 Owners Manuals 226
*
[SV25700(ALL)04/95]
Replacing the Tires
*
[SV25900(ALL)05/95]
Replace any tires that show wear bands. When your tire shows
a wear band, it has only 1/16 inch (2 mm) of tread left.
[SV26150(ALL)0](/img/33/11007/w960_11007-221.png)
226
*
[SV25700(ALL)04/95]
Replacing the Tires
*
[SV25900(ALL)05/95]
Replace any tires that show wear bands. When your tire shows
a wear band, it has only 1/16 inch (2 mm) of tread left.
[SV26150(ALL)05/94]
7-1/2 pica art:0001317-A
A worn-out tire
*
[SV26175(ALL)01/95]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread. Some spots wear more heavily than others.
*
[SV26300(ALL)01/95]
RWARNING
When replacing full size tires, never mix radial,
bias-belted, or bias-type tires. Use only the tire sizes that
are listed on the tire pressure decal. Make sure that all
tires are the same size, speed rating, and load-carrying
capacity. Use only the tire combinations recommended on
the decal. If you do not follow these precautions, your
vehicle may not drive properly and safely.
*
[SV26400(ALL)01/95]
Tires that are larger or smaller than your vehicle's original tires
may also affect the accuracy of your speedometer.
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 223 of 284
![Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
227
%*
[SV27400(ALL)02/95]
Information About Tire Quality Grades
*
[SV27500(ALL)01/95]
New vehicles are fitted with tires that have their Tire Quality
Grade (described below) m Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
227
%*
[SV27400(ALL)02/95]
Information About Tire Quality Grades
*
[SV27500(ALL)01/95]
New vehicles are fitted with tires that have their Tire Quality
Grade (described below) m](/img/33/11007/w960_11007-222.png)
Servicing Your Mystique
227
%*
[SV27400(ALL)02/95]
Information About Tire Quality Grades
*
[SV27500(ALL)01/95]
New vehicles are fitted with tires that have their Tire Quality
Grade (described below) molded into the tire's sidewall. These
Tire Quality Grades are determined by standards that the
United States Department of Transportation has set.
*
[SV27550(ALL)01/95]
Tire Quality Grades apply to new pneumatic tires for use on
passenger cars. They do not apply to deep tread, winter-type
snow tires, space-saver or temporary use spare tires, tires with
nominal rim diameters of 10 to 12 inches or limited production
tires as defined in Title 49 Code of Federal Regulations Part
575.104(c)(2).
*
[SV27600(ALL)01/95]
U.S. Department of Transportation Ð Tire quality grades:The
U.S. Department of Transportation requires Ford to give you the
following information about tire grades exactly as the
government has written it.
%*
[SV27799(ALL)01/95]
Treadwear
*
[SV27800(ALL)01/95]
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a
specified government test course. For example, a tire graded 150
would wear one and one-half (1 1/2) times as well on the
government course as a tire graded 100. The relative
performance of tires depends upon the actual conditions of their
use, however, and may depart significantly from the norm due
to variations in driving habits, service practices and differences
in road characteristics and climate.
*
[SV27999(ALL)01/95]
Traction A B C
*
[SV28000(ALL)01/95]
The traction grades, from highest to lowest, are A, B, and C,
and they represent the tire's ability to stop on wet pavement as
measured under controlled conditions on specified government
test surfaces of asphalt and concrete. A tire marked C may have
poor traction performance. Warning: The traction grade assigned
to this tire is based on braking (straightahead) traction tests and
does not include cornering (turning) traction.
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 224 of 284
![Mercury Mystique 1996 Owners Manuals 228
*
[SV28299(ALL)01/95]
Temperature A B C
*
[SV28300(ALL)01/95]
The temperature grades are A (the highest), B, and C,
representing the tires resistance to the generation of heat and
its ability to Mercury Mystique 1996 Owners Manuals 228
*
[SV28299(ALL)01/95]
Temperature A B C
*
[SV28300(ALL)01/95]
The temperature grades are A (the highest), B, and C,
representing the tires resistance to the generation of heat and
its ability to](/img/33/11007/w960_11007-223.png)
228
*
[SV28299(ALL)01/95]
Temperature A B C
*
[SV28300(ALL)01/95]
The temperature grades are A (the highest), B, and C,
representing the tire's resistance to the generation of heat and
its ability to dissipate heat when tested under controlled
conditions on a specified indoor laboratory test wheel. Sustained
high temperature can cause the material of the tire to
degenerate and reduce tire life, and excessive temperature can
lead to sudden tire failure. The grade C corresponds to a level
of performance which all passenger car tires must meet under
the Federal Motor Vehicle Safety Standard No. 109. Grades B
and A represent higher levels of performance on the laboratory
test wheel than the minimum required by law. Warning: The
temperature grade for this tire is established for a tire that is
properly inflated and not overloaded. Excessive speed,
underinflation, or excessive loading, either separately or in
combination, can cause heat buildup and possible tire failure.
%*
[SV28500(ALL)04/95]
Snow Tires and Chains
*
[SV28601(ALL)06/93]
During the winter months in some climates, you may need to
use snow tires and occasionally chains for your tires.
*
[SV28700(ALL)05/95]
RWARNING
Snow tires must be the same size and grade as the tires
you currently have on your vehicle.
*
[SV28750(ALL)02/95]
Use chains on the tires only in an emergency or if the law
requires them where you live. If you choose to use chains on
your vehicle's tires, be aware of the following:
*
[SV28801(ALL)11/94]
n
Tire chains may scratch or chip aluminum wheels. IT IS
RECOMMENDED THAT TIRE CHAINS ARE INSTALLED
ON STEEL WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before using tire chains
to avoid scratches or damage.
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 225 of 284
![Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
229
[SV28876(ALL)04/94]
n
Tire chains cannot be fitted with 205/60R tires.
*
[SV28901(ALL)11/94]
n
Local regulations may prohibit or restrict the use of tire
chains. Investigat Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
229
[SV28876(ALL)04/94]
n
Tire chains cannot be fitted with 205/60R tires.
*
[SV28901(ALL)11/94]
n
Local regulations may prohibit or restrict the use of tire
chains. Investigat](/img/33/11007/w960_11007-224.png)
Servicing Your Mystique
229
[SV28876(ALL)04/94]
n
Tire chains cannot be fitted with 205/60R tires.
*
[SV28901(ALL)11/94]
n
Local regulations may prohibit or restrict the use of tire
chains. Investigate the laws and regulations in your area
before installing chains.
*
[SV28950(ALL)05/95]
n
Put the chains on the front tires tightly with the ends held
down securely. Retighten the chains after driving 1/2 mile
(1 km). Follow the chain manufacturer's instructions.
*
[SV29001(ALL)05/95]
n
Do not drive faster than 30 mph (50 km/h) or the chain
manufacturer's recommended speed limit, whichever is
lower. Avoid bumps, holes and sharp turns. If you can hear
the chains rub or bang against your vehicle, remove the
chains to prevent damage to your vehicle.
*
[SV29050(ALL)11/94]
n
Tire chains may affect vehicle handling. Drive carefully and
avoid hard braking.
*
[SV29101(ALL)11/94]
n
Do not use chains on temporary spare tires. They may
damage the vehicle and the tire.
*
[SV29151(ALL)05/94]
n
Remove tire chains at the first opportunity after using them
on snow and ice. Do not use the chains on dry roads.
%*
[SV29200(ALL)04/95]
Cleaning the Wheels
*
[SV29225(ALL)05/95]
Wash the wheels with the same detergent you use to wash your
vehicle's body. Do not use acid-based wheel cleaners, steel wool,
abrasives, fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil remover to
remove grease and tar.
*
[SV29250(ALL)04/95]
NOTE: Before going to a car wash, find out if the brushes are
abrasive.
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 226 of 284
![Mercury Mystique 1996 Owners Manuals 230
*
[SV29300(ALL)03/01]
Automatic Transaxle Fluid
*
[SV29310(ALL)03/95]
Under normal circumstances, you do not need to check the fluid
level of the transaxle, since your vehicle does not use up
tran Mercury Mystique 1996 Owners Manuals 230
*
[SV29300(ALL)03/01]
Automatic Transaxle Fluid
*
[SV29310(ALL)03/95]
Under normal circumstances, you do not need to check the fluid
level of the transaxle, since your vehicle does not use up
tran](/img/33/11007/w960_11007-225.png)
230
*
[SV29300(ALL)03/01]
Automatic Transaxle Fluid
*
[SV29310(ALL)03/95]
Under normal circumstances, you do not need to check the fluid
level of the transaxle, since your vehicle does not use up
transaxle fluid. Refer to theMaintenance Schedule and Record
booklet for replacement intervals. However, if the transaxle is
not working properly Ð for instance, the transaxle may slip or
shift slowly, or you may notice some sign of fluid leakage Ð
the fluid level should be checked.
%*
[SV29340(ALL)02/93]
Checking the Automatic Transaxle Fluid
*
[SV29350(ALL)01/95]
With the vehicle on a level surface and the brake fully applied,
start the engine and move the gear shift selector through all of
the gears allowing sufficient time for each position to engage.
Securely latch the gear shift selector in the P (Park) position.
Fully set the parking brake and leave the engine running.
*
[SV29370(ALL)01/95]
Wipe off the dipstick cap and pull the dipstick out. Wipe the
indicator end clean. Put the dipstick back into the filler tube and
make sure it is fully seated. Pull the dipstick out and read the
fluid level.
*
[SV29372(ALL)01/95]
NOTE: Your vehicle should not be driven until some fluid
has been added if the fluid level is below the bottom
dimple on the dipstick and the outside temperature is
above50ÊF (10ÊC). Addonly enough fluid to bring the
level above the bottom hole.
*
[SV29376(ALL)02/95]
If the vehicle has not been driven and the fluid level is above
the bottom dimple on the dipstick, do not add fluid. Recheck
the fluid level after your vehicle has reached normal operating
temperature.
*
[SV29378(ALL)05/95]
Normal operating temperature is reached after driving
approximately 20 miles (30 km). The fluid level should be
within the crosshatched area on the dipstick.
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 227 of 284
![Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
231
*
[SV29380(ALL)01/95]
NOTE: If the vehicle has been operated for an extended
period at high speeds, driven in city traffic during hot
weather, or has been pulling a trailer Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
231
*
[SV29380(ALL)01/95]
NOTE: If the vehicle has been operated for an extended
period at high speeds, driven in city traffic during hot
weather, or has been pulling a trailer](/img/33/11007/w960_11007-226.png)
Servicing Your Mystique
231
*
[SV29380(ALL)01/95]
NOTE: If the vehicle has been operated for an extended
period at high speeds, driven in city traffic during hot
weather, or has been pulling a trailer, the vehicle
should be turned off for about 30 minutes to allow
the fluid to cool before checking.
[SV29382(ALL)05/94]
10-1/2 pica
art:0001226-A
Automatic transaxle fluid dipstick
%*
[SV29400(ALL)01/95]
Adding Automatic Transaxle Fluid
*
[SV29410(ALL)01/95]
Before adding any fluid, be sure that the correct type will be
used. Correct type is shown on the dipstick.
*
[SV29420(ALL)03/95]
Add fluid in 1/2 pint (.25L) increments through the filler tube
to bring the level to the correct area on the dipstick. DO NOT
OVERFILL. If the level is above the top hole on the dipstick,
excess fluid should be removed by a qualified technician.
%*
[SV29425(ALL)04/95]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 228 of 284
![Mercury Mystique 1996 Owners Manuals 232
[SV29800(ALL)02/95]
Manual Transaxle Fluid
[SV29900(ALL)05/94]
The lubricant level and quality should not deteriorate under
normal driving conditions. However, you should have the fluid
level chec Mercury Mystique 1996 Owners Manuals 232
[SV29800(ALL)02/95]
Manual Transaxle Fluid
[SV29900(ALL)05/94]
The lubricant level and quality should not deteriorate under
normal driving conditions. However, you should have the fluid
level chec](/img/33/11007/w960_11007-227.png)
232
[SV29800(ALL)02/95]
Manual Transaxle Fluid
[SV29900(ALL)05/94]
The lubricant level and quality should not deteriorate under
normal driving conditions. However, you should have the fluid
level checked occasionally. If lubricant is required, seeLubricant
Specificationsin this chapter.
*
[SV30200(ALL)03/95]
Brake Fluid
*
[SV30300(ALL)04/95]
Under normal circumstances, your vehicle should not use up
brake fluid rapidly. However, expect the level of the brake fluid
to slowly fall as you put more mileage on your vehicle and the
brake lining wears.
[SV30401(ALL)02/94]
You should check the brake fluid at every scheduled engine oil
change, but be sure to check it at least once a year. You can do
this by looking at the fluid level in the plastic reservoir on the
master cylinder. (SeeThe Engine Typesin this chapter to locate
the brake fluid reservoir.) The fluid level should be at or near
the MAX mark.
*
[SV30450(ALL)05/95]
RWARNING
Brake fluid is toxic.
*
[SV30475(ALL)06/95]
If brake fluid contacts eyes, flush eyes with running water for
15 minutes. Get medical attention if irritation persists. If taken
internally, drink water and induce vomiting. Get medical
attention immediately.
*
[SV30500(ALL)03/95]
If the fluid is low, carefully clean and remove the cap from the
reservoir. Fill the reservoir to the MAX line with Ford High
Performance DOT 3 Brake Fluid C6AZ-19542-AA or equivalent
DOT 3 fluid meeting Ford specification ESA-M6C25-A.
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 229 of 284
![Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
233
*
[SV30800(ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT 3, you will
cause permanent damage to your brakes.
*
[SV30900(ALL)01/95]
Do not fill the reservoir a Mercury Mystique 1996 Owners Manuals Servicing Your Mystique
233
*
[SV30800(ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT 3, you will
cause permanent damage to your brakes.
*
[SV30900(ALL)01/95]
Do not fill the reservoir a](/img/33/11007/w960_11007-228.png)
Servicing Your Mystique
233
*
[SV30800(ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT 3, you will
cause permanent damage to your brakes.
*
[SV30900(ALL)01/95]
Do not fill the reservoir above the MAX line.
*
[SV31000(ALL)01/95]
If you find that the fluid level is excessively low Ð below the
seam or ridge on the outside of the plastic reservoir Ð have the
brake system inspected.
*
[SV31100(ALL)01/95]
RWARNING
Do not let the reservoir for the master cylinder run dry.
This may cause the brakes to fail.
[SV31130(ALL)02/94]
10-1/2 pica
art:0000671-B
The brake fluid reservoir
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
Page 230 of 284
![Mercury Mystique 1996 Owners Manuals 234
*
[SV31200(ALL)03/95]
Power Steering Fluid
*
[SV31225(ALL)03/95]
Checking and Adding Power Steering Fluid
[SV31250(ALL)05/94]
With the power steering system at operating temperature,
switch off th Mercury Mystique 1996 Owners Manuals 234
*
[SV31200(ALL)03/95]
Power Steering Fluid
*
[SV31225(ALL)03/95]
Checking and Adding Power Steering Fluid
[SV31250(ALL)05/94]
With the power steering system at operating temperature,
switch off th](/img/33/11007/w960_11007-229.png)
234
*
[SV31200(ALL)03/95]
Power Steering Fluid
*
[SV31225(ALL)03/95]
Checking and Adding Power Steering Fluid
[SV31250(ALL)05/94]
With the power steering system at operating temperature,
switch off the engine. The fluid level should be up to the MAX
marking on the transparent reservoir.
[SV31275(ALL)05/94]
If it drops to or below the MIN mark, top off with the specified
fluid.
[SV31350(ALL)05/94]
10-1/2 pica
art:0001260-A
The power steering fluid reservoir
[SV32000(ALL)05/95]
Use only power steering fluid that meets Ford's Specification
ESW-M2C33-F or is an equivalent Type F Automatic
Transmission Fluid with a Ford registration number (an 8-digit
number beginning with ª2Pº printed on the fluid container).
File:cdsvz.ex
Update:Fri Feb 23 11:01:54 1996
