Maintenance and care
167
1
1
2
The bulbs for the low beam, high
beam, turn signals and side lamps
are housed in the lamp assembly.
To replace a bulb, the complete
lamp assembly has to be removed
as follows:
1. Switch off the lamps.
2. Open the hood.
3. Remove the lower screw (2)
from the headlamp housing.
4. Remove the two upper screws
(1) from the headlamp housing.
5. Gently pull the headlamp
housing outward.
6. Replace the headlamp bulbs. BULB REPLACEMENT
Handle a halogen headlamp
bulb carefully and keep out
of children’s reach.Grasp the bulb
only by its plastic base and do not
touch the glass. The oil from your
hand could cause the bulb to
break the next time the
headlamps are operated.
Removing the headlamps
assembly
CDW VA1-19Maint en MM 5/15/97 7:56 PM Page 167

Maintenance and care
168Reinstalling the headlamp
assembly
The gasket lining must be seated
properly around the lamp assembly
when reinstalling.
All bulb connectors must be
correctly connected.
Install in the reverse order.
Headlamp – low beam
Pull off the connector, release the
wire clip and replace the bulb.
Pay attention to the tab guides
when replacing.
Headlamp alignment
Check the headlamp alignment
after each replacement of a bulb.
Refer to Aiming the headlamps. Headlamps – high beam
Replacement instructions are the
same as for the low beam
headlamp.
CDW VA1-19Maint en MM 5/15/97 7:56 PM Page 168

Maintenance and care
169 Front turn signal/side lamps
Pull the socket out. Pull the bulb
out and replace it.
Foglamps (if equipped)
1. Detach the cover (access at
bottom of front bumper).
2. Turn the bulb counterclockwise
and pull it out of the light assembly.
3. Remove the electrical connector.
4. Fit the new bulb in reverse order
(do not touch the glass part of the
bulb).
CDW VA1-19Maint en MM 5/15/97 7:56 PM Page 169

Maintenance and care
170
License plate lamp
Unscrew the bulb holder with a
screwdriver. Remove the bulb from
the clip holder.
Replace the new bulb in reverse
sequence. Brake/turn signal/tail lamps
1. Disconnect the electrical
conector.
2. Turn the socket
counterclockwise and pull it out.
3. Turn the bulb counterclockwise
and pull it out.
4. To install, fit the new bulb in
reverse order.
Backup lamps
The backup lamps are located in
the trunk lid. Replacement
instructions are the same as for the
brake/turn signal/tail lamps.
CDW VA1-19Maint en MM 5/15/97 7:56 PM Page 170

Maintenance and care
171
High-mounted brake lamp
Enter the rear seat compartment.
Unscrew both screws and remove
the complete lamp assembly. Bend
the housing outwards to unclip the
lamp module. Press the reflector
fitting from the four locking points
and pull it off. Pull out the wedge
base bulb and replace.
To install, fit the new bulb in
reverse sequence.
On vehicles equipped with a rear
spoiler, the high-mounted brake
lamp is included in the spoiler.
Luggage compartment lamp
Pry out the light assembly from the
holder with a flat screwdriver. Turn
the spherical bulb under slight
pressure counterclockwise and
remove.
CDW VA1-19Maint en MM 5/15/97 7:56 PM Page 171

Maintenance and care
172
FunctionTrade number
3457 NA
9005
9006
893
1157
1156 Front /turn lamp
Headlamp (high)
Headlamp (low)
Fog lamp
Rear tail/turn/brake lamp
Backup lamp
Bulb specifications
2723
C5W
High-mounted brake lamp
License plate lamp
Reading lamps (if equipped)
Open the lamp assembly.
The bulbs can be replaced after the
contact plate has been hinged
back. Interior lamps
Switch off the interior lamps
(middle switch position). Pry out
the lamp assembly with a flat
screwdriver, release the reflector at
the side and replace the festoon
bulb.
To install, fit the new bulb in
reverse sequence.
