Trip Odometer
%*
[LG08900(ALL)01/93]
The trip odometer records the distance of individual trips.
Before each trip, set the trip odometer to zero by pushing the
reset button.
[LG09000(ALL)09/93]
10-1/2 pica
art:0040069-B
Speedometer, odometer and trip odometer
*
[LG09100(ALL)02/95]
Tachometer
[LG09200(ALL)01/93]
The tachometer tells you how fast the engine is running by
indicating approximate engine revolutions per minute.
*
[LG09300(ALL)04/95]
Driving with the pointer in the red zone may cause engine damage.
[LG09350(ALL)06/96]
10-1/2 pica
art:0040400-A
Engine coolant temperature gauge
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

Warning Lights and Gauges
81
%*
[LG09400(ALL)09/93]
Electronic Cluster (If equipped)
[LG09500(ALL)04/95]
33-1/2 pica
art:0040064-I
Electronic cluster
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

82
[LG09600(ALL)01/93]
The electronic cluster has all of the same warning lights as the
mechanical cluster, however, some of the gauges will be
electronic instead of analog. In addition, the electronic cluster
has a fuel computer for measuring fuel economy, distance to
empty and outside air temperature.
*
[LG09700(ALL)01/95]
Engine Coolant Temperature Gauge
[LG09800(ALL)01/93]
This gauge shows you the temperature of the engine coolant
and is identified by a thermometer symbol. The letter H means
that the coolant is hot, C means that it is cold, and NORMAL
means that the coolant is within the normal operating range.
[LG09900(ALL)09/93]
The indicator bar on the graph will move into the normal
operating range as the engine warms up. When you are in
heavy traffic or stop-and-go driving in hot weather, the gauge
may read at the very top of the NORMAL range. This is
acceptable.
[LG10000(ALL)09/93]
However, if the indicator bar on the graph moves into the
H (hot) position, the engine is overheating and may cause
engine damage. If this happens, you should stop your vehicle as
soon as safely possible. Turn off the engine and let it cool.
Check the coolant level to be sure that it is at the proper level.
If your vehicle needs more coolant, seeEngine coolant, checking
and addingin the Index and read the section regarding adding
coolant.
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

Warning Lights and Gauges
83
[LG10100(ALL)09/93]
10-1/2 pica
art:0040068-A
Engine coolant temperature gauge
*
[LG10200(ALL)01/95]
Fuel Gauge
[LG10300(ALL)01/93]
The fuel gauge displays approximately how much fuel you have
in the fuel tank. The number of bars illuminated in the display
indicates how much fuel is left. An accurate reading may be
obtained when the vehicle is on smooth, level ground.
[LG10350(ALL)09/93]
7-1/2 pica art:0040070-A
Fuel gauge
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

84
[LG10400(ALL)02/94]
Fuel and Distance Computer
[LG10500(ALL)09/93]
7-1/2 pica art:0040067-B
Fuel and distance computer
[LG10600(ALL)04/95]
The fuel and distance computer has five buttons to operate the
different functions.
% [LG10700(ALL)01/93]
SELECT Ð The SELECT button lets you choose the functions
of the fuel computer. Each time you press the SELECT
button, the computer advances to the next choice on the
menu. After it reaches the last choice on the menu, it returns
to the top of the menu.
[LG10800(ALL)01/93]
RESET Ð The RESET button is used to reset the Average
Economy function. Press the SELECT button until the
Average Economy function is displayed. Then press the
RESET button.
% [LG10900(ALL)04/94]
ENG/MET Ð The ENG/MET button allows you to change
your gauges from English to metric units or from metric to
English units. The displays remain in the units you choose
until you change them again, even after you turn off the
vehicle and start it again.
[LG11000(ALL)04/95]
TRIP/RST Ð The TRIP/RST button is used to reset the trip
odometer mileage. Press the OD/TRIP button until the trip
odometer mileage is displayed. Then press the TRIP/RST
button.
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

Warning Lights and Gauges
85
[LG11100(ALL)01/93]
OD/TRIP Ð The OD/TRIP button lets you switch the
display between the permanent odometer mileage and the
trip odometer mileage.
[LG11200(ALL)06/94]
Fuel computer functions
[LG11300(ALL)09/93]
10-1/2 pica
art:0040066-A
Fuel and distance computer display
[LG11400(ALL)01/93]
OUTSIDE TEMP
[LG11500(ALL)01/93]
This feature lets you display the temperature of the air outside
of your vehicle.
[LG11550(ALL)04/94]
The fuel and distance computer is designed to prevent
inaccurate temperature display readings. For example, a sudden
temperature change (such as driving out of a cool garage on a
warm day), may show outside temperature display readings
which are lower than expected. The accurate temperature will
be displayed after the vehicle has reached the outside
temperature and is driven at speeds of 30 mph (48 km/h) or
greater.
[LG11575(ALL)01/94]
In the event of a decrease in the outside air temperature, there
will be no delay in an accurate temperature display.
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

86
[LG11600(ALL)01/93]
INST ECONOMY
[LG11700(ALL)01/93]
Your instantaneous fuel economy is the fuel economy you get at
any particular moment. For example, you can see what your
fuel economy is in heavy traffic or on the highway.
[LG11800(ALL)01/93]
Factors such as braking, acceleration, and road terrain affect
your fuel economy.
[LG11900(ALL)01/93]
To display instantaneous fuel economy, press the SELECT
button until the menu displays INST ECONOMY. Your vehicle
must be moving for the computer to calculate a fuel economy
greater than zero.
[LG12000(ALL)01/93]
AVG ECONOMY
[LG12100(ALL)01/93]
The average fuel economy is an overall average of your fuel
economy taken from the last time the reset button was pushed.
The computer takes an average of all the types of driving you
have done since the RESET button was pressed (highway, city,
heavy traffic), and figures out the average fuel economy. You
can calculate your average fuel economy as often as you like.
For example, you can calculate the average fuel economy for
each tank of fuel or for every day.
[LG12200(ALL)01/93]
To display the average fuel economy:
[LG12300(ALL)01/93]1.
Press the SELECT button until the menu displays AVG
ECONOMY.
[LG12400(ALL)03/91]2.
You will probably display the average fuel economy for each
tank of fuel or for each trip you take. Each time you want to
recalculate the average fuel economy, you need to press the
RESET button. The average fuel economy must be displayed
to reset the fuel computer.
[LG12500(ALL)01/93]
The best time to reset the AVG ECONOMY is when you fill
the fuel tank or at the beginning of a trip.
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

Warning Lights and Gauges
87
[LG12600(ALL)01/93]
TO EMPTY
[LG12700(ALL)01/93]
The Distance to Empty function tells you approximately how
many miles or kilometers you can drive until you run out of
fuel.
[LG12800(ALL)01/93]
To see the Distance to Empty, press the SELECT button until
the menu displays TO EMPTY. The fuel computer displays
approximate distance to empty until you select another function.
[LG12900(ALL)07/94]
To ensure accuracy, turn the ignition to the OFF position when
you fill the fuel tank.
File:05vxlgn.ex
Update:Tue Jun 4 11:35:19 1996

89
Instrument Panel Controls
[IP01000(ALL)01/93]
Instrument Panel
[IP01100(ALL)06/95]
33-1/2 pica art:0040084-F
Instrument panel
File:06vxipn.ex
Update:Mon Jun 3 14:33:05 1996

90
*
[IP01200(ALL)01/93]
