Page 32 of 396
30
%*
[SR13410(ALL)05/95]
The air bag system uses a readiness light on the instrument
cluster and a tone to indicate the condition of the system. When
you turn the ignition key to the ON position, this light will
illuminate for approximately six (6) seconds and then turn off.
This indicates that the system is operating normally. NOTE:
Maintenance of the air bag system is not required.
%*
[SR13420(ALL)06/95]
A problem with the system is indicated by one or more of the
following:
*
[SR13430(ALL)06/95]
n
the readiness light will either flash or stay lit,
*
[SR13440(ALL)06/95]
n
or it will not light immediately after ignition is turned on,
*
[SR13450(ALL)06/95]
n
or a group of five beeps will be heard. The tone pattern will
repeat periodically until the problem and light are repaired.
[SR13460(ALL)06/95]
If any of these things happen, have the air bag system serviced
at your Ford or Lincoln-Mercury dealer immediately. Unless
serviced, the air bag supplemental restraint system may not
function properly in the event of a collision.
*
[SR13500(ALL)07/95]
RWARNING
Do not attempt to service, repair, or modify the Air Bag
Supplemental Restraint System or its fuses. See your
Ford or Lincoln-Mercury dealer.
[SR13550(ALL)07/95]
Disposal of supplemental air bags or supplemental air
bag equipped vehicles
*
[SR13560(ALL)06/95]
For disposal of air bags or air bag equipped vehicles, see your
local Ford or Lincoln-Mercury dealer. Air bagsMUSTbe
disposed of by qualified personnel.
File:03vxsrn.ex
Update:Wed Jun 5 12:21:10 1996
Page 226 of 396
230
[DR01600(ALL)09/93]Shift-lock Safety Feature
[DR01700(ALL)04/95]Your vehicle has a special shift-lock safety feature which
prevents you from shifting out of P (Park) without the brake
pedal depressed. To shift the transaxle out of the P (Park)
position, the ignition must be in the ON position and your foot
must be pressing on the brake pedal.
*[DR01800(ALL)04/95]If the shift lever cannot be moved from the P (Park) position
with the brake pedal depressed:
*[DR01900(ALL)01/93]1.Shut the engine off and remove the ignition key.
*[DR02000(ALL)01/93]2.Apply the parking brake.
*[DR02100(ALL)01/93]3.Reinsert the ignition key and turn it clockwise to the first
position (OFF).
*[DR02200(ALL)04/95]4.Depress the brake pedal, move the gearshift lever to N
(Neutral) and start the engine.
*[DR02290(ALL)06/95]If you need to shift out of P (Park) by using the alternate
procedure described above, it is possible that a fuse has blown
and that your brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Villagerin this Owner
Guide for instructions on checking and replacing fuses.
*[DR02300(ALL)05/95]R WARNING
DO NOT DRIVE YOUR VEHICLE UNTIL YOU VERIFY
THAT THE BRAKELAMPS ARE WORKING.
%*[DR02500(ALL)06/92]Backing Up
*[DR02600(ALL)06/95]Before shifting into or out of R (Reverse), you should always
come to a complete stop.
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996
Page 247 of 396
Driving Your Villager
251
*
[DR19600(ALL)01/93]
Trailer Brakes
*
[DR19700(ALL)01/93]
Separate trailer brakes are required on most trailers weighing
over 1,500 lbs. (680 kg).
*
[DR19800(ALL)05/95]
RWARNING
Do not connect a trailer's hydraulic brake system directly
to your vehicle's brake system. Your vehicle may not
have enough braking power and your chances of having
a collision greatly increase.
*
[DR19900(ALL)01/93]
Trailer Lamps
*
[DR20000(ALL)01/93]
Make sure your trailer lamps conform to federal and local
regulations.
*
[DR20100(ALL)01/93]
Class I Trailer Tow electrical wiring provides two circuits (right
hand and left hand) to operate trailer stop/turn tail lamps. Each
stop/turn circuit will operate one combination stop/turn light
bulb (# 1157, 3157, 2357, or 3357) on the trailer. Never add more
than one trailer light bulb to one circuit.
*
[DR20200(ALL)05/95]
RWARNING
Always replace a fuse with one that has the specified
amperage rating. Using a fuse with a higher amperage
rating can cause severe wire damage and could start a
fire.
[DR20210(ALL)04/94]
Trailer Tow Module (If equipped)
[DR20220(ALL)06/94]
The trailer tow module on your vehicle (if equipped) allows
turn/stop lamp control on a trailer being towed by your
vehicle.
[DR20230(ALL)04/94]
The trailer tow package includes:
[DR20240(ALL)04/94]
n
trail or tow module which draws power from the vehicle
stop lamp fuse
File:11vxdrn.ex
Update:Tue Jun 4 11:42:50 1996
Page 292 of 396
298
%*
[SV03800(ALL)03/95]
Opening the Hood
[SV03900(ALL)01/93]1.
Pull the hood release handle, located below the fuse panel
door.
[SV04000(ALL)09/93]
13-1/2 pica
art:0040189-C
Hood release handle location
[SV04100(ALL)01/93]2.
Go to the front of the vehicle and release the hood latch
under the hood in the front center of the vehicle.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996
Page 331 of 396
Servicing Your Villager
337
*
[SV35200(ALL)01/93]
If you must check the power steering fluid when it is cold,
make sure that the fluid reaches at least the minimum (MIN)
mark. The reading will only be accurate if the fluid temperature
is approximately 70Ê to100ÊF (21Ê to 38ÊC).
%*
[SV35300(ALL)04/95]
Fuses, Fuse Links and Circuit Breakers
[SV35400(ALL)05/95]
Fuses, fuse links and circuit breakers protect your vehicle's
electrical system from overloading. If electrical parts in your
vehicle are not working, the system may have been overloaded
causing a blown fuse or tripped circuit breaker. Before you
replace or repair any electrical parts, check the appropriate fuses
or circuit breakers.
[SV35500(ALL)01/93]
The following charts tell you which fuses or circuit breakers
protect each electrical part of your vehicle. If a fuse blows or a
circuit breaker trips (opens) a circuit, all the parts of your
vehicle that use that circuit will not work.
*
[SV35600(ALL)06/95]
Once you have determined which fuses or circuit breakers to
check, follow the procedures underChecking and replacing fuses
orChecking and replacing circuit breakerslater in this chapter.
[SV35700(ALL)09/95]
NOTE: Fuse links should only be repaired by your Ford or
Lincoln-Mercury dealer.
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996
Page 332 of 396
338
%*
[SV35800(ALL)06/95]
Checking and Replacing Fuses
*
[SV35900(ALL)01/93]
If you need to check a fuse, find the fuse panel for the electrical
system, which is located under the instrument panel, and follow
these steps:
*
[SV36000(ALL)09/93]1.
To remove the fuse panel cover, pull down on the fuse panel
cover handle.
[SV36100(ALL)06/95]
17-1/2 pica
art:0040203-B
The instrument panel fuse panel
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996
Page 333 of 396
Servicing Your Villager
339
*
[SV36200(ALL)06/95]2.
On the fuse panel cover, find the number of the fuse you
want to check. The diagram on the cover tells you where to
locate the fuse on the panel.
[SV36250(ALL)06/95]
24 pica art:0040217-I
The fuse panel cover
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996
Page 336 of 396
342
[SV36350(ALL)07/95]
twenty pica
chart:0040240-D*
[SV36400(ALL)06/95]3.
Check the fuse to see if it is blown. Look through the clear
side of the fuse to see if the metal wire inside is separated. If
it is, the fuse is blown and should be replaced.
*
[SV36500(ALL)09/93]
7-1/2 pica art:0040210-B
Fuse puller tool and fuse
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996
Page 337 of 396
ServicingYou rVillager
343
WARNING
Alway sreplac eafusewit hon etha tha sth especified
File:15vxsvn.ex
Page 338 of 396
344
%*
[SV37000(ALL)01/93]
Engine Compartment Main Fuse Panel
[SV37100(ALL)06/95]
10-1/2 pica
art:0040303-A
Engine compartment main fuse panel
File:15vxsvn.ex
Update:Wed Jun 5 12:25:18 1996
