Electronic Sound Systems
49
[AS32720(ALL)06/95]
How to Use Your Steering Wheel Audio
Controls (If equipped)
[AS32740(ALL)06/95]
If your vehicle is equipped with steering wheel audio controls,
the controls are located on the inner right rim of the steering
wheel. These controls duplicate some of the audio functions.
[AS32760(ALL)06/95]
How to adjust volume
[AS32780(ALL)06/95]
Press the up arrow button (
c) to increase the volume.
[AS32800(ALL)06/95]
Press the down arrow button (
d) to decrease the volume.
[AS32820(ALL)06/95]
Using the ªNEXTº button
[AS32840(ALL)07/95]
This control has different functions for each source (mode). In
the radio mode, the radio will cycle through the memory
presets for the given frequency band. In cassette mode, the tape
advances to the next selection. In CD mode, the CD will move
to the next track on the given disc.
*
[AS35200(ALL)04/96]
Common Radio Reception Conditions
[AS35300(ALL)03/93]
Several conditions affect FM reception and can result in noise or
interference in the reception. These are:
[AS35400(ALL)05/96]
Distance/Strength
[AS35500(ALL)05/94]
The strength of the FM signal is directly related to the distance
the signal must travel. The listenable range of an average FM
signal is approximately 25 miles (40 km). Beyond this distance,
the radio is operating in a ªfringeº area and the signal becomes
weaker.
File:04vxasn.ex
Update:Thu May 30 09:46:22 1996
Page 52 of 389
50
[AS35600(ALL)05/96]
Terrain
[AS35700(ALL)05/94]
The terrain (hills, mountains, tall buildings) of the area over
which the signal travels may prevent the FM signal from being
noise-free.
*
[AS35900(ALL)08/95]
If there is a building or large structure between the antenna and
station, some of the signal ªbendsº around the building, but
certain spots receive almost no signal. Moving out of the
ªshadowº of the structure will allow the station to return to
normal.
[AS36000(ALL)05/95]
This condition exists when the radio waves are reflected off
objects or structures; the reflected signal cancels the normal
signal, causing the antenna to pick up noise and distortion.
Cancellation effects are most prominent in metropolitan areas,
but also can becomes quite severe in hilly terrain and depressed
roadways.
[AS36100(ALL)03/93]
To minimize the effects of these conditions, a stereo/mono
blend circuit has been incorporated into this system. This feature
automatically switches a weak stereo signal to a clearer
monaural signal, which improves the quality of reception.
*
[AS36200(ALL)08/95]
Several sources of static are normal conditions on AM
frequencies. These can be caused by power lines, electric fences,
traffic lights and thunderstorms.
*
[AS36300(ALL)08/95]
Another reception phenomenon isStrong Signal Capture and
Overload. This can occur when listening to a weak station and
when passing another broadcast tower. The close station may
capture the more distant station, although the displayed
frequency does not change. While passing the tower, the station
may switch back and forth a few times before returning to the
original station.
File:04vxasn.ex
Update:Thu May 30 09:46:22 1996
Page 53 of 389
Electronic Sound Systems
51
*
[AS36400(ALL)03/96]
When several broadcast towers are present (common in
metropolitan areas), several stations may overload the receiver,
resulting in considerable station changing, mixing and
distortion.
*
[AS36500(ALL)08/95]
Automatic gain control circuitry for both AM and FM bands has
been incorporated into this system to reduce strong signal
capture and overload.
%*
[AS36600(ALL)08/95]
All About Radio Frequencies
[AS36700(ALL)06/95]
The Federal Communications Commission (FCC) and the
Canadian Radio and Telecommunications Commission (CRTC)
establish the frequencies that AM and FM radio stations may
use for their broadcasts. The allowable frequencies are: AM: 530,
540...1700, 1710 kHz in 10 kHz steps; FM: 87.9, 88.1...107.7, 107.9
MHz in 0.2 MHz steps.
[AS36800(ALL)03/93]
Not all frequencies will be assigned to a given area. This radio
will tune to each of these frequencies using manual tuning and
no fine tuning is necessary as radio stations may not use other
frequencies.
[AS36900(ALL)03/93]
Some FM radio stations advertise a ªrounded-offº frequency
which is not the frequency on which they actually broadcast.
For example, a radio station that is assigned a frequency of 98.7
MHz may call itself ªRadio 99º even though 99.0 MHz is not an
allowable FM broadcast frequency.
File:04vxasn.ex
Update:Thu May 30 09:46:22 1996
Page 54 of 389
52
%*
[AS37000(ALL)08/95]
Important Warranty and Service Information
*
[AS37050(ALL)01/95]
About Your Warranty
[AS37100(ALL)05/96]
Your sound system is warranted for three years or 36,000 miles
(whichever comes first). Consult your vehicle warranty booklet
for further information.
*
[AS37150(ALL)01/95]
Servicing Your Audio System
[AS37200(ALL)03/93]
At Ford Audio, we stand behind our audio systems with a
comprehensive service and repair program. If anything should
go wrong with your Ford Audio System, return to your dealer
for service. There is a nationwide network of qualified Ford
authorized repair centers to service your problem.
File:04vxasn.ex
Update:Thu May 30 09:46:22 1996
Page 55 of 389
53
Controls and Features
*
[CF00200(ALL)03/96]
Your vehicle has a variety of features designed for your
comfort, convenience and safety. Read this chapter to find out
about standard and optional features.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996
Page 56 of 389
54
[CF00300(ALL)01/96]
Instrument Panel
[CF00350(ALL)01/96]
33-1/2 pica art:0040084-F
Instrument panel
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996
Page 57 of 389
Controls and Features
55
*
[CF00400(ALL)01/96]
The instrument panel (dashboard) on your vehicle is divided
into several different sections. Illustrations are provided for the
major parts of the instrument panel that are explained in this
chapter. Some items shown may not be on all vehicles.
[CF00500(ALL)01/96]
27-1/2 pica art:0040083-EFile:05vxcfn.ex
Update:Thu May 30 09:49:09 1996
Page 58 of 389
56
[CF00600(ALL)01/96]
The controls for the climate control systems, headlamps, clock,
radio, rear window washer and wiper, hazard flasher, power
switch, and speed control are all on the instrument panel.
%*
[CF00700(ALL)01/96]
Climate Control Systems
[CF00800(ALL)03/96]
13-1/2 pica
art:0040301-B
Climate control system panel
[CF00900(ALL)01/96]
Function Selector Buttons
[CF00950(ALL)03/96]
There are six function selector buttons: OFF, Mix, Defrost, Panel,
Panel/Floor, and Floor. When you press a function selector
button, the indicator light on the button will illuminate. If your
vehicle is equipped with a rear passenger compartment climate
control system, the instrument panel will also include a rear seat
function selector.
[CF01000(ALL)01/96]
n
The OFF button shuts off the air supply to all outlets and
stops all fan operations. Use this setting when driving
through an area where outside air is unpleasant or dusty.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996
Page 59 of 389
Controls and Features
57
[CF01100(ALL)01/96]
RWARNING
Operating with the function selector control in off or in
the recirculated air mode for extended periods of time in
cold weather can result in fog buildup on interior glass
surfaces.
[CF01200(ALL)01/96]
n
The Mix (P) button directs approximately equal amounts of
air to the windshield and floor outlets with a small amount
to the side windows.
[CF01300(ALL)01/96]
n
The Defrost (V) button directs air to the windshield with a
small amount going to the floor outlets.
[CF01400(ALL)03/96]
n
The Panel (Q) button directs air to the instrument panel
outlets.
[CF01500(ALL)01/96]
n
The Panel/Floor (S) button directs approximately equal
amounts of air to the instrument panel outlets and the floor
outlets.
[CF01600(ALL)01/96]
n
The Floor (R) button directs most of the system's air
supply to the floor outlets with a small amount going to the
windshield and side window defrosters.
[CF01700(ALL)01/96]
Air Outlets
[CF01800(ALL)01/96]
Air intake selector button
[CF01900(ALL)01/96]
The typical air intake selection is outside air. However, for
recirculated air, the air intake selector button may be activated.
When the air intake selector button is activated (indicator light
is on), it prevents the intake of outside air. This is the typical
selection when using the air conditioner (if equipped). It
recirculates interior air for faster cooling. The recirculated air
function also helps to prevent the intake of dusty or unpleasant
air.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996
Page 60 of 389
58
[CF02000(ALL)01/96]
There are several air outlets on the instrument panel. There are
side outlets near the driver's window and passenger's window,
two center outlets, floor outlets, and windshield outlets. The
direction and amount of air flow from the center and side
instrument panel outlets can be adjusted for personal comfort.
[CF02050(ALL)03/96]
NOTE: Selection of the recirculated air mode under cold and
humid conditions may result in window fogging due
to entrapped humidity within the vehicle. To
counteract this circumstance, switch to the Defrost
mode and set fan speed to 3 or 4. Adjust air
temperature to a ªwarmº instead of ªhotº setting and
deactivate the air intake selector.
[CF02100(ALL)04/96]
Heating Only System (Without air conditioning)
[CF02200(ALL)01/96]
You can heat and ventilate the inside of your vehicle, or defrost
the windshield with the function selector buttons, the fan speed
knob and the temperature control knob.
[CF02300(ALL)01/96]
An additional push-on/push-off air intake selector button
provides for the selection of recirculated inside air (button
lighted) or outside air (button not lighted).
