Maintenance and Care
287
[MC18423(ALL)01/96]
13-1/2 pica
art:0040205-C
Brake fluid master cylinder reservoir
%*
[MC18425(ALL)02/96]
Windshield Washer Fluid
[MC18435(ALL)01/96]
Check the level of the windshield washer fluid every time you
stop for fuel, or when the warning light indicates low washer
fluid. The reservoir for washer fluid is located in the engine
compartment. This reservoir contains the fluid for both the
windshield and liftgate washers.
*
[MC18440(ALL)01/96]
RWARNING
Do not put windshield washer fluid in the container for
the engine coolant.
*
[MC18445(ALL)05/96]
If sprayed to clean the glass, engine coolant or antifreeze could
make it difficult to see through the windshield.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

290
*
[MC18700(ALL)05/96]
Adding Engine Coolant
[MC18800(ALL)01/96]
17-1/2 pica
art:0040197-C
Engine coolant recovery reservoir
*
[MC18900(ALL)05/96]
RWARNING
Do not put engine coolant in the container for the
windshield washer fluid.
*
[MC19000(ALL)05/96]
When the engine is cool, add a 50/50 mixture of engine coolant
and water to the engine coolant recovery reservoir Ð DO NOT
ADD DIRECTLY TO THE RADIATOR. Add straight water only
in an emergency, but you should replace it with a 50/50
mixture of coolant and distilled water as soon as possible.
*
[MC19025(ALL)05/96]
Check the coolant level in the coolant recovery reservoir the
next few times you drive the vehicle. If necessary, add enough
of a 50/50 mixture of coolant and water to bring the liquid
level to the fill line on the reservoir.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

Maintenance and Care
291
*
[MC19100(ALL)05/96]
RWARNING
Never remove the coolant recovery cap while the engine
is running or hot.
*
[MC19200(ALL)05/96]
If you must remove the coolant recovery cap, follow these steps
to avoid personal injury caused by escaping steam or engine
coolant:
*
[MC19225(ALL)05/96]1.
Before you remove the cap, turn the engine off and let it
cool.
*
[MC19250(ALL)05/96]2.
When the engine is cool, wrap a thick cloth around the cap.
Slowly turn cap counterclockwise to the first stop.
*
[MC19275(ALL)05/96]3.
Step back while the pressure releases.
*
[MC19280(ALL)05/96]4.
When you are sure that all the pressure has been released,
use the cloth to press the cap down, turn it counterclockwise,
and remove it.
[MC19300(ALL)05/96]
Use Ford Premium Engine Coolant E2FZ-19549-AA (in Canada,
Motorcraft CXC-8-B) or an equivalent premium engine coolant
that meets Ford Specification ESE-M97B44-A. Ford Premium
Engine Coolant is an optimized formula that will protect all
metals and rubber elastomers used in Ford cooling systems for 4
years or 50,000 miles (80,000 km).
*
[MC19400(ALL)05/96]
Do not use alcohol or methanol antifreeze or any engine
coolants mixed with alcohol or methanol antifreeze. Do not use
supplemental coolant additives in your vehicle. These additives
may harm your engine cooling system.The use of an improper
coolant may void the warranty of your vehicle's engine cooling
system.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

296
[MC20990(ALL)01/96]
When checking fluid at normal operating temperature, the fluid
level should be within the crosshatched area on the dipstick.
When the vehicle has not been driven, and outside temperature
is above50ÊF (10ÊC), thefluid level should be between the
notches on the dipstick.
[MC21000(ALL)01/96]
RWARNING
Your vehicle should not be driven if the transaxle fluid
level is below the bottom notch on the dipstick.
[MC21010(ALL)01/96]
10-1/2 pica
art:0040202-B
Automatic transaxle fluid dipstick
%*
[MC21020(ALL)01/96
]
Adding Automatic Transaxle Fluid
*
[MC21030(ALL)01/96]
The fluid type is stamped on the dipstick. Before adding any
fluid, be sure that the correct type will be used.
*
[MC21040(ALL)01/96]
Add fluid in 1/2 pint (0.25 liter) increments through the filler
tube to bring the level to the correct area on the dipstick. If an
overfill occurs, excess fluid should be removed by a qualified
technician.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

298battery cells. When operating at ambient temperatures above
90ÊF (32ÊC),check the electrolyte level more frequently.
[MC21340(ALL)05/96]
If the level of the electrolyte in a cell of the battery is low, add
distilled water until the proper level in each cell is restored.
Plain tap water will work; but if it is ªhard waterº having a
high mineral or alkali content, the life of the battery may be
reduced and the frequency of maintenance required on the
battery will increase.
%*
[MC21345(ALL)01/96
]
Help Us Protect Our Environment
*
[MC21350(ALL)01/96]
Ford Motor Company strongly recommends that used lead-acid
batteries be returned to an authorized recycling facility for
disposal.
*
[MC21355(ALL)01/96]
7-1/2 pica art:0040201-A
Battery recycling symbol
*
[MC21360(ALL)02/96]
RWARNING
The gases around the battery can explode if exposed to
flames, sparks, or lit cigarettes. An explosion could result
in injury or vehicle damage.
*
[MC21365(ALL)05/96]
RWARNING
To protect yourself when charging a battery, always
shield your face and eyes. Make sure that you can
breathe fresh air.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

Maintenance and Care
299
%*
[MC21370(ALL)05/96
]
RWARNING
Batteries contain sulfuric acid which burns skin, eyes,
and clothing.
*
[MC21375(ALL)02/96]
If the acid touches someone's skin, eyes, or clothing,
immediately flush the area with water for at least 15 minutes. If
someone swallows the acid, have him or her drink lots of milk
or water first, then Milk of Magnesia, a beaten egg, or vegetable
oil. Call a doctor immediately.
%*
[MC21380(ALL)02/96
]
RWARNING
Applying too much pressure on the ends when lifting a
battery could cause acid to spill. Lift the battery with a
carrier or with your hands on the opposite corners.
[MC21420(ALL)04/96]
Air Filter
[MC21500(ALL)01/96]
10-1/2 pica
art:0040278-A
Air filter housing
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

300
[MC21600(ALL)03/96]
The air filter should not be cleaned and reused. Replace it
according to the maintenance intervals shown in theMaintenance
Schedulebooklet. When replacing the filter, unclip the four
clamps and remove the filter. Wipe the inside of the air filter
housing with a damp cloth when replacing the filter.
*
[MC21700(ALL)01/96]
RWARNING
Never pour fuel in the throttle body or attempt to start
the engine with the air cleaner removed. Doing so could
result in fire and personal injury.
%*
[MC22300(ALL)02/96]
Wiper Blades
*
[MC22400(ALL)01/96]
Check the windshield wiper blades at least twice a year. Also
check them whenever they seem less effective than usual.
Substances such as tree sap and some hot wax treatments used
by commercial car washes reduce the effectiveness of wiper
blades.
*
[MC22500(ALL)01/96]
If the blades do not wipe properly, clean both the windshield
and the wiper blades. Use undiluted windshield washer solution
or a mild detergent. Rinse thoroughly with clear water. Do not
use fuel, kerosene, paint thinner, or other solvents to clean your
wiper blades. These will damage your blades.
*
[MC22600(ALL)01/96]
To reach the wiper blades easily, turn the ignition switch to
ACCESSORY and turn your wipers on. Wait for them to reach a
vertical position and turn the ignition to OFF. Moving the
wipers manually may damage them.
*
[MC22700(ALL)02/96]
Wiper blade replacement
*
[MC22800(ALL)01/96]
If the wipers still do not work properly after you clean them,
you may need to replace the wiper blade assembly. When
replacing the wiper blade assembly always use a Motorcraft part
or equivalent.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

302
*
[MC23800(ALL)03/96]
n
Make sure the weight of your load is evenly distributed.
*
[MC23900(ALL)03/96]
n
Adjust tire pressure to recommended specifications found on
the Safety Compliance Certification Label.
*
[MC24000(ALL)03/96]
If you do not take these precautions, your tires may fail or go
flat.
*
[MC24100(ALL)01/96]
RWARNING
Always obey posted speed limits. If you drive too fast
for road conditions, you could lose control of your
vehicle. Under some circumstances, driving at very high
speeds for extended periods of time may damage vehicle
components, creating a risk of component failure and a
potential loss of vehicle control. Any time you lose
control of your vehicle, it may result in injury.
[MC24300(ALL)01/96]
At least once a month, check the pressure in all your vehicle's
tires, including the spare. Use an accurate tire pressure gauge.
Check the tire pressure when tires are cold, after the vehicle has
been parked for at least one hour or has been driven less than 3
miles (5 km). You can find the proper cold tire pressure on the
Tire Pressure Decal, located in the glove compartment.
*
[MC24400(ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle handling and
can fail suddenly, possibly resulting in loss of vehicle
control.
%*
[MC24500(ALL)01/96
]
Tire Inspection and Maintenance
*
[MC24600(ALL)05/96]
Inspect the tire treads and remove stones, nails, glass or other
objects that may be wedged in the tread grooves. Check for
holes or cuts that may permit air to leak from the tire and make
the necessary repairs.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

304
[MC25400(ALL)01/96]
RWARNING
If you use the temporary spare tire continuously or do
not follow these precautions, the tire could fail, causing
you to lose control of the vehicle.
[MC25500(ALL)01/96]
If your vehicle has aluminum wheels, you may remove the
spare tire from the wheel and remount it on an aluminum
wheel to rotate the spare tire into your vehicle's rotation
pattern.
%*
[MC25600(ALL)01/96
]
Replacing the Tires
*
[MC25700(ALL)01/96]
Replace tires that show wear bands. When your tire shows a
wear band, it has only 1/16 of an inch (1.59 mm) of tread left.
*
[MC25800(ALL)01/96]
7-1/2 pica art:0040200-A
A worn-out tire
*
[MC25900(ALL)02/96]
Because your vehicle's tires may wear unevenly, you may need
to replace them before a wear band appears across the entire
tread.
*
[MC26000(ALL)03/96]
Your wheels and tires are match-mounted for improved ride.
Before you begin to repair a tire, mark the wheel and tire so
that they are properly aligned when remounted. This will
ensure that the tires will continue to give you the same ride
level.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996

Maintenance and Care
305
*
[MC26100(ALL)01/96]
RWARNING
When replacing full size tires, never mix radial,
bias-belted, or bias-type tires. Use only the tire sizes that
are listed on the tire pressure decal. Make sure that all
tires are the same size, speed rating, and load-carrying
capacity. Use only the tire combinations recommended on
the decal. If you do not follow these precautions, your
vehicle may not drive properly and safely.
*
[MC26200(ALL)03/96]
RWARNING
Make sure that all replacement tires are of the same size,
type, load-carrying capacity, and tread design (e.g. ªAll
Terrainº, etc.), as originally offered by Ford.
*
[MC26300(ALL)03/96]
RWARNING
Failure to follow these precautions may adversely affect
the handling of the vehicle and make it easier to lose
control and roll over.
*
[MC26400(ALL)01/96]
Tires that are larger or smaller than your vehicle's original tires
may affect the accuracy of your speedometer and odometer.
%*
[MC26500(ALL)03/96
]
Wheel and Tire Matching
*
[MC26510(ALL)03/96]
See an authorized tire dealer for proper servicing procedures.
Wheels and tires must be properly removed, matched and
remounted to maintain the best possible ride.
%*
[MC27400(ALL)01/96
]
Information About Tire Quality Grades
*
[MC27500(ALL)01/96]
New vehicles are fitted with tires that have their Tire Quality
Grade (described below) molded into the tire's sidewall. These
Tire Quality Grades are determined by standards that the
United States Department of Transportation has set.
File:11vxmcn.ex
Update:Mon Jun 10 15:17:05 1996
