MINI Clubman 2012 Owner's Manual

REFERENCETechnical data
190
CooperCooper S, John Cooper Works
1Vehicle height without roof
antenna 56.1/1,426 56.4/1,432
2 Track, front
57.4/1,45957.2/1,453
3 Vehicle width, with outside mirror
75.3/1,91375.3/1,913
4 Track, rear
57.8/1,46757.5/1,461
5 Vehicle width, without outside
mirror 75.3/1,913
75.3/1,913
6 Wheelbase
100.3/2,547100.3/2,547
7 Vehicle length
155.9/3,961155.9/3,961
All dimensions in inches/mm. Minimu m turning radius dia.: 36 ft/11.0 m.
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

Technical dataREFERENCE
191
Weights
Never exceed either the approved axle loads or the gross vehicle weight.
MINI
CooperCooper SJohn Cooper Works
Curb weight, ready for travel, with all optional extras
>Manual transmission lbs/kg 2,535/1,150 2,668/1,210 2,679/1,215
> Automatic
transmission lbs/kg 2,612/1,185 2,712/1,230 2,723/1,235
Approved gross weight
> Manual transmission lbs/kg 3,384/1,535 3,494/1,585 3,527/1,600
> Automatic
transmission lbs/kg 3,461/1,570 3,538/1,605 3,571/1,620
Approved front axle load
> Manual transmission lbs/kg 1,830/830 1,918/870 1,929/875
> Automatic
transmission lbs/kg 1,907/865 1,962/890 1,973/895
Approved rear axle load lb s/kg 1,664/755 1,664/755 1,676/760
Approved roof load
capacity lbs/kg 165/75 165/75 165/75
Cargo area capacity cu ft/ liters5.7 - 24.0/
160 - 680 5.7 - 24.0/
160 - 680 5.7 - 24.0/
160 - 680
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

REFERENCETechnical data
192
MINI Clubman
Capacities
CooperCooper SJohn Cooper Works
Curb weight, ready for travel, with all optional extras
> Manual transmission lbs/kg 2, 712/1,230 2,833/1,285 2,844/1,290
> Automatic
transmission lbs/kg2,789/1,265 2,877/1,305 2,888/1,310
Approved gross weight
> Manual transmission lbs/kg 3, 549/1,610 3,671/1,665 3,715/1,685
> Automatic
transmission lbs/kg
3,627/1,645 3,726/1,690 3,759/1,705
Approved front axle load
> Manual transmission lbs/kg 1,830/830 1,918/870 1,940/880
> Automatic
transmission lbs/kg1,907/865 1,962/890 1,984/900
Approved rear axle load lbs/kg 1,830/830 1,841/835 1,863/845
Approved roof load
capacity lbs/kg
165/75 165/75 165/75
Cargo area capacity cu ft/ liters9.2 - 32.8/
260 - 930 9.2 - 32.8/
260 - 930 9.2 - 32.8/
260 - 930
US gal/US quartsLitersNotes
Fuel tank 13.2/– approx. 50 Fuel grade: page 129
including reserve of 2.1/– approx. 8
Window washer system incl.
headlamp washer system –/4.8 approx. 4.5 For more details: page 52
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

Technical dataREFERENCE
193
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

194
REFERENCEEverything from A to Z
Everything from A to Z
Index
A
ABS Antilock Brake System64
Accepting a call 121
Accessories, see Vehicle equipment 4
Acknowledgment signals for locking/unlocking vehicle 24
Activated-charcoa l filter for
automatic climate control 84
Adaptive Light Control 77
Adding engine oil 145
Additives
– coolant 146
– engine oil 145
Adjusting temperature inside the car, refer to Air
conditioner 81
Adjusting temperature inside the car, refer to Automatic
climate control 82
Airbags 72
– sitting safely 35
– warning lamp 73
Air conditioner 80
Air conditioning mode
– air conditioner 81
– automatic cl imate control82
– ventilation 84
Air distribution
– automatic 83
– individual 82
– manual 82
Air flow rate 81,83
– air conditioning system 81
– automatic cl imate control83
– heating, ventilation 81
Airing, refer to Ventilation84
Air outlets, refer to Air vents 80
Air pressure, checking, refer to Tire inflation pressure 131Air recirculation, refer to
Recirculated-air
mode 81,83
Air supply
– air conditioner 81
– automatic climate control 82
– ventilation 84
Air vents 80
AKI, refer to Fuel grade 129
Alarm system 29
All-season tires, refer to Winter tires 141
Ambient air, refer to Recirculated-air
mode 81,83
Ambient lighting 79
Antenna, care 149
An

tifreeze
– coolant 146
– washer fluid 52
Antilock Brake System ABS 64
Anti-theft alarm system, refer to Alarm system 29
Anti-theft system 23
Approved axle loads, refer to Weights 191
Approved engine oils 145
Approved gross vehicle weight, refer to Weights 191
Armrest, refer to Center armrest 89
Ashtray 91
Assistant systems, refer to
– Dynamic Stability Control DSC 64
Audio device, external 89
Automatic
– air distribution 83
– air flow rate 83
– cruise control 52
– headlamp control 75Automatic climate control
80
– automatic air distribution 83
Automatic station search 105
Automatic station storage 106
Automatic transmission with Steptronic 46
– interlock 47
– overriding selector lever lock 48
– shiftlock 47
– sport program 48
AUTO program for automatic
climate control 83
Auto radio, refer to Radio MINI Boost CD 104
AUX-In, refer to External audio device 89
AUX-In connection 104
Average fuel consumption 55
– setting the units 58
Average speed 56
Axle loads, refer to Weights 191
B
Background lighting, refer to
Ambient lighting 79
Backrests, refer to Seats 36
Backup lamps
– replacing bulb 158,159
Band-aids, refer to First aid
pouch 167
Bar, refer to Tow-starting, towing away 170
Base plate for telephone or mobile phone
– refer to Snap-in adapter 124
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

Everything from A to ZREFERENCE
195
Battery165
– disposal 32,165
– jump-starting 168
– temporary power failure 165
Battery renewal
– remote control 32
Being towed 170
Belts, refer to Safety belts 38
Belt tensioner, refer to Safety belts 38
Beverage holders, refer to Cupholders 90
Black ice, refer to External
temperature warning 55
Blower, refer to Air flow rate 81,83
Bluetooth, activating/ deactivating 118
Bottle holders, refer to
Cupholders 90
Brake Assist 64
Brake fluid, refer to Service
requirements 59
Brake lamps
– replacing bulbs 158,159
Brake pads, breaking in 94
Brake rotors 96
– brakes 94
– breaking in 94
Brakes
– ABS 64
– breaking in 94
– MINI Maintenance
System 147
– parking brake 46
– service requirements 59
Brakes, refer to Braking safely 95
Brake system 94
– breaking in 94
– disc brakes 96
– MINI Maintenance
System 147
Breakdown service, refer to Roadside Assistance 167
Breaking in the clutch 94
Break-in period 94 Bulb changing, refer to Lamps
and bulbs 155
Button for starting the engine 44
Buttons on the steering wheel 11
C
California Proposition 65
warning 5
Call ending 122
Calling, refer to Phone
numbers, dialing 122
Calling, refer to Telephone 89
Can holders, refer to
Cupholders 90
Capacities 192
Car battery, refer to Vehicle
battery 165
Car care 149
Care 149
– car-care products 149
– car washes 149
– CD/DVD drives 152
– high-pressure washers 150
– leather 151
– manual washing 150
– upholstery and fabrics 151
– windows 150
– wiper blades 150
Cargo, securing 99
Cargo area 96
– capacity 191
– Comfort Access 31
– cover 96
– doors, refer to Split Rear Barn Doors 28
– expanding 97
– lamp 79
– opening from outside 28
– trunk lid, refer to Split Rear
Barn Doors 28
Cargo area doors, refer to Split Rear Barn Doors 28
Cargo area lamp 79 Cargo area lid, refer to
Tailgate 28
Cargo area partition net, refer to Cargo net 98
Cargo loading 98
– securing cargo 99
– stowing cargo 99
– vehicle 96
Cargo net 98
Car key, refer to Keys/remote
controls 22
Carpets, care 151
Car phone
– installation location, refer to Center armrest 89
– refer to Telephone 89,116
Car radio, refer to Radio 16
Car wash, care 149
Car washes 149
Cataly

tic converter, refer to
Hot exhaust system 95
CD player 109
– changing the track 109
– fast forward/reverse 109
– playing a track 110
– random order 109
– volume 104
Center armrest 89
Center brake lamp 160
Center console, refer to
Around the center
console 14
Central locking system 23
– Comfort Access 30
– from inside 26
– from outside 23
Changing bulbs 155
Changing wheels 162
Charging the battery 165
Chassis number, refer to Engine compartment 143
Check Control 61
Child restraint fixing system LATCH 42
Child restraint systems 41
Child seats 41
Chrome parts, care 151
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

REFERENCEEverything from A to Z
196
Chrome parts, refer to Care 149
Cigarette lighter 91
Cleaning headlamps 51
– washer fluid 52
Clock
– setting time 61
– 12 h/24 h mode 58
Closing
– from inside 26
– from outside 23
Clothes hooks 90
Club Door 28
Cockpit 10
Cold start, refer to Starting the engine 45
Comfort Access 30
– replacing the battery 32
– what to observe before
entering a car wash 32
Comfort area, refer to Around the center console 14
Compartment for remote control, refer to Ignition
lock 44
Compass 87
Compressed audio files 109
Computer 55
Condensation, refer to When the vehicle is parked 96
Condition Based Service CBS 147
Configuring settings, refer to
Personal Profile 22
Connecting vacuum cleaner, refer to Connecting electrical
appliances 91
Consumption, refer to Average fuel consumption 55
Control Display
– settings 56
Controls and displays 10
Convenience operation
– windows 24
Convenient access, refer to
Comfort Access 30 Convenient start, refer to
Starting the engine 45
Coolant 146
– checking level 146
– filling 146
Coolant temperature 146
Cooling, maximum 83
Cooling fluid, refer to Coolant 146
Copyright 2
Cornering light, refer to Adaptive Light Control 77
Cruising range 55,56
Cupholders 90
Curb weight, refer to Weights 191
C

urrent fuel consumption 56
D
Dashboard, refer to Cockpit 10
Dashboard instruments, refer
to Displays 12
Dashboard lighting, refer to Instrument lighting 78
Data 186
– capacities 192
– dimensions 187
– engine 186
– weights 191
Data memory 148
Date
– setting 61
Daytime running lights 76
DBC Dynamic Brake Control, refer to Brake Assist 64
Deactivating front passenger airbags 72
Deadlocking, refer to
Locking 24
Defect
– door lock 26
– fuel filler flap 128
Defogging windows 82,84
Defrosting windows 82,84 Defrosting windows and
removing condensation
– air conditioner 82
– automatic climate control 84
Defrosting windshield, refer to Defrosting windows 82,84
Defrost positi on, refer to
Defrosting windows 82,84
Differential, breaking in 94
Digital compass 87
Digital radio, refer to HD Radio 107
Dimensions 187
Dipstick, engine oil 144
Directional indicators, refer to Turn signals 49
Displacement, refer to Engine data 186
Display lighting, refer to
Instrument lighting 78
Displays 12
– instrument panel 12
Displays, care 152
Displays and controls 10
Disposal
– of coolant 146
– remote control battery 32
– vehicle battery 165
Distance remaining to service, refer to Service
requirements 59
Distance warning, refer
to Park
Distance Control PDC 63
Door
– rear, refer to Club Door 28
Door key, refer to Integrated
key/remote control 22
Door lock 26
Door lock, confirmation
signals 24
Doors, manual operation 26
DOT Quality Grades 139
Double doors, refer to Split Rear Barn Doors 28
Drinks holders, refer to
Cupholders 90
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

Everything from A to ZREFERENCE
197
Drive-off assistant, refer to Hill
Assist 66
Driving dynamics control, refer to Sport button 66
Driving lamps, refer to Parking lamps/low beams 75
Driving notes 94
Driving off on inclines, refer to Hill Assist 66
Driving stability control
systems 64
Driving through water 95
Driving tips, refer to Driving
notes 94
Dry air, refer to Cooling function 84
DSC Dynamic Stability Control 64
DTC Dynamic Traction
Control 65
Dynamic Brake Control DBC, refer to Brake Assist 64
Dynamic Stability Control DSC 64
Dynamic Traction Control
DTC 65
E
Eject button 110
Electrical malfunction
– door lock 26
– fuel filler flap 128
Electric power windows
– initializing 33
Electronic brake-force
distribution 64
Electronic Stability Program ESP, refer to Dynamic
Stability Control DSC 64
Emergency operation, refer to Manual operation
– door lock 26
– fuel filler flap 128
– transmission lock, automatic
transmission 48 Emergency services, refer to
Roadside Assistance 167
Ending a call 122
Engine
– breaking in 94
– data 186
– overheated, refer to Coolant
temperature 146
– speed 186
– starting, Comfort Access 30
Engine compartment 143
Engine coolant, refer to Coolant 146
Engine oil
– additives, refer to Approved engine oils 145
– alternative oil types 145
– approved engine oils 145
– capacity 145
– checking level 144
– dipstick 144
– intervals between changes,
refer to Service
requirements 59
– MINI Maintenance
System 147
Engine oil level, checking 144
Engine output, refer to Engine
data 186
Engine starting, refer to
Starting the engine 45
ESP Electronic Stability Program, refer to Dynamic
Stability Control DSC 64
Exhaust system, refer to Hot exhaust system 95
Exterior mirrors 39
– adjusting 39
– automatic heating 39
– folding in and out 39
External audio device 89,104
External care 149
External temperature display
– change units of measure 58
– in the onboard computer 58Eyes
– for tow-

starting and towing
away 169
– for tying down loads 99
F
Failure messages, refer to
Check Control 61
Failure of an electrical
consumer 166
Fastening safety be lts, refer to
Safety belts 38
Fast forward
– CD 109
Fault messages, refer to Check
Control 61
Filter
– microfilter/activated-
charcoal filter for automatic
climate control 84
– microfilter for air
conditioner 82
Fine wood, care 152
First aid pouch 167
Fixture for remote control, refer to Ignition lock 44
Flash when locking/
unlocking 24
Flat load floor 98
Flat tire
– run-flat tires 140
– Tire Pressure Monitor TPM 69
Flat Tire Monitor FTM 66
– indicating a flat tire 67
– initializing the system 67
– snow chains 67
– system limits 67
Flat tires, refer to Tire
condition 139
Floor mats, care 151
Floor plate, refe r to Flat load
floor 98
Fog lamps
– replacing bulb 156,159
Folding rear seat backrest 97
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

REFERENCEEverything from A to Z
198
Footbrake, refer to Braking safely 95
Footwell lamps 79
For universal garage door
openers, refer to the
Integrated universal remote
control 85
For your own safety 4
Front airbags 72
Front fog lamps 78
– indicator lamp 172
– replacing bulb 156
Front seat adjustment 36
Frost on windows, refer to Defrosting windows 82,84
FTM, refer to Flat Tire
Monitor 66
Fuel 129
– fuel tank volume 192
– gauge 54
– high-quality brands 129
– quality 129
Fuel clock, refer to Fuel gauge 54
Fuel consumption display
– average fuel consumption 55
Fuel display, refer to Fuel gauge 54
Fuel filler flap 128
– releasing in the event of
electrical malfunction 128
Fuel specifications 129
Fuses 166
G
Garage door opener, refer to
Integrated universal remote
control 85
Gasoline
– refer to Average fuel consumption 55
Gasoline, refer to Required fuel 129
Gasoline display, refer to Fuel
gauge 54 Gear indicator
– automatic transmission with
Steptronic 47
Gear shifting
– automatic transmission 47
– manual transmission 46
Gearshift lever
– automatic transmission with Steptronic 47
– manual transmission 46
General driving notes 94
Glass roof, electric 32
– convenience operation 24
– opening, closing 33
– remote control 24
– tilting 32
Glove compartment 89
Gong
– volume 104
Grills, refer to Air vents 80
Gross vehicle weight, refer to Weights 191
H
Halogen lamps
– replacing bulb 156
Handbrake, refe r to Parking
brake 46
Hands-free system 14,124
Hazard warning flashers 14
HD Radio 107
Head airbags 72
Headlamp control, automatic 75
Headlamp flasher 49
– indicator lamp 11,81,172
Headlamp glass lens 155
Headlamps
– replacing bulb 156
Headlamps, care 150
Head Light, refer to Adaptive
Light Control 77
Head restraints 37
– sitting safely 35 Heated
– mirrors
39
– rear window 81,83
– seats 38
Heating 80
– mirrors 39
– rear window 81,83
– seats 38
Heavy loads, refer to Stowing cargo 99
Height, refer to Dimensions 187
Height adjustment
– seats 36
– steering wheel 40
High beams 78
– headlamp flasher 78
– indicator lamp 81,172
– replacing bulb 156
High water, refer to Driving through water 95
Hill Assist 66
Hills 95
Holders for cups 90
Homepage 4
Hood 144
Horn 10
Hot exhaust system 95
Hydroplaning 95
I
IBOC, refer to HD Radio 107
Ignition 44
– switched off 45
– switched on 44
Ignition key, refer to Integrated key/remote
control 22
Ignition key position 1, refer to Radio readiness 44
Ignition key position 2, refer to
Ignition on 44
Ignition lock 44
Imprint 2
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG

Everything from A to ZREFERENCE
199
Incoming call121
Indicator and warning lamps 13,172
– Tire Pressure Monitor TPM 70
Indicator lighting, refer to Instrument lighting 78
Individual air distribution 82
Individual settings, refer to Personal Profile 22
Inflation pressure monitoring,
refer to Tire Pressure Monitor
TPM 69
Initializing
– Flat Tire Monitor FTM 67
– glass roof, electric 33
Initializing the
– compass, see Calibration 88
Instrument lighting 78
Instrument panel, refer to
Cockpit 10
Instrument panel, refer to Displays 12
Integrated key 22
Integrated universal remote control 85
Interior lamps 79
– remote control 25
Interior rearview mirror 39
– automatic dimming feature 40
Interlock 47
Intermittent mode of the wipers 50
Internal care 151
Internet page 4
J
Jacking points 164
Jets, refer to Window washer nozzles 51
Jumpering, refer to Jump-
starting 168
Jump-starting 168
K
Key, refer to Keys/remote
controls 22
Keyless-Go, refer to Comfort Access 30
Keyless opening and closing,
refer to Comfort Access 30
Key Memory, refer to Personal Profile 22
Keypad dialing 122
Kickdown 47
– automatic transmission with
Steptronic 47
Knock control 129
L
Lamps, refer to Parking lamps/
Low beams 75
Lamps and bulbs, replacing bulbs 155
Lashing eyes, refer to Securing cargo 99
LATCH child restraint fixing
system 42
Leather care 151
LEDs light-emitting diodes 155
Length, refer to Dimensions 187
License plate lamp
– bulb replacement 159,160
Light alloy wheels, care 151
Light-emitting diodes LEDs 155
Lighter 91
– socket 91
Lighting
– lamps and bulbs 155
– of the instruments 78
– of vehicle, refer to Lamps 75
Light switch 75
Limit 183
Listening to test, scan
– radio MINI Boost CD 106Load
98
Load securing equipment, refer to Securing cargo 99
Lock buttons of doors, refer to
Locking 26
Locking
– adjusting confirmation
signal 24
– from inside 26
– from outside 24
– without remote control, refer
to Comfort Access 30
Locking and unlocking doors
– confirmation signals 24
– from inside 26
– from outside 23
Longlife oils
– approved motor oils 145
Low beams 75
– automatic 75
– replacing bulb 156
Lower back suppo rt, refer to
Lumbar support 36
Luggage compartment, refer to Cargo area 28
Luggage compartment doors, refer to Split Rear Barn
Doors 28
Luggage compartment lid, refer to Tailgate 28
Luggage compartment partition net, refer to Cargo
net 98
Luggage rack, re fer to Roof-
mounted luggage rack 100
Lumbar support 36
M
M+S tires, refer to Winter
tires 141
Maintenance, refer to Service
and Warranty Information
Booklet for US models and
Service Guide Booklet for
Canadian models
Online Edition for Part no. 01 40 2 914 744 - \251 07/12 BMW AG
