MINI Hardtop 2 Door 2007 Owner's Manual

Reference Controls
Driving tips
Mobility At a glance
Reference

Technical data
130
Technical data
Engine data
MINI CooperMINI Cooper S
Displacement cu in/cmµ1,598 1,598
Number of cylinders 4 4
Maximum power output hp 118 172
at engine speed rpm 6,000 5,500
Maximum torque
with overboost functionlb ft/Nm 114/155
–177/240
192/260
at engine speed
with overboost functionrpm 4,250
–1,600-5,000
1,700-4,500

ReferenceAt a glance Controls Driving tips Mobility
131
Dimensions
All dimensions given in inches/mm. Smallest turning circle diam.: 35 ft 10 in/10.7 m.
Figures following the semicolon: values that differ for the MINI Cooper S.

Technical data
132
Weights
Never exceed either the approved axle loads or
the gross vehicle weight.
MINI CooperMINI Cooper S
Curb weight, ready for travel, with all optional extras
>Manual transmission lbs/kg 2,546/1,155 2,668/1,210
>Automatic transmission lbs/kg 2,634/1,195 2,723/1,235
Approved gross weight
>Manual transmission lbs/kg 3,362/1,525 3,483/1,580
>Automatic transmission lbs/kg 3,450/1,565 3,538/1,605
Approved front axle load lbs/kg 1,929/875 1,984/900
Approved rear axle load lbs/kg 1,653/750 1,664/755
Approved roof load capacity lbs/kg 165/75 165/75
Cargo area capacity cu ft/l 5.7/160 5.7/160

ReferenceAt a glance Controls Driving tips Mobility
133
Capacities
US gal/US quartsLitersNotes
Fuel tank Fuel grade: page85
>MINI Cooper 10.6/– approx. 40
>MINI Cooper S 13.2/– approx. 50
including reserve of 2.1/– approx. 8
Window washer system incl.
headlamp washer system –/4.8 approx. 4.5For more details:
page42

From A to Z
134
From A to Z
Index
A
ABS Antilock Brake System54
Accessories, refer to Your
individual vehicle5
Activated-charcoal filter for
automatic climate control68
Additives
– coolant96
– engine oil96
Adjusting temperature inside
the car, refer to Air
conditioner65
Adjusting temperature inside
the car, refer to Automatic
climate control66
Airbags57
– sitting safely28
– warning lamp58
Air conditioner64
Air conditioning mode
– air conditioner65
– automatic climate control66
– ventilation68
Air distribution
– automatic67
– individual65
– manual65
Air flow rate65,66
– air conditioning system65
– automatic climate control66
– heating, ventilation65
Airing, refer to Ventilation68
Air outlets, refer to Air vents64
Air pressure, checking, refer to
Tire inflation pressure86
Air recirculation, refer to
Recirculated-air
mode65,67
Air supply
– air conditioner65
– automatic climate control66
– ventilation68Air vents64
AKI, refer to Fuel
specifications85
Alarm system, preparation
package24
Alarm system preparation
package24
All-season tires, refer to Winter
tires93
All-Season Traction Control
ASC54
Ambient air, refer to
Recirculated-air
mode65,67
Âmbient lighting63
Antenna, care100
Antifreeze
– coolant96
– washer fluid
42
Anti-theft system19
Approved axle loads, refer to
Weights132
Approved engine oils96
Approved gross vehicle
weight, refer to Weights132
Armrest, refer to Center
armrest71
Arrival time
– computer46
ASC All-Season Traction
Control54
Ashtray72
Assistant systems, refer to
– All-Season Traction Control
ASC54
– Dynamic Stability Control
DSC54
AUC Automatic recirculated-
air control67
Audio device, external71Automatic
– air distribution67
– air flow rate67
– cruise control42
– headlamp control59
Automatic climate control64
– automatic air distribution67
Automatic recirculated-air
control AUC67
Automatic transmission with
Steptronic37
– interlock37
– overriding selector lever
lock39
– shiftlock38
– sport program38
AUTO program for automatic
climate control67
AUX-In, refer to External audio
device71
Average fuel consumption45
– setting the units47
Average speed46
Axle loads, refer to
Weights132
B
Background lighting, refer to
Ambient lighting63
Backrests, refer to Seats28
Backup lamps
– replacing bulb105
Backup lamps, refer to Tail
lamps105
Band-aids, refer to First aid
pouch112
Bar, refer to Tow-starting,
towing away114

ReferenceAt a glance Controls Driving tips Mobility
135
Battery111
– charging111
– disposal26,111
– jump starting112
– temporary power failure111
Battery renewal
– remote control26
Being towed114
Belts, refer to Safety belts30
Belt tensioner, refer to Safety
belts30
Beverage holders, refer to Cup
holders72
Blower, refer to Air flow
rate65,66
Bonnet94
Bottle holders, refer to Cup
holders72
Brake fluid, refer to Service
requirements49
Brake lamps
– replacing bulb105
Brake pads, breaking in76
Brake rotors77
– brakes76
– breaking in76
Brakes
– ABS54
– breaking in76
– MINI Maintenance System98
– parking brake37
– service requirements49
Brakes, refer to Braking
safely77
Brake system76
– breaking in76
– disc brakes77
– MINI Maintenance System98
Breakdown service, refer to
Roadside Assistance112
Breaking in the clutch76
Break-in period76
Bulb changing, refer to Lamps
and bulbs102
Button for starting the
engine35
Buttons on the steering
wheel11C
California Proposition 65
warning6
Can holders, refer to Cup
holders72
Capacities133
Car battery, refer to Vehicle
battery111
Car care100
Car-care products, refer to
Suitable car-care
products100
Care100
Cargo, securing80
Cargo area78
– capacity132
– convenient access24
– cover78
– lamp62
– lid, refer to Tailgate23
– opening from outside23
Cargo area, expanding78
Cargo loading
– securing cargo80
– stowing cargo79
– vehicle78
Car jack
– jacking points110
Car key, refer to Key/remote
control18
Carpets, care101
Car phone
– installation location, refer to
Center armrest71
– refer to separate Owner's
Manual
Car wash78
Car wash, refer to Care100
Catalytic converter, refer to
Hot exhaust system76
CBS Condition Based
Service98
CDs/DVDs, care101
Cell phones, use inside the car,
refer to Mobile phone in the
vehicle76
Center armrest71
Center brake lamp106Center console, refer to
Around the center
console14
Central locking system19
– convenient access24
– from inside22
– from outside19
Changing bulbs102
Changing wheels108
Chassis number, refer to
Engine compartment95
Check Control51
Child's seats33
Child-restraint fixing system
LATCH34
Child-restraint systems33
Chock, folding
– space-saver spare tire108
Chrome parts, care100
Chrome parts, refer to
Care100
Cigarette lighter72
Cleaning headlamps41
– washer fluid42
Clock44
– 12h/24h mode47
– setting time50
Closing
– from inside22
– from outside19
Clothes hooks72
Cockpit10
Cold start, refer to Starting the
engine36
Comfort access, refer to
Convenient access24
Comfort area, refer to Around
the center console14
Compartment for remote
control, refer to Ignition
lock35
Computer45
Condensation, refer to When
the vehicle is parked77
Configuring settings, refer to
Personal Profile18
Confirmation signals for
vehicle locking/unlocking20

From A to Z
136
Connecting vacuum cleaner,
refer to Connecting electrical
appliances72
Consumption, refer to Average
fuel consumption45
Consumption display
– average fuel consumption45
Control Display
– settings46
Controls and displays10
Convenience start, refer to
Starting the engine36
Convenient access24
– replacing the battery25
– what to observe before
entering a car wash25
Convenient operation
– windows20
Coolant96
– checking level96
– filling96
Coolant temperature44
Cooling, maximum67
Cooling fluid, refer to
Coolant96
Cruising range45
Cup holders72
Curb weight, refer to
Weights132
Current fuel consumption46
D
Dashboard, refer to Cockpit10
Dashboard instruments, refer
to Displays12
Dashboard lighting, refer to
Instrument lighting62
Data130
– capacities133
– dimensions131
– engine130
– weights132
Date
– setting51
Daytime running lamps60
Deactivating front passenger
airbags57Deadlocking, refer to
Locking20
Defect
– door lock21
– fuel filler door84
Defogging windows66,67
Defrosting windows66,67
Defrosting windows and
removing condensation
– air conditioner66
– automatic climate control67
Defrost position, refer to
Defrosting windows66,67
Differential, breaking in76
Digital clock44
Dimensions131
Dipstick, engine oil95
Directional indicators, refer to
Turn signals39
Displacement, refer to Engine
data130
Display lighting, refer to
Instrument lighting62
Displays12
– instrument combination12
Displays and controls10
Disposal
– of coolant96
– remote control battery26
– vehicle battery111
Distance remaining to service,
refer to Service
requirements49
Distance warning, refer to PDC
Park Distance Control53
Door key, refer to Integrated
key/remote control18
Door lock21
Door lock, confirmation
signals20
Doors, manual operation21
DOT Quality Grades90
Drinks holders, refer to Cup
holders72
Drive-off assistant, refer to Hill
Start Assist55
Driving dynamics control, refer
to Sport button39Driving lamps, refer to Parking
lamps/low beams59
Driving notes76
Driving off on inclines, refer to
Hill Start Assist55
Driving stability control
systems53
Driving through water77
Driving tips, refer to Driving
notes76
Dry air, refer to Cooling
function68
DSC Dynamic Stability
Control54
E
Electrical malfunction
– door lock21
– fuel filler door84
Electronic brake-force
distribution54
Emergency operation, refer to
Manual operation
– door lock21
– fuel filler door84
– transmission lock, automatic
transmission39
Emergency services, refer to
Roadside Assistance112
Engine
– breaking in76
– data130
– overheated, refer to Coolant
temperature44
– speed130
– starting36
– starting, convenient
access24
– switching off36
Engine compartment95
Engine coolant, refer to
Coolant96

ReferenceAt a glance Controls Driving tips Mobility
137
Engine oil
– adding96
– additives, refer to Approved
engine oils96
– approved engine oils96
– capacity96
– checking level95
– dipstick95
– intervals between changes,
refer to Service
requirements49
– MINI Maintenance System98
Engine oil level, checking95
Engine output, refer to Engine
data130
Engine starting, refer to
Starting the engine36
Error messages, refer to Check
Control51
ESP Electronic Stability
Program, refer to DSC
Dynamic Stability Control54
Event data recorders99
Exhaust system, refer to Hot
exhaust system76
Exterior mirrors31
– adjusting31
– automatic heating31
– folding in and out31
External audio device71
Eyes
– for tow-starting and towing
away113
– for tying down loads80
F
Failure messages, refer to
Check Control51
Failure of an electrical
consumer111
Fastening safety belts, refer to
Safety belts30
Fasten safety belts reminder,
refer to Seat belt
reminder31Filter
– microfilter/activated-
charcoal filter for automatic
climate control68
– microfilter for air
conditioner66
Fine wood, care101
First aid pouch112
Fixture for remote control,
refer to Ignition lock35
Flash when locking/
unlocking20
Flat tire
– Flat Tire Monitor56
– indicator/warning lamp56
– Run-Flat Tires56,92
Flat Tire Monitor FTM55
– indicating a flat tire56
– initializing the system55
– malfunction56
– snow chains55
– system limits55
Flat tires, refer to Tire
condition91
Floor mats, care101
Fog lamps
– replacing bulb104,106
Folding rear seat backrest78
Footbrake, refer to Braking
safely77
Footwell lamps62
For your own safety5
Front airbags57
Front fog lamps62
– indicator lamp116
– replacing bulb104
Front seat adjustment28
Frost on windows, refer to
Defrosting windows66,67
FTM, refer to Flat Tire
Monitor55
Fuel85
– gauge45
– high-quality brands85
– quality85
– specifications85
– tank capacity133
Fuel clock, refer to Fuel
gauge45Fuel display, refer to Fuel
gauge45
Fuel filler door84
– releasing in the event of
electrical malfunction84
Fuses111
G
Garage door opener, refer to
Integrated universal remote
control69
Gasoline
– refer to Average
consumption45
Gasoline, refer to Required
fuel85
Gasoline display, refer to Fuel
gauge45
Gear indicator
– automatic transmission with
Steptronic37
Gear shifting
– automatic transmission37
– manual transmission37
Gearshift lever
– automatic transmission with
Steptronic37
– manual transmission37
General driving notes76
Glass sunroof, electric26
– convenient operation20,21
– opening, closing26
– raising26
– remote control20
Glove compartment70
Grills, refer to Air vents64
Gross vehicle weight, refer to
Weights132
H
Halogen lamps
– replacing bulb103
Handbrake, refer to Parking
brake37
Hands-free system14
Hazard warning flashers14
Head airbags57

From A to Z
138
Headlamp control,
automatic59
Headlamp flasher39
– indicator lamp11,116
Headlamps
– replacing bulb103
Headlamps, care100
Head restraints30
– sitting safely28
Heated
– mirrors31
– rear window65,67
– seats30
Heating64
– mirrors31
– rear window65,67
– seats30
Heavy loads, refer to Stowing
cargo80
Height, refer to
Dimensions131
Height adjustment
– seats29
– steering wheel32
High beams61
– headlamp flasher61
– indicator lamp116
– replacing bulb103
High water, refer to Driving
through water77
Hills77
Hill Start Assist55
Holders for cups72
Homepage4
Horn10
Hot exhaust system76
Hydroplaning77
I
Ice warning44
Icy roads, refer to Outside
temperature warning44
Ignition35
– switched off35
– switched on35
Ignition key, refer to
Integrated key/remote
control18Ignition key position 1, refer to
Radio readiness35
Ignition key position 2, refer to
Ignition on35
Ignition lock35
Indicator and warning
lamps13,116
Individual air distribution65
Individual settings, refer to
Personal Profile18
Initializing
– Flat Tire Monitor FTM55
– glass sunroof, electric27
Instrument cluster, refer to
Displays12
Instrument lighting62
Instrument panel, refer to
Cockpit10
Instrument panel, refer to
Displays12
Integrated key18
Integrated universal remote
control operation69
Interior lamps62
– remote control21
Interior rearview mirror32
– automatic dimming
feature32
Interlock37
Intermittent mode of the
wipers41
Internet page4
J
Jacking points110
Jets, refer to Window washer
nozzles41
Jumpering, refer to Jump
starting112
Jump starting112
K
Key, refer to Key/remote
control18
Keyless go, refer to Convenient
access24Keyless opening and closing,
refer to Convenient
access24
Key Memory, refer to Personal
Profile18
Kick-down38
– automatic transmission with
Steptronic38
Knock control85
L
Lamps, refer to Parking lamps/
Low beams59
Lamps and bulbs, replacing
bulbs102
Lashing eyes, refer to Securing
cargo80
LATCH child-restraint fixing
system34
LEDs light-emitting diodes103
Length, refer to
Dimensions131
License plate lamp
– replacing bulb106
Light-alloy wheels, care100
Light-emitting diodes
LEDs103
Lighter72
– socket72
Lighting
– lamps and bulbs102
– of the instruments62
– of vehicle, refer to Lamps59
Light switch59
Limit126
Load securing equipment,
refer to Securing cargo80
Lock buttons of doors, refer to
Locking22
Locking
– adjusting confirmation
signal20
– from inside22
– from outside20
– without remote control, refer
to Convenient access24
