REMOTE CONTROLLED MIRROR
CIRCUIT DIAGRAMS90-79
REMOTE CONTROLLED MIRRORM1901006500993

51-1
GROUP 51
EXTERIOR
CONTENTS
FRONT BUMPER ASSEMBLY . . . . .51-2
REMOVAL AND INSTALLATION . . . . . . . . 51-2
DISASSEMBLY AND ASSEMBLY . . . . . . . 51-3
REAR BUMPER ASSEMBLY . . . . . .51-5
REMOVAL AND INSTALLATION . . . . . . . . 51-5
RADIATOR GRILLE. . . . . . . . . . . . . .51-6
REMOVAL AND INSTALLATION . . . . . . . . 51-6
GARNISHES AND MOLDINGS . . . . .51-7
SPECIAL TOOLS . . . . . . . . . . . . . . . . . . . . 51-7
MOLDINGS . . . . . . . . . . . . . . . . . . . . . . . . . 51-8
REMOVAL AND INSTALLATION . . . . . . . . 51-8
REAR SPOILER . . . . . . . . . . . . . . . . .51-11
REMOVAL AND INSTALLATION . . . . . . . . 51-11
MUD GUARD . . . . . . . . . . . . . . . . . . .51-12
REMOVAL AND INSTALLATION . . . . . . . . 51-12
UNDER COVER . . . . . . . . . . . . . . . . .51-13
REMOVAL AND INSTALLATION . . . . . . . . 51-13
WINDSHIELD WIPER AND WASHER51-14
GENERAL DESCRIPTION . . . . . . . . . . . . . 51-14
WINDSHIELD WIPER AND WASHER DIAGNOSIS . . . . . . . . . . . . . . . . . . . . . . . . . 51-14
SPECIAL TOOLS . . . . . . . . . . . . . . . . . . . . 51-15
ON-VEHICLE SERVICE . . . . . . . . . . . . . . . 51-15
WINDSHIELD INTERMITTENT WIPER
VOLUME CHECK . . . . . . . . . . . . . . . . . . . . 51-15
WINDSHIELD WASHER FLUID EJECTION
CHECK . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51-16
WINDSHIELD WIPER . . . . . . . . . . . . . . . . . 51-17
REMOVAL AND INSTALLATION . . . . . . . . 51-17
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . 51-20
WINDSHIELD WASHER . . . . . . . . . . . . . . . 51-23
REMOVAL AND INSTALLATION . . . . . . . . 51-23
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . 51-24
MARK . . . . . . . . . . . . . . . . . . . . . . . . .51-25
REMOVAL AND INSTALLATION . . . . . . . . 51-25
DOOR MIRROR . . . . . . . . . . . . . . . . .51-27
GENERAL DESCRIPTION . . . . . . . . . . . . . 51-27
DOOR MIRROR . . . . . . . . . . . . . . . . . . . . . 51-28
REMOVAL AND INSTALLATION . . . . . . . . 51-28
INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . 51-29
SPECIFICATIONS . . . . . . . . . . . . . . .51-31
FASTENER TIGHTENING SPECIFICATIONS51-31
SERVICE SPECIFICATIONS . . . . . . . . . . . 51-31
ADHESIVE . . . . . . . . . . . . . . . . . . . . . . . . . 51-31

DOOR MIRROR
EXTERIOR51-27
DOOR MIRROR
GENERAL DESCRIPTIONM1511000100570
OPERATION DOOR MIRROR
Remote Controlled Mirror Operation
The mirror on the door mirror moves up/down
and left/right by operating the remote controlled
door mirror switch when the ignition switch is in
the "ON" or "ACC" position.

DOOR MIRROR
EXTERIOR51-28
DOOR MIRROR
REMOVAL AND INSTALLATIONM1511006400331

DOOR MIRROR
EXTERIOR51-29
REMOVAL SERVICE POINT
.
<> POWER WINDOW SWITCH PANEL
ASSEMBLY REMOVAL
Insert special tool MB990874 as shown to remove the power
window switch panel assembly.
INSPECTIONM1511006500305
ELECTRIC REMOTE CONTROL MIRROR
OPERATION CHECK
Check that the mirror moves as described in the table when
each terminal is connected to the battery.
REMOTE CONTROLLED MIRROR
REMOVAL STEPS
FRONT DOOR TRIM (REFER TO
GROUP 52A, DOOR TRIMS
P.52A-14).
1. DOOR MIRROR COVER
2. REMOTE CONTROLLED MIRROR
ASSEMBLYREMOTE CONTROLLED MIRROR
SWITCH REMOVAL STEPS<>3. POWER WINDOW SWITCH PANEL
ASSEMBLY
4. REMOTE CONTROLLED MIRROR
SWITCH
BATTERY CONNECTION DIRECTION
OPERATION
Connect terminal 6 to the negative
battery terminal.
Connect terminal 4 to the positive battery
terminal.Up
Connect terminal 6 to the positive battery
terminal.
Connect terminal 4 to the negative
battery terminal.Down
Connect terminal 6 to the negative
battery terminal.
Connect terminal 5 to the positive battery
terminal.Right
Connect terminal 6 to the positive battery
terminal.
Connect terminal 5 to the negative
battery terminal.Left

DOOR MIRROR
EXTERIOR51-30
DOOR MIRROR CONTROL SWITCH CONTINUITY
CHECK
SWITCH POSITION TESTER
CONNECTIONSPECIFIED
CONDITION
OFF 9
2, 9 3, 9 6,
9
10, 9 11, 1 2,
1
3, 1 6, 1 10,
1
11Open circuit
Left side OFF 9
6, 9 10, 9 11,
1
6, 1 10, 1 11Open circuit
Up 1
6, 9 11 Less than 2
ohms
Down 1
11, 6 9
Right 1
6, 9 10
Left 1
10, 6 9
Right side OFF 9
2, 9 3, 9 6,
1
2, 1 3, 1 6Open circuit
Up 1
6, 3 9 Less than 2
ohms
Down 1
3, 6 9
Right 1
6, 2 9
Left 1
2, 6 9

SPECIFICATIONS
EXTERIOR51-31
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONSM1511015300279
SERVICE SPECIFICATIONSM1511000300358
ADHESIVEM1511000500448
ITEM SPECIFICATION
Front bumper
License plate screw 0.9
0.1 Nm (8 1 in-lb)
Windshield wiper and washer
Wiper arm and blade assembly nut 37
3.0 Nm (27 1 ft-lb)
Wiper link assembly to Body bolt 8.0
2.0 Nm
Wiper motor to link assembly screw 7.5
1.0 Nm (66 13 in-lb)
Washer tank bolt 12
1.0 Nm (102 15 in-lb)
Door mirror
Remote controlled mirror assembly bolt 5.0
1.0 Nm (44 9 in-lb)
ITEM STANDARD VALUE
Windshield wiper blade (RH) park position 38
5 mm (1.50 0.20 inches)
Windshield wiper blade (LH) park position 38
5 mm (1.50 0.20 inches)
ITEM SPECIFICATION
Door side protector molding Adhesive tape: Double-sided tape
8.0 mm (0.32 inch) width and 1.2 mm (0.05 inch)
thickness
Roof drip molding Adhesive tape: Double-sided tape
10.0 mm (0.39 inch) width and 1.52 mm (0.06 inch)
thickness

FENDER
BODY42-10
FENDER
REMOVAL AND INSTALLATIONM1421001900313
Pre-removal and Post-installation Operation
Front Bumper Assembly Removal and Installation (Refer
to GROUP 51, Front Bumper P.51-2).
Front Mud Guard Removal and Installation (Refer to
GROUP 51, Mud Guard P.51-12).
Headlight Removal and Installation (Refer to GROUP
54A, Headlight and Front Combination Light P.54A-153).
REMOVAL STEPS
1. SPLASH SHIELD MOUNTING CLIP

2. SPLASH SHIELD MOUNTING BOLT

3. SPLASH SHIELD
DOOR MIRROR COVER (REFER TO
GROUP 51, DOOR MIRROR
P.51-28).
FRONT DELTA GARNISH (REFER
TO GROUP 51, GARNISHES AND
MOLDING P.51-8).
4. FENDERREMOVAL STEPS (Continued)

WINDOW GLASS
BODY42-15
WINDSHIELD
REMOVAL AND INSTALLATIONM1422001000324
Pre-removal and Post-installation Operation
Front Deck Garnish Removal and Installation (Refer to
GROUP 51, Windshield Wiper and Washer P.51-17).
Roof Drip Molding Removal and Installation (Refer to
GROUP 51, Garnish and Molding P.51-8).
Front Pillar Trim Removal and Installation (Refer to
GROUP 52A, Trims P.52A-11).
Instrument Panel Front End Garnish Removal and Instal-
lation (Refer to GROUP 52A, Instrument Panel Assembly
P.52A-4).
Inside Rear View Mirror Removal and Installation (Refer
to GROUP 52A, Inside Rear View Mirror P.52A-20).

DOOR
BODY42-53
REMOVAL
>>D<<1. DOOR WINDOW GLASS
RUNCHANNEL
WATERPROOF FILM AND DOOR
PANEL CORE REMOVAL STEPS
DOOR TRIM ASSEMBLY (REFER
TO GROUP 52A, DOOR TRIM
P.52A-14).
DOOR INSIDE HANDLE (REFER TO
P.42-46).
2. DOOR ARMREST BRACKET
>>A<<3. WATERPROOF FILM
4. DOOR PANEL CORE
DOOR OPENING INNER
WEATHERSTRIP REMOVAL
STEPS
FRONT SCUFF PLATE (REFER TO
GROUP 52A, TRIMS P.52A-11).
>>C<<5. DOOR OPENING INNER
WEATHERSTRIP (BODY SIDE)DOOR OPENING OUTER
WEATHERSTRIP REMOVAL
STEPS
DOOR CHECK MOUNTING BOLT
(BODY SIDE) (REFER TO P.42-37).
>>B<<6. DOOR OPENING OUTER
WEATHERSTRIP
DOOR BELTLINE MOLDING
REMOVAL STEPS
DOOR TRIM ASSEMBLY (REFER
TO GROUP 52A, DOOR TRIM
P.52A-14).
REMOTE CONTROLLED MIRROR
ASSEMBLY (REFER TO GROUP 51,
DOOR MIRROR P.51-28).
7. DOOR BELTLINE MOLDING
