MITSUBISHI ASX 2009 1.G Owners Manual

Warning display list (when the ignition switch or the operation mode is OFF)
E00524000622Screen type 1 Screen type 2 Cause Solution (Reference)
l
You have forgotten to turn off
the lamps. Refer to “Lamps (headlamps, fog
lamp, etc.) auto-cutout function” on
page 3-44. l
The
security alarm system is op-
erating. Refer to “Security alarm system” on
page 1-28. Instruments and controls
3-27 3

Screen type 1 Screen type 2 Cause Solution (Reference)
–– l
There is a fault in the keyless op-
eration system. Refer to “Keyless operation system”
on page 1-07.
–– l
There
is a fault in the electronic
immobilizer (Anti-theft starting
system). l
We recommend you to consult a
MITSUBISHI MOTORS Au-
thorized Service Point. Instruments and controls
3-28
3

Screen type 1 Screen type 2 Cause Solution (Reference)
–– l
The keyless operation key is not
detected. l
Insert the keyless operation key
into the key slot in the glove box.
Refer to “If the keyless operation
key is not operating properly” on
page 1-17.
–– l
You
have forgotten to remove
the keyless operation key from
the key slot in the glove box. l
Remove the keyless operation
key from the key slot in the
glove box.
–– l
The steering wheel is locked.
lPress the engine switch.
Refer

to “Steering wheel lock”
on page 1-14.
–– l
The engine is stopped and the se-
lector

lever is in a position other
than the “P” (PARK) position. l
On vehicles with CVT, move the
selector lever to the “P” (PARK)
position to put the operation
mode in OFF.
–– l
The
driver’s door is opened with
the steering wheel unlocked. l
Refer to “Steering wheel lock”
on page 1-14.
–– l
There
is a fault in the electrical
system. l
Immediately stop the vehicle in a
safe place. We recommend you
to consult a MITSUBISHI
MOTORS Authorized Service
Point. Instruments and controls
3-29 3

Warning display list (when the ignition switch or the operation mode is ON)
E00524100665Screen type 1 Screen type 2 Cause Solution (Reference)
l
There is a fault in the EPS.
lStop the vehicle in a safe place
and inspect it.
l If the warning remains on after
you inspect the vehicle, we rec-
ommend you to consult a
MITSUBISHI MOTORS Au-
thorized Service Point.
Refer to “Electric power steering
system (EPS)” on page 4-40. Instruments and controls
3-30
3

Screen type 1 Screen type 2 Cause Solution (Reference)
–– l
There is a fault in the keyless op-
eration system. Refer to “Keyless operation system”
on page 1-07. l
The
brake fluid level in the reser-
voir has fallen to a low level.
l There is a fault in the brake sys-
tem. l
Immediately stop the vehicle in a
safe place.
We recommend you to consult a
MITSUBISHI MOTORS Au-
thorized Service Point.
Refer to “Brake warning dis-
play” on page 3-42. Instruments and controls
3-31 3

Screen type 1 Screen type 2 Cause Solution (Reference)
l
There is a fault in the ABS.
lAvoid sudden braking and high-
speed driving, stop the vehicle in
a safe place, and take corrective
measures. Refer to “ABS warn-
ing” on page 4-38. l
One
of the doors or the tailgate
is not completely closed.
The open door is displayed. l
Close the door or tailgate.
Refer
to “Door ajar warning dis-
play screen (when the ignition
switch or the operation mode is
ON)” on page 3-17. l
The bonnet is open.
lClose the bonnet.
Refer to “Bonnet” on page

8-03.
–– l
There
is a fault in the electronic
immobilizer (Anti-theft starting
system). l
Put the operation mode in OFF,
and then start the engine again.
If the warning is not cancelled,
please contact a MITSUBISHI
MOTORS Authorized Service
Point.
–– l
The
driver’s door is open and the
operation mode is put in a mode
other than OFF. l
Put the operation mode in OFF.
Refer to
“Changing the operation
mode” on page 1-12. Instruments and controls
3-32
3

Screen type 1 Screen type 2 Cause Solution (Reference)
–– l
There is a fault in the steering
wheel lock. l
Immediately stop the vehicle in a
safe place.
We recommend you to consult a
MITSUBISHI MOTORS Au-
thorized Service Point.
–– l
There
is a fault in the electrical
system. l
Immediately stop the vehicle in a
safe place.
We recommend you to consult a
MITSUBISHI MOTORS Au-
thorized Service Point. l
The engine is overheated.
lStop
the vehicle in a safe place
and take corrective measures.
Refer to “Engine overheating”
on page 6-04. l
The
automatic transmission
(CVT) fluid temperature is too
high. Refer to “Automatic transmission IN-
VECS-III Sports Mode 6CVT (Intelli-
gent & Innovative Vehicle Electronic
Control System III)” on page 4-24. l
You
turned the ignition switch to
the “ON” position or put the op-
eration mode in ON without fas-
tening your seat belt. l
Fasten your seat belt properly. Re-
fer to “Seat belt warning” on
page 2-11. Instruments and controls
3-33 3

Screen type 1 Screen type 2 Cause Solution (Reference)
l
There is a fault in the fuel system.
lWe recommend you to consult a
MITSUBISHI MOTORS Au-
thorized Service Point. l
You
are driving with the parking
brake still applied. l
Release the parking brake. Refer
to “Brake warning display” on
page 3-42. l
There
is a fault in the engine oil
circulation system. l
Immediately stop the vehicle in a
safe place. We recommend you
to have it checked.
Refer to “Oil pressure warning
display” on page 3-44. l
There
is a fault in the charging
system. l
Immediately stop the vehicle in a
safe place. We recommend you
to consult a MITSUBISHI
MOTORS Authorized Service
Point.
Refer to “Charge warning dis-
play” on page 3-43. l
There
is a fault in the SRS airbag
or the pretensioner system. l
We recommend you to have it
checked.
Refer to “Supplemental restraint
System (SRS) warning lamp” on
page 2-34. Instruments and controls
3-34
3

Screen type 1 Screen type 2 Cause Solution (Reference)
l
There is an automatic headlamp
levelling fault. l
We recommend you to have it
checked.
Refer to “Automatic headlamp
levelling” on page 3-49. l
There
is a fault in the Active Sta-
bility Control (ASC). l
We recommend you to have it
checked.
Refer to “Active stability control
(ASC)” on page 4-40. l
There
is a fault in the electroni-
cally controlled 4WD system. l
We recommend you to have it
checked.
Refer to “Electronically control-
led 4WD system” on page 4-29. l
There is a fault in the CVT.
lWe
recommend you to have it
checked.
Refer to “Automatic transmis-
sion INVECS-III Sports Mode
6CVT (Intelligent & Innovative
Vehicle Electronic Control Sys-
tem III)” on page 4-24. l
The
electronically controlled
4WD system is hot. Refer to “Electronically controlled
4WD system” on page 4-29. Instruments and controls
3-35 3

Screen type 1 Screen type 2 Cause Solution (Reference)
l
The fuel is running low.
lRefuel as soon as possible. Refer
to “Fuel remaining warning dis-
play” on page 3-15. l
An
excessive amount of particu-
late matter (PM) accumulates in-
side the diesel particultate filter
(DPF). Refer to “Diesel particulate filter
(DPF)” on page 4-15. l
It
is suspected that the engine oil
level has increased excessively. Immediately have your vehicle
checked by a MITSUBISHI MOTORS
Authorized Service Point.
Refer to “Engine oil level warning dis-
play” on page 3-44. l
The
outside temperature is 3 °C
(37 °F) or less. l
Be careful of ice on the road.
l The
road can be icy even when
this warning is not displayed, so
drive carefully. Instruments and controls
3-36
