headrest MITSUBISHI ECLIPSE 1990 Service Manual

23-30
FRONT SEATS
BODY - Front Seats / Rear Seat
Rz3The front seats are sporty
highback seats with an
integral headrestraint that hold your body in place oncurves. The driver’s seat on the higher grade model
is provided with the lumbar support that is
adjust-able in four positions.The.driver’s seat slides 260 mm (10.2 in.) I230 mm
(9.1 in.) on the front passenger’s seat].
The front passenger’s seat can be folded down to
ensure easy egress/ingress for the rear-seat pas-
sengers.
Seatback
2
Adjustment mechanisms
1. Sliding adjustment2. Reclining adjustment3.Lumbar support adjustment(driver’s seat only)
4.
Folddown mechanism
(on front passenger’s seat only)
REAR SEATR23u9ABThe rear seat is for two passengers, having low
seatback and contoured seat cushions. The seat-back can be folded down to give an additional
luggage c5mpartment space.There are cushion pockets at the center, into which
the rear seat belt buckles are stored when the
seatback is folded down.
