21-336AUTOMATIC TRANSAXLE - Transfer Assembly 2210094
2210095
Spacer for
adiustina drivebekel gear mount
\Spacer for
bevel gear preloacSpacer for
adjusting/ driven bevel
gear mount
Spacer for
, adjusting
driven bevel
gear preload
2210129
3. Tooth contact pattern when driven bevel gear is too
low
Possible cause:A-kThe driven bevel gear is further away from the drive bevel
~gear than necessary.
Remedy:Use a thinner spacer for the driven bevel gear mount
adjustment so that the driven bevel gear is closer to the
drive bevel gear.
NOTE(1) If correct tooth contact cannot be obtained by replace-
ment of spacer for adjusting driven bevel gear mount,
change the spacers for adjustment of drive bevel gear
preload and drive bevel gear mount adjustment to those4of appropriate thickness as described below and adjust
-.’the tooth contact again.
lIf the driven bevel gear height is still too small whenthe thinnest spacer for driven bevel gear mount
adjustment
[0.13 mm (.005 in.)] is used;
Change the spacer for drive bevel gear mount
adjustment to the next thicker one and change the
spacer for drive bevel gear preload adjustment to
the next thinner one.
lIf the driven bevel gear height is still too large whenthe thickest spacer for driven bevel gear mount
adjustment
[0.52 mm (021 in.)] is used;
Change the spacer for drive bevel gear mount
adjustment to the next thinner one and change the
spacer for drive bevel gear preload adjustment to
the next thicker one.
Repeat above steps until standard tooth contact
pattern is obtained.
(2) If the tooth contact pattern cannot be brought close to
the standard pattern by the adjustment described
above, replace the drive bevel gear and driven bevel
gear as a set and adjust the tooth contact again.

BODY - Troubleshooting
TROUBLESHOOTINGN23EFd
HOOD, LIFTGATE, GLASS AND DOORS
SymptomProbable causeRemedy
Hood/Improper closureStriker and latch not properly alignedAdjust the alignmentLiftgateDifficult locking and
unlocking
Uneven body
clearance
Uneven height
Incorrectly installed hood or liftgate
Incorrect hood bumper heightAdjust the installation of
hood, deck lid or liftgate
Adjust the hood bumper,deck lid bumper or liftgate
bumper height
i/\/indow Water leak throughDefective sealFill sealantJlasswindshield
Defective body flangeCorrect
Water leak throughIncorrect window glass installationAdjust position
door window glass
Gap at upper window glassAdjust position
Water leak through
Defective sealFill sealantliftgate window
Defective body flangeCorrect
IoorsDoor windowIncorrect window glass installationAdjust position
malfunction
Damaged or faulty regulatorCorrect or replace
Water leak throughCracked or faulty weatherstrip
Replace
door edge
Water leak fromDrain hole cloggedRemove foreign objects
door center
Inadequate waterproof film contact or damageCorrect or replace
Door hard to openIncorrect latch or striker adjustment
Adjust
Door does notIncorrect door installationAdjust position
open or close
completelyDefective door check strapCorrect or replace
Door check strap and hinge required greaseApply grease
Uneven gapIncorrect door installationAdjust position
between body
Wind noise aroundWeatherstrip not holding firmly
Adjust fit of door
doorImproperly installed weatherstrip or setting ofRepair or replace
weatherstrip
Improperly closed door
Improperly fit door
Improper clearance between door glass and
door weatherstrip holder
Deformed doorAdjust
Adjust
Adjust
Repair or replace

BODY - Service Adjustment Procedures23-31
16A0366
10A0370
SERVICE ADJUSTMENT PROCEDURES
HOOD ADJUSTMENTN23FAAK1. Loosen the hood mounting bolts, and then adjust the hood
by moving it so that the clearance is equal on all sides.
2. Turn the hood bumpers, adjust the height of the hood.
3. Loosen the food latch mounting bolts, and move the food
switch to adjust the attachment between the food switch
and food striker.
LIFTGATE ADJUSTMENTN23FCAE1. Loosen the
liftgate hinges mounting bolts, and then adjust
the liftgate by moving it so that the clearance is equal on all
sides.2. Loosen the
liftgate latch mounting bolts, and move the
liftgate latch to adjust the attachment between the liftgatelatch and
liftgate striker.
FUEL FILLER DOOR ADJUSTMENTN23FDAELoosen the fuel filler door mounting screw and adjust the fuel
filler door so that the clearance around the fuel filler door is evenwithout any height differences.
