23-58BODY - Windshield
WINDSHIELD
REMOVAL AND INSTALLATION
ISA0466
Pre-removal Operation0 Removal of Hood
(Refer to P.23-34.)0 Removal of Wiper Arm
(Refer to GROUP &WindshieldWiper)
l Removal of Front Deck Garnish
(Refer to
P.23-47.)0 Removal of Front Headlining Trim
(Refer to P.23-89.)0 Removal of Drip Moulding
(Refer to P.23-72.)
Post-installation Operation0 Installation of Drip Moulding
(Refer to P.23-72.)0 Installation of Front Headlining
Trim
(Refer to
P.23-89.)l Installation of Front Deck Garnish
(Refer to
P.23-47.)l installation of Front Wiper Arm(Refer to GROUP 8-WindshieldWiper)
0 Installation of Hood
(Refer to P.23-34.)
NZBLBAR
,
Removal steps1. Inside rear view mirror
2. Windshield upper moulding
a*3. Windshield glass
4. Windshield glass spacer
Installation steps4. Windshield glass spacer
l 2. Windshield upper moulding
+a 3. Windshield glass
1. Inside rear view mirror
NOTE(1 I Reverse the removal procedures to reinstall.(2) +* : Refer to “Service Points of Removal”.(3) l + : Refer to “Service Points of Installation”.(4) H : Non-reusable parts
SERVICE POINTS OF REMOVAL3. REMOVAL OF WINDSHIELD GLASS
(1) Using a sharp-pointed drill, make a hold in the adhesivearea of the windshield.
From inside the vehicle, insert one end of wire through
adhesive material applied to the upper edge of
windshield.
(2) Insert the other end of wire from inside the vehicle
through adhesive material applied to the lower edge of
windshield.
(3) Secure each end of wire to a piece of wood or similar
object.
(4) Carefully cut through adhesive by pulling wire along the
windshield from outsi,de the vehicle in a sawing motion.
Caution
In order to protect the body from damage, apply cloth
tape to all body areas around the installed glass beforecutting the adhesive.
