9-6 Specifications
9Vehicle dimensions
N01147500411
ECLIPSE
ECLIPSE SPYDEROverall length 180.4 in (4,583 mm) Overall width 72.2 in (1,835 mm) Overall height
Vehicles with
17 inch tires53.5 in (1,358 mm)Vehicles with
18 inch tires53.8 in (1,366 mm)
Wheel base 101.4 in (2,575 mm) Overall length 180.4 in (4,583 mm) Overall width 72.2 in (1,835 mm) Overall height
Vehicles with
17 inch tires54.4 in (1,381 mm)Vehicles with
18 inch tires54.7 in (1,389 mm)
Wheel base 101.4 in (2,575 mm) BK0098300US.book 6 ページ ２００８年１２月８日　月曜日　午前１１時３７分

Specifications
9-7
9 Vehicle weights
N01147600757
ECLIPSE
ECLIPSE SPYDERGVWR: maximum total weight (load) limit specified for the vehicle
GAWR: maximum weight (load) limit specified for the front or rear axle
Seating capacity: the number of maximum occupants
Item
2.4 liter
3.8 liter
Gross vehicle weight rating (GVWR) 4,090 lb (1,855 kg) 4,332 lb (1,965 kg)Gross axle weight rating
(GAWR)
Front 2,260 lb (1,025 kg) 2,469 lb (1,120 kg)Rear 1,852 lb (840 kg) 1,885 lb (855 kg)
Vehicle capacity weight 661 lb (300 kg)Seating capacity4 persons
Item
2.4 liter
3.8 liter
Gross vehicle weight rating (GVWR) 4,266 lb (1,935 kg) 4,464 lb (2,025 kg)Gross axle weight rating
(GAWR)
Front 2,304 lb (1,045 kg) 2,491 lb (1,130 kg)Rear 1,984 lb (900 kg) 1,995 lb (905 kg)
Vehicle capacity weight 661 lb (300 kg)Seating capacity4 persons
BK0098300US.book 7 ページ ２００８年１２月８日　月曜日　午前１１時３７分

9-8 Specifications
9Engine specifications
N01147700181
Item
2.4 liter
3.8 liter
Engine model 4G69 6G75Engine displacement 145.1 CID (2,378 cm³) 233.6 CID (3,828 cm³)No. of cylinders and cylinder arrangement 4 in-line 6-V60°Bore 3.43 in (87.0 mm) 3.74 in (95.0 mm)Stroke 3.93 in (100.0 mm) 3.54 in (90.0 mm)Compression ratio 9.5 10.5Thermostat valve opening temperature 179.6 °F (82.0 °C)Spark plugs
NGK LZFR6AI IFR6B-K
Spark plug gap .028 to.031 in (0.7 to 0.8 mm)Firing order 1-3-4-2 1-2-3-4-5-6Ignition timing, idle speed, mixture Refer to the “Vehicle emission control information label” inside panel of the engine hood.BK0098300US.book 8 ページ ２００８年１２月８日　月曜日　午前１１時３７分

Specifications
9-9
9 Battery
N01147800049
Battery is a 12 volt type.NOTE
There are various sizes of batteries in BCI Groups No.24
and 86.
When you replace the battery, confirm the size of the
replacement battery will not interfere with other compo-
nents in the engine compartment.
Tires and wheels
N01147900561
PCD: Pitch Circle Diameter (installation holes)NOTE
Contact an authorized Mitsubishi Motors dealer for details
on the combination used on your vehicle.

These tires satisfy vehicle loading conditions described in
this owner’s manual.
2.4 liter
BCI Group No.863.8 liter
BCI Group No.24
Tire P225/50R17 93V P235/45R18 94VWheel
Size 17 x 7 1/2JJ 18 x 8JPCD 4.5 in (114.3 mm)Offset 1.81 in (46 mm)
BK0098300US.book 9 ページ ２００８年１２月８日　月曜日　午前１１時３７分

9-10 Specifications
9Capacities
N01148000804
Item
Capacity
Lubricants
Fuel (approximate) 17.7 gal (67.0 L) Refer to “Fuel selection” on page 1-2.Engine oil
Oil pan 4.2 qt (4.0 L) Engine oils displaying the ILSAC certification mark
(“starbust” symbol) on the container.
If these oils are not available, an API classification SM
can be used.Oil filter .32 qt (0.3 L)
Power steering As required Genuine Mitsubishi Power Steering Fluid Automatic transaxle
2.4 liter 8.1 qt (7.7 L)
DIAMOND ATF SP III 3.8 liter 8.9 qt (8.4 L)
Manual transaxle
5M/T 2.3 qt (2.2 L) DiaQueen NEW MULTI GEAR OIL
API classification GL-3
SAE 75W-806M/T 2.1 qt (2.0 L)
Brake As required Conforming to Brake fluid DOT3 or DOT4 Hood lock release mechanism and safety catch As required Multipurpose type grease NLGI Grade 2 Engine coolant
{Includes .63 qt (0.6 L) in
reserve tank}
2.4 liter
Manual transaxle 9.3 qt (8.8 L)
Long Life Antifreeze Coolant or an equivalentAutomatic transaxle 9.2 qt (8.7 L)
3.8 liter
Manual transaxle 8.6 qt (8.1 L)Automatic transaxle 8.5 qt (8.0 L)
Washer fluid 4.2 qt (4.0 L) — Refrigerant (air conditioning)Refer to the air
conditioning label
on page 9-2.HFC-134a BK0098300US.book 10 ページ ２００８年１２月８日　月曜日　午前１１時３７分
