IGNITION SWITCH
CHASSIS ELECTRICAL54A-24
1. Connect the MUT-III to the diagnosis connector
(16-pin).
2. Turn the ignition switch to "ON" position.
3. Select "System select" from the start-up screen.
4. Choose "IMMOBILIZER" from the "POWER
TRAIN" tab.5. Choose "Special Function" from "IMMOBILIZER"
screen.
6. Choose "Key registration" from "Special Function"
screen.
7. Enter the vehicle’s password (secret code) on the
"Key registration" screen, and then click the check
mark icon. Follow the prompts on the screen to
insert key(s) into the ignition switch to begin key
registration.
AC304950
MB991911
16-PIN
MB991827 MB991824
AB

System selectSpecial function
CAN bus diagnosis
Function Select Menu
Menu
AC209666
Maintenance
AD
MPI/GDI/DIESEL
ELC-A/T/CVT
IMMOBILIZER
SS4II
TCL/STARLTY CONTROLAUTO CRUISE CHASSIS BODY System Select Menu
POWER TRAIN
AC305175
Check Chart For
Problem Sy
Data ListSpecial
Function
Self-diagnosisSimulated Vehicle
Speed Out
Resistor
Voltmeter
POWERTRAINIMMOBILIZERIMMOBILIZER
AC305176
Key ID registrationAdditional Key
Registration
POWERTRAINSpecial FunctionIMMOBILIZERSpecial Function
AC305177
POWERTRAIN IMMOBILIZERSpecial Function
789
456
123
0
BackBackSpaceSpaceClearClear
Key registration
AC207300
AD
POWERTRAIN IMMOBILIZERSpecial Function
IMMOBILIZER-ECU registration
ProgressIn-CompleteKey registration
AC207302
