Multi-information display 5-110 Features and controls
5
1. Press and hold the multi-information meter switch (for about 2 seconds or more) to switch from the setting mode screen to the menu screen.Refer to “Changing the function settings (With ignition switch in the “ON” posi- tion)” on page 5-103.2. Lightly press the multi-information meter switch to select “RESET” (return to the factory settings). 3. Press and hold the multi-information meter switch (for about 5 seconds or more), the buzzer sounds and all of thefunction settings are returned to the fac- tory settings.NOTE
 The factory settings are as follows. • Average fuel consumption and average speed reset mode: A (Auto reset)
• Fuel consumption display unit: mpg (US) or (L/100 km) • Temperature unit: °F (Fahrenheit) or {°C (Celsius)} • Display language: ENGLISH • Cooperative language setting: A • Operation sounds: ON (Operation sound on) • “REST REMINDER” display: OFF• Turn signal sound: Turn signal sound 1 • Momentary fuel consumption with the green bar graph : ONNOTE
BK0200800US.book
110 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list Features and controls 5-111
5
N00557700019 N00557800212
Indicator light, warning light, and information screen display list Indicator and warning light list Type 1 Type 21- Position indicator
 P.5-121
2- High beam indicator
 P.5-121
3- Charging system warning light

P.5-123
4- Turn signal indicator/Hazard warning
light
 P.5-121
5- Front fog light indicator
 P.5-121
6- Anti-lock braking system warning light
 P.5-75, 5-75
7- Tire pressure monitoring system warn-
ing light
 P.5-86
8- Brake warning light
 P.5-122
9- Cruise control indicator
 P.5-82
10- Seat belt reminder/warning light

P.4-9
11- Supplemental Restraint System (SRS)
warning light
 P.4-25
12- Engine malfunction indicator (“SER-
VICE ENGINE SOON” or “Check engine light”)
 P.5-122
13- Active stability control (ASC) indicator
 P.5-78
14- Information screen display list

P.5-112
BK0200800US.book
111 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list
5-112 Features and controls
5
N00557900066
When there is information to be announced,
such as light reminder, the tone sounds an
d the screen switches to the displays show
n below. Refer to
the appropriate page and take the necessary measures.When the cause of the warning display is eliminated, the warning display goes out automatically. Refer to “Warning display list (With ignition switch in the “OFF” position)” on page 5-112. Refer to “Warning display list (With ignition
switch in the “ON” position)” on page 5-115.
Refer to “Other interrupt displays (With ignition switch in the “ON” position)” on page 5-119.
N00558000194
Information screen display list
NOTE
 In the following cases, a warning may be displayed on the inform
ation screen and the buzzer may
sound for a few seconds, at tim
es.
This is caused by the system picking up interference such as stro
ng electromagnetic waves or nois
e, and is not a functional pro
blem.
• An extremely strong electromagnetic wave is received from a source
such as an illegal radio set,
a spark from a wire, or a rad
ar station.
• Abnormal voltage or a static electricity discharge is genera
ted by the operation of your vehicle’s electronics (including afte
r-market parts).
If the warning display has occurred a number of times, take your vehicle to an authorized Mitsubishi Motors dealer or a repair
facility of your choice and
have the system checked.
Warning display list (With ignition switch in the “OFF” position)
Screen
Cause
Do this (Reference)
 You have forgotten to remove the key from the ignition switch.
 Remove the key. Refer to “Key reminder system” on page 5-35.
BK0200800US.book
112 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list Features and controls 5-113
5
 You have forgotten to turn off the lights. Refer to “Light auto-cutout function (head-
lights and other lights)” on page 5-127.
 The theft-alarm system is operating. Refer
to “Theft-alarm system” on page 5-40.
 Immobilizer is registered. Refer to “Customer key programming (Except
for vehicles sold in Canada)” on page 5-6.Refer to “Customer F.A.S.T.-key program- ming (Except for vehicles sold in Canada)” on page 5-27.
 After turning off the engine, an attempt was made to open the driver’s door with the ignition switch in any position other than “LOCK” (PUSH OFF).
 Turn the ignition switch to the “LOCK” (PUSH OFF) position. Refer to “Ignition switch return reminder system” on page 5-35.
 An attempt was made to lock all the doors and the trunk lid with the ignition switch in any position other than “LOCK” (PUSH OFF).
 Turn the ignition switch to the “LOCK” (PUSH OFF) position. Refer to “Ignition switch turn-off reminder system” on page 5-18.
Screen
Cause
Do this (Reference)
BK0200800US.book
113 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list
5-114 Features and controls
5
 There is a fault in the F. A. S. T. -key. Refer to “F. A. S. T. -key” on page 5-11.
Screen
Cause
Do this (Reference)
BK0200800US.book
114 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list Features and controls 5-115
5
N00558100212
Warning display list (With ignition switch in the “ON” position)
Screen
Cause
Do this (Reference)
 There is a fault in the F.A.S.T.-key. Refer to “F.A.S.T.-key” on page 5-11.
BK0200800US.book
115 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list
5-116 Features and controls
5
 Immobilizer is registered. Refer to “Customer key programming (Except
for vehicles sold in Canada)” on page 5-6. Refer to “Customer F.A.S.T.-key program-ming (Except for vehicles sold in Canada)” on page 5-27.
 The brake fluid level is low.  There is a fault in the brake system.
 Park the vehicle in a safe place and inspect it. If the light still illuminates after the inspec- tion, contact an authorized Mitsubishi Motors dealer or a repair facility of your choice for assistance. Refer to “Brake warning display” on page 5-123.
 There is a fault in the Anti-lock braking system.
 Avoid sudden braking and high-speed driv- ing, park the vehicle in a safe place, and take corrective measures. Refer to “Anti- lock braking system warning light /dis-play” on page 5-75.
 The tire pressure in one of the tires (except spare tire) is low.
Refer to “Tire pressure monitoring system warning light /display” on page 5-86.
 There is a fault in the Tire pressure moni- toring system.
Refer to “Tire pressure monitoring system warning light /display” on page 5-86.
Screen
Cause
Do this (Reference)
BK0200800US.book
116 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list Features and controls 5-117
5
 One of the doors or the trunk lid is not completely closed. The open door is displayed.
 Close the door or trunk lid. Refer to “Door ajar warning display screen (With ignition switch in the “ON” posi-tion)” on page 5-103.
 The engine hood is open.
Close the engine hood. Refer to “Engine hood” on page 9-3.
 The engine is overheated.
Park the vehicle in a safe place and take corrective measures.Refer to “Engine overheating” on page 8-4.
 The Twin Clutch SST fluid temperature is increased.
 Park the vehicle in a safe place and take corrective measures. Refer to “Twin Clutch SST” on page 5-58.
 The seat belt is not fastened when the igni- tion switch is in the “ON” position.
 Wear your seat belt properly. Refer to “Driver’s seat belt reminder/warning light and display” on page 4-9.
 There is a fault in the fuel system.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.
Screen
Cause
Do this (Reference)
BK0200800US.book
117 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list
5-118 Features and controls
5
 The vehicle is being driven with the park- ing brake still applied.
 Release the parking brake. Refer to “Brake warning display” on page 5-123.
 There is a fault in the engine oil circulation system.
 Park your vehicle in a safe place as soon as possible and contact an authorized Mit-subishi Motors dealer or
a repair facility of
your choice to have the system checked. Refer to “Oil pressure warning” on page 5-124.
 There is a fault in the charging system.
Park your vehicle in a safe place as soon as possible and contact an authorized Mit- subishi Motors dealer or
a repair facility of
your choice for assistance. Refer to “Charging system warning dis- play” on page 5-123.
 There is a fault in the SRS airbag or the pre-tensioner system.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked. Refer to “SRS warning light/display” on page 4-25.
 There is a fault in the Active stability con- trol (ASC).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked. Refer to “Active stability control (ASC)” on page 5-76.
Screen
Cause
Do this (Reference)
BK0200800US.book
118 ページ ２０１３年２月１４日　木曜日　午後２時２８分

Indicator light, warning light, an
d information screen display list Features and controls 5-119
5
N00558200183
The operation status of each system is displayed on the information screen. For further details, refer to the appropriate page
for each system.
 There is a fault in the S-AWC (Super-All Wheel Control).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.Refer to “S-AWC (Super-All Wheel Con- trol)” on page 5-71.
 A safety device in the Twin Clutch SST has been activated due to a possible malfunc-tion in the Twin Clutch SST or in the engine electronic control module.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked. Refer to “Twin Clutch SST” on page 5-58.
 The fuel is running low.
Refuel as soon as possible. Refer to “Fuel remaining warning display” on page 5-101.
 The outside temperature is 37 °F (3 °C) or less.
 Be careful driving on frozen ground.  The ground may be frozen even when this warning is not displayed, so drive care- fully.
 The timing chain may be worn.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choice to have the system checked.
Other interrupt displays (With igniti
on switch in the “ON” position)
Screen
Cause
Do this (Reference)
BK0200800US.book
