Vehicle weights 11-4 Specifications
11
N01147600643
GVWR: maximum total weight (load) limit specified for the vehicle GAWR: maximum weight (load) limit sp
ecified for the front or rear axle
Seating capacity: the number of maximum occupants
N01147700468
Vehicle weights Gross vehicle weight rating (GVWR) 4,542 lb (2,060 kg)Gross axle weight rating (GAWR)
Front 2,381 lb (1,080 kg)Rear 2,315 lb (1,050 kg)
Vehicle capacity weight 827 lb (375 kg)Seating capacity
5 persons
Engine specifications Engine model 4B11Engine displacement 121.9 CID (1,998 cm³)No. of cylinders and cylinder arrangement 4 in-lineBore
3.39 in (86.0 mm)
Stroke 3.39 in (86.0 mm)Compression ratio 9.0Thermostat valve opening temperature 180 °F (82 °C)Spark plugs
NGK DILKR8B6
Spark plug gap .020 to .023 in (0.5 to 0.6 mm)Firing order 1-3-4-2BK0200800US.bo
