CHASSIS ELECTRICAL – Ignition Switch54-10
Inspection Procedure 5
The key reminder warning buzzer dose not sound even if
the driver’s side door is opened while the key is still
inserted. (However, the ignition key should be in the OFF
position.)
Probable cause
The cause is probably a malfunction of the door switch input circuit system, if the
key hole illumination lamp is also faulty. A malfunction of the key reminder switch
input circuit system is also suspected.
Malfunction of door switch

Malfunction of key reminder switch

Malfunction of connector

Malfunction of harness

Malfunction of ETACS-ECU

Malfunction of buzzer ECU
Driver’s side door switch input circuit
system inspection (Refer to Inspection
Procedure 6 on P.54-10.)
OK

MUT-II Pulse check
Key reminder switch input inspection
OK:The MUT-II buzzer sounds once
when the ignition key is removed
from the key cylinder.NGKey reminder switch continuity inspec-
tion (Refer to P.54-12.)NG
Replace
OK
Inspect the harness between the key
reminder switch and junction block.NG
Repair
OK
Replace the ETACS-ECU.OK

MUT-II Pulse check
Driver’s side door switch input signal
OK:The MUT-II buzzer sounds once
when the driver’s side door switch
is turned to the ON position.NG
OK
Junction block harness continuity checkNG
Repair

OK
Inspect the harness between the key
reminder switch and body earth.
Replace the buzzer ECU.
NOTE
The stop indicated with a dotted line
applies only to vehicles with buzzer
ECU.NG
Repair
Inspection Procedure 6
Driver’s side door switch input circuit system inspection
Door switch inspectionNG
Replace
OK
Disconnect the door switch connector
D-03 and measure at the harness side.

Voltage between the terminal No.
2 and body earth
OK:System voltageNGCheck the following connectors.
B-80, B-79NG
Repair
OK
Check trouble symptom.NGCheck the harness between the ETACS-
ECU or buzzer ECU door switch and
repair if necessary.
OK
Check trouble symptom.
NG
Replace the ETACS-ECU or the buzzer
ecu.OK
Check the following connectors.
D-03

CHASSIS ELECTRICAL – Ignition Switch54-11
IGNITION SWITCH
REMOVAL AND INSTALLATION
123 4 5
67
8 9
10 11
12
9
ETACS-ECU or buzzer ECU removal
steps
1. Cowl side trim (R.H.)
2. Junction block
3. Buzzer control unit ETACS-ECUIgnition switch removal steps
4. Hood lock release handle
5. Driver side lower panel
6. Column cover, lower
7. Column cover, upper
8. Illumination ring or ring cover
9. Key hole illumination lamp bulb
A10. Steering lock cylinder
11. Key reminder switch
12. Ignition switch

CHASSIS ELECTRICAL – Ignition Switch54-12
REMOVAL SERVICE POINT
ASTEERING LOCK CYLINDER REMOVAL
1. Insert the key in the steering lock cylinder and turn it
to the “ACC” position.
2. Using a cross-tip (+) screwdriver (small) or a similar tool,
push the lock pin of the steering lock cylinder inward
and then remove the steering lock cylinder.
INSPECTION
IGNITION SWITCH CONTINUITY CHECK
Disconncect the ignition switch connector without removing
the ignition switch from the vehicle. Then, check the continuity
between the following terminals.
Ignition key Terminal No.Ignition key
position
123456
LOCK
ACC
ON
START
KEY REMINDER SWITCH CONTINUITY CHECK
Disconnect the key reminder switch connector with the switch
installed on the vehicle, and then check continuity.
Ignition keyTerminal No.
12
Removed
Inserted
Cross-tip (+)
screwdriverLock pin

CHASSIS ELECTRICAL – Ignition Switch and Immobilizer System54-19
IGNITION SWITCH AND IMMOBILIZER SYSTEM
Caution: SRS
Before removal of air bag module and clock spring, refer to GROUP 52B – SRS Service Precautions
and Air Bag Module and Clock Spring.
REMOVAL AND INSTALLATION
4
58 6
109 7
2
13


3 4
Immobilizer-ECU removal steps
1. Hood lock release handle
2. Driver‘s side lower cover

Radio and tape player vehicles>

Heater control assembly vehicles>
3. Immobilizer-ECUIgnition switch and ignition key
ring antenna removal steps
1. Hood lock release handle
2. Driver‘s side lower cover
4. Steering wheel
5. Column cover, lower
6. Column cover, upper
7. Column switch
8. Ignition key ring antenna
A9. Steering lock cylinder
10. Ignition switch

CHASSIS ELECTRICAL – Ignition Switch and Immobilizer System54-20
REMOVAL SERVICE POINTS
ASTEERING LOCK CYLINDER REMOVAL
1. Insert the key in the steering lock cylinder and turn it
to the “ACC” position.
2. Using a cross-tip (+) screwdriver (small) or a similar tool,
push the lock pin of the steering lock cylinder inward
and then pull the steering lock cylinder toward you.
INSPECTION
IGNITION SWITCH CONTINUITY CHECK
1. Remove the column cover lower and upper.
2. Disconnect the wiring connector from the ignition switch.
3. Operate the switch, and check the continuity between
the terminals.
Ignition key Terminal No.Ignition key
position
12356
LOCK
ACC
ON
START
IGNITION KEY RING ANTENNA CONTINUITY CHECK
Use a circuit tester to check the continuity between the
terminals.
Cross-tip (+)
screwdriver

CHASSIS ELECTRICAL – Combination Meters54-23
SEALANT
ItemsSpecified sealantRemark
Engine coolant temperature gauge
unit threaded portion3M Adhesive nut locking No. 4171 or
equivalentDrying sealant
SPECIAL TOOLS
ToolNumberNameUse
A
B
C
D
MB991223
A: MB991219
B: MB991220
C: MB991221
D: MB991222Harness set
A: Test harness
B: LED harness
C: LED harness
adapter
D: ProbeFuel gauge simple check
A: Connector pin contact pressure check
B, C: Power circuit check
D: Commercial tester connection

CHASSIS ELECTRICAL – Combination Meters54-30
ENGINE COOLANT TEMPERATURE GAUGE UNIT
CHECK
1. Bleed the engine coolant.
2. Remove the engine coolant temperature gauge unit.
3. Immerse the unit in 70C water to measure the resistance.
Standard value: 104 ±13.5 Ω
4. After checking, apply the specified adhesive around the
thread of engine coolant temperature gauge unit. Then,
tighten the unit to the specified torque.
Specified sealant:
3M Adhesive Nut Locking No. 4171 or equivalent
5. Add engine coolant.
COMBINATION METERS
REMOVAL AND INSTALLATION
2 1
3
Vehicle speed sensor removal
steps

Battery and battery tray

Air cleaner assembly
1. Vehicle speed sensorCombination meter removal steps
2. Meter bezel
3. Combination meter
ThermometerCircuit tester
10 – 12 Nm

CHASSIS ELECTRICAL – Headlamp54-33
TROUBLESHOOTING
DIAGNOSIS FUNCTION
INPUT SIGNAL INSPECTION POINTS
Refer to Group 00 – How to Use Troubleshooting / Inspection Service Points.
The lighting monitor buzzer does not sound even when
the ignition key is removed with the tail lamps or
headlamps ON and the driver’s side door open. [However,
the key reminder warning buzzer sounds when inserting
the key into the ignition key cylinder.
Probable cause
The cause is probably a malfunction of the lighting switch input circuit system or
a malfunction of ETACS-ECU or buzzer ECU. When the key reminder warning buzzer
is sounding, the lighting monitor warning buzzer does not sound even if the tail lamps
or headlamps are lit.
Malfunction of harness or connector

Malfunction of ETACS-ECU

Malfunction of buzzer ECU

MUT-II Pulse check
OK:MUT-II buzzer sounds once
when the lighting switch is
turned from OFF to TAIL or
HEAD.NG
Check the following connectors.
B-79Repair
OK
Check trouble symptom.NGOK
Replace the ETACS-ECU.

NG
Check the harness in the junction block.NG
Replace the ETACS-ECU or the buzzer
ECU.OKRepair NG

CHASSIS ELECTRICAL – HeadlampCHASSIS ELECTRICAL – Headlamp54-36
4. After the bulb is replaced, reinstall the socket cover with
the TOP mark facing upward.
NOTE
To prevent the clouding of lens and ingress of water into
the lamp unit, install the socket cover correctly.
POSITION LAMP BULB REPLACEMENT
Remove the position lamp by turning it together with the lamp
socket, then replace its bulb.
HEADLAMP AND FRONT TURN-SIGNAL LAMP
REMOVAL AND INSTALLATION
CAUTION: SRS
Before removal of air bag module and clock spring, refer to GROUP 52B – SRS Service Precautions and Air
Bag Module and Clock Spring.
5 Nm
2 3
4
5 Nm
1
1. Column switchRemoval steps
A2. Front turn-signal lamp
3. Radiator grille
A4. Headlamp
Position lamp connector

CHASSIS ELECTRICAL – Rear Combination Lamp54-42
REAR COMBINATION LAMP
TROUBLESHOOTING
For the troubleshooting of the lighting monitor warning buzzer, refer to P.54-33.
REAR COMBINATION LAMP
REMOVAL AND INSTALLATION
Caution: SRS
Before removal of air bag module and clock spring, refer to GROUP 52B – SRS Service Precautions and Air Bag
Module and Clock Spring.
2
1
3
1. Column switchRear combination lamp removal
steps
2. Rear end trim
3. Rear combination lamp
INSPECTION
LIGHTING SWITCH CONTINUITY CHECK
Switch positionTerminal No.
Connector BConnector A
5671
LIGHTING
SWITCH
OFF
SWITCHTAIL
HEAD
Connector A Connector B
