CHASSIS ELECTRICAL – Side Turn-signal Lamp54-43
SIDE TURN-SIGNAL LAMP
SPECIAL TOOL
ToolNumberNameUse
MB990784Ornament removerRemoval of side turn-signal lamp
SIDE TURN-SIGNAL LAMP
REMOVAL
INSTALLATION
Fit the hook side rearward.
Fender panelMB990784
LockMB990784
Lock
Fender
panel
Hook

CHASSIS ELECTRICAL – Hazard Warning Lamp Switch, Clock
ILL
ILL
54-44
HAZARD WARNING LAMP SWITCH, CLOCK
SPECIAL TOOL
ToolNumberNameUse
MB990784Ornament removerAir conditioner panel removal
HAZARD WARNING LAMP SWITCH
REMOVAL AND INSTALLATION
2
1 3
4
Hazard warning lamp switch
removal steps
1. Air conditioner panel
2. Switch holder
3. Hazard warning lamp switchClock removal steps
1. Air conditioner panel
4. Clock
INSPECTION
HAZARD WARNING LAMP SWITCH CONTINUITY
CHECK
Switch
iti
Terminal No.
position1245679–10
OFF
ON

CHASSIS ELECTRICAL – Speaker / Antenna54-48

7 6
Rear shelf speaker removal steps
6. Speaker garnish 7. Speaker
ANTENNA
POLE ANTENNA
REMOVAL AND INSTALLATION
1
23
5
47 68 9
Removal steps
1. Pole
2. Radio panel
3. Radio and tape player
4. Hood lock release handle5. Driver side lower cover
6. Clip
7. Cowl side trim
A8. Antenna assembly
9. Antenna base gasket

CHASSIS ELECTRICAL – Antenna / Rear Window Defogger54-50
REMOVAL SERVICE POINT
AANTENNA AMPLIFIER ASSEMBLY REMOVAL
Take off the left-hand edge of the hand lining and undo the
clips of the antenna amplifier assembly.
REAR WINDOW DEFOGGER
TROUBLESHOOTING WITH AUTOMATIC A/C>
Refer to GROUP 55.
ON-VEHICLE SERVICE
PRINTED-HEATER CHECK
1. Run engine at 2,000 r/min. Check heater element with
battery at full.
2. Turn ON rear window defogger switch. Measure heater
element voltage with circuit tester at rear window glass
centre A.
Condition is good if it indicates about 6V.
3. If 12 V is indicated at A, there is a break in the negative
terminals from A.
Move test bar slowly to negative terminal to detect where
voltage changes suddenly (0V).
4. If 0 V is indicated at A, there is a break in the positive
terminals from A. Defect where the voltage changes
suddenly (12 V) in the same method described above.
DEFOGGER RELAY CONTINUITY CHECK
Battery voltageTerminal No.Battery voltage1325
Power is not supplied
Power is supplied
Normal characteristic curve
Voltage
A (Centre point)
approx. 6 V
Positive
terminal
Printed heater lineNegative
terminal
Abnormal characteristic curve
Voltage
Open-circuit
point
Positive
terminal
Printed heater lineNegative
terminal
Junction block
Defogger relay
