CHASSIS ELECTRICAL – Combination Meters54-29
FUEL GAUGE UNIT FLOAT HEIGHT
Move float and measure the height at point F (A) and at
point E (B) with float arm touching stopper.
Standard value:
Float positionMainSub
Point F16.417.5
Point E122.6134.6
FUEL LEVEL SENSOR (THERMISTOR)
1. Connect a test lamp (12V – 3.4W) to the fuel gauge
unit connector terminal and apply the battery voltage.
2. Condition is good if lamp goes off when the thermistor
is immersed in water and goes on when it is taken out
of water.
ENGINE COOLANT TEMPERATURE GAUGE SIMPLE CHECK
Remove the engine coolant tempara-
ture gauge unit connector.
Connect a test lamp (12 V – 3.4 W)
between the harness side connector
and the earth.
When the ignition switch is turned to
ON, the test lamp illuminates.OKThe needle of the engine coolant tem-
perature gauge moves.NGReplace the engine coolant tempera-
ture gauge.
OK
Replace the engine coolant tempera-
ture gauge unit.
NG
Repair the harness.
Point F
Point E
A
B Stopper
Stopper
Test lamp
(12V – 3.4 W)
Earth
Thermistor
Thermistor
Lamp goes on
Lamp goes off

CHASSIS ELECTRICAL – Combination Meters54-30
ENGINE COOLANT TEMPERATURE GAUGE UNIT
CHECK
1. Bleed the engine coolant.
2. Remove the engine coolant temperature gauge unit.
3. Immerse the unit in 70C water to measure the resistance.
Standard value: 104 ±13.5 Ω
4. After checking, apply the specified adhesive around the
thread of engine coolant temperature gauge unit. Then,
tighten the unit to the specified torque.
Specified sealant:
3M Adhesive Nut Locking No. 4171 or equivalent
5. Add engine coolant.
COMBINATION METERS
REMOVAL AND INSTALLATION
2 1
3
Vehicle speed sensor removal
steps

Battery and battery tray

Air cleaner assembly
1. Vehicle speed sensorCombination meter removal steps
2. Meter bezel
3. Combination meter
ThermometerCircuit tester
10 – 12 Nm

CHASSIS ELECTRICAL – Combination MetersCHASSIS ELECTRICAL – Combination MetersCHASSIS ELECTRICAL – Combination Meters54-31
INSPECTION
FUEL GAUGE RESISTANCE CHECK
1. Remove the power supply tightening screw.
2. Use a circuit tester to measure the resistance value
between the terminals.
Standard value: Unit: Ω
Measurement terminalResistance value
Power supply – Earth192±19.2
Power supply – Fuel gauge89±8.9
Fuel gauge – Earth103±10.3
Caution
When inserting the testing probe into the power supply
terminal, be careful not to touch the printed board.
ENGINE COOLANT TEMPERATURE GAUGE
RESISTANCE CHECK
1. Remove the power supply tightening screw.
2. Use a circuit tester to measure the resistance value
between the terminals.
Standard value: Unit: Ω
Measurement terminalResistance value
Power supply – Earth187±18.7
Power supply – Engine coolant
temperature gauge90±4.5
Engine coolant temperature
gauge – Earth247±24.7
Caution
When inserting the testing probe into the power supply
terminal, be careful not to touch the printed board.
VEHICLE SPEED SENSOR CHECK
1. Connect a 3 – 10 kΩ resistance as shown in the illustration.
2. Turn the shaft of the vehicle speed sensor one turn and
check that voltage changes are caused when measured
between terminals 2 and 3 using a circuit tester. (1 turn
= 4 pulses)
Fuel gauge
Power
supply
Earth
Earth
Power
supply
Engine
coolant
temperature
gauge
TurnShaft
Circuit testerResistance
3 – 10 kΩ Vehicle
speed
sensor Terminal No.
16R0273
Battery

CHASSIS ELECTRICAL – Headlamp54-35
Standard values:
Vertical direction25’ (22 mm) below hori-
zontal line (H)
Horizontal
directionLeft headlampParallel to direction of
vehicle travel
Right head-
lamp15’ (13 mm) leftward
from vertical line (V)
Caution:
(1) Perform aiming adjustments, one light at a time,
with the other headlamp disconnected so as not
to be lit unless circumstances compel otherwise.
When reconnecting the headlamps, be careful not
to upset their aim. Do not leave the headlamps
on for any longer than 3 minutes if their outer
lenses are covered with a surface covering
impervious to light.
(2) Do not mask the outer lenses by taping or in any
other way.
(3) Aiming adjustment must be completed with the
aiming adjustment screws turned in the tightening
direction.
INTENSITY MEASUREMENT
1. Position the tester so that its light sensor faces each
headlamp center to center at the appropriate distance
shown.
2. Maintain an engine speed of 2,000 r/minto keep the battery
in the charged condition.
3. Check that the high-beam headlamp intensity at the center
of the high intensity zone satisfies the limit value.
Limit: 15,000 cd or more per headlamp
Caution
(1) Perform intensity measurement, one headlamp at
a time, with the low-beam lamp and the other
headlamp disconnected from the battery unless
circumstances compel otherwise. Do not leave
the headlamps on for any longer than 3 minutes
if their outer lenses are covered with a surface
covering impervious to light.
(2) Do not mask the outer lens surfaces by taping
or in any other way.
HEADLAMP BULB REPLACEMENT
1. Disconnect the connector.
2. Remove the socket cover.
3. Unhook the spring which secures the bulb, and then
remove the bulb.
Caution
Do not touch the surface of the bulb with hands or
dirty gloves. If the surface does become dirty, clean
it with alcohol or thinner, and let it dry thoroughly
before installing.

Lamp center
Vertical direction
Vertical direction High
intensity
zone
center
(optical
axis)
High
intensity
zone
center
(optical
axis)High intensity zone
High intensity zoneLamp center V
H
V
H
Screen type tester: 3 m Converging
lens type tester: 1 m
Spring

55-2
FULL-AUTOMATIC AIR
CONDITIONER 33. . . . . . . . . . . . . . . . . . . . .
GENERAL 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outline of Change 33. . . . . . . . . . . . . . . . . . . . . . . .
SERVICE SPECIFICATIONS 33. . . . . . . . . . . .
LUBRICANTS 33. . . . . . . . . . . . . . . . . . . . . . . . .
SPECIAL TOOLS 33. . . . . . . . . . . . . . . . . . . . . .
TROUBLESHOOTING 34. . . . . . . . . . . . . . . . . .
ON-VEHICLE SERVICE 56. . . . . . . . . . . . . . . .
Refrigerant Charging, Level Check, Addition
and Removal, Performance Test, Dual
Pressure Switch Simple Check 56. . . . . . . . . . . .
Power Relay Check 57. . . . . . . . . . . . . . . . . . . . . .
Idle-up Operation Check 57. . . . . . . . . . . . . . . . . .
DAMPER CONTROL MOTOR ASSEMBLY
AND POWER TRANSISTOR 58. . . . . . . . . . . .
PHOTO SENSOR 61. . . . . . . . . . . . . . . . . . . . . .
OUTSIDE AIR TEMPERATURE
SENSOR 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HEATER WATER TEMPERATURE
SENSOR 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OTHER MAINTENANCE SERVICE
POINTS 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HEATER AND MANUAL AIR CONDITIONER – Troubleshooting55-4
TROUBLESHOOTING
TROUBLESHOOTING PROCEDURES
1. Check air ducts, control rods, etc. for improper connection.
2. Check that the electrical connectors of the relevant components are connected securely and the
fuse is not blown.
3. Perform the troubleshooting as follows; first understand the items to be inspected and the the procedures
comprehensively using Trouble Symptom/Failed Component Cross-Reference Table and then inspect
the appropriate items sequentially.
4. Be sure to perform each component check after disconnecting the relevant connector.
Trouble Symptom/Failed Component Cross-Reference Table
Items to be checked1.
When the igni-
tion switch is
“ON”, the A/C
does not oper-
ate.2.
When the A/C
is operating,
temperature
inside the pas-
senger
compartment
does not
decrease (cool
air is not
emitted).3.
Blower fan
motor does not
turn.4.
Blower fan
motor does not
stop turning.5.
When A/C is
operating,
radiator fan
and condenser
fan do not run.
Fuse111
Harness, connector2212
Amount of refrigerant31
A/C compressor relay4
A/C compressor magnet
clutch5
Dual pressure switch623
A/C switch7
Blower switch832
Blower relay4
Resistor53
Blower motor6
Air thermo-sensor93
Condenser fan relay44
Condenser fan motor55
Radiator fan relay (HI, LO)66
Radiator fan motor77
Refrigerant temperature
switch108
Auto compressor control
unit119
Engine-ECU12108

HEATER AND MANUAL AIR CONDITIONER – Troubleshooting55-5
No.Trouble symp-
tomProblem causeRemedyRefer-
ence
page
1When the igni-
tion switch is
“ON”, the A/C
does not oper
Refrigerant leak or overfilling of refriger-
antReplenish the refrigerant, repair the
leak or take out some of the
refrigerant55-6
does not oper-
ate.A/C compressor relay is defectiveReplace the A/C compressor relay55-14ate.
A/C compressor magnetic clutch is
defectiveReplace the A/C compressor magnet
clutch55-26
Dual pressure switch is defectiveReplace the dual pressure switch55-13
A/C switch is defectiveReplace the A/C switch55-17
Blower switch is defectiveReplace the blower switch55-17
Air thermo-sensor is defectiveReplace the air thermo-sensor55-22
Refrigerant temperature switch is defec-
tiveReplace the refrigerant temperature
switch55-25
Automatic compressor-ECU is defectiveReplace the automatic compressor-
ECU–
2When the A/C is
operating, tem-
perat re inside
Refrigerant leakReplenish the refrigerant and repair
the leak55-6
perature inside
the
passengerDual pressure switch is defectiveReplace the dual pressure switch55-13the passenger
compartment
doesn’tde-Air thermo-sensor is defectiveReplace the air thermo-sensor–doesnt de-
crease (cool air
is not emitted)
Condenser fan relay is defectiveReplace the condenser fan relay55-14
is not emitted).Condenser fan motor is defectiveReplace the condenser fan motor55-29
Radiator fan relay (HI, LO) is defectiveReplace the radiator fan relay (HI, LO)55-14
Radiator fan motor is defectiveReplace the radiator fan motor–
Refrigerant temperature switch is defec-
tiveReplace the refrigerant temperature
switch55-25
Automatic compressor-ECU is defectiveReplace the automatic compressor-
ECU–
3Blower fan mo-
tor doesn’t turn
Blower switch is defectiveReplace the blower switch55-17
tor doesn’t turn.Blower relay is defectiveReplace the blower relay55-13
Resistor is defectiveReplace the resistor55-21
Blower fan motor is defectiveReplace the blower fan motor55-21
4Blower fan mo-
tor doesn’t stop
t rning
Defective harness between the blower
fan motor and the blower switchRepair the harness–
turning.Blower switch is defectiveReplace the blower switch55-17
Resistor is defectiveReplace the resistor55-21
5When the A/C is
operating con
Condenser fan relay is defectiveReplace the condenser fan relay55-14
operating con-
denser fan orCondenser fan motor is defectiveReplace the condenser fan motor55-29denser an or
radiator fan
does not runRadiator fan relay (HI, LO) is defectiveReplace the radiator fan relay (HI, LO)55-14does not run.
Radiator fan motor is defectiveReplace the radiator fan motor–
Dual pressure switch is defectiveReplace the dual pressure switch55-13
Engine-ECU is defectiveReplace the engine-ECU–

– Blower Motor Assembly, Resistor and Evaporator HEATER AND MANUAL
AIR CONDITIONER55-21
BCASE COVER, EVAPORATOR REMOVAL
The evaporator, which has been installed in a factory, has
no case cover. Follow the steps below to remove that
evaporator.
1. Cut the case along the shown line to remove the cooling
and blower unit.
2. Remove the air thermo sensor from the evaporator, and
then remove the evaporator towards you, being careful
not to damage its core.
INSPECTION
BLOWER MOTOR CHECK
When battery voltage is applied between the terminals, check
that the motor operates. Also, check that there is no abnormal
noise.
RESISTOR CHECK
Use a circuit tester to measure the resistance between the
terminals as indicated below. Check that the measured value
is at the standard value.
Standard value:
Measurement terminalStandard value Ω
Between terminals 3 and 22.81 ± 10%
Between terminals 3 and 41.28 ± 10%
Between terminals 3 and 10.33 ± 10%
Cut line
Evaporator

– Blower Motor Assembly, Resistor and Evaporator HEATER AND MANUAL
AIR CONDITIONER55-22
AIR THERMO-SENSOR CHECK
Measure the resistance between the sensor terminals in two
or more different temperature conditions. The resistance
values must conform to the values shown in the graph.
NOTE
The temperatures at checking must be within the range shown
in the characteristic curve.kΩ
Temperature
Resistance
°C 0
–10 0 10 20 30 40 5 10 15 20

FULL-AUTOMATIC AIR CONDITIONER – Troubleshooting55-34
TROUBLESHOOTING
STANDARD FLOW OF DIAGNOSTIC TROUBLESHOOTING
Refer to GROUP 00 – How to Use Troubleshooting/Inspection Service Points.
DIAGNOSIS FUNCTION
DIAGNOSIS CODES CHECK
Connect the MUT-II or a voltmeter to the diagnosis connector (16-pin), then check diagnosis codes.
(Refer to GROUP 00 – How to Use Troubleshooting/Inspection Service Points.)
ERASING DIAGNOSIS CODES
Refer to GROUP 00 – How to Use Troubleshooting/Inspection Service Points.
INSPECTION CHART FOR DIAGNOSIS CODES
Code No.Diagnosis itemReference
page
11Inside air temperature sensor system (open circuit)55-34
12Inside air temperature sensor system (short circuit)55-34
13Outside air temperature sensor system (open circuit)55-35
14Outside air temperature sensor system (short circuit)55-35
15Heater water temperature sensor system (open circuit)55-36
16Heater water temperature sensor system (short circuit)55-36
21Air thermo sensor system (open circuit)55-37
22Air thermo sensor system (short circuit)55-37
31Potentiometer system of air mix damper assembly55-38
32Potentiometer system of air outlet changeover damper assembly55-39
41Drive system of air mix damper motor assembly55-40
42Drive system of air outlet changeover damper motor assembly55-40
INSPECTION PROCEDURES FOR DIAGNOSIS CODES
Code No.11 Inside air temperature sensor system (open
circuit)Probable cause
This diagnosis code is output if the power supply line or input line of the inside
air temperature sensor inside A/C-ECU is open-circuited and no signal is input
from the inside air temperature sensor to A/C-ECU.
Malfunction of the A/C-ECU
Replace the A/C-ECU.
Code No.12 Inside air temperature sensor system (short
circuit)Probable cause
This diagnosis code is output if the power supply line or input line of the inside
air temperature sensor inside A/C-ECU is short-circuited and inside air
temperature sensor power supply voltage signals are input to A/C-ECU.
Malfunction of the A/C-ECU
Replace the A/C-ECU.
